Summary of Contents for Lane LRG

  • Page 1 Operators Manual LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 2: Introduction

    Introduction_______________________________ This manual is designed to provide detailed steps on how to successfully operate your LRG 1010F Figure 8 trailer. Your LRG 1010F is manufactured by LANE Trailer Manufacturing Co. The LRG 1010F trailer consists of a figure-eight attachment a retriever/rewinder arm, and a Honda Gx 390 motor skid that contains and operates the hydraulic systems for your trailer.

  • Page 3: Table Of Contents

    Table of Contents__________________________ Table of Contents Introduction_______________________________ ........................2 Table of Contents__________________________ ........................3 Safety ___________________________________ ........................12 Safety Alerts and Signal Words .............................. 12 Safety___________________________________ ........................13 Major Hazards ..................................13 Safety___________________________________ ........................14 Improper Sizing of Trailer Tow Vehicle ..........................14 Driving Too Fast .................................
  • Page 4 Safety___________________________________ ........................25 Safety___________________________________ ........................26 Safety___________________________________ ........................27 Reporting Safety Defects ..............................27 Tire Safety________________________________ ........................28 Trailer Tire Information ................................28 Tire Safety________________________________ ........................29 Steps For Determining Correct Load Limit → Trailer ......................29 Tire Safety________________________________ ........................30 Trailers Under 10,000-pound GVWR ..........................
  • Page 5 Tire Safety________________________________ ........................41 Tire Safety Tips and Checklist ............................41 Coupling to Tow Vehicle_____________________ ........................42 Tow Vehicle and Hitch ................................42 Trailer Information ................................42 Coupling to Tow Vehicle_____________________ ........................43 Tow Vehicle ..................................43 Coupling and Uncoupling the Trailer ............................. 43 Coupling to Tow Vehicle_____________________ ........................
  • Page 6 Coupling to Tow Vehicle_____________________ ........................55 Uncouple Trailer ..................................55 Tongue Weight ..................................55 Coupling to Tow Vehicle_____________________ ........................56 Tongue Weight ..................................56 Checking Tongue Weight ..............................56 Coupling to Tow Vehicle_____________________ ........................57 Adjust Hitch Height (If Equipped) ............................57 Loading and Unloading_____________________ ........................
  • Page 7 Accessory Battery ................................... 67 Inspection Service and Maintenance__________ ........................68 Inspection Service and Maintenance Summary Charts ......................68 Inspection Service and Maintenance__________ ........................71 Inspection and Service Instructions............................71 Trailer Structure .................................. 71 Fasteners and Frame Members ............................71 Inspection Service and Maintenance__________ ........................72 Welds ....................................
  • Page 8 Recommended Fluids ................................84 Self-Loading Reel System___________________ ........................85 Steps For operating The Self-Loading Reel System ......................85 Breakdown of Your LRG Electric-Hydraulic Trailer ......................... 88 Breakdown of Your Electric-Hydraulic System ......................... 89 Recommended Fluids ................................89 Operation of Your Electric-Hydraulic Trailer ..........................90 Self-Loading Reel System___________________ ........................
  • Page 9 While operating your LRF 1010F it is possible that an error code may show up on your HCU. In this section the error code type and possible solutions to the error will be laid out. If your issue persists, please visit a repair technician or LANE Trailer manufacturing’s website: www.lanetrailers.com or call 515-233-1150 to speak to a repair technician.
  • Page 11 General Trailer Safety Information LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 12: Safety

    Safety ___________________________________ ⚠ WARNING This Owner’s Manual contains safety information and instructions for your trailer. You must read this manual before loading or towing your trailer. You must follow all safety precautions and instructions. Safety Alerts and Signal Words Owner’s Manual that provides general trailer information cannot cover all of the specific details necessary for the proper combination of every trailer, tow vehicle and hitch.

  • Page 13: Safety

    Safety___________________________________ The level of risk is indicated by the following signal words: ⚠ DANGER DANGER - Indicates a hazardous situation, which, if not avoided, WILL result in death or serious injury. ⚠ WARNING WARNING - Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 14: Safety

    Safety___________________________________ Improper Sizing of Trailer Tow Vehicle Trailers that weigh too much for the tow vehicle can cause stability problems, which can lead to death or serious injury. The additional strain put on the engine and drivetrain may lead to serious tow vehicle maintenance problems.

  • Page 15: Safety

    Safety___________________________________ Adjust Driving When Towing Trailer When towing a trailer, you will have decreased acceleration, increased stopping distance, and increased turning radius. The trailer will change the handling characteristics of the tow vehicle, making it more sensitive to steering inputs and more likely to be pushed around in windy conditions or when being passed by large vehicles. In addition, you will need a longer distance to pass, due to slower acceleration and increased length.

