ViSion.nEt
control StationS
OVERVIEW
This document provides installation and operation instructions for the following product(s):
P ROD UCT NA M E
Vision.Net slider station, 3 channel & master, 6 presets, 2-gang
Vision.Net slider station, 6 channel & master, 6 presets, 4-gang
Vision.Net slider station, 9 channel & master, 6 presets, 4-gang
Vision.Net slider station, 12 channel & master, 7 presets, 5-gang
Vision.Net slider station, 15 channel & master, 7 presets, 5-gang
Vision.Net push button station, 1 button, 1-gang
Custom Vision.Net station
Vision.Net push button station, 2 button, 1-gang
Vision.Net push button station with IR, 4 button, 1-gang
inStallation and SEt uP
Input Power: +18-26 VDC (powered from Vision Net network)
Current: 20mA
Temperature: Storage: -25° to 85° C
Operating: 0° to 40° C
Relative Humidity: 30-90% (non-condensing)
The Vision Net Network consists of a single CAT5e cable connecting all modules in a daisy chain manner. All
standard units connect to the network using a 9-pin plug-in connector (included).
lEd indicatorS
There are 3 LEDs on the control PCB:
•
RED - blinks when there is any activity from the front Buttons or Slider modules
•
GREEN - blinks when the unit receives or transmits network SVN/485 traffic
•
AMBER - blinks when the unit receives or transmits sensor 4-Wire Digital LAN traffic
NOTE: Not all button or slider activity results in network traffic. For example, moving a slider when not in Manual
mode does not generate LED activity from traffic.
Standard Station inStallation
To install a Vision.net Control Station:
Step 1.
Step 2.
NOTE: Step 3 is only required if there is a need to replace the keypad buttons.
ELECTRICAL
Unpack unit and inspect for any signs of shipping damage. If this is a slider station, remove the slider
knobs by pulling.
Remove the faceplate by pulling on the faceplate top.
SPECIFICATIONS
Vision.Net protocol (SVN/485)
Vision.net 4.5 Wire Digital LAN
Contact Closure
1
Quick Start GuidE
2-450223-010_E
ORDER CODE
63303
63306
63309
63312
63315
63321
63398
63322
63324
COMMUNICATIONS
