VCB601‐ZB01 User Manual
EFR32MG1B232F256GM48802.15.4ZigbeeModule
Rev. 1.0
2017/07/18
Notice:
1.
Delta Networks (XIAMEN) LTD.reserves the right to change specifications detailed in this document at any time without notice,
andassumesnoresponsibilityforanyerrorswithinthisdocument.
2.
This document contains proprietary technical information in which is the property of the Delta Networks (XIAMEN) LTD.and shall not be disclosed to others in whole
or in part, reproduced, copied, or used as the basis for design, manufacturing,orsaleofapparatuswithoutwrittenpermissionofDelta Networks (XIAMEN) LTD.Inc.
VCB601‐ZB01 User Manual
1
Advertisement
Table of Contents
Summary of Contents for Fuda VCB601-ZB01
- Page 1 VCB601‐ZB01 User Manual EFR32MG1B232F256GM48802.15.4ZigbeeModule Rev. 1.0 2017/07/18 Notice: Delta Networks (XIAMEN) LTD.reserves the right to change specifications detailed in this document at any time without notice, andassumesnoresponsibilityforanyerrorswithinthisdocument. ...
- Page 2 Table of Content PRODUCTOVERVIEW ........................ 1 GENERALDESCRIPTION ...................... 3 1.1. FEATURES ............................ 3 1.2. REVISIONHISTORY ........................ 4 VCB601‐ZB01 User Manual...
-
Page 3: Product Overview
ProductOverview 1.1. GeneralDescription The VCB601‐ZB01 is a Zigbee data collector module which can collect data from other devices WithTTL serial port and then send out data throughZigbee. This device is built in Silicon LAB EFR32MG1B232F256GM48 which is a highly integrated single‐chip low power Wireless on Chip controller. The EFR32MG1B232F256GM48combines an ARM‐Cortex M4with DSP instruction,MCUand 2.4G RF in a single chip. It provides UART interface. It also provides a bunch of configurable GPIOs which are configured as digital peripherals for different applications and controls. 1.2. Features IEEE802.15.4 in 2.4G Bandcompatible UART interface ... -
Page 4: Revision History
RevisionHistory Revision Date By Whom Remark 1.0 07/18‐2017 Yuanqiang.xu Initialize ... -
Page 5: Federal Communication Commission Interference Statement
Statement Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: ... - Page 6 End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: 2AMVP‐VCB601”. The grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warnin VCB601‐ZB01 User Manual...
