Sminn RD356 PLUS Instruction Manual

RD356 PLUS
PROXIMITY READER
INSTRUCTION MANUAL
innovative in electronics
DESCRIPTION
The RD356 PLUS is a proximity reader (radio
frequency contactless reader) for KT356
keys or KC356 cards equipped with a
security encryption system to be used with
new generation control units.
It is developed with state-of-the-art
electronic devices that offer a high degree of
reliability and operational safety.
Combined with the control units for SMINN
readers, it provides the activation/movement
command to manoeuvre control devices,
alarm control, access control, home
automation, etc.
It is suitable for industrial, commercial
and/or residential environments.
OPERATION
The RD356 PLUS reader detects or polls the KT356 key or
KC356 card that comes within 5 cm (approx.). It analyses the
key code and sends the access request to a new generation
control unit (BASE STATION PLUS). The control unit con rms
the code and its access privileges. If access is granted, the
control panel activates a relay.
The RD356 PLUS reader has a tri-colour LED. It emits red
when it does not recognise any nearby key, yellow when it
detects a compatible SMINN key or green if access has been
granted from the base station.
APPLICATIONS
The RD356 PLUS reader has been developed for the
identi cation and reading of new generation SMINN RFID
keys and cards with secure encryption in access control
applications requiring an intermediate level of management.
INSTALLATION
Check the integrity of the product to be installed.
Ÿ
Can be installed embedded in the standard mechanism
box or with the SMINN surface separator and visors
(see accessories).
Ÿ It is necessary to keep it away from metallic parts or
other similar elements. As a radio frequency device,
they may cause interference, limiting range and
increasing power consumption.
Ÿ
The RS-485 BUS offers the possibility of installing
equipment over long distances (up to 500 m
depending on the connection cable used). It also allows
the installation of equipment in parallel up to a total of
4 devices, always depending on the power capacity of
the power supply.
THE MANUFACTURER SHALL NOT BE LIABLE FOR ANY
DAMAGE CAUSED BY INCORRECT INSTALLATION OR
IMPROPER OR NEGLIGENT USE.
WIRING
The wiring is done with only four wires on the connector
located on the rear of the device. Two of these wires are for
the power supply and the other two for the data connection
to the control (BASE STATION PLUS). See Fig .1.
Positive (+) Apply the positive pole of the
+12VDC power supply
Negative (-) Apply the negative pole of the
power supply
Line (A) Apply A RS-485 BUS line
Line (B) Apply B RS-485 BUS line
The RS-485 BUS is operated in Half/Duplex mode with two A
and B wires.
All BUS elements must have the same connection. A wires to
A wires and B wires to B wires (do not interchange). See Fig
.2.
ADDRESSES
The equipment has a 4-position DIP-SWITCH to choose the
address of the reader within the BUS and activate the
terminal resistor (in case its the last reader on the bus). Make
sure that each reader has a different address and, if
applicable, follow the addressing scheme explained in the
base station manual.
USAGE RESTRICTION
They are not guaranteed for use when installed in equipment
other than that speci ed.
THE INSTRUCTIONS FOR USE OF THIS DEVICE MUST BE
HANDED OVER TO THE USER, WHO WILL ALWAYS HAVE
THEM IN HIS POSSESSION. IF THE USER LOSES THEM, HE
CAN REQUEST A COPY OR DOWNLOAD THEM DIRECTLY
FROM THE WEBSITE WWW.SMINN.COM.
The manufacturer reserves the right to change the
speci cations of the devices as well as this manual without
prior notice. The device may only be operated by trained
and/or suitably instructed personnel.
WARRANTY
This product has been subjected during its manufacturing
process to a complete TEST that guarantees its reliability and
proper functioning.
The manufacturer grants the product a warranty of 36
months from the date printed on the product and against any
anomaly that the product may present in its appearance or
functionality.
Excluded from this warranty are damages caused by third
parties, natural causes ( ood, re, lightning, etc.), improper
handling or installation, vandalism and, in general, any cause
not attributable to the manufacturer.
The scope of the warranty is limited to the repair or
replacement of the damaged element. Excluded from the
guarantee are the expenses that could be derived from
assembly, displacement, transport, parts subject to wear and
tear, etc. and in general any expenses that are not for the
repair or replacement of the damaged element of the device.
The installer/distributor must request from the manufacturer
an RMA number or authorisation to send the equipment
under warranty. Without this prerequisite, the manufacturer
will not be able to process or honour the warranty.
WARNING
The product must be used for its intended purpose and any
other use is considered inappropriate.
Packaging and containers must NOT be disposed of in the
environment. Keep products, packaging, containers,
documentation, etc. out of the reach of children. Follow
applicable local, national and European regulations.
The information contained in this document may contain
errors which will be corrected in subsequent editions. The
manufacturer reserves the right to modify the contents of this
document or the product without prior notice.
