Haworth Trivati Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Trivati®
Installation Manual – October 2016
Revision: 2.0
Catalog Number: 119-6179
E.C.O. No: 550-007
Part Number: 119-6184

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trivati and is the answer not in the manual?

Questions and answers

Related Manuals for Haworth Trivati

Summary of Contents for Haworth Trivati

  • Page 1 Trivati® Installation Manual – October 2016 Revision: 2.0 Catalog Number: 119-6179 E.C.O. No: 550-007 Part Number: 119-6184...
  • Page 3 Thank you for choosing TRIVATI® by Haworth. TRIVATI is a progressive-built office wall system; therefore careful considerations to the order of component installation must be addressed before the beginning of its installation. Familiarity of the system joints, brackets and support components with regards to the customer-expected layout must be clearly understood before deciding where to start and how to progress.

  • Page 4: Table Of Contents

    Table of Contents Safety • Working with Glass • Cutting Aluminum / Plastic General Installation Guidelines • Tools Required • Cutting Station • Staging Materials & identification • Measuring Order of Assembly • Starting Point • Layout Review • Floor Types •...
  • Page 5 Table of Contents (cont’d) Transitions, Covers & Misc. Rails • Types • Applications • Installation Steps Solid Tile Panels • Types • Applications • Installation Steps Glass Panels & Glazing Connectors • Types • Applications • Installation Steps Channel Caps •...

  • Page 6: Section 1 - Safety

    Section 1 - Safety Working with Glass When handling tempered glass use cut resistant gloves and safety glasses to protect yourself. When staging or placing glass into frames also wear glass sleeves to protect your forearms from sharp edges. When lifting glass on or off crates/carts always keep the glass panes in an upright position. Never carry the glass flat.

  • Page 7: Section 2 - General Installation Guidelines

    Section 2 - General Installation Guidelines Tools Required Robertson Cordless drill with #2 square recess driver bits Square Bit Hammer drill (for concrete anchors or screws) Vacuum 16 to 27 oz Deadblow Hammer Tap block Level (4’ and 2”) Laser - 5 -point Mitre Saw 10”...

  • Page 8: Cutting Station

    Cutting Station To avoid aluminum shavings from damaging carpet and walls, a cutting station should be used. A cutting station can be built by using shipping materials (protective foam or cardboard sheeting) to protect floors and walls. Commercial saw hoods are also available that will mount to the saw or saw table, these hoods are preferred as the saw can be easily moved to work areas.

  • Page 9: Staging Materials & Identification

    Staging Materials & Identification Using the floor plans and technical drawings, determine the product requirements for each build area. All products should be kept close by but not directly in the work area. Keep material type (Rails, Panel Inserts, Brackets, Glass, etc...) grouped together and organized. Glass should be staged in order of installation and glass stamps should be marked to assist in quick and proper glass placement.

  • Page 10: Section 3 - Order Of Assembly

    There are multiple applications of rails and components that must be installed in a specific order during the installation of Trivati due to the progressive nature of the installation process. Failure to install the components at the right time could result in having to rework part of the installation or difficulty installing the components.

  • Page 11: Floor Types

    Floor Types Trivati is capable of, and intended, to be installed on all floor types and substrates. Due to various floor constructions, the anchoring components are not provided by Haworth. The appro- priate fastening components and frequency of attachment should be determined by the site engineer.

  • Page 12: Rail Channels, Seals And Caps

    Rail Channels, Seals and Caps The number of seals and locations of seals required in framing rails is dependent on the Glass panes and Solid panel inserts application as well as Door locations. Seals should be inserted or removed as needed either before rails are installed or before the rail ends are blocked by other framework.

  • Page 13: Panel Types & Levelers

    Panel Types and Levelers The panel inserts that make up the wall partitions can have multiple types and finishes. Panel types can either be Solid or Glass. Glass panel types are typically 10mm or 12mm thick. For glass types, finishes and panel size, refer to the layout to ensure they are installed in the correct orientations and locations.

  • Page 14: Brackets & Rail Joints

    Brackets and Rail Joints The Locking Blocks of the Rail Bracket Kit, Vert-Horz must be slid into the rail slots prior to the rails being anchored to the floor or walls or attached to one another. Pre-planning and understanding how many are needed and in which orientation they should be inserted is critical to a smooth installation.

  • Page 15: Pivot Door Preparations

    Pivot Door Preparations Pivot Door Top Rail Pivot doors with a closer or magnetic lock accessories require a specific top rail with the center walls removed to accommodate the accessories. Each top rail machining (A) is specific to the Door width size. Be sure to install the correct top rail in the correct pivot door location in place of the regular top rail.

  • Page 16: Section 4 - Rail Joint Types

    Section 4 - Rail Joint Types Horizontal / Vertical Joints Applies to 1 Channel and 3 Channel Rails Required Bracket Kit Locking Block Rail Bracket Kit, Vert-Horz 119-1479 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 17 Installation Steps NOTE: Ensure that all flat head screws are loose. Pull rails tight together and hold alignment during the following steps. 0.0” CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 18 Installation Steps 1) Push bracket into corner. 2) Tighten set screws (2) on the block that is parallel to the seam line. Tighten flat head screws (2) on the block that is parallel to the seam line. CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 19 Installation Steps 1) Ensure that flat head screws (2) on the block that is perpendicular to the joint line are loose. 2) Pull block block that is perpen- dicular to the seam line away from the seam line. 3) Tighten set screws (2) on the block that is perpendicular to the seam line This last step will pull the seam...

