- Page 1 PROFINET C2P-PN Series Bus Valve Terminal User Manual Nanjing Solidot Electronic Technology Co., Ltd.
- Page 2 C2P-PN Series Bus Valve Terminal User's Manual All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd. 2024. All rights reserved Without the written permission of our company, no unit or individual may excerpt or copy part or all of the contents of this document, or disseminate it in any form.
-
Page 3: Table Of Contents
C2P-PN Series Bus Valve Terminal User's Manual Table of Contents CONTENTS 1 Product Overview ..................................1 1.1 Product introduction ............................1 1.2 Product Characteristics ............................1 2 Designation rules ..................................2 2.1 Designation rules ..............................2 2.2 Model List ................................. 3 3 Product Parameters .................................4 3.1 General parameter ..............................4 4 Panel ...................................... -
Page 4: Product Overview
C2P-PN Series Bus Valve Terminal User's Manual 1 Product Overview Product Overview 1.1Product introduction C2P-PN series valve terminal is a control module integrating valve terminal technology and PROFINET bus technology, through which it can realize decentralized control and centralized control in industrial field, optimize system design, quick construction, and simplify debugging, performance testing and diagnostic maintenance of complex systems. -
Page 5: Designation Rules
C2P-PN Series Bus Valve Terminal User's Manual 2 Designation rules Designation rules 2.1Designation rules Number Definition Description Product Type C2P (RJ45 connector) bus protocol PN: PROFINET protocol abbreviation Number of 08: 8-bits 12: 12 bits 16: 16 bits 20: 20 bits 24: 24 bits Solenoid Valve Positions... -
Page 6: Model List
C2P-PN Series Bus Valve Terminal User's Manual 2 Designation rules Solenoid Valve Model Code List : Valve Brand Code Series Supported Solenoid Valve Models Pitch 4V110/ 4V120/ 4V130 4V210/ 4V220/ 4V230 10.5 7V0510/ 7V0520/ 7V0530 AirTAC 7V110/ 7V120/ 7V130 7V210/ 7V220/ 7V230 5V110/ 5V120/ 5V130 5V210/ 5V220/ 5V230 vuvg-lk10-t32/ vuvg-lk10-m52... -
Page 7: Product Parameters
C2P-PN Series Bus Valve Terminal User's Manual 3 Product Parameters Product Parameters 3.1General parameter Port parameter Bus Protocol PROFINET Data Transmission Category 5+ UTP or STP (STP recommended) Medium Transmission Distance ≤100 m (station to station) Bus Interface 2◊RJ45 Technical Parameters System Power Supply 18~36 VDC Rated Current... - Page 8 C2P-PN Series Bus Valve Terminal User's Manual 3 Product Parameters Weights Varies by product model Dimension Varies by product model (see 5.1 External Dimensions for details) Operating Temperature -5~+50°C Storage Temperature -20~+75°C Relative Humidity 95%, non-condensing Protection Class IP20 Copyright © Nanjing Solidot Electronic Technology Co., Ltd. 2024...
