Summary of Contents for Daxten GALAXY
- Page 1 Galaxy Cat 5 Video Distribution System Installation and Operation Manual rev 1.1...
- Page 2 LIMITED WARRANTY Daxten warrants the Galaxy™ to be in good working order for one year from the date of purchase from Daxten or an authorised dealer. Should this product fail to be in good working order at any time during this one year warranty period, Daxten will, at its option, repair or replace the Unit as set forth below.
-
Page 3: Operation
INTRODUCTION Thank you for choosing the Galaxy ™ system, designed for Distributing and daisy chain high-resolution video signals over long distances via CAT 5 cables. By choosing Galaxy, you have assured that your installation is equipped for the ever-increasing demands made in a modern computer-based information environment. The Galaxy system allows the info-computer to transmit this monitor image to a number of receiver monitors in large environments such as subway stations, bus terminals, airports, restaurants, malls, banks etc. -
Page 4: Getting Started
GETTING STARTED This manual describes the Galaxy installation and operation of the Galaxy system. All versions of the models are listed here Package Content The Galaxy Tx1 starter package includes: (1024-01TK) Galaxy Tx1 (1024-01T) Power Transformer and mains lead* (9014-00F-AW) VGA Cable (2051-02T) User manual... - Page 5 Package Content The Galaxy Repeater Station Tx1 300M includes: (1024-01TEK) Galaxy Tx1 (1024-01T) Expansion Card (1024-00TU) Power Transformer and mains lead* (9014-00F-AW) This User Manual The Galaxy Repeater Station Tx4 300M includes: (1024-04TEK) Galaxy Tx4 (1024-04T) Expansion Card (1024-00TU) Power Transformer and mains lead* (9014-00F-AW) User Manual The Galaxy Rx60 receiver includes:...
- Page 6 Accessories With the packages the units can be set up. It is however necessary to get additional modules and cables to connect the units: Part Part number Galaxy Tx1 1024-01T Galaxy Tx4 1024-04T Galaxy Rx60 1024-01RM Galaxy Rx125 1024-01RH Galaxy Rx300 1024-01R Galaxy Repeater Tx1 125m 1024-01TEH...
- Page 7 CONNECTORS ON GALAXY Galaxy Tx1 VGA IN UTP OUT Front view of Galaxy Tx4 Galaxy Tx4 OUT 4 VGA IN OUT 3 OUT 2 OUT 1 Rear view of Galaxy TX 1and Tx4 UTP IN EQ GAIN 9-24 V DC Distance label Front view of Galaxy RX 60 9-20V...
- Page 8 Applications Rx60 Tx1 w/UTPin Figure 2: Galaxy Tx1 connected to one Galaxy TX1 with UTP In module...
- Page 9 Tx4 w/UTPin Rx60 Rx60 Tx4 w/UTPin Rx60 Rx60 Rx60 Rx60 Tx1 w/UTPin Large-scale system Voyager 125 Local Voyager 125 Remote Tx1 w/UTPin Galaxy Tx1 with UTP in module used as repeater for high resolution 1200 X 1600 over long distance in a Voyager 125 system...
-
Page 10: Before Installation
BEFORE INSTALLATION Galaxy Transmitter and Galaxy receivers. When planning large installations please chose the right boxes and configuration. When working with Daisy chains please make a drawing with cable lengths of your system and give the boxes a numbers so it is possible to locate the boxes on the drawing. -
Page 11: Troubleshooting
No picture on the Tx1. 1) Is the Green LED lit on the unit? No power, no transmission 2) Bad picture quality with very long transmission lines—Daxten can, on special order deliver Cat 5E cable optimized for VGA transmission. Adding a delay line (skew delay compensator) will also help. -
Page 12: Service Information
Support Department of Daxten. Technical support If you cannot determine the nature of a problem, please call Daxten and ask for Technical Support. If possible call from a phone located near the unit - we may be able to solve your problem directly over the phone. -
Page 13: Appendix A. General Specifications
APPENDIX A. GENERAL SPECIFICATIONS Galaxy Tx1 Size 215 x 105 x 44 mm (8.46 x 4.13 x 1.73 in.) Weight 0.80Kg (1.77lbs) Power Consumption Max. 700mA with UTP-in module Recommended Input Power Regulated DC 12V/1,3A or 9V/2A Galaxy Tx4 Size 215 x 105 x 44 mm (8.46 x 4.13 x 1.73 in.) Weight 0.80Kg (1.77lbs) - Page 16 Fax: +34 9 76 219 943 Fax: +49 (0)30 8595 37-99 Fax: • • FRANCE SWEDEN AUSTRIA Daxten Daxten AB Daxten Österreich GmbH. B.P. 04 Södermälarstrand 29, 6tr Künstlergasse 11/4 77, Route de Cheptainville 118 25 Stockholm A-1150 Wien F-91630 Marolles-en-Hurepoix Sweden Austria France info.fr@daxten.com...
