Basic Manual of Hitachi NE-S1 series inverter
Thank you for purchasing the Hitachi NE-S1 series inverter.
Please read this document and QRG(Quick Reference Guide), and understand perfectly how to handle
properly and the safety cautions of the product before operation, for safety and proper usage.
Note that this Manual is intended for each product and should be delivered to the end user of the inverter.
Safety precautions
Be sure to read this Instruction Manual and appended documents thoroughly before installing, operating the inverter.
Maintenance and service items in this manual are only caution related items. Read QRG (Quick Reference Guide) carefully before starting the
maintenance and service. (QRG can be downloaded from our website.)
In the Instruction Manual, safety instructions are classified into two levels, namely WARNING and CAUTION.
WARNING
: Indicates that incorrect handling may cause hazardous situations, which may result in serious personal injury or death.
: Indicates that incorrect handling may cause hazardous situations, which may result in moderate or slight personal injury or
CAUTION
physical damage alone.
CAUTION
Note that even a
instruction, which contains important safety information. Also focus on and observe the items and instructions described under "Notes" in the text.
Many of the drawings in the Instruction Manual show the inverter with covers and/or parts blocking your view being removed.
Do not operate the inverter in the status shown in those drawings. If you have removed the covers and/or parts, be sure to reinstall them in their
original positions before starting operation, and follow all instructions in the Instruction Manual when operating the inverter.
1. Installation
- Install the inverter on a non-flammable surface, e.g., metal. Otherwise, you run the risk of fire.
- Do not place flammable materials near the installed inverter. Otherwise, you run the risk of fire.
- When carrying the inverter, do not hold its top cover. Otherwise, you run the risk of injury and damage by dropping the inverter.
- Prevent foreign matter (e.g., cut pieces of wire, sputtering welding materials, iron chips, wire, and dust) from entering the inverter. Otherwise, you
run the risk of fire.
- Install the inverter on a structure able to bear the weight specified in the Instruction Manual. Otherwise, you run the risk of injury due to the
inverter falling.
- Install the inverter on a vertical wall that is free of vibrations. Otherwise, you run the risk of injury due to the inverter falling.
- Do not install and operate the inverter if it is damaged or its parts are missing. Otherwise, you run the risk of injury.
- Install the inverter in a well-ventilated indoor site not exposed to direct sunlight. Avoid places where the inverter is exposed to high temperature,
high humidity, condensation, dust, explosive gases, corrosive gases, flammable gases, grinding fluid mist, or salt water. Otherwise, you run the
risk of fire.
-
The inverter is precision equipment. Do not allow it to fall or be subject to high impacts, step on it, or place a heavy load on it. Doing so may
cause the inverter to fail.
2. Wiring
- Be sure to ground the inverter. Otherwise, you run the risk of electric shock or fire.
- Commit wiring work to a qualified electrician. Otherwise, you run the risk of electric shock or fire.
- Before wiring, make sure that the power supply is off. Otherwise, you run the risk of electric shock or fire.
- Perform wiring only after installing the inverter. Otherwise, you run the risk of electric shock or injury.
- The inverter must be powered OFF before you change any of the slide switch settings. Otherwise, you run the risk of electric shock or injury.
Make sure that the voltage of AC power supply matches the rated voltage of your inverter. Otherwise, you run the risk of injury or fire.
- Do not input single-phase power into the 3-phase inverter. Otherwise, you run the risk of fire.
- Do not connect AC power supply to any of the output terminals (U, V, and W). Otherwise, you run the risk of injury or fire.
- NE-S1 series inverter do not have terminals for braking resistor. Do not connect the resistor. Otherwise there is a risk of fire.
- Connect an earth-leakage breaker to the power input circuit. Otherwise, you run the risk of fire.
- Use only the power cables, earth-leakage breaker, and magnetic contactors that have the specified capacity (ratings). Otherwise, you run the risk
of fire.
- Do not use the magnetic contactor installed on the primary and secondary sides of the inverter to stop its operation.
- Tighten each screw to the specified torque. No screws must be left loose. Otherwise, you run the risk of fire.
- Before operating slide switch in the inverter, be sure to turn off the power supply. Otherwise, you run the risk of electric shock and injury.
- Please make sure that earth or ground screw is tightened properly and completely.
-
First, check the screws of output terminal (U, V and W) are properly tighten, and then tighten the screws of input terminal (R, S and T)
level situation may lead to a serious consequence according to circumstances. Be sure to follow every safety
CAUTION
CAUTION
WARNING
CAUTION
1
NT341BX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NE-S1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hitachi NE-S1 Series

