Summary of Contents for Siemens WI14W502GB
- Page 1 WI14W502GB Washing machine EN User manual and installation instructions Register your appliance on My Siemens and discover exclusive services and offers. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Table of contents You can find additional information and explanations online. Scan the QR code on the title page. Table of contents Table of contents 1 Safety .......... 3 11 Laundry ........ 2 9 1.1 General information... -
Page 3: Safety
Safety en 16.1 Cleaning the drum .... 3 3 18.1 Removing the appliance .. 4 3 16.2 Cleaning the detergent 18.2 Inserting the transit bolts .. 4 3 drawer ........ 3 4 18.3 Using the appliance again... -
Page 4: Safe Installation
en Safety inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers. Do not let children play with the appliance. Cleaning and user maintenance must not be performed by chil- dren unless they are being supervised. - Page 5 Safety en WARNING ‒ Risk of fire! It is dangerous to use an extended power cord and non-approved adapters. Do not use extension cables or multiple socket strips. Only use adapters and power cords approved by the manufac- turer. If the power cord is too short and a longer one is not available, please contact an electrician to have the domestic installation adapted.
-
Page 6: Safe Use
en Safety If the appliance is moved by holding onto protruding components, such as the appliance door, the parts may break off. Do not move the appliance by holding onto protruding parts. CAUTION ‒ Risk of cutting! Touching sharp edges on the appliance may lead to cuts. Do not touch the sharp edges on the appliance. - Page 7 Safety en WARNING ‒ Risk of suffocation! Children may breathe in or swallow small parts, causing them to suffocate. Keep small parts away from children. Do not let children play with small parts. WARNING ‒ Risk of poisoning! Detergents and care products may result in poisoning if con- sumed.
-
Page 8: Safe Cleaning And Maintenance
en Preventing material damage If accidentally swallowed, seek medical advice. Keep detergents and care products out of the reach of children. 1.6 Safe cleaning and maintenance WARNING ‒ Risk of electric shock! Improper repairs are dangerous. Never make any technical modifications to the appliance or its features. - Page 9 Preventing material damage en Exceeding the maximum load capa- 100 kPa (1 bar) and max. city impairs the function of the appli- 1000 kPa (10 bar). ance. If the water pressure exceeds the Observe the maximum load capa- maximum value specified, a pres- city for each programme and do sure-reducing valve must be in- not exceed it.
-
Page 10: Environmental Protection And Saving Energy
en Environmental protection and saving energy 3 Environmental protec- 4 Installation and con- Environmental protection and saving energy Installation and connection tion and saving energy nection 3.1 Disposing of packaging 4.1 Unpacking the appliance The packaging materials are environ- ATTENTION mentally compatible and can be re- Objects remaining in the drum that cycled. -
Page 11: Requirements For The Installa- Tion Location
Installation and connection en Note: The appliance has undergone If the appliance is tilted at an angle a function test at the factory. This greater than 40°, residual water may may cause water stains in the appli- leak out of the appliance and cause ance, which the first wash cycle re- material damage. -
Page 12: Removing The Transit Bolts
en Installation and connection Unscrew and remove all of Installation loca- Requirements the screws for the 4 transit bolts tion using a WAF 13 wrench. Note: The use of sliding plates makes it easier to slide the appli- ance into the re- cess. -
Page 13: Tools For Assembly
Installation and connection en If one cover cap is included in rear feet until the appliance is on the scope of delivery, insert the the runners. cover cap in the bottom left opening for the transit bolt. Measure the built-in niche. Note: To install the transit bolts to transport the appliance, perform these steps again in the reverse or-... - Page 14 en Installation and connection Unscrew the rear appliance feet. the housing using a WAF 17 wrench. Align the appliance using a spirit In doing so, hold the foot tight and level. do not adjust its height. Installing the cabinet door Note: Metal elements may impair the function of the control panel.
- Page 15 Installation and connection en Mark on the top edge of the appliance at the right-hand stop Using the mark for the top edge of the appliance on the inside of the door as a basis, mark the drill holes as follows. Mark for the holes at the right-hand stop At the previously marked points,...
- Page 16 en Installation and connection Insert the hinges into the holes Slide in the covering rail and screw them in. screw it in Put the magnetic catches on the appliance. Screw on the counter plates for the magnetic catches. Insert the hinges into the appliance Aligning the cabinet door Vertically aligning the cabinet door...
- Page 17 Installation and connection en Horizontally aligning the cabinet Measure dimension Z and dimen- door sion Y. Screw the spacers in as per the di- mensions. Installing the base panel Insert the spacers for the base panel. Note: When inserting the base panel, ensure that, if the base panel is protruding or the cabinet panel is flush-mounted, the time-...