  • Page 20: Inline & Variable Angle Joints

    Inline & Variable Angle Joints Applies to 1 Channel and 3 Channel Horizontal Rails 60° (min) 90° 180° (Inline) Required Bracket Kit Bracket Locking Block Rail Bracket Kit, 2 Way 119-1482 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 21 Installation Steps Slide a Locking Block into each rail. Loosely engage the flat head screws (2) to the Locking Block to hold the Bracket in place. Position the Rail Bracket Kit Assembly so that the Bracket is approxiamtely centered over the seam.
  • Page 22 Installation Steps 0.0” Pull rails tight together and hold alignment during the following steps. 1) Tighten the set screws (2) on one of the Locking Blocks. 2) Pull the other Locking Block away from the seam. 3} Tighten the set screws (2) on the other Locking Block in its pulled away position.

  • Page 23: 3Way Off Module Joints

    3 Way Off Module Joints Applies to 3 Channel Horizontal Top Rails Required Bracket Kit Rail Bracket Kit, 3 Way, Off Module 119-1483 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 24 Installation Steps 1) Position Bracket to ensure the slots are over the screw channels of Top Rail A and the holes are over the screw channels in Top Rail B. 2) Screw Bracket into Top Rail B using (4) screws though holes. 3) Ensure Top Rail B is firmly against Top Rail A.

  • Page 25: Inline Door Frame Type Joints

    Inline Door Frame Type Joint Applies to any Vertical Transition Rail requiring attachment to a fixed floor. Required Bracket Kit Locking Block Bracket Rail Bracket Kit, Inline Door Fr 119-1481 4.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 26 WARNING: Appropriate fasteners and anchors must be used to attach any Bracket to the floor. Due to various floor construc- tions, fasteners and anchors are not provided by Haworth. Consult with the customer appointed engineer for fastener recommendations.

  • Page 27: Section 5 - Starter Rails

    Section 5 - Starter Rails Rail Types Rail, Top|Starter, 3Chnl, 2.5” Rail, Top|Starter, 1Chnl, 2.5” Rail, Bottom|Starter, 3Chnl, 1.5” 119-1434 119-1435 119-1438 Rail, Bottom|Starter, 1Chnl, 1.5” Rail, Starter w/Trim, 3Chnl, 2.5” Rail, Starter w/Trim, 3Chnl, 1.5” 119-1439 119-1446 119-1484 Rail, Starter, Dr Fr, 3Chnl 120-5312 Supporting Components 1/16”...
  • Page 28 Application Options Floor-to-Ceiling Floor-to-Top Rail (Vertical) (Vertical) Base Rail-to-Ceiling Base Rail-to-Top Rail (Vertical) (Vertical) CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 29 Installation Steps X” X” 1/16” - 1/8” NOTE: Compress carpet and measure. Before securing Starter (A) to the wall, insert Locking Blocks (B) in the correct orientation at each end. Tighten one set screw on each Locking Block to prevent them from sliding out.
  • Page 30 Starter (A) to the wall. Due to various wall constructions, fasteners and wall anchors are not provided by Haworth. Consult with the customer appointed engineer for fastener recommendations. NOTE: Make sure Starter (A) is level.

  • Page 31: Installation Steps

    Installation Steps - Door Frame Option X” X” 1/16” - 1/8” NOTE: Compress carpet and measure. Before securing Dr Fr Starter (A) to the wall, insert Bracket (B) at the bottom end. Tighten set screw to prevent it from sliding out.
  • Page 32 Starter (A) to the wall. Due to various wall constructions, fasteners and wall anchors are not provided by Haworth. Consult with the customer appointed engineer for fastener recommendations. NOTE: Make sure Starter (A) is level.

  • Page 33: Section 6 - Top Rails

    Section 6 - Top Rails Rail Types Rail, Top|Starter, 3Chnl, 2.5” Rail, Top|Starter, 1Chnl, 2.5” Rail, Top Acc Chnl, 2.5” 119-1434 119-1435 119-1436 Supporting Components Locking Block Rail Bracket Kit, Vert-Horz Rail Bracket Kit, 2 Way 119-1482 119-1479 Prep Work: Remove (1) Locking Block from each Rail Bracket assembly required.
  • Page 34 Application Options From Starter or other Vertical Transition From Wall (Horizontal) (Horizontal) From adjacent Top Rail (Inline or Mitre) CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 35 Attach Top Rail to type. Due to various ceiling constructions, fasten- Ceiling Fasteners come with ers and wall anchors are not provided by Ceiling Grip Clips Haworth. Consult with the customer appointed engineer for fastener recommendations. Ceiling Tile Ceiling Grid Clip Ceiling Grid...
  • Page 36 Installation Steps Slide Rail Bracket (B) into corner and tighten per Joint Type instructions detailed in Section 4. NOTE: Review layout plan to determine if any Vertical transitions are along the Top Rail. If so, additional Lock- ing Brackets (B) need to be installed. Slide in required Locking Brackets (B) in the correct orientation.
  • Page 37 Options If any glass panel are center mounted, rubber protective caps must be installed onto the screw tips to protect the glass panel at the time of installation. Part of Leveler Insrt Ctr 1.5 - 119-1470 Leveler Insrt Ctr 2.5 - 119-1471 Tool, Ctr|1Chnl Glass Screw Cap 119-6181 Slide cap (D) into tool (E).