  • Page 1 - Do not connect AC power supply to any of the output terminals (U, V, and W). Otherwise, you run the risk of injury or fire. - NE-S1 series inverter do not have terminals for braking resistor. Do not connect the resistor. Otherwise there is a risk of fire.
  • Page 2 3. Operation WARNING - While power is supplied to the inverter, do not touch any terminal or internal part of the inverter, check signals, or connect or disconnect any wire or connector. Otherwise, you run the risk of electric shock or fire. - Be sure to close the top cover before turning on the inverter power.
  • Page 3 Cautions for UL and cUL (Standard to comply with : UL508C,CSA C22.2 No.14-05) Wiring diagram of inverter DC link choke Circuit breaker or Fuse Power Motor supply Inverter Maximum surrounding air temperature rating of 50ºC. Solid State motor overload protection reacts with max. 150 % of FLA. Suitable for use on a circuit capable of delivering not more than 100,000 rms Symmetrical Amperes, 240 Volts Maximum.
  • Page 4 The warranty period under normal installation and handling conditions shall be two (2) years from the date of manufacture, or one (1) year from the date of installation, whichever occurs first. The warranty shall cover the repair or replacement, at Hitachi's sole discretion, of ONLY the inverter that was installed.
  • Page 5: Cautions For Installation

    2. Name of each portion (removed front cover) ⑩ Switch for termination resistor SW4 (Default) Connector for dedicated operator for NES1-OP ⑩ Switch for RS485/OPE SW5 RS485 (Default) ⑩ RUN/STOP/RESET keys → P9 ⑩ RS422/RS485 port ⑩Switch for O/OI (analog input) ⑩...
  • Page 6 ⑩Ensure Adequate Ventilation To summarize the caution messages – you will need to find a solid, non-flammable, vertical surface that is in a relatively clean and dry environment. In order to ensure enough room for air circulation around the inverter to aid in cooling, it is recommended to maintain the specified clearance and the inverter specified in the below diagram.
  • Page 7 ⑩Cautions for installation into the cabinet Please pay attention to the location of the ventilation holes of the inverter and the cabinet, in case of side-by-side installation and using ventilation fan. cooling performance of the inverter highly depends on the location of the holes. Please pay high attention to the ambient temperature of the Ventilation inverter to be less than the specified value.
  • Page 8: Wiring And Terminal Description

    4.2 Wiring and terminal description Power source, U/T1 (L1) R/L1 3-phase or S/L2 1-phase, per V/T2 inverter model T/L3 W/T3 Short circuit bar DC24V Motor Refer to QRG (section 5.7) when using Short circuit bar external equipment for source logic PD/+1 output and/or external power supply.
  • Page 9 (2) Control terminal description Category Symbol Name Description Electrical characteristics Common for internal control power supply, digital Common for input signals Power inputs/outputs, analog inputs/outputs supply Power supply for external DC10V power supply. Used with variable resistor for O Max.10mA withdraw potentiometer input.
  • Page 10: Mains Wiring

    A special filter to suppress the surge voltage is available. If you need this filter, contact your supplier or local Hitachi Distributor. ⑩ When connecting multiple motors to the inverter, connect a thermal relay to the inverter output circuit for each motor.
  • Page 11 EX30 (20A) Note 1)The peripheral equipment described here is applicable when the inverter connects a standard Hitachi 3-phase, 4-pole squirrel-cage motor. Note 2)Select breakers that have proper capacity. (Use breakers that comply with inverters.) Select above proper ELB capacity following above table for the inverter.
  • Page 12: Confirmation Before Power Up The Inverter

