Summary of Contents for Jazz ENVIRA-NORTH System limited

  • Page 1 Installation Installation & Operation & Operation User Guide User Guide...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents OVERVIEW OVERVIEW ..........................4 4 COMPONENTS ............. 4 TECHNICAL DATA TECHNICAL DATA ......................5 5 FUSING & THERMAL LIMITING FUSING & THERMAL LIMITING ..............6 6 FUSES ................6 THERMAL LIMITING............6 SAFETY SAFETY ...............
  • Page 3 FIRE SHUTDOWN CONNECTION (OPTIONAL) .... 27 MAINTENANCE MAINTENANCE ........................28 RECOMMENDED MAINTENANCE SCHEDULE ....28 LIMITATION OF WARRANTY & LIABILITY LIMITATION OF WARRANTY & LIABILITY ........30 THREE YEAR LIMITED WARRANTY ....... 30 WARRANTY EXCLUSIONS ..........31 WARRANTY DURATION ..........32 WARRANTY CLAIM INSTRUCTIONS ......32 FIFTEEN YEAR SERVICE LIFE PRORATED WARRANTY ..34 FIFTEEN YEAR SERVICE PRORATED WARRANTY FORM 39...

  • Page 4: Overview

    (2) EN823X6955 [3 mm] 1/8” Cable Clamp Zinc EN561X2505 Mount Assembly Optional Custom Lengths Available EN575X0010 Jazz Motor Assembly Hub Cover (5) Jazz Blades (Not Shown) Note: All bolts are “Grade 5” LED Light Kit EN561X3675 (#) = Quantity Supplied Or Lens (below)

  • Page 5: Technical Data Technical Data

    Technical Data Technical Data Conformity Low Voltage (2006/95/EC) & EMC (2004/108/EC) Directives EN61000-6-2:2005, EN61000-6- 4:2007 IEC 60335-2-80:2015 IEC 60335-1:2015 Approvals UL61800-5-1 CSA C22.2 No113 ≤2% Input Voltage Phase Imbalance Input Voltage 120-240 VAC Input Current 4.6 @ 120VAC, 2.5A @ 240VAC Input Frequency 50-60Hz Supported Power Systems...

  • Page 6: Fusing & Thermal Limiting Fusing & Thermal Limiting

    For 110-120 VAC use a fast blow fuse rated 10 Amps. THERMAL LIMITING THERMAL LIMITING The Jazz Fan System is designed to monitor motor and controller temperatures and in the event, that operating temperatures exceed control limits, fan speed will automatically reduce until the system...

  • Page 7: Safety Safety

    Safety Safety ELECTRICAL SAFETY ELECTRICAL SAFETY WARNING! IGNORING THE FOLLOWING WARNING! IGNORING THE FOLLOWING INSTRUCTIONS CAN CAUSE PHYSICAL INJURY OR INSTRUCTIONS CAN CAUSE PHYSICAL INJURY OR DEATH, OR DAMAGE TO THE EQUIPMENT. DEATH, OR DAMAGE TO THE EQUIPMENT. WARNING! ONLY QUALIFIED ELECTRICIANS WARNING! ONLY QUALIFIED ELECTRICIANS ARE ALLOWED TO INSTALL THE DRIVE AND ARE ALLOWED TO INSTALL THE DRIVE AND...

  • Page 8: Clearances

    CLEARANCES CLEARANCES • Open ceiling, center of fan to roof deck for ideal operating performance without compromising overall fan performance. • Min 12” [304.8 mm] from fan blade’s leading edge to obstruction above or below fan. • Min 8” [203 mm] from side of fan to any obstruction. •...

  • Page 9: Installation Preparation Installation Preparation

    • Ensure work area is safe and that all security, policies and procedures for the facility are met. • Inspect the lift device or mobile platform. • Each person installing the Jazz Fan must use a safety harness at all times. • Other safety requirements may be required for installation.

  • Page 10: Tools Required

    • (1) EN561X3660 Jazz LF/SP Assembly • (1) EN561X6205 Packaged Assembly Hardware • (1) EN561X3570 Packaged HMI Control • (1) EN561X3635 Packaged Wire Harness • (1) EN561X3675 Jazz LED Light Kit (Or Lens) • (1) Hub Cover (Optional Color) HARDWARE INCLUDED HARDWARE INCLUDED •...
  • Page 11 • (4) EN823X6031 ¼ x 1 ¼ Hex Cap Screw • (3) EN823X6008 3/8 x 1 ½ Hex Cap Screw • (1) EN562X2540 Jazz Stand Off Ring NOTE: Illustrations may be changed without notice. All dimensions and specifications are approximate and drawings are not to scale.

