Summary of Contents for Meech 984v2
- Page 1 Operating Manual Model 984v2 Ion Sensor...
-
Page 2: Table Of Contents
Products shown in this document may be covered by one or more patents, patents applied for and/or registered designs and/or trade marks. For further information please refer to our Head Office or visit www.meech.com. © Meech Static Eliminators Ltd., 26.10.2017... -
Page 3: Introduction
It is an easy to use tool to verify the operation of both AC and DC powered static elimination bars. The Model 984v2 features a series of indicator lights to show whether ions are being emitted from a... -
Page 4: Operation
Operation A sensor in the end panel of the 984v2 detects ions given off by the emitter pins of an ionising bar. The performance of the bar can then be verified by the distance at which the indicator lights of the 984v2 operate. Repeated measurements over a number of months will give an indication of when the static eliminator bar requires cleaning. - Page 5 AC Powered Clean Dirty Model 910 10mm Model 914 Bar 120mm 100mm Model 915 Bar 200mm 150mm Ionising blowers should be tested with the fan Model 935 switched off. The test results will be similar to the 915 bar. DC Powered 971 Bar 250mm 200mm...
-
Page 6: Technical And Construction
971IPS 30kV Clean Dirty pins Clean Dirty pins Clean Frequency Smallest measuring pins at at 25kV pins at at 20kV pins at distance with dirty pins 30kV 25kV 20kV 30kV >300mm 25mm >300mm 20mm 280mm 0.5 hz 80mm >300mm 25mm >300mm 20mm 250mm... -
Page 7: Repairs And Warranty
Repairs And Warranty The f84v2 Ion Sensor is warranted by Meech Static Eliminators Ltd to the original purchaser against defects in material and workmanship for one year after purchase. Should any malfunction occur, please return the bar directly to Meech Static Eliminators or your local distributor. - Page 8 Meech International Meech Static Eliminators USA Inc Meech Elektrostatik SA Meech International (Singapore) Pte. Ltd. 2 Network Point Kaiserbaracke 166 1298 Centerview Circle Range Road, Witney B-4780 St.Vith 7 Temasek Boulevard Akron, OH 44321 OX29 0YN, UK Belgium #12 - 07 Suntec Tower One...
