Giant STP 0 Datasheet

94
STP 0

Specifications

SIZES Regular, Large
COLORS Black/Gold - Metallic
FRAME ALUXX SL-Grade Aluminum
Marzocchi DJ1 w/ 20mm Thru Axle,
FORK
100mm travel
SHOCK N/A
HANDLEBAR Truvativ Holzfeller, 31.8mm
STEM Truvativ Holzfeller
SEATPOST Giant Pivotal, 30.9
SADDLE Giant Pivotal
PEDALS Alloy Platform, sealed
SHIFTERS Shimano SLX
FRONT DERAILLEUR MRP Mini G2 guide, Custom for Giant
REAR DERAILLEUR Shimano Deore XT shadow, top normal
BRAKES Avid Juicy 3 160F/140R
BRAKE LEVERS
Avid Juicy 3
CASSETTE SRAM PG950 12x26, 9-speed
CHAIN Shimano HG-53
CRANKSET Truvativ Holzfeller, 36T
BOTTOM BRACKET Truvativ Howitzer
RIMS Mavix EX325
[F] Giant Tracker w/ 20mm Axle, [R]
HUBS
Formula, 32h
SPOKES Stainless Steel
TIRES Maxxis Holy Roller, 26x2.4

EXTRAS

Specifications and availability subject to change without notice.
fiND A PLAYGROUND OF POSSIBILITY IN
EVERYDAY STREETSCAPES. SHRED DIRT, VERT
AND EVERYTHING IN BETWEEN ON STP .

Frame Technology

Giant rider Jeff Lenosky, aka the Godfather of Urban Freeride, chooses STP for the gravity-defying
tricks that earned him the rep. With butted ALUXX SL alloy tubing, tight geometry, a low saddle
height and taller front end, it's just what Jeff needs to stick every landing.

Key Upgrades (over STP 1)

— Marzocchi Dirt Jumper 1, 100mm suspension fork
— Truvativ Holzfeller crankset, Howitzer bottom bracket
— Shimano SLX rear trigger, Shimano Deore XT rear derailleur
— Mavic EX325 rim/Giant Tracker (f), Formula (r) hub wheelset

frame geometry

Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
Regular 334650 69.0 74.0
Large 334651 69.0 74.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
22.0 4.6 16.0 41.6
23.0 5.0 16.0 42.6
Standover
Height***
inches
30.8
30.9
