Product name Acoustic Camera Model number Sorama CAM iV64s is in conformity with the requirements of the following EU Directive or other normative documents. This declaration is based on the products' full compliance with the following European standards: General Safety •...
WARRANTY INFORMATION The Sorama CAM iV64s is covered by warranty repair service for abnormality or malfunctions caused by product quality issues within one year from the date of purchase. The warranty repair service excludes issues resulting from improper use or accidental damage, such as drops.
Page 6
Battery-specific • Do not disassemble or crush battery cells and battery packs. • Batteries contain hazardous chemicals that can cause burns or explode. If exposure to chemicals occurs, clean with water and get medical aid. • Contact Sorama when the battery leaks. •...
BATTERY Specifications: Model RRC2057 (2S2P) Type Lithium Ion Voltage 7.20V Capacity 6.90Ah Max. charge current 4.83A Max. charge voltage 8.40V Max. discharge current 9.50A Dimensions (L x W x H) 85.35 x 77.65 x 23.0 mm Weight 230g Warning To prevent personal injury and for the safe operation of the product: •...
Page 8
Dispose of this product according to local Regulations. Do not dispose of this product as unsorted municipal waste. Cautionary notice! Consult accompanying documents. To change the batteries from Sorama CAM iV64s: • Click the battery cover lock and slide open the battery cover. •...
DESCRIPTION The Sorama CAM iV64s is a state-of-the-art acoustic camera that displays highly accurate sound levels and localizes sound sources on its 7- inch touch display, specifically designed for users who require mobility and instant, reliable acoustic information to perform in-field measurements.
Ambient temperature The Sorama CAM iV64s operates in ambient temperatures ranging from -20°C to 50°C (-4°F to 122°F). Note that water can cause condensation, which can lead to damage in the device. The ambient operating relative humidity is between 10-90% RH (non-condensing).
The following items are included with the product: Number Description Quantity External Battery Charger Rechargeable Lithium-ion Battery Pack Country-Specific Adapters for Battery Charger USB-C to USB-A Cable (1.5m) Sorama CAM iV64s Acoustic Camera Protective Case Accessory Bag Shoulder Strap Hand Strap Confidential...
Hardware features and configuration Number Description LED Indicator USB-C Connector Touchscreen Display Shoulder Strap Anchor Battery Compartment / Tripod Connector Acoustic Sensor / Webcam Power on / Measurement Trigger Button / Force Shut Down Hand Strap Anchor and Screw Point Warning The USB-C connector port is not used for charging, and it is solely used for data communication.
Press the trigger button on the pistol grip to power up the device. The LED above the USB-C connector will indicate that the device is turned on. The Sorama CAM iV64s currently has 3 LED colors. The table below explains the meaning of each color. LED Color...
Home screen When the device is fully booted, the home screen contains several icons. The meaning of the icons is as follows: Symbol Description Battery level Storage space is less than 1 GB Recording disabled, memory full Wi-Fi connection Confidential...
Good to know / background info • Sound Pressure Level The sound is defined as pressure variations in the air, which is generally quantified by the sound pressure. Sound Pressure Level (SPL) is a weighted sum of the frequency components of acoustic signals. SPL is expressed in decibels (dB SPL). •...
Page 16
• Quick-Connect Leakage This type of leakage occurs in quick-connect fittings, which are also known as quick-disconnect or quick release couplings. Due to the damages in inner tilts, the compressed air/gases leaks through the quick-connect fitting. • Threaded Coupling Leakage These leakages occurs due to loose sections on the threaded end caps, that are used for a compressed air system’s endpoint.
MENU To reveal the menu, swipe down from the top. The following menu is shown. The user can easily gain access to the different features and settings of the device. The required feature or setting can be selected by touching the related icon on the screen. When the icon is selected it will turn white. The following features and settings are included: Mode This is the menu showing the various modes the device can use.
Page 18
1.7. Image By choosing the “Image” option, user can take screenshots, by clicking on the pistol grip button. After the image is taken, the screen will show the following message, “Your recording has been saved”. The image output will be in .jpeg format. The process flow is shown in the above screenshots.
Page 19
1.9. Partial Discharge Inspection This mode is used to detect partial discharge, i.e., identifying defects in High Voltage (HV) assets. Defects can include voids, gaps, splits, physical sharp points, imperfections or discharges in the open air on/within HV assets. The defect itself discharges as it is not able to insulate the voltage applied across it.
Page 20
By clicking the 3 dots menu { }, adjacent to the option, the user will reach a dashboard, which contains the options: • Unit System: Select the unit system, choosing between Imperial or Metric • Pressure: Enter the pressure of the system. •...
