Palmako FR28-3030-6 Assembly, Installation And Maintenance Manual

Advertisement

Available languages

Available languages

Quick Links

Assembly, installation and maintenance manual
Montage-, Aufbau- und Wartungsanleitung ● Assemblage, manuel de montage et d'entretien ● Montaje, instalación,
y mantenimiento ● Manuale di montaggio, installazione e manutenzione ● Monterings- og vedlikeholdsmanual ●
Monterings-, installations- och underhållsmanual ● Kokoamis-, asennus- ja huolto-ohje ● Vejledning for montering
og vedligehold ● Handleiding voor montage, installatie en onderhoud ● Manual de montagem, instalação e
manutenção ● Návod k montáži, instalaci a údržbě ● Instrukcja montażu, instalacji i konserwacji ● Surinkimo,
montavimo ir priežiūros vadovas ● Montāžas, uzstādīšanas un apkopes rokasgrāmata ● Руководство по сборке
и обслуживанию ● Montaaži-, paigaldus- ja säilitamise juhend
Treatment options, Item code ●
Behandlungsoptionen, Artikel-Code ● Traitement options, code de
l'article ● Tratamiento opciones, código del artículo ● Opzioni di
trattamento, codice articolo ● Behandlingsalternativer, artikkelnummer
● Behandlingsalternativ, varukod ● Käsittelyvaihtoehdot, yksikön koodi
● Behandlingsmuligheder, artikel nummer ● Behandelingsopties,
artikelnummer ● Opções de tratamento, código do artigo ● Povrchové
úpravy, kód položky ● Możliwości leczenia, kod produktu ● Apdorojimo
variantai, prekės kodas ● Apstrādes iespējas, artikula kods ● Варианты
обработки, код изделия ● Töötlusvõimalused, tootekood
Factory inspection by ● Werkskontrolle durch ●
Contrôle à partir de l'usine par ● Inspector de fábrica ●
Collaudato
da
Fabriksbesiktigat av ● Tehtaan tarkastaja ● Fabriks
Kontrol udført af ● Fabriekscontrole door ● Inspeção de
fábrica, por: ● Zkontrolováno ve výrobním závodě ●
Kontrola fabryczna do ● Apžiūrą gamykloje atliko ●
Rūpnīcas pārbaudi veicis ● Заводской контроль ●
Tehase kontroll teostatud:
.........................................................................................
Palmako AS | Näituse 25 | 50409 Tartu | Estonia | Ph: +372 7 355 530 | Fax: +372 7 355 544 | contact@palmako.ee | www.palmako.ee
FR28-3030-6
Log cabin
Fabrikkkontroll
utført
Date ● Datum ● Date ● Fecha ● Data ● Dato ● Datum ●
Päiväys ● Dato ● Datum ● Data ● Datum ● Data ● Datums
● Data ● Дата ● Kuupäev:
av
Pack number ● Pack Nr. ● Packet n° ● Paquete N
N. ● Serienr ● Produktionsnummer ● Pakettinro ● Pakke nr.
● Pak nr. ● Número de embalagem ● Číslo balení ● Numer
opakowania ● Pakuotės numeris ● Iepakojuma numurs ●
Упаковочный номер ● Pakinumber:
NO
108809
● Pacco
o

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR28-3030-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Palmako FR28-3030-6

  • Page 1 ● Pak nr. ● Número de embalagem ● Číslo balení ● Numer opakowania ● Pakuotės numeris ● Iepakojuma numurs ● Упаковочный номер ● Pakinumber: ..................Palmako AS | Näituse 25 | 50409 Tartu | Estonia | Ph: +372 7 355 530 | Fax: +372 7 355 544 | contact@palmako.ee | www.palmako.ee...
  • Page 2: Inspection Certificate

