Page 1 INSTALLATION INSTRUCTIONS Repeater: D5-22 safe smart strong IM-ANC-DX102-EN-v02 Language: English (original)
Page 3: Table Of Contents
Installation instructions│ D5│ CHAPTER 1: INTRODUCTION 1.1 About this document 1.2 About D5 repeater & active antenna CHAPTER 2: SAFETY 2.1 Warnings & restrictions CHAPTER 3: FUNCTIONAL SAFETY CHAPTER 4: TECHNICAL DATA 4.1 Current consumption CHAPTER 4: SYSTEM RADIO FREQUENCY CHAPTER 5: PRODUCT GENERAL DESCRIPTION 5.1 Repeater description 5.2 M12 connector 5.3 Power sources...
Page 4 Installation instructions│ D5│ ANNEX A: DETAILED INFORMATION ABOUT REPEATERS AND REPEATER TECHNOLOGY A.1 Concepts used in this document A.2 How to arrange repeaters physically ANNEX B: INDEX IM-ANC-DX102-EN-v02...
Page 5: Chapter 1: Introduction
Tele Radio AB remote controls are often built into wider applications. It is the responsibility of any such users or integrators to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use.
Page 6 Tele Radio AB Installation instructions do not include or address the specific instructions and safety warnings of the end product manufacturer. Tele Radio AB products are covered by a warranty against material, construction, or manufacturing faults. See "Chapter 8: Warranty, service, repairs, and maintenance".
Page 7: About This Document
1 . 1 A b o u t t h i s d o c u m e n t Before installing or operating the product, read the corresponding documentation carefully. Tele Radio AB's product range is composed of transmitters, receivers, and accessories intended for use together as a system. These Installation instructions cover main technical specifications, standard installation, configuration and operating instructions, as well as general troubleshooting.
Page 8: About D5 Repeater & Active Antenna
Puma and Panther systems to optimize data transmission. D5-22 is a combined repeater / active antenna that can be used to extend transmissions so that the signal can cover greater distances or be received on the other side of an obstruction.
Page 9: Chapter 2: Safety
Installation instructions│ D5│ Chapter 2: Safety CHAPTER 2: SAFETY This product is to be used together with a Tele Radio AB radio system including one or more transmitters and receivers. 2 . 1 W a r n i n g s & r e s t r i c t i o n s...
Page 10 Installation instructions│ D5│ Chapter 2: Safety RISK OF UNINTENDED EQUIPMENT OPERATION Only transmitters that are intended for use should be registered in the receiver. Failure to follow these instructions could result in death, serious injury, or equipment damage. RISK OF ELECTRIC SHOCK The repeater must only be opened by qualified installers or authorized personnel.
Page 11 Installation instructions│ D5│ Chapter 2: Safety Only qualified personnel should be permitted to access the transmitter and operate the equipment. Make sure that the user satisfies the age requirements in your country for operating the equipment. Make sure that the user is not under the influence of drugs, alcohol and medications.
Page 12: Chapter 3: Functional Safety
(safety-related stop function): R20, R21, T24, T26, T28 (Puma) R15, R23, T19, T25, T27 (Panther) IMPORTANT! Adding one or more repeater(s) to a Tele Radio AB radio system (receiver + transmitter) does not modify the original safety level achieved by the system.
Page 13: Chapter 4: Technical Data
Installation instructions│ D5│ Chapter 4: Technical data CHAPTER 4: TECHNICAL DATA REPEATER D5-22 Power supply 12 … 24 VDC (-50% … +35%) Current Max. 600 mA (for more details, see "4.1 Current consumption consumption ") )Connector M12 5-pin female Frequency 2405 – 2480 MHz...
Page 14: Current Consumption
4 . 1 C u r r e n t c o n s u m p t i o n 4 . 1 . 1 E X T E R N A L P O W E R S O U R C E Input power D5-22 Min.* Max.1** Max.2***...
Page 15: Chapter 4: System Radio Frequency
Installation instructions│ D5│ Chapter 4: System radio frequency CHAPTER 4: SYSTEM RADIO FREQUENCY D5-22 repeaters operate on the frequency band 2.4 GHz. The frequency band has been divided into 16 channels (11 to 26). Once the channel has been selected on the transmitter, the receivers and repeaters will automatically detect and switch to the same channel.