  • Page 38: Section 7 - Bottom Rails

    Section 7 - Bottom Rails Rail Types Rail, Bottom, 3Chnl, 2.5” Rail, Bottom|Starter, 3Chnl, 1.5” Rail, Bottom|Starter, 1Chnl, 1.5” 119-1437 119-1438 119-1439 Supporting Components Locking Block Rail Bracket Kit, Vert-Horz Rail Bracket Kit, 2 Way 119-1479 119-1482 Prep Work: Remove (1) Locking Block from each Rail Bracket assembly required.
  • Page 39 Application Options From Wall From Starter or other Vertical Transition (Horizontal) (Horizontal) From adjacent Bottom Rail (Inline or Mitre) CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 40 Installation Steps 1/16” - 1/8” X” X” NOTE: Review layout plan to determine if the condition below applies. If so, review the Options page and the end of this Section for any additional steps before anchoring the Base Rail to the floor. INGLE LASS ANEL IN AN...
  • Page 41 Bottom Rail to the floor. Due to various floor constructions, fasteners and anchors are not provided by Haworth. Consult with the customer appointed engineer for fastener recommendations. NOTE: Review layout plan to determine if a Door opening is along the Bottom Rail.
  • Page 42 Installation Steps Slide Rail Bracket (C) into previously installed Top Rail when adjacent to another Top Rail (Inline or Mitre). NOTE: Review layout plan to determine if a Door opening is Repeat Steps 1 - 4. along the Bottom Rail. If so, review the Options pages at the end of this Section for any additional steps required before Tighten per Joint Type anchoring the Base Rail to the floor.
  • Page 43 Options When glass panels are mounted in the outer channels on both sides (see layout), levelers need to be slid in position before installing the next base rail. This applies to 2.5” or 1.5” profiles. Leveler Kit, Insert, Otr 119-1469 END VIEW Leveler 2.5”...
  • Page 44 Options When a single glass panel is mounted in one of the outer channels and the rail is mounted on carpet (see layout and site condition), support shims are required to balance the load under the base rail. This applies to 2.5” or 1.5” profiles. Rail Support Kit, Sgl Otr 119-6868 END VIEW...

  • Page 45: Section 8 - Transition Rails - 2-Way

    Section 8 - Transition Rails - 2-Way Rail Types Trns, 3Chnl, Std Trns, Tile-Tile, Std Rail, Trnsm, 3Chnl, 2.5” Trns, Tile-3Chnl, 3.5” 119-1440 119-1443 122-4724 121-7862 Trns, Tile-Glass, Otr, Std Trns, Tile-Glass, Otr, Ntch Trns, Tile-Glass, Ctr, Std Trns, Tile-Glass, Ctr, Ntch 119-1442 118-1655 119-1441...
  • Page 46 Application Options Trns, 3Chnl, Std 119-1440 Vertical Applications Trns, 3Chnl, Std 119-1440 Horizontal Applications CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 47 Application Options Trns, Tile-Tile, Std 119-1443 Vertical Application Horizontal Application Trns, Tile-Glass, Ctr, Std 119-1441 Vertical Application Horizontal Application Trns, Tile-Glass, Otr, Std 119-1442 Vertical Application Horizontal Application Trns, Tile-Tile, 1 Slot, Std 119-1444 Trns, Tile-Tile, 2 Slot, Std 119-6871 Trns, Tile-Tile, 1 Slot, Ntch 118-1656 Trns, Tile-Tile, 2 Slot, Ntch 119-6870 Horizontal Application...
  • Page 48 Application Options Trns, Tile-Glass, Ctr, Ntch 118-1654 Rail Bracket Kit, Vert-Horz 119-1479 Bottom Rail, 3Chnl, 2.5” or 1.5” Profile No bracket. Held flush to the Transition Rail when anchored to the floor. Bottom Rail, 1Chnl, 1.5” Profile Trns, Tile-Glass, Otr, Ntch 118-1655 Rail Bracket Kit, Vert-Horz 119-1479 Bottom Rail, 3Chnl,...
  • Page 49 Installation Steps X” X” 1/16” - 1/8” Before securing any Transitions (A), insert Locking Blocks (B) in the correct orienta- tion at each end. Tighten one set screw on each Locking Block to prevent them from sliding out. NOTE: Review layout plan to determine if additional Locking Blocks (B) need to be installed to support horizontal transitions.
  • Page 50 Installation Steps Tighten per Joint Type instructions detailed in Section 4. Options Furniture/Accessory Rail Mounting Block, Kit Applicable on horizontal application of: - Trns, Tile-Tile, 1 Slot, Std 119-1444 - Trns, Tile-Tile, 1 Slot, Ntch 118-1656 - Trns, Tile-Tile, 2 Slot, Std 119-687 - Trns, Tile-Tile, 2 Slot, Ntch119-6870 CUSTOMER SERVICE PHONE: 1-800-426-8562...

  • Page 51: Section 9 - Transitions, Covers & Misc. Rails

    Section 9 - Transitions, Covers & Misc. Rails Rail Types Rail, End of Run, 3Chnl, 1.5” Rail Splice, Vertical Compressible Seal Kit 119-1447 119-1445 119-1448 Intersection, 2 Way 90, Cv Kit Intersection, 2 Way 90, Mitre Intersection, Inline, Cv Kit, w/ACO, 5” 119-1449 119-1450 119-1451...