    (3) 5-line LCD operator (WOP) WOP having serial number of “16918938000081” or later (2011/07 production) is applied to NE-S1 series inverter. (English only) WOP can be used with connector cable (ICS-1,3) and connected to the RS422/RS485 port (RJ45) in the inverter. Turn the changeover switch to the operator side (OFF side) in that case (See page 9).
  • Page 13 0Hz. Additionally, the motor will not run if a FRS (free run stop) signal (and the like) is being given. NE-S1 series inverter has following way to set the run command and frequency command. (This is an example of sink logic and uses internal control power supply.)
  • Page 14 0.00 to 3600 sec. default⑩10 sec. The above is a method to perform analog One of the following is required when changing default parameters on NE-S1 series inverters. input(O/OI) by voltage input. It is necessary for Dedicated operator (NES1-OP) ⑩ Digital operator...
  • Page 15: Specifications

    Standards Compliance UL⑩CE⑩c-UL⑩c-tick Note1⑩ The applicable motor refers to Hitachi standard 3-phase motor (4p). When using other motors, care must be taken to prevent the rated motor current (50/60Hz) from exceeding the rated output current of the inverter. Note2⑩ The output voltage decreases as the main supply voltage decreases (except when using the AVR function). In any case, the output voltage cannot exceed the input power supply voltage.
  • Page 16 NES1-007LB NES1-015LB NES1-022LB SUITABILITY FOR USE Hitachi Industrial Equipment Systems shall not be responsible for conformity with any standard, codes, or regulations that apply to the combination of products in the customer’s application or use of the products. Take all necessary steps to determine the suitability of the product for the Systems, machines, and equipment with which it will be used.
  • Page 17: Appendix A: List Of Data Setting