    Kontrol Certifikat ● Control Certificaat ● Certificado de Inspeção ● Kontrolní certifikát ● Certyfikat kontrolny ● Apžiūros pažyma ● Pārbaudes akts ● Акт осмотра ● Kontrollakt Art. Nr. FR28-3030-6 Please keep safely! Bitte gut aufbewahren! ● A bien conserver, s.v.p.! ● ¡A conservar! ● Da conservare! ●...
  • Page 3 Dansk: Det købte produkt fremstillet i overensstemmelse med de høje kvalitets krav. Produktet er blevet omhyggeligt inspiceret og pakket. For at undgå eventuelle problemer i løbet af monteringen udført af dig selv eller håndværker af dit eget valg, anbefaler vi, at du undersøger leverancen for fuldstændighed i overensstemmelse med listen over dele før samling.
  • Page 4 To be completed by buyer! (Please use block letters) ● Vom Käufer auszufüllen! (Bitte in Druckschrift) ● A remplir par l’acheteur! (en lettres d’imprimerie, s’il vous plaît) ● ¡Completa el cliente! (en mayúsculas) ● Da compilare dall’acquirente! (in stampatello) ● Fylles ut av kjøper! (Vær vennlig å...
  • Page 5 8.5 m...
  • Page 26: General Information

    Installation manual 1 General information Dear client, We are glad that you have decided in favour of our garden house! Please read the assembly manual carefully before proceeding with the house installation! You will thus avoid problems and will not waste time. Recommendations: ➢...
  • Page 27: Preparation For Assembly

    Installation manual Garden house painting and maintenance Wood is a natural material, growing and adapting depending on weather conditions. Large and small cracks, colour tone differences and changes, as well as a changing structure of wood are not errors, but a result of wood growing and a peculiarity of wood as a natural material. Unprocessed wood (except for foundation joists) becomes greyish after having been left untouched for a while, and can be turn blue and become mouldy.
  • Page 28 Installation manual Preparation of components: Sort the components based on the wall plans (see Technical specifications) and place them at the four sides of the house in the installation sequence. ATTENTION: Never place the components directly on grass or a muddy surface because it will very difficult even...
  • Page 29 Installation manual Base frame (Foundation joists) The base frame of the house must be completely flat and level to ensure that the installation proceeds without problems. ATTENTION: different house can have different foundation placements – see the appended base frame drawing (in Technical specifications)! Place the impregnated foundation joists on the prepared foundation in accordance with the drawing at equal intervals.
  • Page 30: Door And Window

    Installation manual Continue the installation of the walls by strongly forcing the wall logs into one another. If necessary, use the hitting block and hammer. At the same time, do not forget to begin the installation of the door and windows. You should definitely begin the door installation after the 5 layer of logs.
  • Page 31 Installation manual ATTENTION: It is not necessary to fix the doors and windows to the wall logs! If you wish to do this, it will be sufficient to fix them with a couple of screws in the lower part of the frame because as they dry, the wall logs will begin subsiding.
  • Page 32 Installation manual Having installed the roof boards, the roof felt and roof Installation of roof slats: slats must be attached. The table of components shows whether the roof cover material and slats are included with this house option! First of all, screw the roof edge reinforcements and eave edgings under the roof board ends.
  • Page 33: General Advice

    Installation manual Storm braces (NB! Not included in some house option kits!) Attach the storm braces (if included in the supplied kit) to the inner sides of Installation of storm braces: the front (2 units) and back (2 units) walls with the supplied bolts. It is important for the logs to be drilled through in advance.
  • Page 34 Notice de montage – Français I. Généralités Cher client, Nous sommes heureux que votre choix se soit porté sur notre maison de jardin! Il est important de lire entièrement cette notice de montage avant de commencer la construction de votre maisonnette en poutres! Vous vous éviterez ainsi des problèmes et des pertes de temps inutiles. Conseils: ...
  • Page 35: Préparation Au Montage

    Notice de montage – Français Peinture et entretien Le bois est un produit naturel qui travaille de façon variable. Des caractéristiques telles que les madrures grossières et fines, les nuances de couleurs et les modifications, de même que les imbrications, ont leur origine dans la croissance du bois.
  • Page 36: Montage

