OPERATING & MAINTENANCE MANUAL
WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT
PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF
YOUR WASCOMAT MACHINE.
PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S)
DATA PLATE(S).
MACHINE TYPE OR MODEL
MACHINE SERIAL NUMBER(S)
ELECTRICAL CHARACTERISTICS: ________ VOLTS, _______ PHASE, _______ HZ.
MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE
REFERENCE.
WASCOMAT W 245 a
438 9030-14/01
99.32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W 245 a and is the answer not in the manual?

Questions and answers

Related Manuals for Wascomat W 245 a

Summary of Contents for Wascomat W 245 a

  • Page 1 OPERATING & MAINTENANCE MANUAL WASCOMAT W 245 a 438 9030-14/01 99.32 WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR WASCOMAT MACHINE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
  • Page 2 Be sure to keep the machine(s) in proper working order: Follow all maintenance and safety procedures. Further information regarding machine safety, service and parts can be obtained from your dealer or from Wascomat through its Teletech Service Telephone - 516/ 371-0700.
  • Page 3 To remove the top panel on models on which it is secured by one or two keylocks, use the keys originally shipped in the drum package. Be certain to relock after remounting the top panel. MANUFACTURED BY WASCATOR DISTRIBUTED BY WASCOMAT INWOOD, NEW YORK, USA 471 7662-02 LOCATED ON WARNING !

  • Page 5: Table Of Contents

    Wascomat Super Giant W 245 a Contents Introduction ....................7 Technical data ....................8 Installation ....................10 Safety rules ....................17 Mechanical and electrical design ............... 18 Procedure ....................34 Wash programs ..................35 Maintenance ....................40 Trouble shooting ..................41 The manufacturer reservs the right to make changes to design and material specifications.

  • Page 7: Introduction

    Introduction Introduction The Wascomat Super Giant washer extractor has been developed to cover Fig. the heavy duty and various size requirements of coin laundries, apartment houses, hotels, motels, nursing homes, hospitals, professional laundries, restaurants, schools, colleges and all on-premises laundries where high quality automatic washing and quick formula variation are required.

  • Page 8: Technical Data

    Technical data Technical data Wascomat W 245 a Dry load capacity up to 75 lbs Dimensions Width 933 mm 36 7/8 in Depth (at the base) 985 mm 38 9/16 in Height 1430 mm 55 in Net weight 380 kg...
  • Page 9 Technical data Outline and dimensions 4897 W 245 a 1. Cold water inlet 2. Hot water inlet 3. Hot water inlet 4. Control panel C 1430 5. Soap box 6. Drain outlet 7. Steam connection (optical) 8. Electrical connection 9. Liquid supply connection...

  • Page 10: Installation

    - bolts are to extend 1 1/2" above concrete. NOTE: A prefabricated steel frame, designed to be placed in the concrete instead of the individual mounting bolts, is available. W 245 a inches 22 5/8 38 3/8 1040...
  • Page 11 Installation Mechanical installation • Place wide steel shims on the concrete foun- Fig. dation over the bolts. • Lift the machine and lower it in position. Never use the door or the door handle to lift or lower the machine. •...
  • Page 12 Installation Electrical Installation All electrical installations are to be carried out by licensed personal. Although the machines are fitted with a thermal Fig. overload in the motor windings, a separate three- phase common-trip circuit breaker must be installed for all three-phase machines. For proper circuit breaker protection, check the 5001 data plate at the rear of the machine.
  • Page 13 Installation The machine is equipped with a control circuit transformer, mounted on the control unit and connected for 220 volt operation. If your incoming voltage is below 210 volts move the wire connection to the 208 volt tab on the transformer. If it is above 230 volts move the wire to the 240 volt tab on the transformer.
  • Page 14 Installation Drain connection Connect a 3" (75 mm) flexible hose to the drain Fig. outlet of the machine. The drain hose must not have any sharp bends and must slope from the machine to assure proper drainage. The outlet must open freely to the main drains.
  • Page 15 IMPORTANT: 3562 Door safety interlock must be checked daily in accordance with above procedure. WARNING: Before servicing Wascomat equipment, disconnect electrical power. IMPORTANT: Le verrouillage de sûreté de la porte doit être vérifié tous les jours selon la procédure ci-dessus.
  • Page 16 The warranty card should be completed and sent to Wascomat. All other items should be placed in a safe place for future reference. The machine should be cleaned when the instal-...