  • Page 16: Safety

    Safety___________________________________ Trailer Not Properly Coupled to Hitch It is critical that the trailer be securely coupled to the hitch, and that the safety chains and emergency breakaway brake lanyard are correctly attached. Uncoupling may result in death or serious injury to you and to others. ⚠...

  • Page 17: Safety

    Safety___________________________________ Proper Connection of Breakaway Brake If equipped with brakes, your trailer will be equipped with a breakaway brake system that can apply the brakes on your trailer if your trailer comes loose from the hitch. You may have a separate set of instructions for the breakaway brake if the trailer is so equipped.

  • Page 18: Safety

    Safety___________________________________ Worn Tires, Loose Wheels and Lug Nuts Inspect all trailer tires before each tow. If a tire has a bald spot, bulges, cut, cracks, or is showing any cords, replace the tire before towing. If a tire has uneven tread wear, take the trailer to a trailer service center for diagnosis. Uneven tread wear can be caused by tire imbalance, axle misalignment or incorrect inflation.

  • Page 19: Safety

    Safety___________________________________ The proper tightness (torque) for wheel nuts or bolts and tightening sequence is listed in the Inspection, Service and Maintenance section of this manual. Use a torque wrench to tighten the lug nuts and use the crisscross star pattern sequence. Improper tightening of the lug nuts voids the axle warranty. Wheel nuts or bolts are also prone to loosen after first being assembled.

  • Page 20: Safety

    Safety___________________________________ Unsafe Load Distribution Improper front / rear load distribution can lead to an unstable trailer or poor tow vehicle handling. Poor trailer stability results from tongue weights that are too low, and poor tow vehicle stability results from tongue weights that are too high.

  • Page 21: Safety

    Safety___________________________________ Shifting Cargo Since the trailer “ride” can be bumpy and rough, you must secure the cargo so that it does not shift while the trailer is being towed. ⚠ WARNING A shifting load can result in failure, or to loss of control of the trailer, and can lead to death or serious injury.

  • Page 22: Safety

    Safety___________________________________ ⚠ WARNING Improper electrical connection between the tow vehicle and the trailer will result in inoperable lights and electric brakes and can lead to collision. Before each tow: • Check that the electric brakes work by operating the brake controller inside the tow vehicle. Check that all lights and turn signals work.

  • Page 23: Safety

    Safety___________________________________ It will take practice to learn how to back up a tow vehicle with a trailer attached. Take it slow. Before backing up, get out of the tow vehicle and look behind the trailer to make sure that there are no obstacles. Some drivers place their hands at the bottom of the steering wheel, and while the tow vehicle is in reverse, “think”...

  • Page 24: Safety

    Safety___________________________________ Slow down for bumps in the road. Do not brake while in a curve unless absolutely necessary. Instead, slow down before you enter the curve. Do not drive so fast that the trailer begins to sway due to speed. Generally, never drive faster than 55 m.p.h. Allow plenty of room for passing.

  • Page 25: Safety

    Safety___________________________________...

  • Page 26: Safety

    Safety___________________________________...

  • Page 27: Safety

    If you believe that your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying. LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 28: Tire Safety

    Tire Safety________________________________ This portion of the User’s Manual contains tire safety information as required by 49 CFR 575.6. This brochure, as well as preceding subsections, describes the following items. Tire labeling, including a description and explanation of each marking on the tires, and information about the DOT •...

  • Page 29: Tire Safety

    Tire Safety________________________________ High speed towing in hot conditions degrades trailer tires significantly. As heat builds up during driving, the tire’s internal structure starts to breakdown, compromising the strength of the tire. It is recommended to drive at moderate speeds. Statistics indicate the average life of a trailer tire is about five years under normal use and maintenance conditions.

  • Page 30: Tire Safety

    Tire Safety________________________________ Trailers Under 10,000-pound GVWR Locate the statement, “The weight of cargo should never exceed XXX kg or XXX lbs.,” on your vehicle’s placard. This figure equals the available amount of cargo and luggage load capacity. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity.

  • Page 31: Tire Safety

    Tire Safety________________________________ Glossary Of Tire Terminology Accessory weight: The combined weight (in excess of those standard items which may be replaced) of automatic transmission, power steering, power brakes, power windows, power seats, radio and heater, to the extent that these items are available as factory installed equipment (whether installed or not).