    Notice de montage – Français Préparation des détails: Classez le matériel et déposez-le sur les quatre côtés de la maison, conformément à l'ordre de montage. IMPORTANT: Ne déposez pas les bois directement sur le gazon ou dans la saleté, car les bois seront alors difficiles, voire impossibles à...
  • Page 37 Notice de montage – Français Posez les longrines imprégnées sur les fondations préparées, en respectant à peu près le même écartement entre les longrines (voir plan de fondations dans les Caractéristiques techniques). Veillez à ce que les longrines soient de niveau et à angles droits, avant qu'elles ne soient assemblées par vissage. REMARQUE: Il est conseillé...
  • Page 38 Notice de montage – Français Porte et fenêtres Montage des dormants (nécessaire seulement dans le cas d'une Dormants: porte double!):  Dans le cas de la porte double, les éléments du dormant sont livrés détachés, pour des raisons transport, faut commencer par les assembler.
  • Page 39 Notice de montage – Français Ne procéder au réglage définitif de la porte qu'au bout de 2 à 3 semaines environ, après que le bois se soit adapté au climat et que les madriers des parois se soient mis en place. Pignons Le triangle du pignon est la plupart du temps en une seule pièce.
  • Page 40 Notice de montage – Français Une fois que les planches du toit ont été posées, il faut Montage des baguettes du toit: mettre en place le carton bitumé du toit et les baguettes de finition du toit. Pour savoir si la couverture et les baguettes de finition du toit font partie de l'étendue de la fourniture, reportez-vous à...
  • Page 41 Notice de montage – Français sèches, mais que le climat est humide, elles absorbent facilement l'humidité. C'est la raison pour laquelle il est conseillé de ne pas fixer les planches trop près les unes des autres, afin d'éviter les éventuels gonflements. Laissez 1 à...
  • Page 42: Instrukcja Instalacji

    Instrukcja instalacji 1 Instrukcja montażu Drogi kliencie, Dziękujemy za wybór naszego domu ogrodowego! Przed montażem prosimy o dokładne zapoznanie się z instrukcją! Pozwoli to uniknąć problemów i oszczędzi czas. Dokumentację załączoną do produktu należy zachować. Zalecenia: ➢ Przed przystąpieniem do montażu opakowanie z domem należy przechowywać w suchym miejscu, nie w bezpośrednim kontakcie z podłożem i zabezpieczone przed czynnikami atmosferycznymi (wilgoć, słońce, itp.) Nie należy przechowywać...
  • Page 43: Przygotowanie Do Instalacji

    Instrukcja instalacji Malowanie i konserwacja domu ogrodowego Drewno jest naturalnym materiałem, który pracuje i zmienia się pod wpływem warunków atmosferycznych. Większe i mniejsze pęknięcia, przebarwienia oraz zmiany struktury drewna nie są wadami a jedynie częścią naturalnego procesu przemian materiału. Drewno pozostawione na jakiś czas bez zabezpieczenia szarzeje, a z czasem robi się niebieskie i pleśnieje.
  • Page 44 Instrukcja instalacji Przygotowanie elementów: Posegregować elementy zgodnie z planami ścian (patrz Specyfikacja techniczna) umieść czterech stronach domku według sekwencji instalacji. UWAGA: Nigdy nie umieszczać elementów bezpośrednio na trawie błotnistej powierzchni, ponieważ może to utrudnić lub uniemożliwić ich wyczyszczenie! Fundament Odpowiedni fundament to najważniejszy aspekt zapewniający długotrwałość i bezpieczeństwo domu. Jedynie całkowicie równy, prostokątny i wytrzymały fundament zapewni bezproblemową...
  • Page 45 Instrukcja instalacji Rama podstawy (legary fundamentu) Rama podstawy domu musi być całkowicie płaska i równa, by zapewnić prawidłową instalację. UWAGA: dla różnych domów konieczne może być odmienne rozmieszczenie fundamentów - patrz załączony rysunek ramy podstawy (w Specyfikacji technicznej)! Zgodnie z rysunkiem umieścić zaimpregnowane legary fundamentów na przygotowanym fundamencie w równych odstępach.
  • Page 46 Instrukcja instalacji Kontynuować instalację ścian mocno wciskając jedną belkę w drugą. W razie konieczności skorzystać z klocka i młotka. Jednocześnie należy pamiętać, by rozpocząć instalację od drzwi i okien. Należy rozpocząć instalację drzwi po umieszczeniu 5-6 warstw belek. Okna i drzwi Futryna: Instalacja futryny (konieczna tylko w przypadku drzwi dwuskrzydłowych!):...
  • Page 47 Instrukcja instalacji UWAGA: Przymocowywanie drzwi i okien do belek ścian nie jest konieczne! W przypadku potrzeby mocowania, wystarczy przymocować je przy użyciu kilku śrub w dolnej części ramy, ponieważ belki będą się obniżać w miarę wysychania. Można finalnie dopasować drzwi i okna dopiero po 2-3 tygodniach od zainstalowania domu, gdy dom dostosuje się...
  • Page 48 Instrukcja instalacji zainstalowaniu desek dachowych należy Instalacja łat dachowych: przymocować papę bitumiczną oraz łaty dachowe. W tabeli elementów pokazano czy do danego domu dołączono materiał pokrywający dach oraz łaty! Najpierw przykręcić śrubą wzmocnienia krawędziowe dachu oraz krawędzie listwy okapu pod końcami desek dachowych.
  • Page 49: Zalecenia Ogólne

