20V Cordless Cultivator
20V Cordless Cultivator
v01:
K158
v001: 25/10/21
Please read and retain these instructions for future reference
K158
v001: 22/10/21
Please read and retain these instructions for future reference
Please read and retain these instructions for future reference
•
20V BATTERY, WORKING TIME UP TO 50 MINUTES
4-5 HOUR CHARGE TIME
•
•
NO LOAD SPEED: 250r/MIN
•
CULTIVATING WIDTH: 2.3CM
•
CUTTING DEPTH 7CM
•
SOFT GRIP HANDLE
•
LIGHT WEIGHT AND EASY TO USE AT JUST 2.3KG
•
NO TRAILING CABLES
•
1 BLADE WITH 10 TINES – SIZE OF MAIN BLADE IS 15CM DIAMETER
•
HANDLE HEIGHT 155CM
•
THE PRONGS ALTERNATE IN DIFFERENT DIRECTIONS
•
EACH PRONG IS 1CM STICKING OUT
•
TWO EASY GRIP HANDLES WHICH CAN BE ROTATED TO SUIT BOTH LEFT AND RIGHT HANDED
PEOPLE
•
COMES COMPLETE WITH BATTERY AND CHARGER
ASSEMBLY INSTRUCTIONS / INSTRUCTIONS FOR USE:
Unpack the components carefully. Please check all parts have been removed from the packaging.
Technical Data
Battery Voltage*
Battery Capacity
Charging Time
Use: This item requires two hands to use safely.
Please read this instruction manual thoroughly before starting and ensure you are familiar with the
operation of your new 20V Cordless Cultivator.
Blade size
20 V D.C.
Blade speed
2.0 Ah
4-5 hours
6 inches/150mm
250 rpm
Advertisement
Summary of Contents for Gainsborough K158
- Page 1 20V Cordless Cultivator 20V Cordless Cultivator v01: K158 v001: 25/10/21 Please read and retain these instructions for future reference K158 v001: 22/10/21 Please read and retain these instructions for future reference Please read and retain these instructions for future reference •...
-
Page 2: Personal Injury
Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Explanation of Warnings and Symbols on your product. WARNING! Read the user instructions carefully to make sure you understand all the controls and what they do. - Page 3 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Know your product – Know how to start and stop the machine. Be thoroughly familiar with the controls. Use the right tool – Do not use this machine for any job except that for which it was intended.
- Page 4 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Training • Read, understand, and follow all instructions on the cultivator and in the manual before operating this unit. Thoroughly familiarize yourself with the controls and the proper use of the equipment.
- Page 5 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 • Exercise caution when changing direction and operating the tool on slopes. Always keep feet and legs a safe distance away from the machine. Look for hidden obstacles or hazards.
- Page 6 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Battery & Charger Safety Instructions We pay a great deal of attention to the design of every battery pack to ensure that we supply you with batteries that are safe, durable and have a high energy density.
- Page 7 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 If an extension cord must be used, plug the charger into a properly wired 16 gauge or larger extension cord with the female plug matching the male plug on the charger. Make sure that the extension cord is in good electrical condition.
- Page 8 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Lithium-ion batteries are subject to a natural aging process. The battery pack must be replaced at the latest when its capacity falls to just 80% of its capacity when new. Weakened cells in an aged battery pack are no longer capable of meeting the high power requirements needed for the proper operation of your cultivator, and therefore pose a safety risk.
- Page 9 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Do not use the supplied battery charger to charge other cordless tools. Do not overcharge batteries. Do not exceed the maximum charging times. These charging times only apply to discharged batteries.
- Page 10 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 When handling batteries, be wary of electrostatic charge. Electrostatic discharges can damage the electronic protection system and the battery cells. Avoid electrostatic charging and never touch the battery poles.
- Page 11 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Assembly WARNING! Do not insert the battery until assembly is complete. Failure to comply could result in accidental starting and serious personal injury.
- Page 12 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 1. MOUNT THE BLADE • Remove the nut from the motor shaft. Mount the cultivator blade on the motor shaft (Fig. 2a), then tighten the M8 nut with wrench supplied (Fig.2b)
- Page 13 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 1. CONNECTING THE CULTIVATOR HEAD WITH THE SHAFT • Lifting the spanner of the shaft (Fig. 3a), connecting the head with the shaft (Fig. 3b). Then press the spanner.
- Page 14 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 5. CONNECTING THE BATTERY PACK TO THE MACHINE (Fig.5) Fig.5 Battery Pack Operation The equipment is powered by a lithium-ion battery. The battery pack is completely sealed and maintenance free.
- Page 15 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 Care and Maintenance The Golden Rules for Care WARNING! Always switch the product off, remove the battery, and let the product cool completely before inspecting, cleaning, or performing any other maintenance task.
- Page 16 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 • All nuts and bolts must be checked periodically for tightness before operation. After prolonged use, especially in sandy soil conditions, the working tool will become worn and lose some of its original shape.
- Page 17 Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 BATTERIES • Keep batteries away from children and pets. • Do not mix used and new batteries. • Remove the batteries if left for long periods.
-
Page 18: Eu Declaration Of Conformity
- Product Description: CORDLESS CULTIVATOR Item Number: K158 OR Model Number: ASYRTM0115520 The Supply of Machinery (Safety) Regulations 2008 & Machinery Directive 2006/42/EC and Electrical Equipment (Safety) Regulations 2016 & LVD Directive 2014/35/EU Electromagnetic Compatibility Regulations 2016 &... -
Page 19: Battery Charger
Instructions for Use 20V Cordless Cultivator K158 Please read and retain these instructions for future reference v001: 25/10/21 BATTERY CHARGER: Electrical Equipment (Safety) Regulations 2016 & LVD Directive 2014/35/EU Plugs & Sockets Safety Regulations 1994: BS1363-1:2012 Electromagnetic Compatibility Regulations 2016 & EMC Directive 2014/30/EU: Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 (as amended) &...