  • Page 32: Tire Safety

    Tire Safety________________________________ Innerliner separation: The parting of the innerliner from cord material in the carcass. Intended outboard sidewall: The sidewall that contains a white wall, bears white lettering or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire or the outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounted on a vehicle.

  • Page 33: Tire Safety

    Tire Safety________________________________ Overall width: The linear distance between the exteriors of the sidewalls of an inflated tire, including elevations due to labeling, decorations, or protective bands or ribs. Pin Weight: The downward force applied to the 5th wheel or gooseneck ball, by the trailer kingpin or gooseneck coupler.

  • Page 34: Tire Safety

    Tire Safety________________________________ Test rim: The rim on which a tire is fitted for testing and may be any rim listed as appropriate for use with that tire. Tread: That portion of a tire that comes into contact with the road. Tread rib: A tread section running circumferentially around a tire.

  • Page 35: Tire Safety

    Tire Safety________________________________ Improve vehicle handling. • Help protect you and others from avoidable breakdowns and accidents. • Improve fuel economy. • Increase the life of your tires. • This booklet presents a comprehensive overview of tire safety, including information on the following topics: Basic tire maintenance •...

  • Page 36: Tire Safety

    Tire Safety________________________________ Manufacturers of passenger vehicles and light trucks determine this number based on the vehicle’s design load limit, that is, the greatest amount of weight a vehicle can safely carry and the vehicle’s tire size. The proper tire pressure for your vehicle is referred to as the “recommended cold inflation pressure.” (As you will read below, it is difficult to obtain the recommended tire pressure if your tires are not cold.) Because tires are designed to be used on more than one type of vehicle, tire manufacturers list the “maximum permissible inflation pressure”...

  • Page 37: Tire Safety

    Tire Safety________________________________ Tire Tread The tire tread provides gripping action and traction that prevents your vehicle from slipping or sliding, especially when the road is wet or icy. In general, tires are not safe and should be replaced when the tread is worn down to 2/32 of an inch.

  • Page 38: Tire Safety

    Tire Safety________________________________ Information on Passenger Vehicle Tires P: The “P” indicates the tire is for passenger vehicles. Next number: This three-digit number gives the width in millimeters of the tire from sidewall edge to sidewall edge. In general, the larger the number, the wider the tire. Next number: This two-digit number, known as the aspect ratio, gives the tire’s ratio of height to width.

  • Page 39: Tire Safety

    Tire Safety________________________________ Note: You may not find this information on all tires because it is not required by law. U.S. DOT Tire Identification Number: This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code where it was manufactured, and the last four numbers represent the week and year the tire was built.

  • Page 40: Tire Safety

    Tire Safety________________________________ Additional information on Light Truck Tires Tires for light trucks have other markings besides those found on the sidewalls of passenger tires. LT: The “LT” indicates the tire is for light trucks or trailers. ST: An “ST” is an indication the tire is for trailer use only. Max.

  • Page 41: Tire Safety

    Tire Safety________________________________ Tire Safety Tips and Checklist Preventing Tire Damage Slow down if you have to go over a pothole or other object in the road. • Do not run over curbs or other foreign objects in the roadway and try not to strike the curb when parking. •...

  • Page 42: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Follow all the safety precautions and instructions in this manual to ensure safety of persons, cargo, and satisfactory life of the trailer. Tow Vehicle and Hitch If the vehicle and hitch are not properly selected and matched to the Gross Vehicle Weight Rating (GVWR) of your trailer, you can cause an accident that could lead to death or serious injury.

  • Page 43: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ by the trailer axle(s). The total weight of the cargo and trailer must not exceed the GVWR, and the load on an axle must not exceed its GAWR. TIRE SIZE: The tire size and load range for your trailer. RIM SIZE: The rim size and load range for your trailer.

  • Page 44: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Trailer lighting (and braking) connector: A device that connects electrical power from the tow vehicle to the trailer. In addition, if your trailer has a separate braking system, the electrical connector will also supply power to the trailer brakes from the tow vehicle.

  • Page 45: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Ball Hitch Coupler A ball hitch coupler connects to a ball that is located on or under the rear bumper of tow vehicle. We have utilized a ball hitch coupler that is suitable for the size and weight of the trailer. The load rating of the coupler and the necessary ball size are listed on the trailer tongue.

  • Page 46: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ ⚠ WARNING A loose hitch ball nut can result in uncoupling, leading to death or serious injury. Make sure the hitch ball is tight to the hitch before coupling the trailer. Prepare Coupler and Hitch Lubricate hitch ball and inside of coupler with a thin layer of automotive bearing grease. Remove safety latch pin and open coupler locking mechanism.

