domi outdoor living LGMF1612A Assembly Manual

10'x12' solarium wall-mounted sunroom

Advertisement

Quick Links

Please retain this instruction for future usage and read carefully before assembly.
Make sure you have all the parts & hardware as item list shows.
3 adults or more are recommended to install your Sunroom.
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Check all bolts for tightness before use, and periodically check and tighten bolts ensure your gazebo works properly.
Some parts might have sharp edge/corners/Please follow basic safety precautions to reduce the risk of hurts.
Avoid installing and settling the solarium in a corridor of heavy wind.
Some assembly parts contain sharp edges, you should wear protective gloves when handling these items.
For safety issues you must not leave the unit unattended if it is not completed, even if it is already anchored to the ground.
It is essential to place the gazebo on level ground and not less than 6 feet from any obstruction such as fences,
garages, overhanging branches, laundry lines, or electrical wires.
If you have questions or concerns.
Please contact us via email at service@domioutdoorliving.com
Warnings and Cautions

Advertisement

loading
Need help?

Need help?

Do you have a question about the LGMF1612A and is the answer not in the manual?

Questions and answers

Summary of Contents for domi outdoor living LGMF1612A

  • Page 1 Warnings and Cautions Please retain this instruction for future usage and read carefully before assembly. Make sure you have all the parts & hardware as item list shows. 3 adults or more are recommended to install your Sunroom. Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings. Check all bolts for tightness before use, and periodically check and tighten bolts ensure your gazebo works properly.
  • Page 2: Assembly Manual

    Domi outdoor living o u t d o o r l i v i n g 10'X12' SKU:LGMF1612A Solarium Wall-Mounted Sunroom ASSEMBLY MANUAL © Copyright 2023-2025 Domi Outdorr Living LLC. All Rights Reserved.
  • Page 5 Domi outdoor living’s Sunroom Read and follow this assembly and operation guide. To reduce personal injury and damage to you Sunroom We recommend a three-person team for assembly and disassembly. Please remove snow accumulation at all times.
  • Page 6 Matters needing attention Regulation Three or more people are required IMPORTANT: A sunroom may entail to purchase a municipal for assembly. permit or be subject to specific building codes. It is the consumer's responsibility to inform themselves of any restrictions. Care and Cleaning:...
  • Page 7 x 14...
  • Page 8 x 14 Or you can make a concrete inground base, is recommended. use expansion bolts to mount the pergola like shows.
  • Page 18 Rubber Gasket...
  • Page 22 If you don't need to �ix the post against the wall, please skip this step. The bracket T2 is used to �ix the post against the wall. If you don't need �ixing the post against the wall,then please retain it for future use.
  • Page 23 Front Beam Assembly...
  • Page 28 M6*16...
  • Page 31 Use glass cement (part #15) to af�ix the gap between the two beams.
  • Page 33 Side Beam Assembly...
  • Page 38 Side Beam Assembly...
  • Page 43 Rear Beam Assembly...
  • Page 49: Frame Assembly

    Frame Assembly...
  • Page 51 M6*16 M6*12(L20) M6*15(L30)
  • Page 54 Two Central Beams Assembly...
  • Page 62 The notch of #V7 & V9 is facing inward.
  • Page 64 The notch of #V8 & V10 is facing inward.
  • Page 66 Black Rubber Rubber Gasket...
  • Page 69 silicone sealant application (1)Apply 3 mm wide silicone sealant to the first row of roof panels as shown. (2)Install the second row of roof panels and fix the screws.
  • Page 70 Repeat above procedures to assemble the third row of roof panels.
  • Page 72 ATTENTION: The orientation of Screen Panel #Z6.
  • Page 74 ATTENTION: The orientation of Part #E1 & #E2 when assembling.
  • Page 76 Attach the lock piece Z16 to the door frame Z15 with 2 screws 2#. Tip:Please pay attention to the orientation of lock piece Z16 showed in the image and make sure the tip of the lock piece Z16 is facing down.
  • Page 78 Pay attention to the orientation of R1...
  • Page 81 Install each stop block S2 to the upper and lower parts of the right side of the doorframe S3 with 2 screws #16.
  • Page 82 Slide the door into the track.
  • Page 83 Install each stop block S2 to the upper and lower parts of the left side of the doorframe S3 with 2 screws #16.
  • Page 85 You can install the side wall with sliding door in either side.
  • Page 89 ATTENTION: The orientation of Screen Panel #Z7.
  • Page 95 ATTENTION: The orientation of Screen Panel #Z7.
  • Page 98 Rear Support Tube...
  • Page 99 The two support tubes can strengthen the weight capacity of the metal roof. In bad weather, especially snowstorm, they are essentially needed to prevent the roof from collapsing under heavy snow. In daily life, you can put them away.
  • Page 100 Follow this step only if you need �ixing the sunroom to the wall (you need to drill holes into the wall). The install position of water-proof panel M3 should �it as close as the edge of rear roof panel.
  • Page 101 Follow this step only if you need �ixing the sunroom to the wall (you need to drill holes into the wall). If possible, use silicone sealant on the top of M3 to seal out water. Otherwise please skip this step.