    Instrukcja instalacji Klamry burzowe (Uwaga! Nie są załączone do zestawów w niektórych domach!) Przymocować klamry burzowe (jeśli znajdują się dostarczonym Instalacja klamer burzowych: zestawie) wewnętrznych jednostki) i tylnych (2 jednostki) stron ścian pomocą dostarczonych sworzni. Ważne jest, by belki zostały przewiercone wcześniej.
  • Page 50 Istruzioni di montaggio – Italiano 1 In generale Gentile Cliente, siamo veramente lieti che Lei abbia scelto la nostra casetta di legno per il Suo giardino! E’ importante leggere accuratamente le istruzioni prima di iniziare con il montaggio della Sua casetta di legno! In tal modo eviterà...
  • Page 51: Preparazione Al Montaggio

    Istruzioni di montaggio – Italiano Verniciatura e cura Il legno è un prodotto naturale e si muova in modo diverso. Caratteristiche quali venature grosse e fini, sfumature di colore e cambiamenti nonché nodi sono dovuti alla crescita dell’albero. Sono del tutto normali nei legni che crescono all’aperto, e pertanto non sono da considerare difetti ma piuttosto una caratteristica del legno naturale.
  • Page 52 Istruzioni di montaggio – Italiano Preparazione dei particolari: Dividere il materiale e predisporre i quattro lati della casetta nella sequenza indicata. IMPORTANTE: Non appoggiare mai i legni direttamente sul prato o su superfici sporche in quanto sarebbe difficile o persino impossibile pulirli successivamente! Fondamenta La cosa più...
  • Page 53 Istruzioni di montaggio – Italiano Travetti I travetti devono assolutamente trovarsi a livello e in piano per garantire un montaggio perfetto. ATTENZIONE: Lo schema delle fondamenta può variare a seconda del modello di casetta. Rispettare lo schema allegato (vedi Dati Tecnici)! Appoggiare i travetti impregnati sulle fondamenta preparate ad una distanza uguale tra di loro (vedi schema delle fondamenta in Dati Tecnici).
  • Page 54 Istruzioni di montaggio – Italiano Proseguire incastrando saldamente le prossime tavole tra loro. Se necessario, utilizzare il blocchetto di legno ed il martello. Ricordare sempre di iniziare con il montaggio delle finestre e delle porte. Il montaggio delle porte dovrebbe in ogni caso avvenire dopo il 5°-6° strato di tavole. Porta e finestra Telaio porta: Montaggio del telaio porta (solo per doppia porta!):...
  • Page 55 Istruzioni di montaggio – Italiano IMPORTANTE: Non è necessario fissare la porta e le finestre alle tavole della parete. Se desiderate, fissateli con una o due viti nella parte inferiore del telaio in modo che le tavole della parete possano assestarsi durante l’asciugatura.
  • Page 56 Istruzioni di montaggio – Italiano ➢ Le tavole tetto devono chiudere a filo, davanti e dietro, con gli arcarecci del tetto. Se necessario, accorciare le ultime tavole tetto con una sega. Dopo aver posato le tavole del tetto, applicare del Montaggio listelli tetto: cartone catramato e i listelli di chiusura tetto.
  • Page 57 Istruzioni di montaggio – Italiano Listelli antivento (se in dotazione!) I listelli antivento devono essere montati all’interno con le viti a testa quadra in Montaggio dei listelli antivento: dotazione sulla parete anteriore (2) e su quella posteriore (2). A tale scopo è necessario forare prima...