  • Page 47: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ If the coupler cannot be secured to the hitch ball, do not tow the trailer. Contact your dealer for assistance. Lower the trailer so that its entire tongue weight is held by the hitch and continue retracting the jack to its fully retraced position.

  • Page 48: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Before Coupling Trailer to Tow Vehicle Be sure the size and rating of pintle match the size and rating of the ring. Hitch ring and pintles are marked with their size and rating. Wipe the pintle clean and inspect it visually and by feel for flat spots, cracks, and pits. ⚠...

  • Page 49: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ 4. See the coupler instructions for details of placing the pintle in the “open” position. 5. Slowly back up the tow vehicle so that the pintle is aligned under the ring. Couple Trailer to Tow Vehicle 1.

  • Page 50: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Connect Safety Chains 1. Visually inspect the safety chains and hooks for wear or damage. Replace worn or damaged safety chains and hooks before towing. 2. Safety chains must crisscross under the coupler so if the trailer uncouples, the safety chains can hold the tongue up above the road.

  • Page 51: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Connect Electrical Cable Connect the trailer lights to the tow vehicle’s electrical system using trailer electrical cable. Check all lights for proper operation. Repair or replace non-working lights before towing trailer. Check electric brakes for proper operation using brake controller mounted in the cab. ⚠...

  • Page 52: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ While towing the trailer at less than 5 mph, manually operate the electric brake controller in the tow vehicle. You should feel the operation of the trailer brakes. If the trailer brakes are not functioning, the brake system MUST be evaluated to determine the cause of the problem and corrective action MUST be taken before the trailer is used.

  • Page 53: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Test Electrical Breakaway Brakes ⚠ ⚠ WARNING WARNING An ineffective breakaway brake system can Failure to replace the pull pin can result in ineffective brakes, leading to loss of control, result in a runaway trailer, leading to death or serious injury or death.

  • Page 54: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Test Surge Breaks (If Equipped) Move the trailer to flat, level ground, pulling FORWARD several feet before parking. This forward motion will ensure trailers equipped with free-backing brakes are in their normal operating mode. Disconnect the trailer from the tow vehicle and jack up the trailer’s tongue until it is horizontal.

  • Page 55: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Uncouple Trailer Follow these steps to uncouple trailer from the tow vehicle: Park the trailer on a firm level surface and block trailer tires. Disconnect electrical connector. Disconnect breakaway brake switch lanyard. Disconnect safety chains from tow vehicle. Unlock the coupler and open it.

  • Page 56: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Tongue Weight The numbers quoted are for example purposes only and should be tailored to the specific trailer. For questions regarding the actual percent of tongue weight for the trailer, check with the manufacturer for specifics. ⚠...

  • Page 57: Coupling To Tow Vehicle

    Coupling to Tow Vehicle_____________________ Adjust Hitch Height (If Equipped) The height of the hitch on the trailer must be adjusted so that the trailer, when loaded to rated capacity, is level while connected to the tow vehicle. A level trailer allows equal weight distribution on the axles. Your dealer or a trailer service center can perform this adjustment, or you can use the following steps to adjust the hitch height yourself.

  • Page 58: Loading And Unloading

    Loading and Unloading_____________________ Improper trailer loading causes many accidents and deaths. To safely load a trailer, you must consider: Overall load weight. • Load weight distribution. • Proper tongue weight. • Securing the load properly. • To determine that you have loaded the trailer within its rating, you must consider the distribution of weight, as well as the total weight of the trailer and its contents.

  • Page 59: Loading And Unloading

    Loading and Unloading_____________________ Loading Trailer Prepare Trailer for Loading Inspect the floor of the trailer. Inspect the tie down rings and track system for damage, looseness or signs of bending before loading the trailer. Park the tow vehicle and trailer on a firm and level surface. Clear the area around the trailer.

  • Page 60: Loading And Unloading

    Loading and Unloading_____________________ Loading a Rigid Deck Trailer ⚠ CAUTION Use a safe lifting procedure to avoid injury when handling ramps. ⚠ WARNING Load can suddenly move or topple, which can result in death or serious injury. Do not load or unload trailer unless coupled to tow vehicle and is on a firm and level surface.

  • Page 61: Loading And Unloading

    Loading and Unloading_____________________ Manual Tilt Trailers ⚠ WARNING Trailer must be coupled to tow vehicle before loading trailer ⚠ ⚠ WARNING WARNING An unlocked pivoting deck can result in loss Do not transport flammable, explosive, of cargo or loss of control of the trailer, poisonous or other dangerous materials on which can result in death or serious injury.

