Summary of Contents for Bullmer KW2000S
- Page 1 The Machine For KW2000S Model Operation Instruction Read a handbook please detailedly before handling a machine...
- Page 2 Mechanical and Electrical Technology Co.Ltd. NO.181,Qiyihe Road Jiangnan Street , Zhejiang Province Lin Hai City,China. Tel：0576-89399566 Fax：0576-89399599 Global service hotline ：400 111 9100...
- Page 3 KW2000S model bullmer Copyright Notice This manual's copyright is reserved by bullmer Mechanical and Electrical Technology Co.Ltd. Without the company's written permission, can't copy all or part of this document in any way. This document is the patent equipped by our company.
- Page 4 KW2000S model bullmer Pay Attention To Before Operation： Proximity Switch Induced Point When proximity switch goes to left and passes through induction point, the current position returns to 0. This is the benchmark point of machine calculating position.returns to 0.
- Page 5 KW2000S model bullmer Normal Operation : Rewinding Cloth: Place as the above figure. When spreading the necessary keys are: Folding yard cloth: place as the above figure. When spreading the necessary keys are:...
- Page 6 KW2000S model bullmer Normal Operation: Single Spreading Hang up cutting group and plug connector,the spreader will automatically enter into Single Spreading mode,and don't have to do any other setting. Double Spreading Remove the cutting group and install the outrigger,the spreader will automatically enter into Double...
- Page 7 KW2000S model bullmer Doublespreading : needs to use two-end pressure device, the back-end device should push forward and be fixed the front point with bolt. (For single spreading, not needs back-end device, when double spreading should pull to bottom and be fixed the back point.)
- Page 8 KW2000S model bullmer [Inch move handle] : Manually rotate machine's handle.Clockwise rotation for Right movement, counter clockwise rotation for left movement, and control speed by rotation angle. Normal Operation : Set spreading length Set quantity Demon Strate location now...
- Page 9 KW2000S model bullmer Press it and display digital keyboard as the right figure, input the desired figure and press ENTER ,「Spreading length」 Unit: cm 1M=100cm 1inch=2.54cm Single spreading mode: When「COUNT」achieves「WANTED」value, the machine will stop. Continuous spreading mode: When all「COUNT」achieve「WANTED」value, the machine will stop.
- Page 10 KW2000S model bullmer Normal Operation: Rewinding cloths are placed into bucket and controlection by The piece of cloth will not use buckettion key and cancel ON to make bucket not operate. Cloth Sending Button Under the cloth sending status, when the machine moves, the cloth sending roller will send out cloth downwards by rotation.
- Page 11 KW2000S model bullmer Press it Press it Press automatic key and the spreader will enter into automatic spreading status. When the cloths are all set, confirm the direction be correct and then press the key to spread.
- Page 12 KW2000S model bullmer Call buck Inch move Cloth bucket roller“Manual”key When press the cloth will roll back with low speed. When press the cloth will roll out with low speed. The key of knife stone Press The blade rotates and then gently press millstone to sharpen according to the set time.
-
Page 13: Normal Operation
KW2000S model bullmer Normal Operation: Layer number grid Figure grid grid 1.Press Layer mumber grid for 0.5 second to let all layer number grids return to 0. 2.Press Figure grid for 0.5 second to let the grid return to 0. Please input 0 for unused mode... - Page 14 KW2000S model bullmer For single mode spreading, please use Mode 1.Spreading mode: when spreading length has long and short yards,can preset Mode 2-3 length and layer number. Start coherent spreading functions, the machine will pass through all modes of having set preset value according to mode 123,then stop.
- Page 15 KW2000S model bullmer Normal Operation: Left-end Point Stop Key If you need to stop operation when completing the next cloth, press and the machine will stop at left-end point after completing this cloth. Set Value Of Automatic Rising Quantity Automatic rising quantity.
- Page 16 KW2000S model bullmer Cutting speed Cutting length Cutting bottom 2 Cutting button 2: Press this button for manual cutting, the layer number will add 1. According to cloth nature and width to set cutting speed and length to make them well cooperate with.
- Page 17 KW2000S model bullmer Faults: F1——Round knife motor Circuit protector F2——DC24V Circuit protector F3——Opposite side motor Circuit protector For overcurrent, the circuit protector will jump, after pressing back and again tries out, if not jump, can safely continue to operate.
- Page 18 KW2000S model bullmer Simple trouble removal ： Problem Cause Countermeasures 1.Circuit protector F1 jumps 1.Press back and again try out, if normal, 2.Relay connection continue to use. If over and over again point is burned Cutter blade doesn't jump, maybe have a short circuit, Or the 3.Motor carbon or rotor is...
- Page 19 KW2000S model bullmer Maintenance: Figure 1 Figure 2 Figure 3 Basic Maintenance : 1.Chain: Add Lubricant And Adjust Elasticity For lubricant of chain, 40# machine oil is advisable,adding once every 2 months,note not excessive to avoid greasy dirt.
