- Page 1 USER MANUAL 100cm Dual Fuel Range Cooker MODEL- IR100DFMCB/SL WWW.SWIFTUK.CO.UK...
- Page 2 WELCOME Thank you for choosing Inalto for your new appliance. Your item is pre-registered, and your warranty begins from the date of purchase - just be sure to keep your proof of purchase. We take pride in offering a range of appliances designed with you in mind. Our products combine style, reliability, and ease of use, ensuring years of hassle-free performance.
-
Page 3: Table Of Contents
Safety information Care and Maintenance Safety information Cleaning Removing the door Getting to know your Replacing the lamps Freestanding Cooker Technical specifications Energy fiche Ready? Let’s begin Overview Circuit Diagram Accessories Product support Installing your Freestanding Cooker Troubleshooting Support Installation requirements Disposal Data Label Guarantee... -
Page 4: Safety Information
Safety information Important - Please read these instructions fully before installing or operating INSTALLATION WARNINGS DURING USAGE IMPORTANT: This product MUST be installed IMPORTANT: This appliance can be used by by a qualified Gas Safe registered installer in children aged from 8 years and above and accordance with local regulations. - Page 5 - Please read these instructions fully before installing or operating IMPORTANT: The materials surrounding the CAUTION: When the oven is hot never touch appliance (cabinets) must be able to the oven glass by hand or with tools. withstand a minimum temperature of 100°C. CAUTION: Before starting to use your IMPORTANT: When using your oven for the appliance, ensure curtains, paper or...
- Page 6 Safety information Important - Please read these instructions fully before installing or operating GENERAL SAFETY WARNINGS CLEANING AND MAINTENANCE IMPORTANT: This appliance has been designed for non-professional, domestic before operations such as cleaning or use only. Do not use this oven for maintenance.
-
Page 7: Getting To Know Your Freestanding Cooker
Getting to know your Freestanding Cooker You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your Freestanding Cooker and ensure safe and correct installation and operation. -
Page 8: Overview
Getting to know your Freestanding Cooker You’ll be up and running in no time Oven Door Rapid Burner Semi-rapid Burner Auxiliary Burner Trivets Burner Control Knobs Adjustable Feet Oven light indicator Function/temperature control knob Hob top burner control knob... -
Page 9: Accessories
Getting to know your Freestanding Cooker You’ll be up and running in no time Oven Accessories... -
Page 10: Installing Your Freestanding Cooker
RISK OF ELECTRIC SHOCK DO NOT OPEN Installing your Freestanding Cooker Bringing it all together Installation requirements Data Label THIS COOKER MUST BE INSTALLED The Data Label is located on the rear of the ACCORDING TO BS 6172: 2010 BY A SUITABLY appliance.This appliance is suitable for Natural QUALIFIED GAS SAFE REGISTERED INSTALLER Gas and Universal LPG;... - Page 11 Installing your Freestanding Cooker Bringing it all together Installation of Cooker This modern cooker was manufactured with parts and There must be enough natural ventilation to provide materials of the highest quality and was designed to the gas to be used in the environment. The average air meet your cooking needs.
-
Page 12: Positioning
Installing your Freestanding Cooker Bringing it all together Gas Connection IMPORTANT - All Gas installations must be carried out by a suitably qualified person. For information on choosing a gas installer contact the ‘Gas Safe Register’. www.gassaferegister.co.uk The appliance can be placed close to other furniture on condition that the furniture’s height does not Figure 3 exceed the height of the cooker panel. -
Page 13: Installing Your
Installing your Levelling feet CAUTION Safety chain RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION RISK OF ELECTRIC SHOCK... -
Page 14: Electrical Connection
Installing your Freestanding Cooker Bringing it all together Electrical connection correction IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance with all relevant local building and installation regulations. Fitting on a Power Supply Cable Connecting appropriate power supply ·... - Page 15 Installing your Freestanding Cooker Bringing it all together Gas Conversion (NG to U-LPG) Setting the minimum level CONVERSION TO A DIFFERENT GAS TYPE MUST BE 1. Light one of the burners and turn the tap to CARRIED OUT BY A SUITABLY QUALIFIED GAS SAFE minimum flame REGISTERED INSTALLER 2.