  • Page 62: Loading And Unloading

    Loading and Unloading_____________________ Unload Trailer Unload Manual Tilt Trailer Couple the trailer to the tow vehicle. Park the tow vehicle and trailer on a firm and level surface. Clear the area around the trailer. Remove chains, straps and tensioning devices. Release deck latch pin to pivot trailer deck for unloading.

  • Page 63: Loading And Unloading

    Loading and Unloading_____________________ Unload Hydraulic Tilt Trailer Press and hold button to lower the tilt deck. Release the button when the tilt deck is in the driving position. Stow controller. ⚠ WARNING Trailer must be coupled to tow vehicle before loading trailer Hydraulic Components Do not alter or substitute and hydraulic components on the trailer.

  • Page 64: Pre-Tow Checklist

    Pre-Tow Checklist__________________________ Pre-Tow Checklist Before towing, double-check all these items: Tires, wheels, and lug nuts. See “Breaking in A New Trailer” section of this manual. • Tire Pressure. Inflate tires on trailer and tow vehicle to the pressure stated on the Certification / VIN label. •...

  • Page 65: Breaking In A New Trailer

    Breaking In a New Trailer____________________ Retighten Lugs at First 10, 25, and 50 Miles Wheel lugs can shift and settle quickly after being first assembled, and must be checked after the first 10, 25 and 50 miles of driving. Failure to perform this check may result in a wheel coming loose from the trailer, causing a crash leading to death or serious injury.

  • Page 66: Breaking In A New Trailer

    Breaking In a New Trailer____________________ Synchronizing Brake Systems Trailer brakes are designed to work in synchronization with the brakes on the tow vehicle. When the tow vehicle and trailer braking systems are synchronized, both braking systems contribute to slowing, and the tongue of the trailer will neither dive nor rise sharply.

  • Page 67: Accessories

    Accessories_______________________________ This section provides some basic information for the safe operation of accessories. You must read and follow these instructions before using the accessory. If you are uncertain whether you have all of the instructions, contact your dealer before operating the accessory. Accessory Battery Your trailer may be equipped with an accessory battery that operates the tilt deck.

  • Page 68: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Inspection Service and Maintenance Summary Charts You must inspect, maintain and service your trailer regularly to insure safe and reliable operation. If you cannot or are unsure how to perform the items listed here, have your dealer do them. Note: In addition to this manual, also check the relevant component manufacturer’s manual.
  • Page 69 Wheels - Lug Nuts Or Bolts Check for tightness. & Hub Tighten. For new and remounted wheels, check torque after first 10, 25 & 50 miles of driving and after any impact. Inspection And Service Every Month Item Inspection / Service Notes Lubrication Lubricate tilt deck pivot points (if equipped).
  • Page 70 Ring And Pintle Check for cracks, pits, and flats. Replace w/ ring and pintle having trailer GVW Rating. Grease. Check locking device & replace when worn. Inspection And Service Every Year or 12,000 Miles Item Inspection/Service Notes Brakes, all types. Check for scoring and wear.

  • Page 71: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Inspection and Service Instructions To perform many of the inspection and maintenance activities, you must jack up the trailer. When jacking and using jack stands, place them so as to clear wiring, brake lines, and suspension parts (springs, torsion bars, etc.).

  • Page 72: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Welds All welds can crack or fail when subjected to heavy loads or movement of cargo that was not properly secured. Any time that you know or suspect that the trailer has been subjected to heavy loads or movement of cargo, immediately inspect the welds and fasteners for damage.

  • Page 73: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Manually Adjusting Brake Shoes Some braking systems are not automatically adjusted. These brakes require manual adjustment. The following steps apply to adjust most manually adjustable brakes. Read your axle and brake manual to see how to adjust your brakes. If you do not have this manual, contact your dealer for assistance.

  • Page 74: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Tow Vehicle Operated Electric Brakes The electric brakes that operate in conjunction with the tow vehicle brakes must be “synchronized” so that braking is properly distributed to the tow vehicle brakes and the trailer brakes. For proper operation and synchronization, read and follow the axle/brake and the brake controller manufacturers’...

  • Page 75: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Master Cylinder Bleeding Remove the master cylinder’s cap and fill the reservoir to three quarters full with DOT-3 or DOT 4 brake fluid. DO NOT allow brake fluid to contact painted surfaces since it will damage the finish. Wipe up any spills immediately and wash the area with water.

  • Page 76: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Trailer Connection to Tow Vehicle Coupler and Ball Before each tow, coat the ball with a thin layer of automotive bearing grease to reduce wear and ensure proper operation; and check the locking device that secures the coupler to the ball for proper operation. See the coupler manufacturer’s manual for other inspection and maintenance procedures.

