OWNER'S MANUAL
NB2800.1
NB300.4
High performance amplifier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB2800.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prodigy NB2800.1

  • Page 1 OWNER’S MANUAL NB2800.1 NB300.4 High performance amplifier...

  • Page 2: Before You Begin Installation

    Before You begin installation Your new Prodigy Audio amplifier is one of the most rugged, reliable, powerful and best performing amplifier in the world and exemplifies our commitment to excellence in car audio musical reproduction. Before you begin , you will need tools, supplies and adapters. It is best to make sure you have everything you need before you start.

  • Page 3: Power Terminal ( +12V )

    This turns on the amplifier whenever the source unit is turned on. Fuse rates NB2800.1 : 300A ( 600A strappable ) Drill 1/8” hole in NB300.4 : 130A Chassis sheet metal...
  • Page 4 NB2800.1 Speaker connection 4 - 1ohms Caution !! NB2800.1 minimum working impedance is 1ohm or 2ohm strappable. Impedance lower than 1 ohm can damage the amplifier 4 - 2ohms 4 - 2ohms...
  • Page 5 Strappable input connection Step 1. Connect the Master amplifier to the head-unit and set its output master / input slave switch to OUTPUT MASTER. Step 2. Set Slave amplifier output master / input slave switch to INPUT SLAVE. Step 3. Connect RCA cable “OUT” from the master to “IN” the slave amplifier as shown in the diagram. Strapable speaker connection Step 1.
  • Page 6 MASTER AMPLIFIER Connect positive of master amplifier’s terminal to positive of subwoofer’s terminal Connect positive of slave amplifier’s terminal to SLAVE AMPLIFIER negative of subwoofer’s terminal In strappable connection, Minimum working impedance is 2ohm. Impedance lower than 2ohm strappable connection can damage the amplifiers...
  • Page 7 NB-300.4 Speaker connections Mid-range Mid-range Tweeter Tweeter Crossover Crossover Caution !! NB300.4 minimum working impedance 2ohm stereo or 4ohm bridged. Mid-range Mid-range Impedance lower than 2 ohm stereo can damage the amplifier Tweeter Tweeter Crossover Crossover 4 - 2ohms...

  • Page 8: Troubleshooting

    ... In any case, consult authorized dealer AMPLIFIER GOES IN PROTECTION MODE AT HIGHER GAIN Check speaker impedance NB2800.1 working impedance is 1ohm or 2ohm strappable. NB300.4 is 2ohm stereo or 4ohm bridged. Check working voltages ( 9V - 16Volts )

This manual is also suitable for:

Nb300.4