  • Page 52: Installation Steps

    Application Options Rail Splice, Vertical 119-1445 Note: Applied when any vertical rails are applied in a back-to-back scenario (Std Transitions shown). Vertical Application (only) Installation Steps Cut (2) lengths X” X = Same length as the Rail to be applied to CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 53 Application Options Rail, End of Run, 3Chnl, 1.5” 119-1447 Floor-to-Ceiling (Vertical) Installation Steps X” X” 1/16” - 1/8” CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 54 Installation Steps Before securing the Rail, End of Run, insert Locking Blocks (B) in the correct orienta- tion at each end. Tighten one set screw on each Locking Block to prevent them from sliding out. NOTE: Review layout plan to determine if additional Locking Blocks (B) need to be installed to support horizontal transitions.
  • Page 55 Application Options Compressible Seal Kit 119-1448 Floor-to-Ceiling Floor-to-Top Rail Base Rail-to-Ceiling Base Rail-to-Top Rail (Vertical) (Vertical) (Vertical) (Vertical) Installation Steps CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 56 Application Options Intersection, Inline, Cv Kit, w/ACO, 5” 119-1449 Intersection, Inline, Cv Kit, No ACO. 5” 119-1468 Intersection, Inline, Cv Kit, w/ACO, 3.5” 120-5310 Intersection, Inline, Cv Kit, No ACO, 3.5” 120-5311 Between Std Transitions Floor-to-Ceiling Floor-to-Top Rail Base Rail-to-Ceiling Base Rail-to-Top Rail (Vertical) (Vertical)
  • Page 57 Installation Steps Repeat steps 1-3 for the opposite side. CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 58 Application Options Intersection, 2 Way 90, Cv Kit 119-1450 Between Between Between Std Transitions Door Jambs Door Jamb & Std Transition Floor-to-Ceiling Floor-to-Top Rail Base Rail-to-Ceiling Base Rail-to-Top Rail (Vertical) (Vertical) (Vertical) (Vertical) Installation Steps X” X” 1/16” - 1/8” CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 59 Installation Steps Connecting Rails may not be as shown. CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 60 Application Options Intersection, 2 Way 90, Mitre 119-1451 50.5° Base Rail-to-Top Rail (Vertical) Installation Steps X” X” 1/16” - 1/8” 9.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 61 Installation Steps Before securing 2 Way 90, Mitre (A), insert Locking Blocks (B) in the correct orienta- tion at each end. Tighten one set screw on each Locking Block to prevent them from sliding out. NOTE: Review layout plan to determine if additional Locking Blocks (B) need to be installed to support horizontal transitions.
  • Page 62 Application Options Intersection, 3 Way 90, 1Chnl 119-1452 Floor-to-Ceiling Floor-to-Top Rail Base Rail-to-Ceiling Base Rail-to-Top Rail (Vertical) (Vertical) (Vertical) (Vertical) Frame runs Frame abutts to through Intersection 3 Way Installation Steps X” X” 1/16” - 1/8” 9.12 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 63 Installation Steps Locking Rail, 3Chnl Bracket (see layout to determine type) ~ 460mm (18”) Locking Bracket Installation Steps From Step 3 (shown without additional Rail) 9.13 CUSTOMER SERVICE PHONE: 1-800-426-8562...

  • Page 64: Section 10 - Solid Tile Panels

    Section 10 - Solid Tile Panels Panel Types All panel tile types are available in: • Veneer (WD) • Melamine (TFL) • Laminate (LAM) • Painted Steel (PTD) • Wallcovered Drywall (WLCV) Tile Insert, Vt, Full Height Tile Insert, Vt, Bottom Tile Insert, Vt, Mid Tile Insert, Vt, Top 121-9926...
  • Page 65 Application Options Full Height Full Height (vertical tile shown) Bottom Segmented (vertical tiles shown) 10.2 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 66 Installation Steps Ensure Levelers are in position. Levelers must slope to the outside of channel. Only for (PTD) or (WLCV) Tile types. Trim away the Fin portion of the Channel Seals (B) in all rails that the Tile will be inserted into. 10.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 67 Installation Steps Raise Lower Tile Tile ~4” ~4” 10.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 68 Options - Insulation Insulation, Acoustic, 21” TVT Insulation Tape HWP 119-1476 120-3168 1) Apply length of tape horizontally on the top of the installed solid panel. 2) Peel the backing of the tape that was attached on the installed panel to expose the adhesive.

  • Page 69: Section 11 - Glass Panels & Glazing Connectors

    Section 11 - Glass Panels & Glazing Connectors Connector Types Glazing Connector, Tape 2mm 119-1453 6.4mm 10mm 10mm 10mm 12mm 12mm 12mm Glazing Connector, Glazing Connector, Glazing Connector, Glazing Connector, Glazing Connector, Glazing Connector, Inline, 10mm 2 Way 90 2 Way Vara 3 Way 90 3 Way Brdg, 10mm 3 Way Vara, 10mm...
  • Page 70 Application Options Single Channel Single Glazed Double Glazed Center Glazed Triple Glazed (outer) Single Glazed Double Glazed Center Glazed Triple Glazed (outer) Segmented Glass Panels using a Standard Transition Rail horizontally 11.2 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 71 Installation Steps Ensure Levelers (A, B, or C) are in position based on the Base Rail type. (Double Glazed application shown) (Single Glazed - outer application shown) 11.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 72 Installation Steps Raise Lower Glass Panel Glass Panel ~ 4” Note: Leveler A shown, same applies to Levelers B and C. Levelers A, B and C can be replaced for Setting Block D if the Glass Panel needs to ~ 4” lower passed the limitations of the leveler.
  • Page 73 Glazing Connectors Connector, In-line or Tape Connector, Tape In-line 10mm 12mm Glazing Connector, Tape, 2mm In-Line 10 or 12mm NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge.
  • Page 74 Glazing Connectors Connector, 2 Way 90 NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge. Once prepped the installer cannot touch the edge again.
  • Page 75 Glazing Connectors Connector, 2 Way, Vara NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge. Once prepped the installer cannot touch the edge again.
  • Page 76 Glazing Connectors Connector, 3 Way 90 NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge. Once prepped the installer cannot touch the edge again.
  • Page 77 Glazing Connectors Connector, In-Line, Brdg 10mm 12mm END VIEW NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge. Once prepped the installer cannot touch the edge again.
  • Page 78 Glazing Connectors Connector, In-Line, Vara 10mm 12mm END VIEW NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top to bottom of glass edge. Once prepped the installer cannot touch the edge again.