  • Page 77: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Lights and Signals Before each tow, check all trailer lights for proper operation. ⚠ WARNING To avoid risk of collisions, all lights must work. Wheel Rims If the trailer has been struck, or impacted, on or near the wheels, or if the trailer has struck a curb, inspect the rims for damage.

  • Page 78: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Tires Figure 1-Tire inspection chart ⚠ WARNING Worn, damaged, or under-inflated tires can cause loss of control, injury, and damage. Check tires before each tow.

  • Page 79: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Wheel Bearings A loose, worn or damaged wheel bearing is the most common cause of brakes that grab. To check your bearings, jack up the trailer and secure it on adequate capacity jack stands. Check wheels for side-to-side looseness. If the wheels are loose, or spin with a wobble, the bearings must be serviced or replaced.

  • Page 80: Inspection Service And Maintenance

    Inspection Service and Maintenance__________ Lug Nuts or Bolts Lug nuts or bolts are prone to loosen right after a wheel is mounted to a hub. When driving on a remounted wheel, check to see if the lug nuts or bolts are tight after the first 10, 25 and 50 miles of driving, and before each tow thereafter.
  • Page 81 This Page is Intentionally Left Blank...
  • Page 82 LRG Hand-Pump Operations Manual LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 83: Breakdown Of Your Lrg Hand-Pump

    Breakdown of Your LRG Hand-Pump__________ The LRG Hand Pump is composed of two main subsystems. They are the Self-Loading Reel System and the Hand Pumps. The following sections will outline all important functions, parts, and necessary operations information needed to fully utilize your LRG. For any additional questions, information, or replacement parts please contact or visit: LANE Trailer Mfg.

  • Page 84: Operation Of Your Hydraulic Hand Pump System

    Operation of Your Hydraulic Hand Pump System The LRG Hand pump has two main systems contained within it. The Hydraulic Reservoir which contains your hydraulic reservoir with an inlet and drain, and the two gunrack lifts. To operate the gunrack lifts pull down on each handle one at a time in an alternating motion to raise your gunracks.

  • Page 85: Self-Loading Reel System

    Your LRG comes standard equipped with a self-loading and autolocking reel system. This is to assist with the loading and unloading of reels on your LRG . This section will lay out the proper use and necessary precautions to take when utilizing your autolocking and self-loading reel system.
  • Page 86 This Page is Intentionally Left Blank...
  • Page 87 Electric Hydraulic Operations Manual LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 88: Breakdown Of Your Lrg Electric-Hydraulic Trailer

    LRG. Please note that the battery utilized in your LRG’s Electric-Over-Hydraulic skid is a Deep cycle marine/rv battery. This battery is additionally hooked up to a solar panel on the lid of your toolbox for recharging purposes. For any additional questions, information, or replacement parts please contact or visit: LANE Trailer Mfg.

  • Page 89: Breakdown Of Your Electric-Hydraulic System

    LRG’s hydraulic system. Your hydraulic reservoir on your LRG electric-hydraulic skid is responsible for holding all the necessary hydraulic fluid you will need while operating your LRG hydraulic systems. Your hydraulic reservoir comes factory installed with an appropriate amount of hydraulic fluid. The hydraulic fluid must be changed based upon the season the...

  • Page 90: Operation Of Your Electric-Hydraulic Trailer

    Operation of Your Electric-Hydraulic Trailer Button # Function Raise Driver Side Gunrack Lower Driver Side Gunrack Raise Passenger Side Gunrack Lower Passenger Side Gunrack...

  • Page 91: Self-Loading Reel System

    Your LRG comes standard equipped with a self-loading and autolocking reel system. This is to assist with the loading and unloading of reels on your LRG . This section will lay out the proper use and necessary precautions to take when utilizing your autolocking and self-loading reel system.
  • Page 92 This Page is Intentionally Left Blank...
  • Page 93 Retriever/Rewinder Operations Manual LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 94: Breakdown Of Your Lrg 1010/1008 Retriever

    Breakdown of Your LRG 1010/1008 Retriever___ The LRG Retriever/Rewinder is composed of three main subsystems. They are the Self-Loading Reel System, The Retriever/Rewinder arm, and the Hydraulic Skid. The following sections will outline all important functions, parts, and necessary operations information needed to fully utilize your LRG. For any additional questions, information, or replacement parts please contact or visit: LANE Trailer Mfg.