Page 16: Chapter 5: Product General Description
Installation instructions│ D5│ Chapter 5: Product general description CHAPTER 5: PRODUCT GENERAL DESCRIPTION NOTE: The pictures shown in this chapter are for illustrative purposes only. Depending on the configuration, the actual product appearance may differ from the basic model used for reference. 5 .
Page 17 Installation instructions│ D5│ Chapter 5: Product general description 5 . 1 . 1 L E D I N D I C A T O R S High power LED Battery LEDs High power LED The repeater is equipped with two high power LEDs and two dual-color LEDs. H i g h p o w e r L E D s The high power LEDs are located one on each side of the repeater.
Page 18 Installation instructions│ D5│ Chapter 5: Product general description 5 . 1 . 2 C A P S E N S O R B U T T O N A C T I O N S The repeater is equipped with one Cap sensor button with two possible user interfaces allowing for different actions, e.g.
Page 19: M12 Connector
The two replaceable, rechargeable lithium-ion batteries (hot swappable). An external charger/ power source. If D5-22 is powered by an external power supply, the batteries will be charged one at a time. If the two batteries are empty, one battery will be fully charged before starting to charge the other battery.
Page 20: Mounting Dimensions
Installation instructions│ D5│ Chapter 5: Product general description 5 . 4 M o u n t i n g d i m e n s i o n s IM-ANC-DX102-EN-v02...
Page 21 Installation instructions│ D5│ Chapter 5: Product general description 5 . 4 . 1 P R E C A U T I O N S F O R T H E I N S T A L L A T I O N O F T H E R E P E A T E R / A C T I V E A N T E N N A Before connecting the equipment, make sure that the power supply is switched off.
Page 22: Chapter 6: Status And Error Indications
Installation instructions│ D5│ Chapter 6: Status and error indications CHAPTER 6: STATUS AND ERROR INDICATIONS High power LED Battery LEDs High power LED Repeater status and errors are indicated with the two high power LEDs and the battery LEDs. 6 . 1 I n d i c a t i o n w h e n i n r a d i o s e s s i o n When the repeater is in session, the high power LEDs flash once, very briefly, for each packet received/sent.
Page 23: Charging And Battery Led Indications
Installation instructions│ D5│ Chapter 6: Status and error indications Designation Description High power LED Comments indication 'Erase Something was Ramping from highest Repeated three success' successfully erased to lowest intensity times. from settings during one second, and letting it off for one second.
Page 24: Fatal Start-Up Error Indications
Installation instructions│ D5│ Chapter 6: Status and error indications LED color On Flashing Indication Orange fast Charging overload detected. NOTE: Could indicate that the battery consumes too much current during charging. This could be caused by water or something else that is in contact with the battery connections in the unit.
Page 25: Chapter 7: Operation
Installation instructions│ D5│ Chapter 7: Operation CHAPTER 7: OPERATION 7 . 1 G e n e r a l i n f o r m a t i o n To control a receiver, the transmitter must be registered and logged in to the receiver.
Page 26 Installation instructions│ D5│ Chapter 7: Operation 7 . 2 . 2 R E G I S T E R / E R A S E P U M A R E C E I V E R S I N T H E R E P E A T E R NOTE: Only for Puma systems.
Page 27 Installation instructions│ D5│ Chapter 7: Operation 7 . 2 . 3 R E G I S T E R / E R A S E P A N T H E R T R A N S M I T T E R S I N T H E R E P E A T E R NOTE: Only for Panther systems.
Page 28: Replace Transmitters In The Repeater
Installation instructions│ D5│ Chapter 7: Operation 7 . 3 R e p l a c e t r a n s m i t t e r s i n t h e r e p e a t e r NOTE: Only for Panther systems.
Page 29 Installation instructions│ D5│ Chapter 7: Operation Once the repeater has entered the configuration mode via the Function button, it will remain in this mode for 30 seconds, or until a transmitter starts sending configuration packets, and if so, it will remain in configuration mode indefinitely or until the transmitter terminates the configuration session.
Page 30: Chapter 7: Battery
Installation instructions│ D5│ Chapter 7: Battery CHAPTER 7: BATTERY 7 . 6 B a t t e r y p r e c a u t i o n s Carefully read the following safety instructions and warnings before using or disposing of the batteries.
