  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. CHAMPION WCM28 Owner's Manual Shop genuine replacement parts for CHAMPION WCM28 Find Your CHAMPION Evaporative Cooler Parts - Select From 82 Models -------- Manual continues below part list --------...
  • Page 2 TOP FOR: WC/WCM/WM28 & MMB10 324102-203 LOUVER ASSEMBLY (ASPEN PAD) - BACK - FOR 110088 PAD (ASPEN) - BACK - FOR: WC/WM/WCM28 (2 3PW-2 PAD RETAINER - BACK - FOR: CPH2500 & WC/ 110087 PAD (ASPEN) - SIDE - FOR: WC/WM/WCM28 (1...
  • Page 3 3PW-1 PAD RETAINER - SIDE - FOR: CPH2500 & WC/...

  • Page 4: Operation

    C H A M P I O N • E S S I C K Window Evaporative Cooler Manual Models WCM28 N28W Serial # Número De Serie Read Carefully All Of This Manual Before Installing The Unit Lea Con Cuidado Todo Este Manual Antes...

  • Page 5: Cooler Installation

    Cooler Installation be broken off. Apply pressure on the edge of the panel that extends over the edge of the surface and break off unwanted piece. Installing House Legs • Install fi ll-in panels. Place one window fi ll-in panel on each side •...

  • Page 6: Wiring Diagram

    • Clean pump. Cleaning the pump is necessary once a year at • Cover unit. To protect the life of the fi nish, a cover for the unit is start-up. For your safety, turn unit off and unplug from power suggested in extended periods of non use.

  • Page 7: General Specifi Cations / Especifi Caciones Generales

    Height Width Depth Width Height Seco Lleno Altura Anchura Profundidad Anchura Altura WCM28, N28W 21 1/4 Electrical Specifi cations / Especifi caciones Eléctricas Model No. Volts Motor Speed Motor Amperage Pump Amperage Modelo Voltios Velocidad del Motor Amperaje Del Motor...

  • Page 8: Limited Warranty

    Parts Drawing / Dibujo De Piezas Register your product online at www.championcooler.com/eac/onlineregistration-eac.htm Limited Warranty This warranty is extended to the original purchaser of an evaporative cooler installed and used under normal conditions. It does not cover damages incurred through accident, neglect, or abuse by the owner.
