Regular
Mounting
plate type
mounting
Dimension(unit: mm)
LR130U/LR131U
Regular
LR130C/LR131C
Magnetic mounting
上海南华机电有限公司
电话：+86 021-39126868
LR13 Beacon LED
Application
Design for engineering machinery(overhead crane, crawler crane, gantry crane etc), harbour
crane(quay crane, mobile crane etc.)
Main features& advantages
• Super bright LED light source, long lifetime, energy saving and environment protection, instant
light up and off.
• Adopts single group constant current drive, digit control technology ensure product stability
and durability.
• Integrated lens adopts high transmitting material, professional photometric design improve
luminous efficient.
• Water proof, anti-corrosion, vibration resistant and UV resistant.
• Various mounting and wiring type for option.
• Option: external power supply
Magnetic
Specification
Operating
voltage
Power supply
Input voltage
Warning
mode
Color
Operating
temperature
Humidity
Material
Model selection table
----
LR13
e.g.：LR130C
Installation and Operation
• Check whether the operating voltage complies with the rated voltage of the warning light
• Regular mounting: Fix it onto the surface with 3pcs M6 bolts
Flange mounting: Fix it onto the surface which has enough strength with 3pcs M6 bolts and nuts
Magenetic mounting: Fix it onto the surface of the magnetic metal which has enough magnetic
force to avoid the coming off because of fierce shock or strong wind.
Thread rod mounting: Fix it on M24 thread rod.
传真：+86 021-39126868 分机 808/818
南华机电版权所有，如无南华书面授权，任何部分不得以任何形式复制或传播
DC12V/DC24V/AC110~AC260V (optional)
AC380V/AC460V (optional)
Flash/ Steady burning/ Rotating/ Strobe flash
Red, Amber (can be customized)
-40˚C ~ +75˚C
10% ~ 95% (non condensation)
Base: PA6+GF30%, Lens: PC
-
-
0---110
U ---
Screw mounting
V~260VAC
---
C ---
Magnetic mounting
1
12VDC/24VDC
T ---
Mounting plate
H ---
Threaded pipe mounting
F ---
Flange mounting
LR13
，110~260VAC，
means
series
网址：www.nanhua.com
Power
Light
source
light
intensity
IP rating
Weight
（
）
Regular
（
DC voltage only
Mounting plate type.
E-mail：sales@nanhua.com
地址：上海嘉定区蕰北路 1755 号 9 号楼
LR13-E0-V10
≤40W
LED
≥300cd
IP65
0.8kg
）
邮编：201802
1 / 1
Advertisement
Summary of Contents for NANHUA LR13
- Page 1 LR13-E0-V10 LR13 Beacon LED Application Design for engineering machinery(overhead crane, crawler crane, gantry crane etc), harbour crane(quay crane, mobile crane etc.) Main features& advantages • Super bright LED light source, long lifetime, energy saving and environment protection, instant light up and off.
- Page 2 LR13-E0-V10 LR13 Beacon LED Wiring dagram Dimension(unit: mm) This product comes with a 2 x 0.75mm black jacket wire, line length 2M; which type of installation for the U, C, T by the side of the stuffing outlet; installation for the F and H using the bottom outlet line, as shown in figure 1, for the installation with lead wire, red wire to DC+ or AC_L(Fire wire), black wire to DC-or AC_N(neutral).
- Page 3 LR13-E0-V10 LR13 Beacon LED Installation and wiring connection diagram Method of power supply The product with flash work mode manual adjustable function, also with fault alarm function. （picture 2）； M20*1.5 Cable gland Manual adjusting way for alarm mode, please operate it under power off. Screw off setscrew at the side of the light.
