HURAKAN HKN-XRFSG18-2A User Manual

Advertisement

Quick Links

2024
Gas Stock Pot Ranges
Models:
HKN-XRFSG18-2A
HKN-XRFSG18-1A SINGLE
Please read this manual thoroughly prior to equipment set-up,
Note:
operation, and maintenance.
User Manual
DOUBLE
www.equip.me
HKN-XRFSG18-1A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HKN-XRFSG18-2A and is the answer not in the manual?

Questions and answers

Summary of Contents for HURAKAN HKN-XRFSG18-2A

  • Page 1 User Manual 2024 HKN-XRFSG18-1A Gas Stock Pot Ranges Models: HKN-XRFSG18-2A DOUBLE HKN-XRFSG18-1A SINGLE Please read this manual thoroughly prior to equipment set-up, Note: operation, and maintenance. www.equip.me...
  • Page 2 WARNINGS Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other equipment. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 3 Gas Stock Pot Ranges Table of Contents Features & specifications Installation instructions Regular maintenance Troubleshooting Instructions and images in this manual are only for reference and may differ from the actual product. Launch the E-Manual. www.equip.me...
  • Page 4: Features And Specifications

    BTU/hr Input Rating Qty of burners Rating HKN-XRFSG18-1A 85,000 52,000 1 outer+1 inner HKN-XRFSG18-2A 170,000 104,000 2 outer+2 inner Installation IMPORTANT! PLEASE READ BEFORE INSTALLATION: The installation of this equipment must conform with local codes, or with the National Gas Code, ANSIZ223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1, as applicable.
  • Page 5: Propane Gas Conversion

    SET UP Pressure testing: The equipment and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa). The equipment must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½...
  • Page 6: Lighting The Pilot

    LIGHTING THE PILOT: The manifold units are equipped with standing pilots and each should be lit immediately after the gas is supplied to the equipment. 1. Before attempting to light the pilots, turn off the main gas valve to the equipment and wait 5 minutes to clear the gas.
  • Page 7: Operation

    Preheating the stock pot range : Allow thestock pot range to preheat for 30 minutes. Rub grates with cooking oil before using After 20 minutes of burn-in, equipment is ready for use. OPERATION: 1. To ignite the burners, depress and turn the gas control knob to high position.
  • Page 8: Troubleshooting

    Troubleshooting Before requesting any service on your unit, please check the following points. Please note that this guide serves only as a reference for solutions to common problems. Problem Possible Cause Pilot flame too low Pilot Outage Restriction in pilot orifice Restriction in pilot valve Improper burner combustion Improper ventilation...

This manual is also suitable for:

Hkn-xrfsg18-1a