  • Page 95: Breakdown Of Your Hydraulic Skid

    3. Three Spool Valve – See pg. 99 4. Honda Gx 390- See pg. 96-97 5. Hydraulic Reservoir- See pg. 98 6. Fill Tube- See pg. 98 7. Skid- The skid is the plate that your LRG’s hydraulic system’s components are mounted on.

  • Page 96: Hydraulics Skid

    Your Honda Gx 390 comes with a universal Honda Engine Key Do Not Loose This Key. The Honda Engine is responsible for powering all hydraulic systems on your LRG. The following steps will lay out how to turn on and operate the Honda Gx 390.

  • Page 97: Hydraulics Skid

    Hydraulics Skid ___________________________ Figure 3- Honda Gx 390 Component Identification Steps for Operating the Honda Gx 390 1. Ensure that the air filter is inserted and attached. ⚠ 2. Ensure that the engine is appropriately filled with CAUTION oil. Ensure that gas lever is flipped to off 3.

  • Page 98: Breakdown Of Your Hydraulic Reservoir

    Breakdown of Your Hydraulic Reservoir_______ Your hydraulic reservoir on your LRG hydraulic power skid is responsible for holding all the necessary hydraulic fluid you will need while operating your LRG hydraulic systems. Your hydraulic reservoir comes factory installed with an appropriate amount of hydraulic fluid. In the case of needing to replace hydraulic fluid please use:...

  • Page 99: Breakdown Of Your Three Spool Valve

    Breakdown of Your Three Spool Valve________...

  • Page 100: Retriever/Rewinder Arm

    Retriever/Rewinder Arm____________________ The LRG 1010F’s Retriever/Rewind attachment is to assist you with spinning your fiber reel for fiber laying/blowing applications. As shown above there are four main components to your Retriever/Rewinder arm, they are: 4. The manual Retriever/Rewinder crank that is used to manually actuate your Retriever arm towards the reel and away from the reel.

  • Page 101: Retriever/Rewinder Arm On Your Figure 8

    2. Pull down on the retriever tire rotation handle on your 3-spool valve to activate the retriever arm, to control speed you must use the flow control valve. Utilizing the flow control valved to control the retriever tire speed will increase the life on your LRG’s hydraulic system. See pg. 99 for the breakdown of your 3-spool valve 3.

  • Page 102: Self-Loading Reel System

    Your LRG comes standard equipped with a self-loading and autolocking reel system. This is to assist with the loading and unloading of reels on your LRG. This section will lay out the proper use and necessary precautions to take when utilizing your LRG autolocking and self-loading reel system.
  • Page 103 This Page is Intentionally Left Blank...
  • Page 104 Hydraulic Operations Manual LRG 1010F LANE Trailer Mfg. Co. 1215 Montana Road Boone, IA 50036 515-233-1150 www.lanetrailers.com info@lanetrailers.com 1-515-233-1150...

  • Page 105: Hydraulics Operation Manual Introduction

    Hydraulics Operation Manual Introduction_____ This portion of the manual serves to provide detailed instructions on how to successfully operate your LRG 1010F Figure 8 trailer. Your LRG 1010F is manufactured by LANE Trailer Manufacturing Co. The LRG 1010F trailer consists of a figure 8 retriever/rewinder arm, a self-loading reel system, and a Honda Gx 390 motor skid paired with a wireless remote that controls and operates the hydraulic system for your LRG 1010F.

  • Page 106: Hydraulics Skid And Wireless Remote

    Hydraulics Skid and Wireless Remote_________ The Hydraulic Skid and Wireless remote control all the systems on your LRG 1010F. The Skid is equipped with a Honda Gx 390 gas powered engine with a gear pump, a battery contained within a battery box, a Hydraulic Power Unity (HCU), a wireless receiver, a hydraulic reservoir with an intake and filter, and a hydraulic manifold and shield.

  • Page 107: Hydraulics Skid And Wireless Remote

    Your Honda Gx 390 comes with a universal Honda Engine Key Do Not Loose This Key. The Honda Engine is responsible for powering all hydraulic systems on your LRG 1010F. The following steps will lay out how to turn on and operate the Honda Gx 390.

  • Page 108: Hydraulics Skid And Wireless Remote

    Hydraulics Skid and Wireless Remote_________ Figure 7- Honda Gx 390 Component Identification Steps for Operating the Honda Gx 390 1. Ensure that the air filter is inserted and attached. ⚠ 2. Ensure that the engine is appropriately filled with CAUTION oil.

