OWNER'S
MANUAL
Model No. GZFI8063.6
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (inside tower)
QUESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Visit our website at
www.freemotionfitness.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ICON FREEMOTION EPIC FLY/REAR DELT
Summary of Contents for ICON FREEMOTION EPIC FLY/REAR DELT
- Page 1 OWNER’S MANUAL Model No. GZFI8063.6 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (inside tower) QUESTIONS? At FreeMotion Fitness, we are committed to providing com- plete customer satisfaction. If you have questions, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.
-
Page 2: Table Of Contents
HOW TO CONTACT CUSTOMER CARE ..........Back Cover FREEMOTION is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the strength equipment. 1. Read all instructions in this manual before port a maximum user weight of 350 lbs. (159 using the strength equipment. kg). -
Page 4: Warning Decal Placement
WARNING DECAL PLACEMENT The decals shown below have been placed on the strength equipment in the indicated locations. If a decal is missing or illegible, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual and order a free replacement decal. -
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the FREEMOTION ® EPIC™ after reading this manual, see HOW TO CONTACT FLY/REAR DELT strength equipment. The strength CUSTOMER CARE on the back cover of this manual. To equipment’s stylish ergonomic design and never-before- help us assist you, please note the product model seen features improve upon traditional strength training. -
Page 6: Adjustment
ADJUSTMENT This section explains how to adjust the strength equipment. Make sure all parts are properly tightened each time the strength equipment is used. Replace any worn parts immediately. ADJUSTING THE RESISTANCE To change the amount of resistance for your workout, insert the weight pin into the desired weight. -
Page 7: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING For optimal performance of the strength equipment and to reduce the chances of injury to users, you must per- form preventive maintenance on a regular basis. Instruct all personnel to perform the procedures described in this section. Personnel must also record and report any accident. To maintain the strength equipment’s warran- ty, use only FREEMOTION EPIC parts for repair or replacement. -
Page 8: Monthly Maintenance
Cable Guards If there is not enough tension on the cables, the top Check the cable guards to ensure that they are not weight will not be lifted immediately when the repeti- rubbing against the cable and that they are holding tion is begun. - Page 9 WEIGHT STACK SERVICING 8. Replace the top weight and the weight pin on top of the weight stack. Servicing the weight stack involves replacing the two guide bushings and the weight insert in the top weight. 9. Reattach the “U”-bracket to the weight rod with the To order these parts, see HOW TO CONTACT CUS- bolt, the two washers, and the locknut.
-
Page 10: Cable Diagram
CABLE DIAGRAM The cable diagram shows the proper route of the cable. Use the diagram to make sure that the cable Cable (24) and the cable guards have been assembled correctly. If the cable has not been correctly routed, the strength equipment will not function properly and damage may occur. - Page 11 NOTES...
- Page 12 NOTES...
- Page 13 NOTES...
-
Page 14: Part List
PART LIST—Model No. GZFI8063.6 R0507A If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual. Key No. Qty. Description Key No. Qty. Description Base 1/4" x 1" Button Bolt Tower Small Bumper Tower Cap... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. GZFI8063.6 R0507A 54 54 72 68... -
Page 16: How To Contact Customer Care
Please be prepared to give the following information: • the MODEL NUMBER of the product (GZFI8063.6) • the NAME of the product (FREEMOTION EPIC FLY/REAR DELT strength equipment) • the SERIAL NUMBER of the product (see the front cover of this manual) When ordering replacement parts, please also give the KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and the EXPLODED DRAWING on pages 14 and 15).