  • Page 17: Safety Rules

    Safety rules Safety rules • This machine is designed for water washing only. • All installation operations are to be carried out by qualified personnel. Licensed personnel are necessary for all electric power wiring. • The interlock of the door must be checked daily for proper operation and must not be bypassed.

  • Page 18: Mechanical And Electrical Design

    Mechanical and electrical design General The door, cycle indicator, coin meter or manual start switches, indicator light and program-selection knob are located at the front of the machine. All control and indicating components, i.e. relays, level control, cycle timer, etc are assembled under the top cover, easily accessible from the top of the machine for simplified servicing.

  • Page 19: Machine Construction

    Mechanical and electrical design Machine construction Outer shell The outer shell is made of heavy gauge surgical steel and is attached to a heavy Fig. duty, rigid head casting (back gable). The whole assembly is mounted on a heavy gauge fabricated steel base, galvanized for long life and corrosion resistance.
  • Page 20 A grease seal is mounted to prevent escape of grease. The bearings are permanently lubricated and need no maintenance. Wascomat's design transfers the weight of the loaded wash cylinder to the largest possible surface area away from the bearings, for longest machine life.

  • Page 21: Control Unit

    Mechanical and electrical design Control unit Fig. The cycle timer (K51), rotary program selector (S5), level controls (B1 and B2) and rotation guard (B31) are mounted just behind the control panel. The relays (K1-4) are located at the top of the machine, easily accessible for service.
  • Page 22 Mechanical and electrical design Relays The W245 employs four relays to control the Fig. motor speeds: • wash speed (K1 and K2) • distribution speed (K3) • extract speed (K4) Construction The body of the relay holding the stationary Fig. contacts is made of current-resistant plastic.
  • Page 23 Mechanical and electrical design Drive motor description The three-speed operation of the wash cylinder is Fig. achieved by two motors. One 2-speed motor for wash speed (12-pole drive) and distribution speed (8-pole drive) and one single speed motor for extraction speed (4-pole drive). The motors are mounted on a motor bracket, the extract motor fixed the bracket, the wash and distribution motor in slots which allow adjusting the distance...
  • Page 24 Mechanical and electrical design Motor connections Fig. This diagram illustrates motor connections to the connector plug: Wash/distribution motor: 1, 2 and 3: wash speed (12-pole winding). 4,5 and 5: distribution speed (8-pole winding). 7 and 9: motor overload protector. Extract motor: 1, 2 and 3: extract speed (4-pole winding).
  • Page 25 Mechanical and electrical design How to remove motors Loosen the spring loads set screw. Lift the motor Fig. unit and detach the V-belts. Dismount the bracket holding the motor hinge shaft. Lift out the motor bracket with motors mounted. Loosen the mounting screws of the wash/distribution motor and the set screws.
  • Page 26 Mechanical and electrical design Description The machine door lock consists of the following: Fig. • The locking unit, located behind the front panel below the detergent dispenser. The unit consists of a solenoid which locks the door, and two microswitches. Switch S4A indicates that the door is locked and switch S3 indicates that the door is closed.
  • Page 27 Mechanical and electrical design Door lock control unit The sole function of this control unit is to oversee the correct functioning of Fig. the door lock. The CPU board receives information from the motor control unit about motor rotation, and has its own level-monitoring device. The control unit also detects water level and motor speed through separate level measurement devices and the rotation guard (speed-monitoring device).
  • Page 28 Mechanical and electrical design Error indication patterns Fig. If the door lock is working correctly, this is indicated by the red LED, by a pattern of flashes which indicates “OK”. The error indication patterns revealed by the LED flash at various frequencies for the various errors or faults.
  • Page 29 Mechanical and electrical design Inlet valve, detergent Construction The valve has a single-inlet with either one, two Fig. or three outlets, each with its own solenoid coil. The body is made of heat-resistant polyamid plastic and the solenoids encased in water-tight plastic.