  • Page 109: Hydraulics Skid And Wireless Remote

    Battery and Battery Box The battery contained within the battery box on your LRG 1010F power skid is a U1-1 battery. This battery is responsible for powering the electric starter on your Honda Gx 390, the wireless receiver mounted on your LRG 1010F’s hydraulic power skid, and any other electric necessities for your LRG 1010F’s hydraulic system.

  • Page 110: Hydraulic Reservoir

    Hydraulics Skid and Wireless Remote_________ Hydraulic Reservoir Your hydraulic reservoir on your LRG 1010F’s hydraulic power skid is responsible for holding all the necessary hydraulic fluid you will need while operating your LRG 1010F’s hydraulic systems. Your hydraulic reservoir comes factory installed with an appropriate amount of hydraulic fluid.
  • Page 111 Hydraulics Skid and Wireless Remote_________ Hydraulic Manifold...

  • Page 112: Error Code Trouble Shooting

    While operating your LRF 1010F it is possible that an error code may show up on your HCU. In this section the error code type and possible solutions to the error will be laid out. If your issue persists, please visit a repair technician or LANE Trailer manufacturing’s website: www.lanetrailers.com or call 515-233-1150 to speak to a repair technician.
  • Page 113 Hydraulics Skid and Wireless Remote_________ In the case your LRG 1010F shows an error code first asses if the code is mentioned on pg. 89 of this manual and resolve the issue from there. In the case that you are unable to resolve the issue turn off your Honda Gx 390 and wait 5 minutes before restarting the Honda Gx 390 and test if the same error code appears.
  • Page 114 3. Insert key into the Honda Gx 390, and turn to on position 4. Remote will then sync with your Hydraulic Control Unit (HCU) and system will be operational 5. Please follow the instructions for Steps for Operating the Honda Gx 390 to turn on your LRG 1010F’s hydraulics.
  • Page 115 Hydraulics Skid and Wireless Remote_________ Sleep Time Programming To change the sleep time, follow these steps. 2. With Transmitter OFF, press and hold buttons 3, 4, 8, and Power. 3. Keep holding the buttons for a few seconds then release the buttons. At this point, both lights will blink once per second.
  • Page 116 Hydraulics Skid and Wireless Remote_________ Button Breakdown of Your Wireless Remote Button Operation Button Operation POWER ON RETRIEVER TIRE AWAY FROM REEL LOW BATTERY LIGHT LOWER REEL SPINS HYDRAULIC MOTOR CLOCKWISE LIFT REEL SPINS HYDRAULIC MOTOR COUNTER- ENGAGE FIGURE 8 MOTOR CLOCKWISE RETRIEVER TIRE TOWARDS REEL ENGAGE RETRIEVER MOTOR...
  • Page 117 Retriever/Rewinder Arm On Your Figure 8______ The LRG 1010F’s Retriever/Rewind attachment is to assist you with spinning your fiber reel for fiber laying/blowing applications buttons 3 and 4 as seen in Button Breakdown of Your Wireless Remote act as variable speed controllers to match the speed at which your fiber cable is being blow. Holding and pressing the button will gradually increase the speed and is useful for fine tuning the speed to match.
  • Page 118 Retriever/Rewinder Arm On Your Figure 8______ Retrieving Function 1. Apply Pressure to the reel from the retriever arm utilizing button #5 as referenced on page 93. 2. Use button #3 or #4 on your remote to incrementally step up the speed, step down the speed, or to change directional rotation of your reel.
  • Page 119 Self-Loading Reel System___________________ The LRG 1010F comes standard equipped with a self-loading and autolocking reel system. This is to assist with the loading and unloading of reels on your LRG 1010F. This section will lay out the proper use and necessary precautions to take when utilizing your LRG 1010F’s autolocking and self-loading reel system.
  • Page 120 Figure 8 attachment________________________...
  • Page 121 The following sections will outline the necessary steps to operate, utilize, and safely secure for transportation your LRG 1010F’s Figure 8 attachment. Ensure that all steps are followed, and necessary maintenance is performed between each use to ensure that your Figure 8 is safe to use.
  • Page 122 “Figure 8’ing” refers to the process of laying out a fiber cable prior to blowing (laying the cable through a pre- drilled underground hole). The LRG 1010F’ has a Figure 8 attachment to assist with this process. The process of Figure 8’ing is when cable is laid in an 8 pattern onto the ground.
  • Page 123 This section will lay out how to properly maintain your LRG 1010F’s hydraulicly operated systems. The following steps will lay out how to properly grease elements on your LRG 1010F, how to replace hydraulic fluid in your LRG 1010F, and how to bleed any necessary lines on your hydraulic manifolds.
  • Page 124 This Page is Intentionally Left Blank...

Table of Contents
