Summary of Contents for FAMOCO Square
- Page 1 User manual Famoco Square FX107 March 2025...
-
Page 2: Table Of Contents
8.3 How to read an NFC card__________________________________________________________________________________________________________________________________________ 9 8.4 Smart card reader________________________________________________________________________________________________________________________________________________ 9 8.5 How to access the dashboard______________________________________________________________________________________________________________________________________ 10 8.6 How to find your specific Famoco ID_________________________________________________________________________________________________________________________________ 10 8.7 How to charge the device__________________________________________________________________________________________________________________________________________11 8.9 How to use the battery____________________________________________________________________________________________________________________________________________ 11 8.10 Single SIM slot_________________________________________________________________________________________________________________________________________________ 12... -
Page 3: Copyright
No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Famoco. -
Page 4: Warnings And Safety Notices
4. Limitation of liability Famoco shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using this product, whether or not Famoco had been advised, knew or should have known the possibility of such damages. -
Page 5: Device Layout
6. Device layout 6.1 Overview 1 Smart card reader 2 Front camera 3 NFC 4 Power button 5 Single Nano SIM tray 6 USB Type-C User manual... -
Page 6: Buttons And Other
6.2 Buttons and other Name Function Long press: turn the device ON/OFF Power button Short press: screen ON/OFF (standby mode) Connect the device to a USB Type-C power source or computer for USB Type-C port Data transfer Smart card reader Used for inserting the smart card and getting information securely User manual... -
Page 7: Package Contents
The supplied items are designed only for this device and may not be compatible with other devices. Appearances and specifications are subject to change without prior notice. Third-party accessories may not be compatible with your device. Available accessories for Famoco Square: Wall mounting User manual... -
Page 8: Getting Started
8. Getting started 8.1 How to switch the device ON or OFF To power ON: Press and hold the power button for three seconds then release. The home screen will be displayed after a few moments. To power OFF: Press and hold the power button for two seconds, then select the shutdown option on the screen. Standby mode: The device enters the standby mode after 30 seconds by default if left alone. -
Page 9: Home Screen And Synchronization
8.2 Home screen and synchronization Once your device is switched on it will start synchronizing. If there are no applications installed on it yet, the device will be locked on a screen that shows the following indication to configure the internet. Connection: To set up your device you need connectivity so that it can synchronize. -
Page 10: How To Read An Nfc Card
8.4 Smart card reader The Famoco Square is equipped with a smart card reader that enables reading and authentication of chip cards ISO7816. To use the reader, insert the smart card into the designated slot on the top of the device with the chip facing inward. Once the card is inserted, the device detects it and establishes a connection for data exchange. -
Page 11: How To Access The Dashboard
There are two ways of finding the unique Famoco ID: Long press the home button to access the dashboard and then press the owner’s name. The Famoco ID is written at the top. The serial number is written on the back of your device on the sticker. -
Page 12: How To Charge The Device
8.7 How to charge the device To charge the device, only use the USB Type-C cable and charger head in the box. Use of a different charger and/or cable may damage the device. Insert the charger cable carefully. Check that the plug and socket are aligned. The indicator light will turn red to indicate that the device is charging and will turn green when the full charge level is reached. -
Page 13: Single Sim Slot
Please use the SIM ejector inside the box to Eject the SIM tray The tray has one slot compatible with Nano SIM (4FF). Famoco Square introduces HOT SWAP feature that allow the user to change SIM while device is ON. User manual... -
Page 14: Technical Specifications
9. Technical specifications Type MT8766, Quad-core, ARM Cortex A53 Processor Speed 2GHz Famoco OS based on Android 12 Memory Mass Storage 32GB Characteristics 4.0 ”, 480x480 TFT Display Touch Panel 2 Points & Gesture Secure Element Embedded SE Reader/writer Operating modes ISO14443 A/B, Felica®, Mifare®... - Page 15 TDD: B38, B40, B41 Wi-Fi Dual band (2.4GHz and 5GHz) 802.11 a/b/g/n Wireless connection BT 4.2 Camera Front camera 5 MP FF Speaker, Accelerometer Size L x W x H 90 x 84 x 15 mm Weight 150g Battery 1700mAh Power supply USB Type-C User manual...
-
Page 16: Warranty Information
10. Warranty information The warranty does not apply to defects or errors in the product caused by: Normal wear and tear, misuse, mishandling, and physical damage. Exposure to water or any other liquids or solvents. Any unauthorized disassembly, repair or modification. Power surges, lightning, fire, flood or other natural events. ... -
Page 17: Safety And General Information
11. Safety and general information The device contains delicate electronic circuitry, magnets, and battery systems. You should treat it with care and pay attention to the following points: Handle the device with care. Do not drop or throw the device. Do not immerse it in any liquid. Do not place the device near computer disks, credit cards, and other magnetic media. - Page 18 Don’t use the device immediately after a sudden temperature change e.g. from an air-conditioned environment to high temperature and humidity outside. In such cases, there could be condensing moisture inside the device, which can cause internal damage. Switch off and leave for 30 minutes before use.
-
Page 19: Electromagnetic Waves Safety Information - Sar
11.1 Electromagnetic waves safety information – SAR Your device is designed to not exceed the radio wave limits recommended by the European authorities. These limits include safety margins to ensure the protection of all persons regardless of their age or health. The SAR (specific absorption rate) of mobile phones quantifies the maximum level of exposure of the user to electromagnetic waves, for aural use. -
Page 20: Declaration Of Conformity
A reception icon indicates the quality of reception on your device. A 4-full bar display means that reception is good. 12. Declaration of conformity FAMOCO SAS declares that the radio equipment type Famoco Square is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.famoco.com/conformity/... -
Page 21: Frequency Band Information
13. Frequency band information Cellular connectivity Frequency band information 2G/3G GSM: 850 MHz 900 MHz FDD: B1 (2100 MHz) B8 (900 MHz) FDD: B1 (2100 MHz) B3 (1800 MHz) B7 (2600 MHz) B8 (900 MHz) B20 (800 MHz) TDD: B38 (2570 – 2620 MHz) B40 (2300 MHz) B41 (2500 - 2690 MHz) User manual... -
Page 22: Restrictions In The 5 Ghz Band
14. Restrictions in the 5 GHz band According to Article 10 (10) of Directive 2014/53/EU, the packaging shows that this radio equipment will be subject to some restrictions when placed on the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ), Denmark (DK), Germany (DE), Estonia (EE), Ireland(IE), Greece(EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden (SE), Northern Ireland (UK(NI)), Turkey (TR), Norway (NO),Switzerland (CH), Iceland (IS), and Liechtenstein (LI). - Page 23 March 2025...
