Summary of Contents for Kicker CompVR Series
- Page 1 Owner’s Manual Manual del Propietario Manuel d’utilisatio Benutzerhandbuch CompVR-Series Subwoofers select language seleccione el idioma choisir la langue sprache auswählen...
-
Page 2: Table Of Contents
Contents Overview ......3 Specifications ......4 Installation ...... 5 Wiring Configuration ....5 Sealed Enclosures ....7 Vented Enclosures ....9 Box Building Notes ....10 Warranty ...... 13 Garantía | Garantie ..English CVR-a-250407... -
Page 3: Overview
VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND LEVELS THAT CAN PERMANENTLY DAMAGE YOUR HEARING! TURNING UP A SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING TO YOUR EARS THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE SAME VOLUME LEVEL. -
Page 4: Specifications
Please allow two weeks of break-in time for the subwoofer to reach optimum performance. Pro Tip: You’re a KICKER amplifier and a few cables away from a full system upgrade that will dominate any factory system! KICKER line of amplifiers make it easy to upgrade to solid bass with your existing or stock source unit. -
Page 5: Installation
Installation Wiring Configuration CompVR-Series subwoofers are made with 2Ω or 4Ω voice coils. Make sure your source unit or amplifier is rated at the correct ohm load for operation. The speaker wire should be kept away from sharp edges and avoid the possibility of getting pinched by the trunk. - Page 6 Series Wiring Dual 2Ω Voice Coils = 4Ω Load Dual 4Ω Voice Coils = 8Ω Load Parallel Wiring Dual 2Ω Voice Coils = 1Ω Load Dual 4Ω Voice Coils = 2Ω Load English...
-
Page 7: Sealed Enclosures
Sealed Enclosures These sealed enclosure designs give the smoothest response with increased energy at the lowest frequencies, 20 to 30Hz. These designs deliver massive amounts of highly-accurate bass and can be driven with punishing levels of amplifier power. The CompVR-Series high performance suspension system can operate in a larger sealed enclosure. - Page 8 Panel Dimensions for Minimum Sealed Enclosures using 3/4” (1.9cm) thick MDF: CVR10 CVR12 CVR15 Volume ft .8 [22.7] 1 [28.3] 1.8 [51] Panel A in. [cm] 13.5 x 13.5 [34.3 x 34.3] 14.5 x 14.5 [36.8 x 36.8] 17.25 x 17.25 [43.8 x 43.8] Panel B in.
-
Page 9: Vented Enclosures
Vented Enclosures CompVR subwoofers will handle massive amounts of power in any of the recommended enclosures, minimum or maximum. The smaller enclosures are best for use in limited-space applications. The larger recommended enclosures will yield slightly more bass at the lowest frequencies. -
Page 10: Box Building Notes
Box Building Notes Use 3/4” (1.9cm) or thicker MDF (medium density fiberboard) and seal the joints with silicone. Use the “template” inside your CompVR subwoofer’s shipping carton to mark the mounting hole, then cut directly on the line. These designs need internal bracing. - Page 11 Do not install a port opening against a solid surface, such as an internal brace, back- panel or trunk wall, seat or interior panel of your vehicle. The port opening must remain unobstructed. Use the smallest dimension of the rectangular port as the minimum amount of space between the port opening and any solid surface to insure unrestricted airflow.
- Page 12 CVR12, CVR15: D = 3” x 3” (8cm x 8cm) CVR10: D = 2” x 2” (5cm x 5cm) For more advice on box building, refer to your Authorized Kicker Dealer, or click on the Support tab on the Kicker homepage, www.kicker.com. Please e-mail support@kicker.com or call Technical Support at (405) 624-8583 for specific or unanswered questions.
-
Page 13: Warranty
Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction during the warranty period, KICKER will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replacements may have cosmetic scratches and blemishes. -
Page 14: What Is Not Covered
Service performed by anyone other than KICKER HOW LONG WILL IT TAKE? KICKER strives to maintain a goal of one-week service for all acoustics (subwoofers, midrange drivers, tweeters, crossovers, etc) returns. Delays may be incurred if lack of replacement inventory or parts is encountered. -
Page 15: Garantía | Garantie
(“a todo volumen”) en todo sentido. La línea de altavoces y amplificadores KICKER es la mejor del mercado de audio de automóviles y por lo tanto representa el “combustible” para vivir a todo volumen en el área de “estéreos de automóvil” de la vida de nuestros clientes.