  • Page 79: Section 12 - Channel Caps

    Section 12 - Channel Caps Cap Types Cap, Otr Chnl 119-1464 Cap, Ctr Chnl 119-1465 Cap, w/ Chnl Seal, Otr-Ctr Chnl 119-1466 Cap, w/ Chnl Seal, Ctr Chnl 119-1467 12.1 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 80 Application Options 119-1465 119-1465 119-1466 119-1467 119-1464 Triple Glazed Single Glazed Double Glazed Center Glazed (outer) Note: 2.5” Base Rail profiles shown (Caps are also applicable to 1.5” Base Rail profiles) 12.2 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 81 Installation Steps For Horizontal Caps: Y = X For Vertical Caps: Y = X + 1.5mm (1/16”) NOTE: Do not pull out all the way. 12.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 82 Installation Steps 1) Bow away from the rail at the middle. 2) Work the cap into the channel from the ends towards the middle. This will avoid damaging the finish on the previously installed top and bottom Caps. 12.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 83 Installation Steps Cap, w/ Chnl Seal, Ctr Chnl 119-1467 Note: Apply Caps before setting the Glass in place. 119-1467 Triple Glazed 12.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...

  • Page 84: Section 13 - Door - Pivot (Glass Slab)

    Section 13 - Door – Pivot (Glass Slab) Door kit Pvt/Dr, Glass Slab Dr Lf, Lchst 119-1507 Pvt/Dr, Glass Slab Dr Lf, DPull 119-1508 Hinge Door #8-18 x 1/2" Screw 1/4-20 x 1/4" Set Screw #10-24 x 1/2" Flat Head Screw #10-32 x 1/4"...
  • Page 85 Pivot Plate (E) to the floor. X” Door Width Due to various floor constructions, fasteners and 36” (914mm) 1012mm (39-13/16”) floor anchors are not provided by Haworth. Consult 42” (1067mm) 1164mm (45-13/16”) with the customer appointed engineer for fastener 48” (1219mm) 1317mm (51-13/16”) recommendations.
  • Page 86 Installation Steps NOTE: Locate points onto ceiling track to determine position of door frame strike vertical. X” NOTE: Compress carpet and measure. BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 13.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 87 Installation Steps X” BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 13.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 88 Installation Steps 1/4-20 x 1/4" Set Screw #10-24 x 1/2" Flat Head Screw #10-32 x 1/4" Flat Head Screw #8-18 x 1/2" Screw 13.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 89 Installation Steps CAUTION: Do not over-tighten. 60mm (2-23/64”) Repeat steps 6 & 7 for strike side. Y” NOTE: if Door is not present on site, use this alternative method. Ceiling height - 79mm (3-1/8”) W” If actual ceiling height differs from nominal height on layout drawing then adjust accordingly.
  • Page 90 Installation Steps #10-24 x 1/2" Flat Head Screw 13.7 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 91 Installation Steps Pre-Install Checklist 1) Is the top pivot pin (N1) freely moving up/down? The pivot pin is spring loaded and should spring out when released. Check for top setscrew (N2) (riding in the top slot) to have free motion though out the slot. If not free moving, file any burrs in the slot or check if spring/pivot assembly is properly installed.
  • Page 92 Installation Steps 1/4-20 Hex Flange Nut 1/4 - 20 X 1” Square Bolt NOTE: Glass should not extend above pivot extrusion, must be below or flush. ABOVE BELOW FLUSH NOTE: Close door (P) than adjust. Refer to Step 7. 13.9 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 93 Options - Cylinder Patch Kit Gasket Outer Plate #10-24 x 1" Flat Head U/C Screw 13.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 94 Options - Cylinder Patch Kit (Cylinder latchset may not be as shown) 13.11 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 95 Options - Mortise Patch Kit (Right-Hand application shown) Lock Body Lock Body Cover Screw Armor Plate (FSB SM-I latchset shown for Screw instruction purposes only) Lock Body Armor Plate Plate Dovetail Cover Lock Body Gasket Spacer #12-24 x 1/2" Flat Head Screw Dovetail Gasket Dovetail...
  • Page 96 Options - Mortise Patch Kit 13.13 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 97 Options - Closer (only) Closer Body Closer - Dorma ITS-9625 Closer Kit Closer Assembly (Right-Hand reverse application shown) Mechanism Double-sided Tape (cut to fit) Closer Arm Closer Track Closer Cover Screw Plate Closer Track Closer Cover #10-32 x 1/4" Flat Head U/C Screw #10-32 x 3/8"...
  • Page 98 Options - Closer (only) Cut tape to size to fit as shown. Closer Body Remove Closer Arm to attach Cover Plate (D). Closer Arm Re-assemble Closer Arm with Door assembly. Adjust Closer per manufacturer’s instructions. 13.15 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 99 Options - Closer & Magnetic Lock Closer Body Closer - Dorma ITS-9625 / Magnetic Closer Closer/Mag Lock Lock - SDC 1562 ITCM Mechanism Kit Assembly Closer Cover (Right-Hand reverse application shown) Plate Double-sided Tape (cut to fit) Closer Arm Magnetic Lock Kit #10-32 x 3/8"...
  • Page 100 Options - Closer & Magnetic Lock Center Closer Assembly kit within Glass cutout Masking Tape Shear Tab Alignment Slot NOTE: Prep edge of glass with a 50/50 Isopropyl Alcohol and distilled water solution. A damp lint free cloth is pulled in one motion from top Apply a strip of masking tape on the Header rail above to bottom of glass edge.
  • Page 101 Options - Closer & Magnetic Lock Remove middle Nylon Hex Bolt, Bracket and Mounting Screw Door Frame removed for illustration clarity. Closer Track Door Frame removed for illustration clarity. Closer Arm Re-assemble Closer Arm with Door assembly. Adjust Closer per manufacturer’s instructions. 13.18 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 102 Options - Electric Strike Electric Strike Rutherford L6505 (Left-Hand Reverse application shown) Door Frame Vertical (Strike Side) Extension Bracket Electric Strike Options - Roller Catch (Right-Hand application shown) Roller Catch Bracket (align with Roller Catch mechanism in door frame) Double-sided Tape (cut to fit) Glass Door Top Corner Strike Side...