-
Page 18: Connecting The Appliance
en Installation and connection Install the base panel. ATTENTION Material damage may be caused if the water inlet hose is connected in- correctly. Tighten the screw connections on the water inlet until they are hand- tight. Connect the water inlet hose to a tap (26.4 mm = 3/4"). -
Page 19: Before Using For The First Time
Before using for the first time en 5.1 Starting an empty washing Siphon Secure the con- nection point with cycle a (24–40 mm) Your appliance was inspected thor- hose clamp. oughly before leaving the factory. To remove any residual water, run the first wash cycle without any laundry. -
Page 20: Familiarising Yourself With Your Appliance
en Familiarising yourself with your appliance "Basic operation", Page 30 Start the first wash cycle or set the programme selector to Off to switch off the appliance. 6 Familiarising yourself with your appliance Familiarising yourself with your appliance 6.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. -
Page 21: Detergent Drawer
Familiarising yourself with your appliance en 6.2 Detergent drawer Measuring aid for liquid deter- Page 30 gent Note: Observe the manufacturer's in- structions on the use and dosage of Compartment II: Detergent for the detergent and care product and the main wash the information in the programme de- Compartment : Fabric softener... -
Page 22: Display
en Display 7 Display Display The display shows the current settings, options or relevant information. Depending on the programme status, the display shows some information in area, e.g. Example: Display Display Description 1 0:40 Expected programme duration or programme time re- maining in hours and minutes. 1 Program end time "Buttons", Page 23... -
Page 23: Buttons
Buttons en Display Description Lights up: The childproof lock is activated. Flashes: The childproof lock is activated and the appli- ance has been operated. "Deactivating the childproof lock", Page 33 Shortened programme duration is activated. "Buttons", Page 23 Flashes: Drum cleaning is required. Run the Drum Clean programme for cleaning and caring for the drum and the outer tub. -
Page 24: Programmes
en Programmes Button Selection More information Set temperature in °C. Spin Speed – – – - 1400 Adjust the spin speed or activate – – – (Rinse Hold). Set spin speed in rpm. If – – – is selected, the water is not drained at the end of the washing cycle and the spin cycle is deactivated. - Page 25 Programmes en Programme Description Max. load (kg) Cottons Wash hard-wearing items made from cotton or 1 linen. Also suitable as a short programme for normally soiled laundry when you activate vario Speed. Programme setting: Max. 70 °C Max. 1400 rpm Eco 40-60 Wash items made from cotton or linen. Note: Fabrics which can be washed from 40 °C up to 60 °C as per the care symbol can be...
- Page 26 en Programmes Programme Description Max. load (kg) Delicate/Silk Wash delicate, washable items made from silk, vis- cose and synthetic fabrics. Use a detergent that is suitable for delicates or silk. Note: Wash especially delicate items or items with hooks, eyelets or clips in a mesh laundry bag. Tip: Gently cleaning the laundry reduces abrasion of textile fibres and microplastic fibres.
- Page 27 Programmes en Programme Description Max. load (kg) Place the detergent for outdoor fabrics in compart- ment II in the detergent drawer and the waterproof- ing agent in the compartment. "Detergent drawer", Page 21 After-treat the laundry in accordance with the manu- facturer's instructions. Programme setting: Max.