-
Page 9: Panel
4 Panel C2P-PN Series Bus Valve Terminal User's Manual Panel 4.1Product structure Name and function description of each part of the product Number Name Definition ① solenoids "Solenoid Valve Model Code List" for details. ② LED indicator Indicates power, operation and bus status ③... -
Page 10: Indicator Light Function
4 Panel C2P-PN Series Bus Valve Terminal User's Manual ⑥ a ventilation shaft G1/4 ⑦ air intake G1/4 ⑧ communications unit valve terminal Communication and Control Body ⑨ Solenoid valve wiring 4Pin Pop-Up Terminal Block socket ⑩ spoiler (automotive) valve terminal body with A and B silkscreen on both ends 4.2Indicator light function Name Markings... -
Page 11: Installation
C2P-PN Series Bus Valve Terminal User's Manual 5 Installation Installation 5.1Dimensional drawing Overall specifications (unit: mm) L size Positions K=10.5 59.5 80.5 101.5 122.5 143.5 164.5 185.5 206.5 227.5 248.5 269.5 K=16 K=19 K=23 P size Positions K=10.5 136.5 157.5 178.5 199.5 220.5... -
Page 12: Solenoid Valve Assembly Sequence
C2P-PN Series Bus Valve Terminal User's Manual 5 Installation 5.2Solenoid valve assembly sequence Solenoid Valve for valve terminal For details of solenoid valves for valve terminals, see "2.1 Designation Rules Solenoid Valve Model Code List". Solenoid valve installation sequence ... -
Page 13: Wiring
6Wiring C2P-PN Series Bus Valve Terminal User's Manual Wiring 6.1Solenoid valve wiring valve terminal Terminal Distribution The valve terminal terminals are distributed on both sides of the valve terminal manifold, respectively A side and B side, A and B side can be distinguished according to the silkscreen on the end of the valve terminal manifold. - Page 14 6Wiring C2P-PN Series Bus Valve Terminal User's Manual Wiring Tool Requirements The solenoid valve terminal adopts screw-free design, and the installation and removal of cables can be operated with a screwdriver (specification: ≤2mm). Stripping length requirements Recommended cable stripping length for solenoid valve terminals 10 mm Wiring Method For single stranded hard wires, after stripping the corresponding...
- Page 15 6Wiring C2P-PN Series Bus Valve Terminal User's Manual Solenoid valve wiring For different types of valve terminals, 4Pin sockets with corresponding positions are configured on both sides of the manifold, and a set of "+" and "-" of the sockets can drive a solenoid valve coil. As shown in the figure below, A1 and A2 can drive one solenoid valve coil respectively.
-
Page 16: Power Wiring
6Wiring C2P-PN Series Bus Valve Terminal User's Manual Solenoid valve wiring principles: Install the solenoid valve in accordance with "5.2 Solenoid Valve Installation Sequence". AX and BX can be connected to a double electric solenoid valve, and AX can be connected to a single electric solenoid valve. -
Page 17: Bus Wiring
6Wiring C2P-PN Series Bus Valve Terminal User's Manual Precaution The module system-side power supply and the field-side power supply are configured and used separately, so do not mix them. PE needs to be reliably grounded. 6.3Bus Wiring The bus interface uses an RJ45 connector as shown below: Precaution ... -
Page 18: Operation
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Operation 7.1Control method The solenoid valve of the valve terminal is controlled in byte mode. One byte controls 4 valves; at the same time, it can be controlled in bit mode , a set of 8 positions, control 1->8 pass channel, the channel value is If the channel value is 1, the corresponding solenoid valve is open, and if the channel value is 0, the corresponding solenoid valve is closed. - Page 19 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation control valve [9...12] method valve valve valve valve valve valve valve valve channel [9..12] [9...12] [9...12] [9...12] [9...12] [9...12] [9...12] [9...12] address Coil Solenoid Valve No. control valve [13...16] method Valve Valve Valve Valve...
-
Page 20: Diagnostic Function
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 7.2diagnostic function The C2P-PN valve terminal has an open circuit diagnostic (Open load) and a short circuit or overtemperature diagnostic (Short circuit or overtemperature). An open circuit can only be monitored if the valve is closed and a short circuit can only be monitored if the valve is open. - Page 21 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation diagnostic Open load[24..31] function Open Open Open Open Open Open Open Open channel [24..31] [24..31] [24..31] [24..31] [24..31] [24..31] [24..31] [24..31] address Coil Solenoid Valve No. diagnostic Open load [32..39] function Open Open Open...