Page 31: Battery Information
NOTE: Only batteries approved by Tele Radio AB should be used in D5-22 repeaters. D5-22 repeaters are equipped with two batteries to allow hot swap: one battery is used at a time, which allows to replace a low level battery during operation. The...
Page 32: Charge The Battery In The Table Charger
NOTE: When approximately 10 % of a battery capacity remains, the corresponding battery LED will light red. 1. Remove the battery from its compartment and place it in the Tele Radio AB battery charger. 2. The charger's LED lights red while the battery is charging.
Page 33: Chapter 8: Warranty, Service, Repairs, And Maintenance
Tele Radio AB products are covered by a warranty against material, construction and manufacturing faults. During the warranty period, Tele Radio AB may replace the product or faulty parts. Work under warranty must be performed by Tele Radio AB or by an authorized service center specified by Tele Radio AB.
Page 34: Chapter 9: Regulatory Information
D5-22 9 . 1 . 1 C E M A R K I N G Hereby, Tele Radio AB, declares that the radio equipment type(s) listed above is/ are in compliance with the Radio Equipment Directive 2014/53/EU. The latest version of the complete EU Declaration of Conformity is available on the Tele Radio AB website, www.tele-radio.com.
Page 35 Installation instructions│ D5│ Chapter 9: Regulatory information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 36 Installation instructions│ D5│ Chapter 9: Regulatory information this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Gain of antenna: 3.0 dBi max. Type of antenna: 50 ohm, Omni-directional Le présent émetteur radio a été...
Page 37: Annex A: Detailed Information About Repeaters And Repeater Technology
Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology ANNEX A: DETAILED INFORMATION ABOUT REPEATERS AND REPEATER TECHNOLOGY The diagrams used in this document are for illustrative purposes only. A.1 Concepts used in this document A.2 How to arrange repeaters physically A .
Page 38 Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology In the diagram below, the radio coverage is just enough to allow the two units to communicate. In the following diagram however, the two units are unable to communicate, the red area does include the receiver, and vice versa.
Page 39 Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology 1. Each repeater will repeat packets in its own timeslot, and only in this particular timeslot. 2. Each repeater must have a unique timeslot. 3. The closer a repeaters is to the transmitter, the earlier its timeslot will be available and the closer a repeater is to the receiver, the later its timeslot will be available (counted from when the transmitter sends its packet).
Page 40 Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology C o v e r i n g f o u r s h o r t e r l i n e s f r o m a r e c e i v e r p o s i t i o n e d i n t h e m i d d l e C o v e r i n g a l i n e w i t h d i f f e r e n t t r a n s m i t t e r p o s i t i o n s Good as well.
Page 41 Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology C o v e r i n g a r e a s w i t h d i f f e r e n t T r a n s m i t t e r p o s i t i o n s A .
Page 42 Installation instructions│ D5│ Annex A: Detailed information about repeaters and repeater technology In this arrangement, the packet will be repeated by repeater 3, 4, 5, 6 and 7, but not by repeaters 0, 1 and 2 so nothing will reach the receiver. NOTE: If the receiver is also moving around, things become more difficult.
Page 43: Annex B: Index
Installation instructions│ D5│ Annex B: Index ANNEX B: INDEX AC adapter Active antenna Antenna Battery Charge Battery LEDs Battery pack Battery precautions Handling Storage Cap sensor button CHARGERS Charging and battery LED indications Charging temperature 13, 31 Configuration mode Current consumption Description Disposal Erase all...
Page 44 Installation instructions│ D5│ Annex B: Index Failure Fatal errors FCC statement FCC/IC labels Function button High power LEDs IC Statement Installation precausions IP code LED indicator LED indicators M12 connector pinout M245060 M769746 M769755 M769780 Maintenance Mounting dimensions Repeater Operating temperature Operation outcome indications IM-ANC-DX102-EN-v02...
Page 45 Installation instructions│ D5│ Annex B: Index Power sources Power supply Radio communication Radio frequency output power Register/erase receivers Register/erase transmitters Registration mode Registry management mode Repeater Replace transmitters Status indications Storage temperature Battery Store success Technical data Warnings & restrictions Installation and commission Maintenance Operation...
Page 46 safe smart strong These Installation instructions are subject to change without prior notice. Download the latest Installation instructions from www.tele-radio.com .
