EV7/7+

Instruction Manual

Table of Contents

Need help?

Do you have a question about the EV7 and is the answer not in the manual?

Questions and answers

Summary of Contents for techtron EV7

Page 1 EV7/7+ Instruction Manual...
Page 2 Ethos Welcome to techtron®. By combining passion, drive and intellect with market leading research and cutting-edge technology, we innovate and deliver premium quality products that excite, inspire and challenge the sector. Striving for perfection, embracing new ideas and investing in the future is our ethos.
Page 3: Table Of Contents
Contents Product and Accessories Product Overview Installation Instructions Wiring Method and Solution Diagram Instructions For Use techtron® Smart App Technical Data Troubleshooting Warranty IMPORTANT! Read carefully and keep for future reference.
Page 4: Product And Accessories
EV7/7+ 7.6 kW (Level 2) ev-charger For all Type 2 Vehicles Worldwide Compatibility Smart Connectivity WiFi & Bluetooth (+4G on EV7+) Compact & Space Saving Efficient Design Weatherproof & Durable For all Conditions 5 Metre Long Cable For Extra Flexibility...
Page 5 Product and Accessories Charging Gun x 1pc Gun Holder x 1pc Keys x 2pc Wall Mount Screws x 12pc Plastic Expansion Template x1pc Tube x 12pc...
Page 6: Product Overview
Product Overview...
Page 7 Product Overview RFID Card Swiping Area Power Cable AC Input Display Screen Charging Cable Emergency Stop Button Keyhole Position Charging Gun Product Overview This product is a 7.6kW single phase AC charging pile, which is composed of a charging pile body, and wall hanging backplate.
Page 8: Installation Instructions
Installation Instructions Tips For additional safety, we recommend the installation by qualified personnel of a leakage protection air switch (rated current 40A) and with matching voltage to local demands. It is recommended to drill holes in the wall at a height of 1.2-1.5M, ensure unit is level, mark the hole positions with a marker according to the size diagram of the back plate provided, drill holes with an impact drill with a diameter of 6 mm and a hole depth of 55 mm, and use a hammer to knock the expansion tubes into the wall.
Page 9 Installation Instructions Open Charging Post Panel Unlock the charging post panel with the key to access the interior. Align Charging Post Position the charging post so that its screw holes align with those on the wall.
Page 10 Installation Instructions Close and Lock Post Panel Close and lock the charging post panel using the key. Secure Anti-Theft Screw Lock the anti-theft screw at the bottom. Place the gun mount in a suitable location. Remove Protective Film Carefully remove any protective film from the equipment.
Page 11: Wiring Method And Solution Diagram
Wiring Method and Solution Diagram Wiring Method If the connection to the distribution box is used, connect the L, N, and PE terminals of the input wire connector of the plug to the L, N, and PE terminals of the air switch, respectively.
Page 12: Instructions For Use
Instructions for Use How to Start Charging • Connect the Charger: Plug the charging connector into your vehicle's charging port. Ensure it is securely connected. • Authenticate (If Required): Swipe your access card or authenticate through the App, depending on your charger’s setup.
Page 13: Techtron® Smart App
Smart App The techtron EV7 / 7+ EV Charger App delivers a highly functional and ® user-friendly interface for managing EV charging sessions. It combines essential real-time monitoring with advanced scheduling and tracking features, ensuring a seamless charging experience tailored to user preferences and needs.
Page 14 Smart App Charging Record Setting Charging Record Power Current (A) Alarm Close 12:00-23:59, Every Day 20:18:40 Current Temp 40°C 18:22:33 Schedule Charging System Version Device Details Scan to get Download to your smart device via techtron® the Apple App Store or Google Play.
Page 15 Smart App Startup Screen Home Screen Charge Button: A large, easily accessible button labeled "Charge" allows users to start or stop the charging session with a single tap. Schedule Charging: Allows you to set a fixed start hour and/or end time hour for charging.
Page 16: Technical Data
Technical Data EV7 ev-Charger Areas of Application Ideal for convenient and efficient home / residential EV charging, seamlessly integrating into daily routines while providing reliable performance for personal electric vehicles. Product Benefits And Features • Smart Charging with Customised App: Integrated with a smart charging App featuring a user-friendly interface tailored to meet customer preferences for a seamless charging experience.
Page 17 Wi-Fi 3G / 4G Support Voice Control Function Waterproof • Outdoor Control Box: IP54 • Gun Head: IP67 Smart App techtron® Smart App General Characteristics Material Plastic PC940 / Galvanized Steel Power Input Cable 0.7M (UK Plug) Cable Length Cable Material...
Page 18 Technical Data EV7 ev-Charger User Interface HMI Display 4.3" LCD Screen Touch Screen Voice Control Electric Meter Not included (Home / Residential charger) User Authentication RFID and Key Fobs Certification and Standards Safety And EN IEC 61851-1:2017, BS EN IEC 61851-21-2: 2018,...
Page 19 Technical Data EV7+ ev-Charger Areas of Application Ideal for convenient and efficient home / residential EV charging, seamlessly integrating into daily routines while providing reliable performance for personal electric vehicles. Product Benefits And Features • Smart Charging with Customised App: Integrated with a smart charging App featuring a user-friendly interface tailored to meet customer preferences for a seamless charging experience.
Page 20 Technical Data EV7+ ev-Charger Technical Data Protections • Voltage and Current Limiting: Prevents overloads and ensures optimal performance. • Emergency Braking: For immediate stopping in critical situations. • Overvoltage Protection: Safeguards against voltage surges. • Undervoltage Protection: Protects against low voltage conditions.
Page 21 Technical Data User Interface HMI Display 4.3" LCD Screen Touch Screen Voice Control Electric Meter Not included (Home / Residential charger) User Authentication RFID and Key Fobs Certification and Standards Safety And EN IEC 61851-1:2017, BS EN IEC 61851-21-2: 2018, Compliance EN IEC 61000-6-1:2019, EN IEC 61000-6-3:2021, Standard...
Page 22: Troubleshooting
Troubleshooting Error Codes And What They Mean Faults with techtron® ev-Chargers rarely happen, but if you’re unfortunate enough to encounter a problem, just cross reference the error code shown on the ev- Charger’s display panel with the ones listed in the table opposite.
Page 23 Troubleshooting Fault Analysis Of Processing Method Causes AC Overvoltage AC Input Voltage • If the voltage exceeds 265VAC for a short period of time, Too High wait for the power grid to restore itself to within the normal voltage range. •...
Page 24: Warranty
(including negligence) or other legal or equitable theory, even if techtron® knew or should have known of the possibility of such damages. In no event will techtron®'s cumulative liability for all claims relating to the Electric Vehicle Supply Equipment exceed the price you paid for the Electric Vehicle Supply Equipment.
Page 25 Product Registration For exclusive offers, product support and information on the latest techtron® innovations, register your product by completing the form on the website Simply scan the QR Code and dive with your serial number and details: into our comprehensive, step-by-step https://techtron.co/pages/warranty...
Page 26 Notes Notes:...
Page 27 Notes Notes:...
Page 28 For further information and advice you can find us at: e: info@techtron.co w: techtron.co UK: techtron® Future Tech Ltd. EU: Multibrands® techtron® Ltd, Dublin Ireland. techtron® is a Registered Trademark. V03 03.2025...