-
Page 22: Parameter Description
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 7.3Parameter description 7.3.1 Output signal clear/hold function The clear/hold function is for the output signal of the valve terminal, and this function can configure the output action of the valve terminal in the abnormal state of the bus. Clear Output: When communication is disconnected, the valve terminal output channel automatically clears the output. -
Page 23: Configuration Applications
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 7.4Configuration Applications 7.4.1 Application in TIA Portal V17 software environment 1、Preparation hardware environment valve terminal Model C2P-PN-24B One computer with pre-installed TIA Portal V17 software Shielded cable for valve terminal ... - Page 24 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 3、Adding PLC controller Click “Configure A Device”, as shown in the following figure. Click "Add New Device", select the PLC model you are currently using, and click "Add", as shown in the following figure.
- Page 25 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 4、Scanning connected devices Click "Online Access -> Update Accessible Devices" in the left navigation tree as shown below. When the update is complete, the connected slave devices are displayed, as shown in the following figure.
- Page 26 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 5、Adding a GSD profile In the menu bar, select "Options -> Manage General Station Description File (GSDML) (D)". Click Source Path to select the file. Check if the status of the GSD file you want to add is "Not yet installed", click the "Install" button if it is not installed, or click "Cancel"...
- Page 27 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Find "C2P-PN-24B" module in the hardware catalog, drag or double-click "C2P-PN-24B" to the "Network View", as shown below. If you want to connect more than one module, you can add modules according to the actual topology under "Hardware Catalog" on the right side. Click "Unassigned (blue font)"...
- Page 28 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click on the device name to rename the device, as shown in the following figure. Click "Device View" to enter the device overview, you can see the topology configuration information, including the I/O address automatically assigned by the system, the I/O address can be changed by yourself, as shown in the following figure.
- Page 29 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 7、Assign device name Switch to "Network View", right-click the connection cable between PLC and C2P-PN-24B, and select "Assign Device Name" as shown below. The "Assign PROFINET Device Name" window pops up as shown below. Check whether the MAC address on the module silk screen is the same as the MAC address of the assigned device name.
- Page 30 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Select the slave device in turn, click Update List, and click Assign Name. Check whether the status of the node in the "Accessible nodes in the network" is "OK", as shown in the following figure. If it is not OK, click Assign Name.
- Page 31 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click "Start Search" as shown below. Click on "Download". Select "Continue without synchronization" as shown below. Select "Stop All". Copyright © Nanjing Solidot Electronic Technology Co., Ltd. 2024...
-
Page 32: Communication Connection
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click “Load”. Click “Finish”. Power on again the device. 9、Communication connection Click the button, and then click the "Go Online" button, the icons are all green, that is, the connection is successful, as shown in the figure below. Copyright ©... -
Page 33: Parameter Setting
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 10、 Parameter setting Open “Network View”, and in the offline state, right-click on the Module View icon section and click “Properties”, as shown in the following figure. In the property page, click "Module Parameters", as shown in the following figure. Parameters can be configured according to the actual use of the need to configure, after the completion of the configuration, re-download the program to the PLC, the PLC and the module need to be re-powered. - Page 34 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Output Signal Clear/Hold Parameter Function, Module Overall Clear and Hold Function Module Data Clear or Hold Settings, you can choose Clear, Hold or Clear_Hold_By_Channel as shown below. Output Signal Clear/Hold Parameter Function, Module Single Channel Clear or Hold Function Chx Data Clear or Hold Settings.The prerequisite for the single channel setting to take effect is to set the overall function Module Data Clear or Hold Settings to Clear_Hold_By_Channel, and after that, set each channel function, you can choose Clear or Hold, as shown in the following figure.
-
Page 35: Function Verification
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 11、 Function verification Expand the left side of the project navigation, select "Watch and Force Tables", as shown in the following figure. Double-click "Add New Watch Table", the system adds a new watch table, as shown in the following figure. - Page 36 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Open the "Device overview" and check the channel Q address (channel address of the output signal) and I address (channel address of the input signal) of the module C2P-PN-24B in the device overview.
- Page 37 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Open diagnostic Open load, a diagnostic value valid when the channel solenoid coil output is off (i.e., 0). In the "Monitor Value" of Open load[0..7]~Open load[40..47], you can check the diagnostic value of open solenoid valves for each group of channels of the valve terminal as a whole, and it will be 0 if the solenoid valve coils of a group of channels are normal, but not 0 if any solenoid valves have open circuits.