-
Page 28: Accessories
en Accessories Programme Description Max. load (kg) Do not use fabric softener. Do not use liquid detergent or detergent that is in- tended for woollens or delicates. Note: The drum cleaning indicator flashes to re- mind you if you have not used a programme at 60 °C or higher for a long time. -
Page 29: Laundry
Laundry en 11.2 Care symbols on the care 11 Laundry labels Laundry 11.1 Preparing the laundry Washing care symbols ATTENTION Symbol Recommended pro- Objects remaining in the laundry may gramme damage the laundry and the drum. Cottons (normal) Remove all items from any pock- ets in your laundry before using the appliance. -
Page 30: Basic Operation
en Basic operation Do not use color-bleaching agents Open the door. in the appliance 13 Basic operation Basic operation 13.1 Switching on the appli- ance Requirement: The appliance has been correctly installed and connec- Page 10 ted. Turn the programme selector to a programme. -
Page 31: Using The Measuring Aid
Basic operation en Insert the measuring aid. Fold the measuring aid down and click it into place. 13.6 Using the measuring aid 13.7 Adding detergent and To more easily measure the liquid care product detergent, you can use a measuring aid in the detergent drawer. Note: Observe the information about detergents and care products Note: Do not use a measuring aid for... -
Page 32: Adding Laundry
en Childproof lock uses the filled detergent for soaking 13.12 Resuming the pro- and washing. gramme when the pro- gramme status is Rinse Requirements The laundry is placed in the appli- Hold Page 30 ance. Requirements A programme has started. Rinse Stop is activated. Page 31 ... -
Page 33: Deactivating The Childproof
Basic settings en switched off and in the event of a Set the volume of the signal power cut. tone emitted when the buttons are pressed: 14.2 Deactivating the child- 0 (off) to 4 (very loud) proof lock Activate (On) or deactivate Requirement: To deactivate the (OFF) the reminder to clean the childproof lock, the appliance must... -
Page 34: Cleaning The Detergent Drawer
Tip: You can get our tested and ap- proved machine care and machine cleaner products online at https:// www.siemens-home.bsh-group.com/ store or from customer service. Run the Drum Clean programme without laundry but with washing powder that contains oxygen... -
Page 35: Cleaning The Drain Pump
Cleaning and servicing en Fit the insert and click it into place. Emptying the drain pump Turn off the tap. Switch off the appliance. Disconnect the appliance's mains plug from the power supply. Remove the base panel. Slide a suitable receptacle under the opening for draining the deter- gent solution. - Page 36 en Cleaning and servicing To allow the detergent solution to Loosen the dirt and remove the flow out into the container, remove filter insert. the locking cap. Clean the interior, the thread on Once emptied, press firmly on the the pump cap and the pump hous- locking cap.
-
Page 37: Cleaning The Rubber Gasket
Troubleshooting en panel is flush-mounted, the time- Switch on the appliance. Light is not visible. Pour 1 litre of water into compart- Install the base panel. ment II. Select a suitable programme for draining. "Programmes", Page 24 16.4 Cleaning the rubber gas- Clean the rubber gasket regularly. Page 30 Open the door. - Page 38 en Troubleshooting Fault Cause and troubleshooting The display goes out Energy-saving mode is active and Start/Reload Press Start/Reload. flashes. E:36 -10 / E:30 -80 / The water outlet hose is connected too high, is kinked E:18 or trapped, or has been extended impermissibly. The detergent solution Check the installation of the water outlet hose.
- Page 39 Troubleshooting en Fault Cause and troubleshooting E:30 -10 / The water level measuring system is defective. With this error message, the appliance starts a draining process. Wait approx. 5 minutes until the draining process ends. Restart the appliance. If required, start the draining process again. If the fault persists, call customer service.
- Page 40 en Troubleshooting Fault Cause and troubleshooting or heavy foam Detergent dosage is too high. build-up. Mix one tablespoon of fabric softener with 0.5 litres of water and pour the mixture into compartment II (not for outdoor clothing, sportswear or items stuffed with down).
- Page 41 Troubleshooting en Fault Cause and troubleshooting The appliance is vi- Appliance is not correctly aligned. brating, 'wandering' Align the appliance. and making loud The appliance feet are not fixed. noises during the spin Secure the appliance's feet. cycle. Transit bolts have not been removed. Remove the transit bolts.
-
Page 42: Emergency Release
en Troubleshooting Fault Cause and troubleshooting Water is leaking out at The water inlet hose is not correctly connected or is the water inlet hose. damaged. Check the installation of the water inlet hose. Page 10 In the event of damage, call customer service. Page 44 ... -
Page 43: Restart The Appliance
Transportation, storage and disposal en Pull the emergency unlock down- Drain the water. "Cleaning the drain pump", wards with a tool and release. Page 35 Detach the hoses. 18.2 Inserting the transit bolts Secure the appliance before trans- portation using transit bolts in order to prevent transport damage. -
Page 44: Product Number (E-Nr.) And Production Number
en Customer Service pliance door or prevent it from Detailed information about the war- opening. ranty period and the warranty condi- With redundant appliances, unplug tions in your country is available via the power cord. Then cut through the QR code on the enclosed docu- the cord and damage the lock on ment on service contacts and war- the appliance door beyond repair... -
Page 45: Consumption Values
Consumption values en must be connected to the power defective supply lines or fittings up supply. to the Aqua-Stop connection on The liability guarantee is valid for the tap. the service life of the appliance. If your appliance is fitted with A claim can only be made under Aqua-Stop, you can in principle the guarantee if the appliance has... -
Page 46: Technical Data
en Technical data Programme Load Pro- Energy Water Max- Spin Resid- (kg) gramm con- con- imum speed 1 e dura- sump- sump- temper- (rpm) mois- tion tion tion (l/ ature ture 1 1 1 (h:min) (kWh/ cycle) (°C) 5 1 1 cycle) mins Cottons... - Page 48 EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom BSH Hausgeräte GmbH Carl-Wery-Straße 34...
