- Page 1 IMU100 Insulation Monitor User Manual Version: V1.0 June 19, 2025...
-
Page 2: Standards Compliance
CET Inc. This manual may not be reproduced in whole or in part by any means without the express written permission from CET Inc. (CET). The information contained in this manual is believed to be accurate at the time of publication; however, CET assumes no responsibility for any errors which may appear here and reserves the right to make changes without notice. - Page 3 CET Inc. DANGER Failure to observe the following instructions may result in severe injury or death and/or equipment damage. ➢ Installation, operation and maintenance of the meter should only be performed by qualified, competent personnel that have the appropriate training and experience with high voltage and current devices. The meter must be installed in accordance with all local and national electrical codes.
-
Page 4: Limited Warranty
CET Inc. Limited warranty ➢ CET offers the customer a minimum of 12-month functional warranty on the meter for faulty parts or workmanship from the date of dispatch from the distributor. This warranty is on a return to factory for repair basis. ➢... -
Page 5: Table Of Contents
CET Inc. Table of Contents Chapter 1 Introduction ........................1 1.1 Overview ........................... 1 1.2 Features ............................ 1 Chapter 2 Installation ........................2 2.1 Appearance ..........................2 2.2 Installation ..........................3 2.3 Wiring Connections ........................4 Chapter 3 Front Panel ........................6 3.1 Indicators .......................... -
Page 6: Chapter 1 Introduction
When the first single-phase ground fault occurs in an IT system, the IMU100 responds promptly by issuing an alarm signal and precisely identifying the specific circuit where the fault is located. This enables maintenance personnel to locate and repair the fault quickly and accurately, ensuring a continuous and reliable power supply. -
Page 7: Chapter 2 Installation
Chapter 2 Installation Caution Installation of the IMU100 should only be performed by qualified and competent personnel who have the appropriate training and experience with high voltage and current devices. The device must be installed in accordance with all local and national electrical codes. -
Page 8: Installation
Move the installation clips at the back of the IMU100 downward to the “unlock” position ▪ Align the top of the mounting channel at the back of the IMU100 at an angle against the top of the DIN Rail as shown in the figure below ▪... -
Page 9: Wiring Connections
CET Inc. 2.3 Wiring Connections 2.3.1 Connection to a DC System Up to 12 circuits IMU100 IC100 ILU100 Monitoring Ethernet/RS-485 System Power Power Power Supply Supply Supply CANHCANL CANHCANL CANH Figure 2-3 Connection to DC System 2.3.2 Connection to an AC System... - Page 10 ▪ Communication Ports Wiring Ethernet Port: Use standard Ethernet cable. Connect to network switch, HMI, or coupled IMU100 devices as required. RS-485 Port: Terminals D+ (A) and D- (B). Use shielded twisted pair cable. Maximum 32 devices on one bus, max bus length 1200m. Ensure correct polarity. Install a 120Ω...
-
Page 11: Chapter 3 Front Panel
CET Inc. Chapter 3 Front Panel Figure 3-1 Main Display 3.1 Indicators LED Indicator Color Status Description Green Blinking Device is running normally Green Blinking Ethernet Comm. Activities Alarm1 Yellow The insulation resistance of the IT system falls below the set warning or alarm response value. -
Page 12: Display And Configuration
Earth Connection IC Data System Connection Runtime Alarm General Coupling Setup Comm. Display Others IL Settings IMU100 Modify Time Modify Password Clr SOE Logs Clr Stat Logs Maintenance Clr Runtime Clr All Data DO Operation Test Reboot Device Model Version... -
Page 13: Chapter 4 Function Description
The IMU100 supports single busbar section coupling function. The NO or NC auxiliary contact of the bus tie/coupler circuit breaker should be connected to a DI port of the IMU100 (#2). When the IMU100 detects the bus tie breaker is closed (sections coupled), it stops injecting pulses and enters standby mode. -
Page 14: Soe Log
The Monitoring System is configured to provide regular time synchronization by broadcasting time- sync packets over the Ethernet or RS-485 of the IMU100. Further, the IMU100 is equipped with a battery-backed real-time clock. If the supply power is lost or removed, the internal back-up battery... -
Page 15: Chapter 5 Technical Specification
CET Inc. Chapter 5 Technical Specification IT System Nominal Voltage Un 0~690V 3AC/AC, 0~1000V DC (AC) Nominal Frequency fn 50Hz/60Hz Power Supply Standard 95~250V AC/DC, 47~440Hz Burden <7W Inputs and Outputs Digital Input (DI) 2 channels, 24VDC internally powered DO1, DO2: 8A @ 250VAC or 24VDC, Normally Open (NO) Digital Output (DO) contact Communications... -
Page 16: Chapter 6 Standards Compliance
CET Inc. Chapter 6 Standards Compliance IEC 61557-8: 2007 Electrical safety in low-voltage distribution systems up to 1000 Va.c. and 1500 Vd.c.- Equipment for testing, measuring or monitoring of protective measures - Part 8: Insulation monitoring devices for IT systems IEC 61557-9: 2009 Electrical safety in low-voltage distribution systems up to 1000 Va.c. -
Page 17: Chapter 7 Contact Us
CET Inc. Chapter 7 Contact Us CET Electric Technology Inc. Address: Floor 33-35, Building #6, Shenzhen International Innovation Valley, Dashi First Road, Nanshan District, Shenzhen, Guangdong, P.R. China 518055 sales@cet-global.com W: www.cet-global.com...
