F23
INSTRUCTION MANUAL
BODY SHELL SET
● Compatible with Kyosho Mini-Z Racer
MR-04 (MM) Wheelbase LL (98mm)
MR-03
+
● Use wide front width
● IC tag mountable
● Parts are unpainted
● This is not a genuine Kyosho product
● Specifications may change without notice
Motor Case Set (MR-04MM) MZ714
Rear Shock Set MZ206C
Small Parts for Suspension (MR-04) MZ708
Advertisement
Summary of Contents for MZ Formula F23
- Page 1 INSTRUCTION MANUAL BODY SHELL SET ● Compatible with Kyosho Mini-Z Racer MR-04 (MM) Wheelbase LL (98mm) MR-03 Motor Case Set (MR-04MM) MZ714 Rear Shock Set MZ206C Small Parts for Suspension (MR-04) MZ708 ● Use wide front width ● IC tag mountable ●...
- Page 2 Contents of the Product Front Wing Body Rear Wing Small Parts Helmet 2x6mm F/H tapping screw x1 2x6mm Bind tapping screw x1 3x8mm F/H tapping screw x1 MZ FORMULA F23...
- Page 3 Case Set (MR-04MM) MZ714. ※ If you are converting from a chassis other than the MR- 03MM, you will need the Rear Shock Set MZ MZ206C and Small Parts for Suspension (MR-04) MZ708 separately. ■ MZ FORMULA dedicated wheels MZF-W01F / Wheel Type A Front（Contains 2 pieces）...
-
Page 4: Handling Precautions
※ The material is UV resin; avoid direct sunlight or temperatures above 40° C. More information about MZ FORMULA MZ FORMULA enjoy smile Official FACEBOOK Official YouTube MZ FORMULA Product Inquiry Distributor : enjoy smile Co. https://enjoysmile.co.jp/ MZ FORMULA F23... - Page 5 Body Assembly Cut off the integrated small parts from the support using nippers or similar tools. MZ FORMULA F23...
- Page 6 Fix with glue (instant, multi- Fix with screws purpose, wood glue, etc.) Left side part has a ▲ -shaped protrusion inside. Right side part has a ▲ -shaped recess inside. 3x8mm F/H tapping screw MZ FORMULA F23...
- Page 7 Remove the body mount parts from chassis and use the same screws to install the front wing in the same position. 2x6mm Bind tapping screw MZ FORMULA F23...
- Page 8 Set the shaft to the highest position. Assemble the differential gear shaft and insert the wing. Align the position using the pin on the bottom side of the wing part, then slide and push it in the direction of the arrow. MZ FORMULA F23...
- Page 9 Push the entire wing into the motor case, and hook the tab on the top of the wing mount onto the corner of the hole at the rear end of the motor. Fix with 2x6mm F/H tapping screw. MZ FORMULA F23...
- Page 10 Insert the front tab of the body between the holders at the rear end of the nose, then place the body over the chassis. MZ FORMULA F23...
- Page 11 ※ Be careful not to overexpand the body as it may crack! Attach the wheels and tires to complete. When using Mini-Z tires, install two rubber tires on one wheel. MZ FORMULA F23...
- Page 12 MZ FORMULA F23...
