INSTALLATION INFORMATION
7/16" Socket
}
P/N: 025527KP
}
P/N: 0SS119KP
P/N: 025527KP
TRIPLE UTILITY HOOK
RM470209 Rev 2
P/N: 0SS119KP
Page 1 of 5
Advertisement
Summary of Contents for Masterack 025527KP
- Page 1 INSTALLATION INFORMATION Recommended Tools 7/16” Socket Air or Hand Ratchet 7/16” Combo Wrench Torque Wrench P/N: 025527KP Hardware P/N: 025527KP 1/4-20 x 3/4 1/4-20 Hex Head Screw E-Stop Nut P/N: 0SS119KP TRIPLE UTILITY HOOK P/N: 0SS119KP 0SS011P 1/4-20 x 2...
-
Page 2: Torque Setting
ATTACHING TRIPLE HOOK TO SHELVING MODULES ATTACHING TO STANDARD MODULES ATTACHING TO SMARTSPACE MODULES Position Triple Hook at the desired location, Position Triple Hook at the desired location, and secure to Upright using: and secure to Upright using: (2) 1/4-20 x 3/4 Hex Head Screws (2) 1/4-20 x 2 Hex Head Screws (2) 1/4-20 E-Stop Nuts (2) Channel Nut... - Page 3 ATTACHING TRIPLE HOOK TO PARTITIONS and OTHER SURFACES Installed PlusNuts ATTACHING TO OTHER SURFACES ATTACHING TO PARTITIONS Position Triple Hook at the desired location, Position Triple Hook at the desired location, and secure to Upright using: and secure to Upright using: (2) 1/4-20 x 3/4 Hex Head Screws (2) 1/4-20 x 3/4 Hex Head Screws (2) 1/4-20 PlusNuts (See Page 4 of 5)
- Page 4 PLUSNUT INFO RM470209 Rev 2 Page 4 of 5...
- Page 5 3 Year / 36,000 Mile Limited Warranty (3) years or 36,000 miles (60,000 KM)
