- Page 1 Pro Strength Booty Shaper (PL-PS-BS) Installation Manual 1/10...
- Page 2 Table of Contents 01/ Safety Instructions 02/ Installation Steps Diagram and Checklist 03/ Product Description 04/ Product Specifications 05/ Maintenance Guide 2/10...
- Page 3 01/ Safety Instructions: Thank you for choosing our company's product. Correct use of the trainer ensures your safety and convenience. Before using the trainer, please read the following carefully: 1. Before using this product, carefully read all the instructions and strictly follow the methods described in the manual.
- Page 4 02/Installation Steps Parts Checklist 1. Installation step one Name Specs Qty. Ground Fixing Completed Image Main Frame Curved Connection Plate 200*52.5*T6 Drum Pad Φ12 Hexagon Lock Nut Socket Cap Screw M12*125 4/10...
- Page 5 2. Installation Step Two Parts Checklist Completed Image Name Specs Qty. Foot Swing Arm Socket Head Cap Screw M12*25 Spring Washer ￠12 End Cap Φ43.5*14.5 Shaft Φ25*143 5/10...
- Page 6 3. Installation Step Three Parts Checklist Name Specs Qty. Completed Image Drum Pad Φ12 Hex Lock Nut Socket Head Cap Screw M12*75 Outer Guard Plate 215*85.3*T6 Support Sleeve Ø18*38 Foot Pedal 6/10...
- Page 7 4. Installation Step Four Parts Checklist Specs Name Qty. Completed Image Hex Lock Nut Socket Head Cap Screw M12*25 Spring Washer ￠12 End Cap Φ43.5*14.5 Rotating Shaft Ø25*86 Rotating Axis Φ17*105 Hex Nut Flat Washer ￠12 Socket Head Cap Screw M12*45 Knob Handle Φ60*35...
- Page 8 Parts Checklist 5. Installation Step Five Specs Name Qty. Completed Image Hex Lock Nut Socket Head Cap Screw M12*25 Flat Washer ￠12 End Cap Φ43.5*14.5 Rotating Shaft Ø25*86 Rotating Axis Φ17*105 Armrest Swivel Fixing 8/10...
- Page 9 6. Installation Sept Six Parts Checklist Completed Image Name Specs Qty. Seat Cushion 489*410*60 Armrest Pad 280*133*60 Socket Head Cap Screw M8*25 SpringWasher ￠8 Flat Washer ￠8 Note: Installation complete, tighten all bolts in each part, and use screw caps for all drum pad positions.
- Page 10 ·We use large-diameter steel pipes for manufacturing and electrostatic spray coating for durability, ensuring the safety, reliability, and longevity of the machine. 03/Product Description: PL-PS-BS Name Pro Strength Booty Shaper SKU 80" x 60" x 57" Dimension 564 lb Net Weight 05/ Maintenance Guide 1.