-
Page 16: Using Your Freestanding Cooker
Using your Freestanding Cooker Getting the most from your appliance Controls Instructions for use (hob top burners) Control knob (Hob top Burners) The symbols on the control knobs mean the following: Maximum gas flow or ‘high’ flame and lighting position Upper and lower left cavity Minimum gas flow or ‘low’... -
Page 17: Using The Hob Burner Zones
Using your Freestanding Cooker Getting the most from your appliance To light the hob burners The use of pans in excess of the maximum To light the burner, press the control knob fully diameter recommended in the table above can down and hold the knob down before rotating result in over heating/discoloration of hob surface. -
Page 18: Using The Oven
Using your Freestanding Cooker Getting the most from your appliance Positioning the oven trays & shelves When fitting the trays or shelves, ensure they are fitted between the moulded edges inside the cavity that are closest together. Oven Shelves have a stop so that they are not fully withdrawn by accident. -
Page 19: Cooking Modes
Using your Freestanding Cooker Getting the most from your appliance MAIN OVEN COOKING MODES Grill Mode Convection mode Select ‘Grill’ mode with cooking mode selection When set to Convection mode, the top and knob and turn cooking temperature selection bottom heating elements operate together like a knob to ‘Max’... -
Page 20: Baking Cakes
Using your Freestanding Cooker Getting the most from your appliance Baking cakes Using the Grill When baking cakes, always place them in a Use the ‘Grill’ mode with the oven door closed, preheated oven. Make sure you wait until the oven place the food on the centre of the grill pan, has been preheated thoroughly (the indicator light insert and fit the grill pan on either the 3rd or 4th... -
Page 21: Cooking Pizza
Using your Freestanding Cooker Getting the most from your appliance Cooking pizza Cooking fish and meat For best results when cooking pizza: When cooking white meat, fowl and fish, use a • Preheat the oven for at least 10 minutes. temperature setting from 180°C to 200°c. -
Page 22: Care And Maintenance
Care and maintenance Looking after your appliance Cleaning Burner Caps: WARNING! Isolate the power supply to the cooker and Periodically, the enamelled pan support, make sure that the oven is cool. enamelled covers and burner heads must be washed with warm soapy water, rinsed and dried. Before cleaning your oven or performing After drying them thoroughly, place them back in maintenance, make sure that the cooking mode... -
Page 23: Replacing The Lamps
Care and maintenance Looking after your appliance Replacing the oven lamps Replacement lamps are available from our support team. Please call 0333 0914 049. Light source shall be replaced by professional. WARNING: Ensure that the appliance is switched o before replacing the lamp to avoid the possibility of electric shock. -
Page 24: Routine Maintenance
Care and maintenance Looking after your appliance Routine maintenance Have the condition and efficiency of the gas pipe and the pressure regulator (if installed) checked periodically. If anomalies are found, do not repair components but have the faulty component replaced. To ensure good performance and safety, the gas regulator taps must be greased periodically. -
Page 25: Technical Specifications
Care and maintenance Looking after your appliance Technical specification Upper right cavity Upper left cavity Lower left cavity IR100DFMCB / IR100DFMCSL Cavity volume (L) 1400 1400 1400 Top element power (W) Bottom element power (W) 1000 1000 Lamp power (W) -
Page 26: Energy Fiche
Energy fiche Brand Model IR100DFMCB/ IR100DFMCSL Type of oven Electric Mass 76 (+/-2) N.A. (upper-left oven) 93.5 (lower-left oven) 93.5 (upper-right oven) N.A. (upper-left oven) N.A. (lower-left oven) N.A. (upper-right oven) Energy Class A (upper-left oven) A (lower-left oven) A ( upper-right oven) -
Page 27: Circuit Diagram
Circuit Diagram CA CA CA CA Light Lamp Lamp Top Grill Top Grill Bottom Grill Thermostat switch Thermostat switch Light Lamp Top Grill Bottom 120°C Thermal cut-out Grill Thermostat switch 40402501148 Note: CA: SPARK PLUG MI: IGNITION MICRO SWITCH GA: IGNITION GENERATOR... -
Page 28: Product Support
Product support Help is always at hand Troubleshooting 3. DO NOT ATTEMPT TO REPAIR THIS 1. If no electrical functions appear to work, check COOKER YOURSELF. CALL PRODUCT the cooker isolation switch has not been turned off also check the fuse in the switch and the SUPPORT ON 0333 0914 049 OR CONSULT A GAS SAFE REGISTERED INSTALLER circuit breaker in you consumer unit... -
Page 29: Support
‘Troubleshooting’ section of this user manual. Your Inalto product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retail supplier. If you still require further assistance after 28 days, call one of our experts on 0333 0914 049. -
Page 30: Disposal
PRODUCT DISPOSAL Declaration of conformance to product standards. This appliance conforms to all relevant standards applicable to domestic appliances sold in the UK. This appliance/fitting is marked according to the European directive 2012/19/EY on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent negative consequences for the environment and human health, which could otherwise be caused inappropriate waste handling of this product. -
Page 31: Guarantee
The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Inalto disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice.