  • Page 103: Section 14 - Door - Sliding (Glass Slab)

    Section 14 - Door – Sliding (Glass Slab) Door kit Sl/Dr, Glass Slab Dr Lf, Lchst 119-1512 Sl/Dr, Glass Slab Dr Lf, DPull, Lk 119-1513 Sl/Dr, Glass Slab Dr Lf, DPull, nLk 119-1514 (S2) (D2) 1/4-20 x 1/4" Set Screw 1/4-20 Hex Flange Nut #10-24 x 1/2"...
  • Page 104 Pivot Plate (E) to the floor. Due to various floor constructions, fasteners and Sliding (Q Position) (Door Opening) floor anchors are not provided by Haworth. Consult Door Width with the customer appointed engineer for fastener 42” (1067mm) 1108mm (43-3/8”) ~ 830mm (32-5/8”)
  • Page 105 Installation Steps ~ 305mm (12”) NOTE: For instructional purposes, a 2.5” profile is shown. The same steps apply to a 1.5” profile. Bottom rail shown with inner channel Repeat on opposite side. removed for clarity. 14.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 106 Installation Steps NOTE: Locate points onto ceiling track to determine position of door frame strike vertical. X” NOTE: Compress carpet and measure. BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 14.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 107 Installation Steps X” IMPORTANT! ORIENT CHANNELS (D1 & D2) AS SHOWN BEFORE CUTTING. EACH CHANNEL MUST HAVE A HOLE AT THE BOTTOM. X” RIGHT LEFT LEFT (M2) #8-18 x 3/4" Self-Drilling Screw BASE RAIL BASE RAIL (STANDARD) (LOW PROFILE) 14.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 108 Installation Steps (D2) 1/4-20 x 1/4" Set Screw #10-24 x 1/2" Flat Head Screw (E2) #8-18 x 1/2" Screw #10-32 x 1/4" Flat Head Screw NOTE: Caps (D3) are BASE RAIL BASE RAIL (STANDARD) (LOW PROFILE) used when one full height post (D1) is ordered.
  • Page 109 Installation Steps Loosely thread in Caution: Refer to Door Track (B) Refer to Door Track (B) Do not for spacing for spacing over-tighten 140mm (5-1/2”) NOTE: Level from low side for (W). LOW SIDE NOTE: The paint “indicator” at the LOW SIDE end of screw must not be visible.
  • Page 110 Installation Steps (V4) #10-24 x 1/2" Flat Head Screw 14.8 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 111 Installation Steps (A1) #8-32 x 1/2" Screw 14.9 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 112 Installation Steps (T3) #10-32 x 3/8" Screw 14.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 113 Installation Steps 14.11 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 114 Options - Hook Lock Hook Lock hardware kit Adams Rite 2331 Heavy Duty Deadbolt Blocking Ring 3/8” (Locking Cam may not be exactly as shown) (used for Left-Hand applications) Standard Core Blocking Ring 1/4” (used for Right-Hand applications) Blocking Ring 3/8” (used for Left-Hand applications) Small Format IC Housing Blocking Ring 1/4”...
  • Page 115 Options - Hook Lock (Right-hand application shown) (Right-hand application shown) 14.13 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 116 Options - Egress Lock Egress Entry Lock hardware kit (RA-B) Egress ADA Entry Lock hardware kit (RC-B) (Locking Cam may not be exactly as shown) Preparation: Check: Strike must be on the same side of door as cutout in glass slab.
  • Page 117 Options - Egress Lock 14.15 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 118 Options - Egress Lock Adjust door height per door instruction so that edge of door is parallel to door frame and latch is in center of strike hole. Adjust top stop in door track so that lock engages easily in strike without excessive play.

  • Page 119: Door - Pivot (Metal Glazed, Wood And Wood Glazed)