  • Page 12: Installation Procedure Installation Procedure

    INSTALLATION OF THE MOUNTING HARDWARE NOTE: Consult a structural engineer before installation. Choose one of the following mounting options for your Jazz Fan and follow the corresponding steps. The mounting kits included in the Jazz Fan package are glu-lam, purlin, OWSJ and web truss.
  • Page 13 4. Before fastening the mounting brackets install four ¼” x 1-1/4” long hex cap screws (EN823X6031) with ¼” flat washers (EN823X6905) into mounting bracket deck facing down. 5. Using a 3/8” X 9” threaded rod with welded nut (EN823X8313) and 3/8” nylock nut (EN823X6999), suspend the mounting brackets using the center bottom hole only.
  • Page 14 PURLIN MOUNT PURLIN MOUNT 1. From an accessible landmark, on the first purlin, measure to the centre line of the bottom centered hole of the 3 mounting holes. 2. Drill the centered bottom mounting hole with a ½” drill bit, so that there will be a minimum of ¾”...
  • Page 15 using four ¼” flat washers (EN823X6905) and four ¼ nylocks (EN823X6312). 9. Continue on to “Installing the Motor Assembly”. OWSJ MOUNT OWSJ MOUNT 1. Insert two 3/8” X 9” long threaded rod with welded nut (EN823X8313) through the studded mounting plate pointing upward.
  • Page 16 WOOD TRUSS MOUNT WOOD TRUSS MOUNT Insert two 3/8” X 9” long threaded rod with welded nut (EN823X8313) through the studded mounting plate pointing upward. Place the studded mounting plate against bottom face of the truss straddling the threaded rods around the bottom chord.

  • Page 17: Installing The Motor Assembly

    INSTALLING THE MOTOR ASSEMBLY INSTALLING THE MOTOR ASSEMBLY 1. Place round stand-off (EN562X2540) on top of flange of fan assembly. 2. Ensure power wire, communication wire and safety cable are directed through either a hole on side of stand-off ring (EN562X2540) or up through the centre of the studded mount assembly (EN562X2510).

  • Page 18: Installing Blades

    INSTALLING BLADES INSTALLING BLADES 1. Using 3/8” socket fasten Jazz blade (EN501X2000) to hub plate on the bottom of the motor assembly (EN571X0010). 2. Insert four ¼” x 5/8” serrated flange hex cap screws (EN823X6031) through all four holes in blade.

  • Page 19: Installing The Optional Led Light Kit

    INSTALLING THE OPTIONAL LED LIGHT KIT INSTALLING THE OPTIONAL LED LIGHT KIT CAUTION! TO REDUCE THE RISK OF FIRE, ELECTRIC CAUTION! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, DISCONNECT THE SHOCK, OR INJURY TO PERSONS, DISCONNECT THE ELECTRICAL SUPPLY CIRCUIT TO THE FAN BEFORE ELECTRICAL SUPPLY CIRCUIT TO THE FAN BEFORE INSTALLING LIGHT KIT.

  • Page 20: Installing The Hub Cover (With Lens)

    4. Plug the LED panel light into the power wire. 5. Install the four - #6 x 3/8 screws (EN022X0402) and the two electrical box clips (EN562X2490) to secure the LED panel light (EN562X2475) to the electrical box (EN562X2480) in the same manner it was packaged.

  • Page 21: Electrical Installation Electrical Installation

    However, as the Jazz Fan EN575X0010 does not have a built-in surge suppression device, it is highly recommended to install a Jazz LF/SP Assembly (EN561X3660) or other surge suppression device on the fans input power line to protect the fans electrical system.
  • Page 22 JAZZ LF/SP ASSEMBLY (EN561X3660) JAZZ LF/SP ASSEMBLY (EN561X3660) EUROPE (CE) – REQUIRED EUROPE (CE) – REQUIRED NORTH AMERICA (UL/CSA) – OPTIONAL NORTH AMERICA (UL/CSA) – OPTIONAL 1. The power input & output cables are to be installed into the bottom of the enclosure and should be drilled to accommodate a cable gland for the appropriate gauge of wire required in accordance with applicable electrical codes and standards.
  • Page 23 WIRING – WITH JAZZ LF/SP ASSEMBLY (EN561X3660) WIRING – WITH JAZZ LF/SP ASSEMBLY (EN561X3660)

  • Page 24: Hmi Control Hmi Control

    (30m) CAT 5 cable using supplied fasteners. It is recommended the fan remain in line of site of the HMI. JAZZ HMI CONTROL JAZZ HMI CONTROL The bottom left button toggles ‘Light’ to ‘Fan’ depending on what functionality you are looking to set or adjust. When the screen says ‘Fan’, the remaining buttons on the keypad are controlling...

  • Page 25: Multi-Fan Control (Optional)

    NOTE: The Jazz Fan System is designed to monitor motor and controller temperatures and in the event that operating temperatures exceed control limits, fan speed will reduce until the system is within temperature limits. No user intervention is needed. MULTI-FAN CONTROL LAYOUT (OPTIONAL)

  • Page 26: Advanced Controls (Smartair/Touchair)

    ADVANCED CONTROLS (SmartAIR/TouchAIR) ADVANCED CONTROLS (SmartAIR/TouchAIR) • For full integration instructions with Modbus controls, refer to the manual included with the controller ordered. For ease of installation, the Modbus controls utilize Cat5 cables to facilitate the integration of the VFDs with the control. Under ideal conditions, the controls can support: Number of Max Cable...

