SERVO MOTOR
INDUSTRIAL AND COMMERCIAL
ROLLER DOOR OPERATOR
KG90SF/KG100SF
Installation and Users Manual
WARNING
ONLY QUALIFIED AND EXPERIENCED
TECHNICIANS SHOULD ATTEMPT
INSTALLATION OR SERVICE TO THIS UNIT,
OTHERWISE, SERIOUS PERSONAL INJURY,
DEATH, OR PROPERTY DAMAGE MAY OCCUR.
SAVE THESE INSTRUCTIONS.
Total Door Automation (Australia) Pty Ltd
www.totaldoorautomation.com.au
sales@totaldoorautomation.com.au
Technical Support 1800 AUSTDA (1800 287 832)
S0110
Advertisement
Table of Contents
Summary of Contents for TdA KG90SF
- Page 1 SERVO MOTOR INDUSTRIAL AND COMMERCIAL ROLLER DOOR OPERATOR KG90SF/KG100SF Installation and Users Manual WARNING ONLY QUALIFIED AND EXPERIENCED TECHNICIANS SHOULD ATTEMPT INSTALLATION OR SERVICE TO THIS UNIT, OTHERWISE, SERIOUS PERSONAL INJURY, DEATH, OR PROPERTY DAMAGE MAY OCCUR. SAVE THESE INSTRUCTIONS.
-
Page 2: Table Of Contents
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL TABLE OF CONTENTS Safety Instructions Main Features Operator Dimensions Technical Parameters Tools required Installation Manual Operation and Release Function Wiring and Adjusting ● Control box ● Control board ● Terminal block ● Terminal function description ●... -
Page 3: Safety Instructions
SERVO motor, high efficiency, more powerful, runs smoothly. Soft start and soft stop. High-precision encoder, easy to set. LED display. Adjustable running speed and auto-close time. Over-load protection. Chain box can be rotated 360°. 3. Operator Dimensions Fig.1-1 KG90SF... -
Page 4: Technical Parameters
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Fig.1-2 KG100SF 4. Technical Parameters Model KG90SF KG100SF Power supply AC240V, 50Hz AC240V, 50Hz Max. output torque 90N.m 100N.m 40rpm 18rpm Rated output shaft rotation speed Motor power 750W 750W Door area ≤35m²... - Page 5 SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL On-shaft mounting Door operator Wall bracket Screw Expansion Bolt Spacer ring Door shaft Fig.2 Mounting via chain drive Sprocket wheel Door shaft Chain Sprocket Connecting shaft Bracket Door operator Fig.3 Door adjustment Adjust the torsion spring of the door before installing the door opener.
- Page 6 SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL The 1st spacer ring Screw Gate operator Wall bracket Bolt Expansion bolt Screw 6 5 4 The 2nd spacer ring Fig.5 Fig.6 On-shaft mounting Slot the door operator onto the door shaft, check the mounting position of the wall bracket, ...
- Page 7 SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL 1 2 3 4 Base Terminal block Hexagon socket screw Limit switch Plastic cover Screw Fig.7 R ight side Left side Fig.8 Information: The optional accessories are not included in the standard package, they can be purchased separately.
-
Page 8: Manual Operation And Release Function
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL 7. Manual Operation and Release Function Manual operation The operator is equipped with a manual chain, which is used for lifting/lowing of the door in case of power cut. Operation with hand chain In case of power failure, move the door in the OPEN or CLOSE direction by pulling on the hand chain. -
Page 9: Wiring And Adjusting
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL 8. Wiring and adjusting Before carry out any wiring work, it is essential to disconnect the control unit from the mains supply. Locate control unit: within sight of door but away from all moving parts of the door and at a ... -
Page 10: Control Board
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Control board 48 47 46 45 44 43 42 41 40 39 38 37 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 （AC220) -
Page 11: Terminal Block
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Terminal block Emergenc stop button Live wire Neutral wire Ground Common CHAIN Hand chain WICKET Wicket door Thermal protection Common Fire Interlock input 12V power Common STOP CLOSE OPEN Common Loop detector or ladar Infrared photocell or safety edge Keypad Ground... -
Page 12: Terminal Function Description
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Spare terminal COM4 Electromagnet Common Electromagnet N.C. Electromagnet N.O. COM3 Close limit common C(O) Close limit output COM2 Open limit common O(O) Open limit output COM1 Common Red light output Green light output Terminal function description Category Terminal... -
Page 13: Control Panel
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL during closing. Keypad Max.output Power 5V current： 50mA Encoder Common terminal Encoder signal wire Control panel Press button ‘4’, the LED indicates ‘0000’, press button ‘1’ or ‘2’ to enter password ‘0008’. Press button ‘4’... - Page 14 SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Parameter Function description Value Range Default Modify the password P006 Set P019 to 0088 before modifying the 0000～9999 0008 password. Brake 0：No brake P007 0000 0000～0002 1：Brake when stop 2：Keep brake when stop 0000～0240 P008 Radar/Loop detector auto close time...
-
Page 15: Set Open And Close Limit Positions
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Parameter Function description Value Range Default then change the P006 password. Infrared failure height P020 0000～0100 0005 The larger the value range, the higher the height. Running mode 0000～0001 0000 P021 0：Small inertia 1：Big inertia Interlock N.O. -
Page 16: Maintenance
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL Button 1 Button 1 Button 3 Button 2 Button 2 Button 4 Button 3 Button 4 YKF06 YKF09 Fig.15 Warning: For safety and security, we recommend that the factory setting be replaced with a personal code. 10. -
Page 17: Packing List
SERVO INDUSTRIAL DOOR OPERATOR INSTALLATION AND USER’S MANUAL 12. Packing List After receiving the product, you should make an unpack-inspection, in which you should check whether the product was damaged. If you have any problem please contact our sales agent. You should find the following items in our standard packing: Item Quantity Door operator...
