- Page 1 F1000 1000W LED Follow Spot Light User Manual Please read manual carefully before use...
-
Page 2: Table Of Contents
CONTENTS 1.Safety Instructions ................... 3 2. Technical Specification ................... 5 3. DMX Set Up ....................6 4. Display ......................7 5. LUX Data ......................8 6. DMX Channel List ................... 8 7.Product Size .....................9 8. Attention ......................10 9. Trouble Shooting ...................10 A. -
Page 3: Safety Instructions
1.Safety Instructions Please read this manual carefully, which includes important information on installation,use and maintenance. Attention Please keep this USER MANUAL for future consultation. If you sell the facility to another user, be sure that they also receive this USER MANUAL. - Page 4 for technical support. Do not touch any wire during operation as high voltage might be causing electric shock. When the housing or lens is damaged, it must be replaced. Direct sunlight or any other strong light source penetrating the lens of the ...
-
Page 5: Technical Specification
2. Technical Specification Light Source LED 1000W lamp beads use imported chips ≥25,000 hours, 10 meters distance, beam up to 42,000 Lamp life lumens Power Voltage AC220-240V ，50-60Hz Power Consumption 1000W Color Temperature 3200K/4500/9000 White light + five colors (red, orange, yellow, green, Color blue, and white) Beam Angle 6°-8°... -
Page 6: Dmx Set Up
3. DMX Set Up Pin1: Ground pin2: Negative pin3: Positive DMX Connection To ensure optimal transmission of DMX data, please connect facilities in the shortest way. The connection order won't affect the DMX address code. For example, if the address code is set to 1, no matter where the facility is connected, its address code will not change. -
Page 7: Display
4. Display 1. The follow spot light will automatically reset after power on; 2. The color buttons correspond to the colors on the color wheel and are used to select colors; 3. The black button controls the opening and closing of the light; 4. -
Page 8: Lux Data
5. LUX Data 6. DMX Channel List When there is a DMX signal input, the lighting control takes DMX signal as priority; The OLED display can adjust the DMX start address; ▶ DMX Mode Function DMX Value Description Pattern 0-255 Change the pattern every 5 values Aperture 0-255... -
Page 9: Product Size
Function DMX Value Description 100-149 Color 3 150-199 Color 4 200-255 Color 5 7.Product Size... -
Page 10: Attention
6. Attention 1. When the facility is powered on, please avoid looking directly at the facility. 2. When assembling/ replacing LED, be sure to cut off the main power of facilities before opening the cover upon the LED board. 7. Trouble Shooting Following are a few common problems that may occur during operation. -
Page 11: One Of The Channels Is Not Working Well
C. One of the channels is not working well 1. The stepper motor might be damaged or the cable connected to the PCB is broken. 2. The motor’s drive IC on the PCB might be out of condition. 8. Fixture Cleaning The lens and diffuser should be clean frequently to get better light effect. -
Page 12: Product Warranty Card
Product Warranty Card Product: 1000W LED Follow Spot Light Model NO.: F1000 Manufacture Date: User: Purchase Date: Manufacturer: Sales Store: Address: ATTN.: ATTN.: Phone: Phone: Note: The above blank must be filled in and sealed by the end user or sales point, otherwise no warranty will be provided.
