- Page 1 DVDO-C6DL-1-G 4K Dual-Lens All-in-One Camera with HDMI/IP/USB/USB-C & AI Auto Tracking User Manual Version v1.0 DVDO │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com...
-
Page 2: Limitation Of Liability
Limitation of Liability This manual does not contain any warranties or implied warranties of any kind. The contents of this manual may be updated at any time without notice. Operating this equipment in a residential environment may cause radio interference. FCC &... -
Page 3: Class A Ite
Class A ITE Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE limits. Such equipment should not be restricted in its sale, but the following warning shall be included in the instructions for use: European Community Compliance Statement (Class A) This product is herewith confirmed to comply with the requirements set out in the Council... -
Page 4: Table Of Contents
Table of Contents Safety Precautions ......................... 1 Packing List..........................1 Connections ........................... 2 Product Description ....................... 3 Features ............................. 3 Appearance............................4 Dimensions ............................5 Wall Mount............................6 Remote Control ..........................7 AI Tracking ..........................8 Person Tracking ..........................8 Speaker Tracking .......................... -
Page 5: Safety Precautions
Safety Precautions ⚫ During the installation and operation, all electrical safety regulations of the country and region of use must be strictly observed. ⚫ Please use the 12V 5A power adapter that comes standard with this product. ⚫ Do not connect multiple devices to the same power adapter (exceeding the capacity of the adapter may generate excessive heat or cause fire). -
Page 6: Connections
Connections The cable connection contains optional configurations and for reference only. Please connect the cables according to actual needs. The recommended horizontal cascade distance is 3 meters, and the maximum number of cascades is 3 The EXT LAN port can power the extension microphones over PoE. -
Page 7: Product Description
the microphone directly towards the speaker, Product Description better sound and enhancing communication clarity, richness, and realism. Supports cascading 4.1 Features extension microphones over PoE for wider ⚫ Binocular Collaborative Design coverage of harmony distance. Featuring a new binocular collaborative design ⚫... -
Page 8: Appearance
⚫ Rich Interfaces TVs/displays, making it easier to deploy quickly in Support multiple interface types including USB crowded meeting rooms. 3.0, HDMI, RJ45, etc., the USB3.0 enabling ultra- ⚫ Plug and Play high-definition audio-video signal transmission. Connects to computers or commercial displays ⚫... -
Page 9: Dimensions
4.3 Dimensions Unit: mm... -
Page 10: Wall Mount
4.4 Wall Mount The installation diagram is for reference only. Please refer to actual product for the installation accessories. -
Page 11: Remote Control
4.5 Remote Control 8. Preset 2 Key Key Description Long press to set preset 2; Short press to call 1. Privacy Cover Switch preset 2 ⚫ When closing the video: Close the 9. Standby Key panoramic camera privacy cover and adjust Short press to enter/exit the standby mode the variable lens to the privacy position. -
Page 12: Ai Tracking
AI Tracking This camera supports four tracking modes: Person Track, Speaker Track, Auto Frame and Smart Gallery. The Speaker Track, Auto Frame and Smart Gallery function can be directly turned on or off through the remote control; Alternatively, enter the AI setting menu of the camera to select to turn on/off the AI mode. 5.1 Person Tracking ➢... -
Page 13: Auto Frame
Step 2 When the participant speaks, the Camera will automatically lock the Speaker's position and give a close-up image based on the sound source. Step 3 Press the “ ” on the remote control to disable the Speaker Tracking function. 5.3 Auto Frame ➢... -
Page 14: Smart Gallery
Step 2 When the participant's position moves, the camera will automatically adjust the image using facial recognition to achieve the best composition. Step 3 Press the “ ” on the remote control to disable the Auto Frame function. 5.4 Smart Gallery ➢... -
Page 15: Web Settings
Step 2 The meeting layout adjusts according to the number of participants, the close-up images of participants will be extracted and arranged intelligently (refer to the below diagram for specific layouts). Step 3 Press the “ ” on the remote control to disable the Smart Gallery function. Web Settings Access the camera’s IP address in the browser (default: 192.168.100.88) to pop up the login window, input the username (default: admin) and password (default: admin) and click the “Submit”... - Page 16 AI: Configure the AI modes (such as Off, Person Track, Speaker Track, Auto Frame and Smart Gallery) and check the lens calibration. Network: Configure the LAN and DSE parameters. System: Support perform the Reboot, Factory Default, Download Log, and modify the username and the password for the WEB login.
-
Page 17: Troubleshooting
Troubleshooting Image ⚫ The monitor shows no image. 1) Ensure that the camera power supply is connected, the voltage is normal, and the power indicator is always on. 2) Turn off the power switch to check that the camera is self-testing. 3) Ensure the cable of the video platform and TV is in the correct connection. - Page 18 Follow us DVDO │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com...