- Page 38 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Channel output control, if you want to make the valve terminal of any group of solenoid valve coil output open to the first group of channels, for example, you can enter "FF" in the "Modified Value" cell of QB0, click the button to write, you can open the first group of solenoid valve coil channels, other channels open output method is the same, as shown in the figure below.
-
Page 39: Application In Step 7-Microwin Smart Software Environment
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 7.4.2 Application in STEP 7-MicroWIN SMART software environment 1、Preparation Hardware environment Valve terminal Model C2P-PN-24B A computer with pre-installed STEP 7-MicroWIN SMART V2.6 software Shielded cable for valve terminal ... - Page 40 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click the left navigation tree button, the "Communication" window pops up, switch the communication interface for the actual interface used by the PLC, click the "Find CPU" button to find the PLC, as shown in the following figure. Click the "Edit"...
- Page 41 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation 3、Importing GSD files Click the menu bar "File -> GSDML Management", click the "Browse" button in the GSDML management window, select the GSDML file to be imported, click "OK" button, as shown in the figure below.
- Page 42 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click the "Edit" button to edit the module name, after editing, click the "Set" button, as shown in the figure below. 5、Configuration of PROFINET networks Click "Tools -> PROFINET" in the menu bar to open the PROFINET Configuration Guide, as shown in the following figure.
- Page 43 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click “Next” to enter the Controller Configuration page, add a device from the device catalog tree on the right, select C2P-PN-24B, and click the “Add” button as shown below. Double-click the input box below the device name to enter the device name, which needs to be the same as the name set when finding the device;...
- Page 44 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click the "Next" button, you can see that the starting address of the module's inputs and outputs are all 128, as shown in the following figure. Click the “Next” button to see the module's configuration parameters page, as shown in the following figure.
- Page 45 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Output Signal Clear/Hold Parameter Function, Module Overall Clear and Hold Function Module Data Clear or Hold Settings, you can choose Clear, Hold or Clear_Hold_By_Channel as shown below. Output Signal Clear/Hold Parameter Function, Module Single Channel Clear or Hold Function Chx Data Clear or Hold Settings.The prerequisite for the single channel setting to take effect is to set the overall function Module Data Clear or Hold Settings to Clear_Hold_By_Channel, and after that, set each channel function, you can choose Clear or Hold, as shown in the following figure.
-
Page 46: Download Program
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click the "Next" button to complete the configuration wizard, click the "Generate" button, the network configuration is complete, as shown in the following figure. 6、Download program Click the menu bar "File -> Download" button, the download window pops up, click the "Download"... -
Page 47: Functional Verification
C2P-PN Series Bus Valve Terminal User's Manual 7 Operation When the download window indicates that the download has been successfully completed, click the "Close" button. Note: After the download is complete, power the module back up for processing. 7、Functional verification Click "PLC ->... - Page 48 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Click "Status Chart -> Chart 1" in the left navigation tree, and enter the corresponding channel address and data format in Chart 1, you can perform forced output and input monitoring operations on the module here.
- Page 49 C2P-PN Series Bus Valve Terminal User's Manual 7 Operation Short circuit/overtemperature diagnosis, the diagnostic value is valid when the channel solenoid valve coil output is on (i.e. 1). In IB134~IB139 corresponding to the "current value", you can check the diagnostic value of short circuit or overtemperature of solenoid valve corresponding to each group of channels of the valve terminal as a whole, and the value will not be 0 if there is a solenoid valve with short circuit/overtemperature, and it will be 0 if there is no short circuit/overtemperature.
-
Page 50: Faq
8 FAQ C2P-PN Series Bus Valve Terminal User's Manual 8.1 When updating accessible devices, the device cannot be found 1. Confirm that TIA Portal software is installed correctly. 2. Make sure that no other software is occupying the network adapter used by the Porto software. 3.