    Section 15 - Door – Pivot (Metal Glazed, Wood and Wood Glazed) Door kit Pvt/Dr, Metal Glazed Dr Lf, Lchst 119-1505 Pvt/Dr, Metal Glazed Dr Lf, DPull 119-1506 Pvt/Dr, Wood Slab Dr Lf, Lchst 121-0806 Pvt/Dr, Wood Slab Dr Lf, DPull 121-0807 Pvt/Dr, Wood Glazed Dr Lf, Lchst 121-0808 Pvt/Dr, Wood Glazed Dr Lf, DPull 121-0809 #10-12 x 1-3/4"...
  • Page 120 Pivot Plate (E) to the floor. X” Door Width Due to various floor constructions, fasteners and 36” (914mm) 1012mm (39-13/16”) floor anchors are not provided by Haworth. Consult 42” (1067mm) 1164mm (45-13/16”) with the customer appointed engineer for fastener 48” (1219mm) 1317mm (51-13/16”) recommendations.
  • Page 121 Installation Steps NOTE: Locate points onto ceiling track to determine position of door frame strike vertical. X” NOTE: Compress carpet and measure. BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 15.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 122 Installation Steps X” BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 15.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 123 Installation Steps 1/4-20 x 1/4" Set Screw #10-32 x 1/4" Flat Head Screw #10-24 x 1/2" Flat Head Screw #8-18 x 1/2" Screw 15.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 124 Installation Steps CAUTION: Do not over-tighten. 60mm (2-23/64”) Repeat steps 6 & 7 for strike side. Y” NOTE: if Door is not present on site, use this alternative method. Ceiling height - 79mm (3-1/8”) W” If actual ceiling height differs from nominal height on layout drawing 23mm Y”...
  • Page 125 Installation Steps #10-24 x 1/2" Flat Head Screw 15.7 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 126 Installation Steps Pre-Install Checklist 1) Is the top pivot pin (N1) freely moving up/down? The pivot pin is spring loaded and should spring out when released. Check for top setscrew (N2) (riding in the top slot) to have free motion though out the slot. If not free moving, file any burrs in the slot or check if spring/pivot assembly is properly installed.
  • Page 127 Installation Steps NOTE: Screw (G) is used for Metal Glazed Doors. Screw (J) is used for Wood Slab & Wood Glazed Doors. For Wood Doors, drill pilot holes (7/64") for Screws (J). #10-24 x 1/2" Flat Head Screw #10-12 x 1-3/4" Flat Head Wood Screw NOTE: Door leaf frame should not extend above...
  • Page 128 Options - Cylinder Patch Kit Pvt/Dr, Metal Glazed Dr Lf, Lchst 119-1505 Metal Glazed Door (Cylinder latchset may not be as shown) 15.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 129 Options - Mortise Patch Kit Pvt/Dr, Metal Glazed Dr Lf, Lchst 119-1505 (Cut-outs may not be as shown) Metal Glazed Door (Mortise latchset may not be as shown) 15.11 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 130 Options - Closer (only) Closer Body Closer - Dorma ITS-9625 Closer Mechanism (Right-Hand reverse application shown on a Metal Glazed Door) Double-sided Tape (cut to fit) Closer Arm #10-32 x 1/4" Flat Head U/C Screw Closer Track Closer Cover Screw Plate Closer Track Closer Cover...
  • Page 131 Options - Closer (only) Cut tape to size to fit as shown. Closer Body Remove Closer Arm to attach Cover Plate (D). Closer Arm Re-assemble Closer Arm with Door assembly. Adjust Closer per manufacturer’s instructions. 15.13 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 132 Options - Closer & Magnetic Lock Closer - Dorma ITS-9625 / Magnetic Closer Body Lock - SDC 1562 ITCM Double-sided Closer Tape (cut to fit) Mechanism (Right-Hand reverse application shown on a Metal Glazed Door) Closer Cover Plate Magnetic Closer Arm Lock Kit Closer Track Screw...
  • Page 133 Options - Closer & Magnetic Lock Cut tape to size to fit as shown. (feed wiring harness into frame) Closer Body Assemble using Magnetic Lock manufacturer supplied fastners. Remove Closer Arm to attach Cover Plate (D). Closer Arm Re-assemble Closer Arm with Door assembly. Adjust Closer per manufacturer’s instructions.
  • Page 134 Options - Electric Strike Electric Strike Rutherford L6505 (Left-Hand Reverse application shown) Door Frame Vertical (Strike Side) Extension Bracket Electric Strike Options - D-Pull Spacers Metal Glazed Doors only Note: Use a screwdriver through the spacer assembly to ensure it does not fall between the glass panes.

  • Page 135: Section 16 - Door - Metal Glazed Sliding

    Section 16 - Door - Metal Glazed Sliding Door kit Sl/Dr, Metal Glazed Dr Lf, Lchst 119-1509 Sl/Dr, Metal Glazed Dr Lf, Lk 119-1510 Sl/Dr, Metal Glazed Dr Lf, nLk 119-1511 (E2) (D3) (D2) #8-18 x 1/2" Screw #8-24 x 1/2" Tek Screw #10-32 x 1/4"...
  • Page 136 Pivot Plate (E) to the floor. Due to various floor constructions, fasteners and Sliding (Q Position) (Door Opening) floor anchors are not provided by Haworth. Consult Door Width with the customer appointed engineer for fastener 42” (1067mm) 1108mm (43-3/8”) ~ 830mm (32-5/8”)
  • Page 137 Installation Steps NOTE: For instructional purposes, a 2.5” profile is shown. The same steps apply to a 1.5” profile. Bottom rail shown with inner channel removed for clarity. 16.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 138 Installation Steps NOTE: Locate points onto ceiling track to determine position of door frame strike vertical. X” NOTE: Compress carpet and measure. BOTTOM IMPORTANT! DO NOT CUT BOTTOM OF CHANNEL! X” 16.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 139 Installation Steps X” IMPORTANT! ORIENT CHANNELS (D1 & D2) AS SHOWN BEFORE CUTTING. EACH CHANNEL MUST HAVE A HOLE AT THE BOTTOM. X” RIGHT RIGHT LEFT LEFT 16.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 140 Installation Steps (D2) 1/4-20 x 1/4" Set Screw #10-24 x 1/2" Flat Head Screw (E2) #8-18 x 1/2" Screw #10-32 x 1/4" Flat Head Screw BASE RAIL NOTE: Caps (D3) are BASE RAIL (STANDARD) (LOW PROFILE) used when one full height post (D1) is ordered.
  • Page 141 Installation Steps Loosely thread in Caution: Refer to Door Track (B) Refer to Door Track (B) Do not for spacing for spacing over-tighten 140mm (5-1/2”) NOTE: Level from low side for (W). LOW SIDE NOTE: The paint “indicator” at the LOW SIDE end of screw must not be visible.
  • Page 142 Installation Steps (V4) #10-24 x 1/2" Flat Head Screw 16.8 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 143 Installation Steps (A1) #8-32 x 1/2" Screw 16.9 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 144 Installation Steps 16.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 145 Options - Hook Lock Hook Lock hardware kit Adams Rite 2331 Heavy Duty Deadbolt Blocking Ring 3/8” (Locking Cam may not be exactly as shown) (used for Left-Hand applications) Standard Core Blocking Ring 1/4” (used for Right-Hand applications) Blocking Ring 3/8” (used for Left-Hand applications) Small Format IC Housing Blocking Ring 1/4”...
  • Page 146 Options - Hook Lock Metal Glazed Door (Right-hand application shown) (Right-hand application shown) 16.12 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 147 Options - Egress Lock Egress Entry Lock hardware kit (RA-B) Egress ADA Entry Lock hardware kit (RC-B) (Locking Cam may not be exactly as shown) Preparation: Check: Strike must be on the same side of door as cutout in glass slab.
  • Page 148 Options - Egress Lock Metal Glazed Door 16.14 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 149 Options - Egress Lock Adjust door height per door instruction so that edge of door is parallel to door frame and latch is in center of strike hole. Adjust top stop in door track so that lock engages easily in strike without excessive play.
  • Page 150 Options - D-Pull Spacers Metal Glazed Doors only Note: Use a screwdriver through the spacer assembly to ensure it does not fall between the glass panes. From Step 1 D-Pulls type may not be as shown. Assemble D-Pulls per manufacturer’s instructions. 16.16 CUSTOMER SERVICE PHONE: 1-800-426-8562...