  • Page 27: Fire Shutdown Connection (Optional)

    FIRE SHUTDOWN CONNECTION (OPTIONAL) FIRE SHUTDOWN CONNECTION (OPTIONAL) To integrate fan controls with a fire detection / suppression system use supplied connector to wire to a relay contact in fire system enclosure as shown below.

  • Page 28: Power Cord

    Maintenance Maintenance WARNING! RISK OF SHOCK! WARNING! RISK OF SHOCK! ONLY QUALIFIED PERSONNEL TO REMOVE ONLY QUALIFIED PERSONNEL TO REMOVE DRIVE COVER! THERE IS NO ADJUSTMENTS DRIVE COVER! THERE IS NO ADJUSTMENTS OR REPLACEMENT PARTS FOR THE USE! OR REPLACEMENT PARTS FOR THE USE! TERMINALS: TERMINALS: Power Terminal: 3A, 300V, 10-30 AWG Torque = 0.5-0.6 Nm...
  • Page 29 6. All personnel working on the fan, mount, or guy wires, shall wear the appropriate personal safety equipment as mandated by local, provincial, and national regulations. 7. A risk assessment shall be performed before any maintenance is done on the fan, mount, guy wires and fan controller. 8.

  • Page 30: Limitation Of Warranty & Liability Limitation Of Warranty & Liability

    Limitation of Warranty & Liability Limitation of Warranty & Liability THREE YEAR LIMITED WARRANTY THREE YEAR LIMITED WARRANTY Jazz Fans should provide many years of virtually maintenance-free use. Warranty duration is as follows: Blades 3 year Limited Warranty Mount 3 year Limited Warranty...

  • Page 31: Warranty Exclusions

    WARRANTY EXCLUSIONS WARRANTY EXCLUSIONS Please note that the following may or could void any or all of the above listed Warranties. • Not following required installation procedures as in installation guide and all other documentation supplied with the fans and related equipment, supplied by manufacturers of individual fan and control components.

  • Page 32: Warranty Duration

    established by the instructions, codes and standards, regardless of when the installation occurred. With regard to electrical and electronic components provided by Envira-North that comprise part of the Products, including motors, motor drives and variable frequency drives, Envira-North relies on the determination by the original manufacturer as to whether the failure of such component was the result of a defect.
  • Page 33 PO. This PO allows for an order to be established in the Envira- North System. 7. Once the units have been changed over, submit all pre- approved costs to Envira-North for payment. 8. All items being returned for warranty consideration will be required to arrive at 139 Sparling Street, Seaforth, Ontario, Canada, N0K1W0, no later than 45 days from the date your RGA (Return Goods Authorization) is issued.

  • Page 34: Fifteen Year Service Life Prorated Warranty

    LIMITED WARRANTY: This prorated limited warranty (this “Warranty”) applies only to the original End-User (the “End- User”) of any Envira-North Systems’ Jazz Fan(s) (Individually and collectively, the “Product”) and cannot be transferred. This Warranty applies even in the event that the Product is initially sold by Company for resale to End-User.

  • Page 35: What This Warranty Does Not Cover

    For the avoidance of doubt, Company’s responsibilities under this Warranty are as follows: YEAR 1-3 YEAR 1-3 - Product repaired or replaced pursuant to terms if Limited Warranty applies YEAR 4-15 YEAR 4-15 - Unit Credit ($) = Current List Price X Years of Unexpired Life 15 Years of Warranted Life WHAT THIS WARRANTY DOES NOT COVER:...

  • Page 36: Limitation Of Liability

    Registration Form within thirty (30) days of purchase; • If the Product’s serial numbers have been removed or are illegible; • If any warranted items repaired or replaced pursuant to this Warranty will be warranted for the remaining portion of the original Warranty subject to all the terms thereof.

  • Page 37: Other Limitations

    Schedule, minimum every 18 months. OTHER LIMITATIONS: OTHER LIMITATIONS: Company’s obligations under this Warranty are expressly conditioned upon receipt by Company of all payments due to it, including all applicable interest charges. During such time as Company has not received payment of any amount due to it for the Product, in accordance with the contract terms under which the Product is sold, Company shall have no obligation under this Warranty.

  • Page 39: Fifteen Year Service Prorated Warranty Form

    FIFTEEN YEAR SERVICE LIFE PRORATED WARRANTY FORM FIFTEEN YEAR SERVICE LIFE PRORATED WARRANTY FORM The Jazz Fan is covered by our standard Three Year Limited Warranty. To register for our extended Fifteen Year Prorated Limited Warranty, you must complete and return this form within 30 days of purchase by fax to 1(519)527-2560 OR email bigair@ enviranorth.com.
  • Page 40 1-866-771-7766 bigair@enviranorth.com enviranorth.com...
