- Page 1 NOTICE D’INSTALLATION ET D’EMPLOI ● INSTRUCTION MANUAL FOR INSTALLATION AND USE ● FRITEUSE ELECTRIQUES 16L ELECTRIC FRYER 16L MOD. ACFE16L...
- Page 2 INSTRUCTION D’EMPLOI POUR LA FRITEUSE Precaution d’emploi Lire attentivement les instructions contenues dans ce manuel Conserver ce manuel pour que les futurs utilisateurs puissent le consulter aisément. Avant de brancher l’appareil, controler que les données eportées sur la plaquette technique (figure 1) correspondent à...
- Page 3 Problemes de fonctionnement 6.1 Vérifier que les conditions suivantes soient remplies : • Qu’il y ait de la tension dans le réseau ; • Que le pin ( fig.2,C )soit bien rentré dans la tete comme expliqué au point 2.3 ; •...
- Page 4 Branchement eléctric - Boite antérieur A = Sélecteur B = Télérupteur C = Thermostat de sécurité D = Thermostat de travail E = Temoin lumineux F = Temoin lumineux - Boite postérieur G = Micro-interrupteur H = Resistence...
- Page 5 INSTRUCTIONS FOR INSTALLATION AND USE General Instructions Read carefully the instructions given in this booklet. Keep this booklet so that the operators can refer to it as necessary. Before connecting the appliance make sure that the data shown on the technical plate (fig.1), corresponds with that of the mains power supply.
- Page 6 Functioning problems 6.1 Check the following: ● That the mains power supply is on; That the pin ( fig.2, D ) is well inserted in the head as explained in point 2.3; ● ● That the safety thermostat ( fig.3,4, B ) is in the proper position (red pin not lowered). The safety thermostat comes into action when the temperature of the oil exceeds 230°C as a result of the non-functioning of the working thermostat ( fig.4, F ).
-
Page 7: Electric Connection
Electric connection: - Front panel A = Power selector B = Contactor C = Safety thermostat D = Working thermostat E = Start up light F = Thermostat light - Back panel G = Micro-switch H = Resistance... - Page 9 El suscrito, nombrado representante legal de la Sociedad Constructora, declara que los productos indicados a continuaciòn: APPARECCHIATURE ELETTRICHE ELECTRIC EQUIPMENTS APPAREILLES ELECTRIQUES ELEKTRO-GERÄTE EQUIPO ELECTRICA Mod. ACFE16L • Sono conformi a quanto prescritto dalle seguenti norme: • Are in compliance with the following directives: • Sont conformes aux prescriptions des directives suivantes: •...