  • Page 151: Section 17 - Electrical Power Base

    Section 17 - Electrical Power Base Locking Block (Part A) Locking Block (Part B) 1/4-20 x 3/8" Set Screw Hex Socket Cone Tip #10-24 x 3/8" Flat Head Screw Hex Socket Optional spacer for connection to 2 way intersection or door frame extrusions #10-24 x 3/4"...
  • Page 152 Installation Steps 17.2 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 153 Installation Steps (2x) (2x) 17.3 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 154 Installation Steps Note: Remove Wall Panel Tile to access PDA location. X - 10mm (3/8”) 17.4 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 155 Installation Steps Note: Extend cutouts in Rail (E) only if exisiting cables need to be passed through vertically. Based on accessibility at the time of installation, determine which extrusion wall side to remove. Image shows extrusion with side walls cut away. 17.5 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 156 Installation Steps (4x) (2x) (4x) 17.6 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 157 Installation Steps 46mm (1-13/16”) 1) Scribe a line on the back of the tile at the dimension shown. This will be used to align top of Rail (E). 2) Assemble Brackets (P) to Clips (Q). 3) Attach the Clip and Bracket assemblies to the existing Vertical Rails.
  • Page 158 Installation Steps FROM STEP 7 1) Rest Rail (E) onto Brackets (P). 2) Slide Blocks (A) & (B) together. 3) Insert top Set Screw (C) halfway to hold the blocks together. The remainder of the Set Screw sticking out will act as a stop to prevent the block from sliding too far behind Brackets (F) in Step 10.
  • Page 159 Installation Steps 1) Fasten Flat Head Screws (D) to Block Assembly. Repeat on opposite side. 2) Align Rail (E) to scribed line on the back of tile. 3) Fasten/tighten Set Screws (C) against Vertical Rail. Repeat on opposite side. 17.9 CUSTOMER SERVICE PHONE: 1-800-426-8562...
  • Page 160 Installation Steps 1) Pass any vertical cabling through openings before securing the Cover (N). 2) Secure Cover (N). 3) Remove Bracket (P) and Clip (Q) assemblies. 4) Assemble Wall Panel Tile. 17.10 CUSTOMER SERVICE PHONE: 1-800-426-8562...

  • Page 161: Section 18 - Quick Reference Profiles

    Section 18 - Quick Reference Profiles Trns, Tile-Glass, Ctr, Ntch Trns, Tile-Glass, Otr, Ntch Trns, Tile-Tile, 1 Slot, Ntch 118-1654 118-1655 118-1656 (See Section 8) (See Section 8) (See Section 8) Rail, Top|Starter, 3Chnl, 2.5” Rail, Top Acc Chnl, 2.5” Rail, Top|Starter, 1Chnl, 2.5”...
  • Page 162 Profiles Trns, Tile-Tile, Std Trns, Tile-Tile, 1 Slot, Std Rail Splice, Vertical 119-1443 119-1444 119-1445 (See Section 8) (See Section 8) (See Section 9) Rail, Starter w/Trim, 3Chnl, 2.5” Rail, End of Run, 3Chnl, 1.5” Compressible Seal Kit 119-1446 119-1447 119-1448 (See Section 5) (See Section 9)
  • Page 163 Profiles Cap, w/ Chnl Seal, Otr-Ctr Chnl Cap, w/ Chnl Seal, Ctr Chnl Intersection, Inline, Cv Kit, No ACO. 5” 119-1466 119-1467 119-1468 (See Section 12) (See Section 12) (See Section 9) Rail, Starter w/Trim, 3Chnl, 1.5” Trns, Tile-Tile, 2 Slot, Ntch Trns, Tile-Tile, 2 Slot, Std 119-1484 119-6870...
  • Page 164 Profiles Rail, Header, Pivot Door Rail, Jamb, Pivot Door Rail, Jamb, Sliding Door (See Section 13 or 15) (See Section 13 or 15) (See Section 16) Rail, Jamb, Sliding, GLSB Door Rail, Pocket Vert, Sliding Door Track, Sliding Door (See Section 14) (See Section 14 or 16) (See Section 14 or 16) Pivot Rail, Pivot, GLSB Door...
  • Page 165 Profiles Glazing Connector, Inline, 10mm Glazing Connector, Inline, 12mm Glazing Connector, 2 Way 90 119-1454 119-1455 119-1456 (See Section 11) (See Section 11) (See Section 11) 10mm 12mm Glazing Connector, 2 Way Vara Glazing Connector, 3 Way 90 Glazing Connector, 3 Way Brdg, 10mm 119-1457 119-1458 119-1461...
  • Page 166 For more information call 800.344.2600 or 616.393.3000. Haworth is a registered trademark of Haworth, Inc. ©Haworth, Inc. 2016 10 03 haworth.com | haworth-europe.com | haworth-asia.com...

Table of Contents
