- Page 1 MIG-V12 Pro User manual V1.0 △ Before using the 4K video switcher, please read this manual carefully and keep it for future reference. Document version: V1.0 document release date: March 12th,2025. MIG-V12 Pro...
-
Page 2: Revision History
Statement Without the written permission of Magnimage, any organization or individuals can not reproduce, copy, transcribe or translate part or all of the contents of this Manual without authorization. The Manual can not be distributed as a commodity or used for any commercial or profit-making purposes in any form or by any means (electronic, mechanical, photocopying, recording or other possible means). -
Page 3: Table Of Contents
CONTENT BRIEF INTRODUCTION ..................1 ..........................1 RADEMARK REDIT ..........................1 BOUT OFTWARE ..........................2 RODUCT EATURES ............................. 3 AFETY OTICE FUNCTION INTRODUCTION ................. 4 .............................. 4 UMMARY TECHNICAL SPECIFICATIONS ..............5 INTRODUCTION TO FRONT AND REAR PANELS ........6 ............................6 RONT ANEL ........................ -
Page 4: Brief Introduction
Brief Introduction Thank you for purchasing our MIG-V12 Pro video switcher. We hope you can fully enjoy the excellent performance of this product. This video switcher is designed in accordance with international and industry standards, but improper operation may still cause personal injury and property damage. -
Page 5: Product Features
Product Features 8 *4K main output and 4*4K AUX output. 1 Multi-window preview is supported, and the preview interface can be customized. 1 HDMI output, can be used for console real-time display or AUX output. 16 mixed matrix input, a variety of 4K input cards can be selected. ... -
Page 6: Safety Notice
Safety Notice The input voltage range of this product's power supply is 100~240VAC, 50/60Hz. Please use the correct power supply. When you want to connect or remove any signal line or control line, make sure that all power lines have been unplugged in advance. When you want to add hardware devices to this product or remove hardware devices ... -
Page 7: Function Introduction
4K input modules, including 4Kx2K/60Hz RGB4:4:4 input/output, enabling real-time preview of both input and output images. MIG-V12 Pro video switch supports a variety of signal source input: 12G-SDI, DP1.2, HDMI2.0, supports 4Kx2K/60Hz input, can realize EDID management of the input signal, can be expanded to 4 input boards at most, and can realize synchronous locking of the input signal, ensuring synchronous output of the signal. -
Page 8: Technical Specifications
Technical Specifications Input Information Input Board Type Port Quantity Resolution Specifications 4DP/4HDMI DP1.2/HDMI2.0 3840x2160/60Hz, 7680x1080/60Hz and customized 2DP/2HDMI+2SDI DP1.2/HDMI2.0 2/2+2 3840x2160/60Hz, 7680x1080/60Hz and customized / 4K +12G SDI SDI backward compatibility 4SDI 12G SDI 3840x2160/60Hz downward compatibility Output Information Board Interface Port Quantity... -
Page 9: Introduction To Front And Rear Panels
Introduction to Front and Rear Panels Front Panel POWER: Power standby button. Touch screen: display the current working status of the machine, can browse input information, firmware version, etc.. MENU: You can browse or set the menu content, including confirmation key, return key and shortcut knob. -
Page 10: Back Panel Introduction
Back Panel Introduction Input area, 4 input cards, optional for a variety of 4K input interfaces. Redundant power input port. Output area, 8 HDMI2.0 & 8 group OPT port output. MULTI-VIEW: Multiple preview window ports. AUX/MIONITOR: HDMI monitor port and AUX4 mode are selected from two options AUX1-AUX3: 3*AUX output ports. -
Page 11: Mig-V12 Pro Board Introduction
MIG-V12 Pro Board Introduction The MIG-V12 Pro video switcher has a rich selection of board resources. The control board is the standard resource, which is the core component of the whole device. The output board is the standard resource, and the input board is optional resources, which can be matched at will according to actual needs. -
Page 12: Output Board
Compatible with 12G-SDI and below; interface FULL SIZE 20 Needle, HDMI TYPE-A and BNC/mother interface specification MIG-V12 Pro-IN SDI (12G-SDI * 4 input card) Signal 12G SDI, supporting 3840x2160@60Hz downward compatibility. Specifications Interface BNC / Mother port... -
Page 13: Use Menu
Use Menu The menu system of the product allows for convenient and intuitive settings of the MIG-V12 Pro video switcher to meet user requirements. The MIG-V12 Pro video switcher features a high-brightness, high-contrast touchscreen LCD screen that displays the entire user menu. - Page 14 If the power line is connected and the power supply is normal, the power icon will Supply be displayed in green; if the power line is not connected or the power supply is not powered, it will be displayed in red. IP Address Displays the current IP address of MIG-V12 Pro video switcher.
-
Page 15: Main Menu
Main Menu In the non-menu state, press the "OK" key, the menu system will enter the main menu state, and the LCD screen will display as shown in the figure below: There is one main menu item. Select the four menu titles listed above by touch or knob. After selection, press the "OK"... -
Page 16: Factory Reset
Gateway The default machine gateway is 192.168.1.1, which can be customized Communication according to user requirements. Settings MIG-V12 Pro video switch MAC address. Address Edit To edit the IP address and gateway, you need to operate with a knob. Reset Restore the network Settings to their default state. -
Page 17: Language
LANGUAGE： English Set the display language of the menu system to English Chinese Simplified Set the display language of the menu system to Simplified Chinese Traditional Chinese Set the display language of the menu system to Traditional Chinese... -
Page 18: Warranty Statement
Warranty Statement Machine Warranty Period 24 months from the date of purchase invoice. If the user loses the purchase invoice, the warranty starts on the 60 days after the production date of the product. Non-warranty Machine water immersion, collision, stains or surface scratches caused by other ...
