ROTARY-5

5 Channel Rotary Encoder to

Output Pulse Converter

User Manual

Table of Contents

Need help?

Do you have a question about the ROTARY-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hagstrom Electronics ROTARY-5

Page 1 ROTARY-5 5 Channel Rotary Encoder to Output Pulse Converter User Manual...
Page 2 HAGSTROM ELECTRONICS, INC. is pleased that you have selected this product for your application. The ROTARY-5 unit is configurable in a variety of ways in order to meet your specific requirements. Please take a few minutes to read this manual before using your ROTARY-5.
Page 3: Table Of Contents
CONTENTS Introduction to the ROTARY-5 ROTARY-5 Connections Option Jumper Settings Interfacing Rotary Encoders to the ROTARY-5 Unit Setup Appendix A - ROTARY-5 Specifications 9-10 Appendix B - Hagstrom Electronics, Inc. 11-12 Keyboard Encoder Power Locations Accessories...
Page 4: Introduction To The Rotary-5
Note: If the ROTARY-5 is powered by an external power supply, - the logic ground on the ROTARY-5 must be tied to the logic ground of the keyboard encoder, - do not tie the +5V DC on the ROTARY-5 to the +5V DC on the keyboard encoder. Supported Keyboard Encoders The ROTARY-5 is suitable for use with all standard Hagstrom Electronics, Inc.
Page 5: Rotary-5 Connections
These connectors are electrically connected, identical in pinout, and either header can be used for power, options, or daisy chaining to another Rotary-5 module. Note: In the case of daisy chaining, power supplied at one module will be propagated to the others in the same daisy chain.
Page 6 KE-USB108 User Manual for a suitable logic ground location. Note: When using an external supply to power the ROTARY-5 do not tie the +5V DC on the ROTARY-5 to the +5V DC on the keyboard encoder. Doing so might damage the...
Page 7: Option Jumper Settings
Option Jumper Settings The ROTARY-5 module features two option jumper settings for each of the five Rotary Switch Input locations. These jumpers affect how each rotary input is handled. The Option Jumpers for each Rotary Switch Input may be adjusted independently. This feature allows for customizing the response sent by each rotary input based on the type of switch and the desired output action.
Page 8: Interfacing Rotary Encoders To The Rotary-5
The examples provided below demonstrate the connection to the rotary encoder. To connect an optical rotary encoder Optical Rotary Encoder Hookup: to the ROTARY-5, use the arrangement shown below. The 5V from the ROTARY-5 is used to power the optical encoder. +5 V Signal Line...
Page 9: Unit Setup
11-12 for the keyboard encoder power locations. Note: If power is supplied from an external power source, be sure that the logic ground of the ROTARY-5 is connected to the logic ground of the keyboard encoder. With power on the 5V supply off, connect the power supply positive and ground to the corresponding ROTARY-5 connections.
Page 10: Appendix A: Rotary-5 Specifi Cations
Appendix A: ROTARY-5 Speciﬁ cations 4.050 .725 2.175 .250 .125 .150 Dia. (4) Note: Dimensions are in inches. Operating Voltage 5 Volts DC +/- 5% 30 ma Typical at 5.00 V Operating Current 0 to 70 Degrees C Operating Temp.
Page 11 Rotary Switch Outputs: The ROTARY-5 outputs are high logic level when idle, pulsed low for detected movement. 50ms 50ms 50ms The ROTARY-5 outputs use 50msec on/off when the pulse speed option jumper on the power header is open. 18ms 18ms 18ms The ROTARY-5 outputs use 18msec on/off when the pulse speed option jumper on the power header is On .
Page 12: Appendix B: Hagstrom Electronics, Inc. Keyboard Encoder Power Locations
Note: The ROTARY-5 must be externally powered when used with keyboard encoder model KE-USB108. Note: Only connect the ROTARY-5 to these locations if a stand-alone power supply is not in use. Damage may occur if an external power source and the keyboard encoder power are connected at the same time.
Page 13 KE24 Connection Points: Ground +5 V LP24 Connection Points: Ground +5 V KE18 Connection Points: +5 V Ground...
Page 14: Accessories
5V/2A regulated DC. Use to supply power to the ROTARY-5. MTA100-5-36-FF Cable Set 36 inches long. MTA style headers. May be used to “daisy-chain” multiple ROTARY-5 units. KE-232-IF Interface Cable (for custom Rotary-5 units only) 4 feet. Use to connect the ROTARY-5 logic level to the PC RS-232 port.
Page 15: Warranty
Depending on the state in which you live, you may have additional rights. Great care has been taken during the assembly, testing, and burn-in of your ROTARY-5 to ensure its performance. If you have any questions, please send us an email.
