- Page 1 LCD TV L42E77AZ/L46E77AZ OPERATION MANUAL...
-
Page 3: Warning And Precaution
WARNING AND PRECAUTION Read all of the instructions before operating the set. Keep these instructions well for later use. All instructions must be followed during the operation. PRODUCT Do not block or cover the ventilation openings on the back cover. Do not push any objects of any kind into this unit through the cabinet slots as they could touch the current carrying parts or short-circuit parts, resulting in fire, electric shock, or damage to the unit. - Page 4 WARNING AND PRECAUTION Keep away from direct Apparatus shall not be exposed to Do not use the set near dusty sunlight. dripping or splashing and no objects environments. filled with liquids, such as vases, shall be placed on the apparatus. CLEANING Dust the set by wiping the screen and cabinet with a soft, clean cloth or some special liquid cleaner.
-
Page 5: Table Of Contents
TABLE OF CONTENTS WARNING AND PRECAUTION..........TABLE OF CONTENTS............FUNCTIONS AND FEATURES..........EXTERNAL SCHEMATIC AND INSTALLATION....FRONT & SIDE PANEL................. BACK PANEL..................BASE INSTALLATION................ANTENNA/CABLE CONNECTION............REMOTE CONTROL................SETTING UP YOUR TV............MENUS CONTROL..............BASIC OPERATION................ADJUSTING THE PICTURE..............ADJUSTING THE SOUND..............SETTING THE TIME................ -
Page 6: Functions And Features
FUNCTIONS AND FEATURES TV FUNCTION 1. Auto Volume Control 2. English menu 3. 3 Selectable Colour Temperatures 4. USB socket (supports MPEG1-2-4, MP3, JPEG playback and printer output) 5. Full-function Infra-red Remote Control 6. Multi-system 7. 100 preset programs in Analogue mode, and 1000 preset programs in Digital mode 8. -
Page 7: External Schematic And Installation
EXTERNAL SCHEMATIC AND INSTALLATION FRONT & SIDE PANEL POWER INDICATOR 5. VOLUME DOWN button 9. SPEAKER 2. PROGRAM UP button 6. MENU button 7. INPUT button 3. PROGRAM DOWN button 4. VOLUME UP button 8. REMOTE SENSOR... -
Page 8: Back Panel
EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL 1. HDMI(P): Connect to same jacks of other HDMI(P) terminals (such as DVD and Games Console; supports up to 1080P). 2. HDMI: Connect to same jacks of other terminals (such as DVD and Games Console; supports up to 1080i). - Page 9 EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL 8. VGA AUDIO INPUT: Connect a PC via an audio VGA AUDIO INPUT cable. 9. VGA INPUT: Connect a PC via a VGA cable. VGA INPUT 10. COMPONENT INPUT: Connect component terminals (DVD, SET TOP BOX, VCR, Camcorder, etc.) to COMPONENT INPUT(Y, Pb/Cb,Pr/Cr) jacks on the TV Pb/Cb...
- Page 10 EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL connect to USB devices such as USB disk, digital camera, mp3, PRINTER mobile hard disk. connect to a printer. 15. AV2: Connect video terminals (DVD, SET TOP BOX, VCR, Camcorder, etc.) to the VIDEO jack on the TV; AUDIO: Connect audio terminals (DVD, SET TOP BOX, VCR, Camcorder, etc.) to the R and L AUDIO jacks on the TV.
-
Page 11: Base Installation
EXTERNAL SCHEMATIC AND INSTALLATION BASE INSTALLATION Note: If the base has been assembled, just ignore the following instructions and go to the next section. M4X16 machine screws M4X20 machine screws The state after installing 1. Get the base and the supplied screws out of the package. Note: Be careful to place the hefty base safely in case of damage. -
Page 12: Antenna/Cable Connection
EXTERNAL SCHEMATIC AND INSTALLATION ANTENNA/CABLE CONNECTION There are two kinds of antenna in use. VHF TV ANTENNA TWO KINDS OF ANTENNA UHF TV ANTENNA To TV VHF/UHF No need to install adapter ANTENNA jack (Note 1) U/V MIXER COAXIAL ANTENNA Need to install adapter VHF/UHF When connected with... -
Page 13: Remote Control
EXTERNAL SCHEMATIC AND INSTALLATION REMOTE CONTROL REMOTE CONTROL KEYS MUTE To switch sound off and back on again. (standby) To turn the TV on or off (standby). INPUT To select TV signal source. MUTE A/DTV To switch between analogue TV mode and digital TV mode. RADIO To switch to Radio in DTV mode. - Page 14 EXTERNAL SCHEMATIC AND INSTALLATION For using the remote control, follow these instructions: 1. Open the back cover of the remote control, then insert two AAA 1.5V batteries with polarities matching with the marks inside the battery compartment. Then, close back cover. 2.
