Sony DAV-DX170 Service Manual

DAV-DX170/DX250
SERVICE MANUAL
Ver. 1.0 2005.03
• DAV-DX170, 250 are composed of following models.
As service manuals are issued for each component model, please refer to them.
COMPONENT MODEL NAME
COMPACT DISCDECK RECEIVER
PACKAGE SPEAKER
FRONT SPEAKER
SURROUND SPEAKER
CENTER SPEAKER
SUB SPEAKER
Sony Corporation
9-879-558-01
Audio Group
2005C16-1
Published by Sony Engineering Corporation
© 2005.03
DAV-DX170 DAV-DX250
HCD-DX170 HCD-DX250
SS-DS15 SS-DS14
SS-TS31 SS-TS41
SS-TS31B
SS-CT31
SS-WS32
PARTS LIST
Part No. Description
ACCESSORIES
************
1-479-223-11 COMMANDER, STANDARD (RM-ADU001)
(INCLUDING BATTERY COVER)
1-754-059-12 ANTENNA, LOOP (AM)
1-754-147-41 ANTENNA (FM)
1-769-108-11 CORD, CONNECTION (VIDEO)
1-830-063-11 CORD (WITH CONNECTOR)(SPEAKER)
2-590-791-11 MANUAL, INSTRUCTION (ENGLISH)
2-590-791-21 MANUAL, INSTRUCTION (FRENCH)(CND)
2-595-062-01 FOOT PAD (DX250)
4-243-457-01 RUBBER (SPEAKER)(DX170)
Canadian Model
Remarks
DVD HOME THEATRE SYSTEM
US Model