  • Page 30: Troubleshooting

    Mechanical and electrical design Maintenance instructions Limescale can block the hole in the valve diaph- ragm and interfere with the function of the valve. It is therefore advisable to dismantle and clean Fig. the valve at certain regular intervals. The fre- quency depends on operating conditions and the level of contamination in the water.

  • Page 31: Inlet Valves

    Mechanical and electrical design Inlet valves The water inlet valves have brass bodies with Fig. larger cross section of the outlet in order to achieve a shorter filling time for the machine. Construction The valve housing is made of pressed brass. The Fig.
  • Page 32 Mechanical and electrical design Soap supply box The three-compartment soap supply box is located at the top of the machi- Fig. ne. Viewed from the front, the compartments marked with figures 1, 2 and 3 are used as follows: Compartment 1 This compartment is used for adding detergent to the wash at the start of the Soak cycle.

  • Page 33: Drain Valve

    Mechanical and electrical design Drain valve Description Fig. The drain valve consists of a bracket (1), on which are mounted the motor and gear (2) and diaphragm (3). The rubber diaphragm is resistant to a water temperature up to 100°C (212°F). The installation of a lint trap is not necessary.

  • Page 34: Procedure

    Procedure Procedure for use Preparations Sort the laundry according to the types of wash cycle listed on the control panel. Check washing instructions on garment tags. Empty pockets and close zippers. Open door, put laundry in the machine and close door.

  • Page 35: Wash Programs

    Wash Programs Wash Programs Fig. In the figure below is an overview of the four wash programs. On the following pages you will find a more detailed description of the programs. WARM COLD PERM PRESS Time Temp. Water Time Temp. Water Time Temp.
  • Page 36 Wash Programs Wash program HOT After the machine has started and the door Fig. automatically locked, the drain valve will close and the hot and cold water valves will open to fill the machine with mixed hot and cold water to the level determined by the level control.
  • Page 37 Wash Programs Wash Program WARM On starting the machine, the door will automatic- Fig. ally be locked, and the prewash carried out as previously described, whereafter the main wash is started. As the main wash is started, the drain valve WARM closes, detergent is admitted and mixed hot and Time Temp.
  • Page 38 Wash Programs Wash Program COLD On starting the machine, the door will automatic- Fig. ally be locked, the drain valve closed, the cold water valve opened and the prewash carried out as previously described, whereafter the main wash is started. COLD As the main wash is started, the drain valve Time Temp.
  • Page 39 Wash Programs Wash Program PERMANENT PRESS Fig. On starting the machine, the door will automatic- ally be locked, the drain valve closed, the hot and cold water valves opened and the prewash will be carried out as previously described, where- after the main wash is started.

  • Page 40: Maintenance

    Maintenance Maintenance Preventive maintenance has been reduced to a minimum by the careful design of reliable components and material. However, the following measures should be taken at regular intervals and in proportion to the hours of service. Make certain that all electrical power to the machine is shut off before removing top or rear panels.

  • Page 41: Trouble Shooting

    Trouble shooting Make certain that all electrical power to the machine is shut off before removing top or Supply signals Program Prewash step Mainwash Rinse Final extract rear panels. Doorlock delay START Door unlocked STOP If the machine does not start A Check the circuit breaker in the power feed Fig.
  • Page 42 Trouble shooting If the machine does not extract Fig. A Check the extract relay and relay coil for proper operation. If the motor does not operate at wash speed A Check the wash relays. Fig. B Check the motors and V-belts. C Check auxilliary contact on extract relay.
  • Page 43 Trouble shooting If the machine runs slowly on wash speed or there is a slapping or thumping noise Fig. A Replace V-belts If a metallic noise can be heard at rear of machine B Tighten the pulley on motor shaft. 0437...
  • Page 44 Trouble shooting If water does not enter the machine Fig. A Check the valve coils on the inlet valves. B Check wires leading to the valve coils. C Be sure manual shut-off valves are in open position. 4984...
  • Page 45 Trouble shooting If water continues to fill without stopping Fig. A Check inlet valves for dirt underneath the valve diaphragm. To localize, shut off power. If water continues to flow, inlet valves have foreign material in them and should be thoroughly cleaned.
