- Page 1 Product Manual Installation & System Settings FORGE Biometric Ultra Slim Smart Handle Lock SKU: FEUTSLMH2A (Version 1.0.1) ULTRA SLIM SMART LOCK Copyright © 2025 Forge Electrical. All rights reserved.
-
Page 2: Product Features
Overview Designed for narrow aluminium frame doors, suitable for both residential and commercial application. This lock is engineered to have an extremely narrow body at a width of only 30mm. The outdoor panel is tested for IP65 ingress protection, and to endure extreme temperature, humidity, vibration and the harsh Australian weather condition. -
Page 3: Basic Parameters
Basic Parameters Note: The installation drawings in this manual are for installation instructions only and do not represent the actual product. Battery Cover Card Reader PIN Pad Fingerprint Reader Rear Handle Front Handle Mechanical Keyhole Emergency Power Supply (Type-C) -
Page 4: Assembly Overview
Assembly Overview Battery cover AAA batteries Connection stud Rear panel Front panel Door frame Data cable junction hole Mortise Spindle Mortise screw Connection screw... - Page 5 Drilling and Installation of the Lock Mortise 1.1 Drill holes in the door profile according to the hole dimensions of the cut-out template and fix the mortise to the profile with mortise screws.
-
Page 6: Install The Front Panel
Install the Front Panel 1.2.1 Adjust the direction of the front handle according to the direction of opening the door. Use a hexagonal wrench to unscrew the screw in the hole of the handle rotor. Pull out the handle and rotate it by 180 degrees before inserting it again. And then tighten the handle screw to fix the handle (the same operation applies for changing the handle direction at the back). - Page 7 Install the Rear Panel 1.3.1 Adjust the direction of the rear handle in the same way as the front panel. 1.3.2 Adjust the position of the lock paddle according to the direction of the door opening. Use sharp nose pliers to hold the paddle and lift it upward, and then toggle it to the other side until the paddle is aligned with the corresponding marking and then put it down (R: right opening, L: left opening) 1.3.3 Connect the front and rear lock data cables through the data cable hole.
-
Page 8: Install The Batteries
Install the Batteries 1.4 Load 4 AAA batteries according to the positive and negative terminal markings in the battery compartment. -
Page 9: Completion Of Installation
Completion of Installation 1.5 According to the operating instructions, follow the steps to test the door lock related functions, the door lock installation is now completed. -
Page 10: Operation Menu
Operation Menu This lock works with a local voice-prompt, and number key-input based operating system. The hierarchy and number key functions are: 1.Add Module (The "Remote Settings" option will be displayed if this is 1.Wireless Setting a remote controller (optional) model) 2.Delete Module 1.Add User 1.Enable Passage... -
Page 11: Initial Setups
Initial Setups 1. The Initial State The initial factory default PIN is "123456" • • Once the first administrator PIN is registered, the initial default PIN will be automatically deleted. IMPORTANT: Untill the first administrator is registered, the lock is at a unlocked status and can be unlocked by any fingerprint, or PIN. - Page 12 Initial Setups 3.2. Connect to the App Download the FORGE Smart App Download the FORGE Smart App by scanning the below QR Code: For iOS For Android Apple App Store Google Play Store Alternatively, please search for the “FORGE Smart” app on your app store. Log In or Sign Up Follow the instructions on the app, sign up and log in your account.
-
Page 13: Function And Operation
Function and Operation 4. General User Management Adding a New User Press "* #" (star & hash) or short press the "Factory Reset" key to enter system settings. Press “2” to enter lock function Press “1” to add user Follow the voice prompt to add admin information - either by place your finger on the fingerprint reader, or input a PIN, or swipe the card. - Page 14 11 Function and Operation 5. Basic Lock Function Settings Basic lock functions can be managed on the lock itself without using the app. This includes function settings, volume settings, language settings, time settings, and more. Press "* #" (star & hash) to enter system settings. Press “2”...
- Page 15 11 Function and Operation 6. App Functionalities The FORGE Smart App can be used for: • Remote unlock • Generate and manage PINs (permanent, time-limited, and once off) • Check access records • Receive doorbell notifications • Receive low battery notifications IMPORTANT: Please ensure the lock has strong and stable internet connectivity.
-
Page 16: Factory Reset
11 Function and Operation 7. Factory Reset Press and hold the "Factory Reset" key on the rear panel for 5 seconds, all unlock credentials and records will be cleared. Once reset, the initial PIN will be restored to the default factory code of 123456 and the lock is returned to the initial unlocked status. - Page 17 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, contact us via: Address: 152 Maroondah Hwy, Ringwood VIC 3134 Email: sales@forgeelectrical.com.au Phone: 1800 1 FORGE (36743) Copyright ©...