Page 21
1.11. Mechanical Inspection This feature can be used to inspect the rotating mechanical components and study their behaviour. By clicking on the 3 dots menu { }, the different modes of operation can be found. These are namely: Narrow Band, Multi-band and Anomaly Detection.
Page 22
1.11.2. Multi-band This is a second recommended feature, after starting from a narrow band. When selecting the multiband option, you get to select the amount of bands. After selecting a number of bands, in each option, the lowest frequency band can be moved manually, while other accompanying bands will automatically move along in a pre-defined pattern.
Page 23
Train Mode: The training procedure can be started by tapping the “+” symbol. It will ask you to supply a model name. As the model name is entered, press “Enter” and your device is now ready to start training. Keep the device still and press the trigger button to start training the model.
Page 24
Measurement Mode: The models trained are shown in the dropdown menu, as shown below: These models can be selected to test the asset. Models can also be retrained and deleted by pressing the respective model in the dropdown menu for a few seconds, and clicking on the corresponding option. After the model is selected, the measurement trigger button can be pressed to start studying the behavior of the asset.
Memory The user can view all the saved measurements and transfer, rename and/or delete measurements in the device storage. to access the file storage. The “default” folder is automatically created and all the measurements are saved in this, until specified explicitly. Folders: The new folders can be created by using the option “New Project”.
Page 26
For the Leak Inspection module, it displays the analysis results, as calculated by the parameters entered during the measurement. For more information on parameters, refer to Section 1.10. The results contains: type of leak, estimated leak rate, estimated energy and estimated cost.
Acoustics to adjust the acoustic settings: • dB Scale: This shows the SPL scale on the homepage for all the modes. Tap this setting to switch on/off the mode • Max dB: The scale maximum can be set manually (when switched on) or automatically (when switched off). •...
Settings to view the general device settings. 1.12. Wi-Fi Enable a Wi-Fi connection to connect with the internet. When Wi-Fi is enabled, a list of available networks is shown. To select a network to connect to, click on the network name from the list.
Page 29
1.13. Screen Sharing To use the screen sharing the device must be connected to a Wi-Fi network. Connect your Sorama CAM iV64s to the same Wi- Fi network to which your computer is connected and go to the Screen Sharing page on the Sorama CAM iV64s. Here you can set a password and later use the same password to connect and view the Sorama CAM iV64s screen from your computer.
Page 30
1.16. Date & Time Select your preferred Date Format. User can also change settings to the current date and time. 1.17. Device Info Select ‘Device info’ to view the ‘Firmware version’, ‘Installed On, ‘Device name’, ‘Device serial number’ and ‘Language’. This page can also be used to check for new firmware updates, install those updates or to reset the user settings to the default settings.
Page 31
1.18. Documentation Scan the QR-code to quickly navigate to the Sorama CAM iV64s documentation page: https://sorama.eu/products/camiv64-ex. 1.19. Login This can be used to login to Sorama Portal using the credentials provided by Sorama via the email. The screen below will be shown.
It is possible to mount Sorama CAM iV64s with an external tripod. The external tripod has to be explosion-proof. As the battery compartment rubber part has to be secured with tripod connector, it is not allowed to mount Sorama CAM iV64s with tripod in hazardous area.
Sorama Portal Sorama Portal is a tool that can be used for generation of additional reports for the measurements done on device. The user can go to the portal using the following link: https://portal.sorama.eu/ and “Sign In” using the credentials provided by Sorama. After the sign in, user will need to pick out, one of the three markets, named as “R&D”, “Building Acoustics”...
Page 34
Sorama CAM iV64s to the Sorama Portal. When the Sorama CAM iV64s has successfully been connected to the Sorama Portal, go to the ‘Manage Sorama CAM iV64s files’ tab within the Sorama Portal’s ‘Manage’ workflow. The screen will be shown as below: Note: Make sure you are logged into portal using the credentials provided by Sorama via email.
The downloaded file will be a zip, containing the report in .pdf format presenting the result of the measurement as performed on the Sorama CAM iV64s. Below an example is shown of a report that can be downloaded after performing Partial Discharge Inspection.
Page 37
4.2. Packages: The required package can be bought and added using the “+” icon, shown adjacent to the package name. As the package is selected, it will show the prompt screen with the message of either Activate or Cancel. Select the required option to install the package on device.
Contact Sorama if you require more information. Service Contact Sorama for information by sending an email to helpdesk@sorama.eu. Specifications Complete specifications are at www.sorama.eu. See the Sorama CAM iV64s product specifications. Confidential...