    Appendix A: List of data setting [Parameter Settings for Keypad Entry] NE-S1 series inverters provide many functions and parameters that can be configured by the user. We recommend that you record all parameters that have been edited, in order to help in troubleshooting or recovery from a loss of parameter data.
  • Page 18 [Function mode (F Group)] Note) Mark “ ” in [ Run Mode Edit] shows the accessible parameters when b031 is set “10”, high level access. “F” Function Defaults Func. Mode Name Description Initial data Units Edit Code Output frequency setting Standard default target frequency that F001 0.00...
  • Page 19 [Function mode (A Group)] “A” Function Defaults Mode Func. Name Description Initial data Units Edit Code − Frequency source Five options; select codes: A001 00 00 00 00 …POT on ext. operator 01 01 01 01 …Control terminal 02 02 02 02 …Function F001 setting −...
  • Page 20 “A” Function Defaults Mode Func. Name Description Initial data Units Edit Code − A039 Jog stop mode Define how end of jog stops the motor; six options: 00 00 00 00…Free-run stop (invalid during run) 01 01 01 01…Controlled deceleration (invalid during run) 02 02 02 02…DC braking to stop(invalid during run) 03 03 03 03…Free-run stop (valid during run) 04 04 04 04…Controlled deceleration (valid during run)
  • Page 21 “A” Function Defaults Mode Func. Name Description Initial data Units Edit Code A061 Frequency upper limit Sets a limit on output frequency less than the 0.00 Α004 Α004 Α004). maximum frequency (Α004 Α062) to Α062 Α062 Range is from frequency lower limit (Α062 Α004 Α004 Α004).
  • Page 22 “A” Function Defaults Mode Func. Name Description Initial data Units Edit Code 00 00 00 00…AVR enabled − A281 AVR function select, 01 01 01 01…AVR disabled motor 02 02 02 02…AVR enabled except during deceleration AVR voltage select 200V class inverter settings: A082 ……200/215/220/230/240 A282...
  • Page 23 “A” Function Defaults Mode Func. Name Description Initial data Units Edit Code A145 ADD frequency An offset value that is applied to the output 0.00 frequency when the [ADD] terminal is ON. Range is 0.00 to 400.00 Hz ADD direction select Two options: −...
  • Page 24 [Function mode (b Group)] “b” Function Defaults Mode Func. Name Description Initial data Units Edit Code Restart mode on power failure / Select inverter restart method, − b001 under-voltage trip Four option codes: 00 00 00 00…Alarm output after trip, no automatic restart 01 01 01 01…Restart at 0Hz 02 02 02 02…Resume operation after frequency matching 03 03 03 03…Resume previous freq.
  • Page 25 “b” Function Defaults Mode Func. Name Description Initial data Units Edit Code Sets the level of overload restriction, between b022 Overload restriction level Rated 20% and 200% of the rated current of the inverter, current setting resolution is 1% of rated current x 1.50 Overload restriction level, b222...
  • Page 26 “b” Function Defaults Mode Func. Name Description Initial data Units Edit Code b037 Function code display restriction Five option codes: − 00 00 00 00…Full display 01 01 01 01…Function-specific display 03 03 03 03…Data comparison display 04 04 04 04…Basic display 05 05 05 05…Monitor display only 000…Func.
  • Page 27 “b” Function Defaults Mode Func. Name Description Initial data Units Edit Code b089 Automatic carrier frequency reduction Three option codes: − 00 00 00 00…Disabled 01 01 01 01…Enabled, depending on the output current 02 02 02 02…Enabled, depending on the heat-sink temperature Stop mode selection 00(Dec and Stop) / 01(FRS)
  • Page 28 “b” Function Defaults Mode Func. Name Description Initial data Units Edit Code b165 Ex. operator com. loss action Five option codes: − 00 00 00 00…Trip 01 01 01 01…Trip after deceleration to a stop 02 02 02 02…Ignore 03 03 03 03…Coasting (FRS) 04 04 04 04…Decelerates to a stop 00 00 00 00…...
  • Page 29 “C” Function Defaults Mode Func. Name Description Initial data Units Edit Code C039 Low current detection level Set the level of low load detection, range is 0.00 to Rated 2.00*inverter rated current current Output mode of overload warning Two option codes: −...
  • Page 30 “C” Function Defaults Mode Func. Name Description Initial data Units Edit Code C091 Debug mode enable * Displays debug parameters. − Two option codes: 00 00 00 00…Disable 01 01 01 01…Enable <Do not set> (for factory use) C101 Up/Down memory mode selection Controls speed setpoint for the inverter after power −...
  • Page 31 “C” Function Defaults Mode Func. Name Description Initial data Units Edit Code C164 Input [5] response time − Multistage speed determination time Set range is 0. to 200. (x 10ms) C169 Input Function Summary Table – This table shows all thirty-four intelligent input functions at a glance. For detailed description of these functions, related parameters and settings, and example wiring diagrams, please refer to the QRG (Quick Reference Guide).
  • Page 32 Input Function Summary Table Option Terminal Function Name Description Code Symbol Selects the direction of motor rotation: OFF = REV. While the motor is rotating, a change of F/R will start a deceleration, followed by a change in direction Temporarily disables PID loop control. Inverter output turns Α071 Α071 Α071=01 01 01 01)
  • Page 33 Output Function Summary Table – This table shows all functions for the logical outputs (terminals [11] and [AL]) at a glance. For detailed descriptions of these functions, related parameters and settings, and example wiring diagrams, please refer to the QRG (Quick Reference Guide). Output Function Summary Table Option Terminal...
  • Page 34 Output Function Summary Table Option Terminal Function Name Description Code Symbol logical “0” result Starting Contact Signal Either FW or RV command is given to the inverter No FW or RV command is given to the inverter, or both are given to the inverter Heat Sink Overheat Temperature of the heat sink exceeds a specified value...
  • Page 35: Appendix B: Monitoring Trip Events, History, And Conditions

    Appendix B: Monitoring Trip Events, History, and Conditions 1. Indication of the error The microprocessor in the inverter detects a variety of fault conditions and captures the event, recording it in a history table. The inverter output turns OFF, or “trips” STOP similar to the way a circuit breaker trips due to an over-current condition.
  • Page 36 [Digital Operator (NES1-OP, OPE-S/SR/SBK/SRmini)] Trip History and Inverter Status We recommend that you first find the cause of the fault before clearing it. When a fault occurs, the inverter stores some important performance data at the moment of the fault. To access the data, use the monitor function (δ δ δ δ xxx) and select δ081 δ081 δ081...
  • Page 37: Error Code

    2. Error code When you use the optional operator [NES1-OP, OPE-S/SR/SBK/SRmini], an error code will appear on the display automatically when a fault causes the inverter to trip. The following table lists the cause associated with the error. The following error code will not be displayed with the standard panel. Error Name Cause(s)
  • Page 38: Other Display For Digital Operator

    3. Other Display for Digital operator The other display for Digital operator is follows. It is not displayed with the standard panel. Name Description Display on digital operator Rotating Reset RS input is ON or STOP/RESET key is pressed. If the input voltage falls, the inverter will shut off its output, display the code shown on the right, and wait for the recovery of the input voltage.