-
Page 15: Setting Up Your Tv
SETTING UP YOUR TV There are several steps you need to follow before you can turn on the TV. Follow the instructions below to set up and turn on your TV. 1. Plug one end of the cord into the back of the TV, and plug the other end into an appropriate wall outlet. -
Page 16: Menus Control
MENUS CONTROL This section explains the menus of your TV, to help you get the most from your TV. BASIC OPERATION 1. Press MENU on the remote control to display the overview menu. 2. Press PROGRAM UP/DOWN to select the desired item. 3. -
Page 17: Adjusting The Sound
MENUS CONTROL ADJUSTING THE SOUND The Sound menu lets you adjust audio output. Display the OVERVIEW menu by pressing the MENU button. Select the Sound option and press OK or VOLUME UP to confirm. Sound 08:05 The Sound menu appears with the following options: Effect Music Treble... -
Page 18: Setting The Installation
MENUS CONTROL Timer Type: use VOLUME UP/DOWN to select a type offered (Turn Off, Inactive, Turn On), which enables this function and provides access to the relevant options. Timer1 08:05 Timer Type Turn Off Channel • DTV: set a channel which you want to wake up. Press Channel DTV Time 17:27:00... -
Page 19: Setting The Preferences
MENUS CONTROL Channel Edit: edit channels, such as deleting channels, skipping channels, sorting channels, locking or unlocking channels. Select the Channel Edit option using PROGRAM UP/DOWN, and press OK or VOLUME UP to display the ATV Channel menu in ATV mode, or the DTV Channel menu in DTV mode. - Page 20 MENUS CONTROL Favorite Mode: select one from the favorite lists you have edited in the Organizer menu as the current active list using VOLUME UP/ DOWN. Once a favorite list is selected, you can only access all the channels included in the favorite list by pressing PROGRAM UP/ DOWN.
-
Page 21: Calendar And Games
MENUS CONTROL CALENDAR AND GAMES The Cal/Game menu can be used to browse the calendar Cal/Game 08:05 and play games. Calendar Calendar: select this option using PROGRAM UP/DOWN, Boxman press OK or VOLUME UP to confirm. Calendar menu Tetris displays. Use VOLUME UP/DOWN to display different year, to display different month using PROGRAM UP/ DOWN. -
Page 22: Special Functions
SPECIAL FUNCTIONS CHANNEL LIST The List menu is a shortcut to access a channel. In ATV or DTV mode, press the LIST button on the remote control to display the List menu. The menu is displayed with the current channel selected. Browse through the previous or next pages using VOLUME UP/DOWN and select a channel on the current page using PROGRAM UP/DOWN, then press OK to display the selected channel. - Page 23 SPECIAL FUNCTIONS SELECT TELETEXT 1. USING NUMERIC BUTTONS Enter the desired page number using the number buttons. 2. OTHER SELECTION Press colour buttons on the remote control to select the corresponding page directly with the colour item on the navigation line.
-
Page 24: Usb Functions
USB FUNCTIONS SOURCE 1. Press the INPUT button on the remote control or on the TV set repeatedly to select USB. Then the USB root menu will display on the screen. 2. Press the USB function buttons on the remote control to perform the operations. -
Page 25: Music
USB FUNCTIONS To browse pictures: 1. Press to switch between the auto mode and manual mode. 2. When playing manually, press LEFT/RIGHT to browse pictures. 3. When playing pictures, press OSD to display the control menu. 4. Press LEFT/RIGHT and OK to use the functions on the control menu. 5. -
Page 26: Picture & Music
USB FUNCTIONS PICTURE & MUSIC Press LEFT/RIGHT to select p&m icon on the root menu, then press OK. 2. Press UP, DOWN, LEFT or RIGHT and OK to access the folders and sub-folders until any music file appears. 3. Press RIGHT to highlight the selected MP3 file, this means that the system will play from that file as the background music. -
Page 27: Text
USB FUNCTIONS TEXT MEDIA PLAYER Press LEFT/RIGHT to select text icon on the root menu, USB.TXT then press OK. 2. Press UP, DOWN, LEFT or RIGHT and OK to access the folders and sub-folders until any TXT file appears. press OK to show text, LEFT to return 3. -
Page 28: Supported Usb Devices And File Types
USB FUNCTIONS Jpeg Play Mode MEDIA PLAYER 1. When displaying the operation interface, press UP/DOWN to Jpeg Quality Priority select Jpeg PlayMode, then press OK (see figure 5). Jpeg Speed Priority 2. Press UP/DOWN and OK to select the Jpeg Quality Priority or Jpeg Speed Priority. -
Page 29: Troubleshooting
TROUBLESHOOTING NO PICTURE, NO SOUND 1. Check if the fuse or circuit breaker is working. 2. Plug another electrical device into the outlet to make sure it is working or turned 3. Power plug is in a bad contact with the outlet. 4. - Page 30 TROUBLESHOOTING SNOWY DOTS AND INTERFERENCE If the antenna is located in the fringe area of a television signal where the signal is weak, the picture may be marred by dots. When the signal is extremely weak, it may be necessary to install a special antenna to improve the reception.
-
Page 31: Specification
SPECIFICATION MAIN UNIT Audio output power: 42": 10W 46": 10W Working voltage: 110-240V~ 50/60Hz Rated power consumption: 42": 204W 46": 279W Power consumption: <1W (in standby mode) Screen size (diagonal): 42": 107cm 46": 117cm Dimensions (WXDXH): 42": 1062mm X 280mm X 769mm(with stand) 46": 1148mm X 280mm X 815mm(with stand) Environment: Working temperature: 5 C~35 C...
