Summary of Contents for SUNWAYTECH NSFL100D10
-
Page 2: Table Of Contents
Contents 1.Introduction 2.Reference Standards and Specifications 3.Product Features 4. Product Parameters 4 5.Product Description 5 6. Common Alarms and Troubleshooting 9 7. Battery Maintenance 8. Battery Usage Precautions 12... -
Page 3: Introduction
1.Introduction This product is a household type lithium iron phosphate energy storage battery specifically designed for the household storage market. This product is widely used in household energy storage markets in various regions around the world for its integrated, miniaturized, lightweight, intelligent, long cycle and other design features, simple and beautiful shape, safe and reliable products. -
Page 4: Product Parameters
4. Product Parameters Battery cells Internal Nominal Model Capacity resistant Connection voltage standard NSFL100D10 100A 3.2V ≥0.5mΩ 60S1P NSFK100D10 100A 3.2V ≥0.5mΩ 30S1P Product Minimum Maximum Discharge Nominal Nominal Charging Working capacity charging cut-off capacity voltage current current (0.2C5A） voltage... -
Page 5: Product Description
5.Product Description... - Page 6 Main control box Connect terminals(B+/B-) Battery pack 8-cores aviation plug Power switch Handle Display screen Output terminals(P+/P-) RS232 host computer port Battery rack steering wheel RS485 communication port (1). Battery and inverter connection Selection of connecting wires between batteries and inverters...
- Page 7 (2). Battery Communication Description ①．Communication Connect between battery packs The upper battery pack number corresponds to the lower battery pack number. For example,The upper battery pack number 1-1 corresponds to the lower battery pack number1-1. ②. Communication connect between battery pack and inverter (3).
- Page 8 (5). Buzzer Action Description In case of fault, Long beep and automatic shutdown; ● In case of protection,Long beep until recovery; ● In case of alarm,Long beep until recovery; ● The buzzer function can be enabled or disabled by the host computer, and is disabled by factory ●...
-
Page 9: Common Alarms And Troubleshooting
6. Common Alarms and Troubleshooting Cannot start, fault Shut down, restart, and press the reset button to restore. indicator light is on Screen Check the battery operation indicator and the power indicator. If the battery does not works properly, the screen is burned out or the wiring is disconnected. light up Battery Check whether the inverter charging setting cut-off SOC is set to 100%, check... - Page 10 ⑤ To ensure transportation safety, the lithium battery's power level is about 30% when it leaves the factory. Due to battery self-discharge during transportation and storage process, the battery level may be low or even zero when used for the first time. This is normal. Don't worry, just recharge according to the charging instructions.
- Page 11 otherwise the battery may be completely discharged and cause irreversible damage. ④ The most suitable storage capacity of the battery is 30%. If the battery is stored at a capacity lower than 10% or higher than 50% for a long time, it will cause irreversible capacity decay. ⑤...
-
Page 12: Battery Usage Precautions
8. Battery Usage Precautions To prevent battery leakage, abnormal heating, fire, performance degradation, explosion and other accidents, please use the battery correctly according to the following specifications. NPP is not responsible for any accidents caused by failure to operate according to the provisions of this manual.
