ECCO SAFETY GROUP Code 3 CD5031 Series Assembly, Installation And Operation Instructions

Surface mount/stud mount

Advertisement

Available languages

Available languages

Quick Links

IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1.
Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2.
Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3.
This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4.
Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5.
Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the effectiveness of the air bag or become a projectile that could cause serious personal injury or death.
Refer to the vehicle owner's manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable
mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6.
It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
7.
The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator's responsibility to be sure they can proceed safely before entering an
intersection, drive against traffic, respond at a high rate of speed, or walk on or around traffic lanes.
8.
This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specifications:
Input Voltage
Current
Power
Temp. Range
Physical H x W x L
Ship Weight
CD5031XX
CD5031XXX
12-24VDC
0.6A @ 12VDC
7.7W
-40C to 65C [-40F to 149F]
3.2" x 0.6" x 0.9" (No Bezel)
4.0" x 0.9" x 0.9" (With Bezel)
0.2 lb
Installation and Operation Instructions
CD5031 SURFACE MOUNT/STUD
MOUNT
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Code 3 CD5031 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ECCO SAFETY GROUP Code 3 CD5031 Series

  • Page 1 Installation and Operation Instructions CD5031 SURFACE MOUNT/STUD MOUNT IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user. WARNING! Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/ or death to those you are seeking to protect! Do not install and/or operate this safety product unless you have read and understood the safety information contained in this manual.
  • Page 2: Installation And Mounting

    Installation and Mounting: IMPORTANT! This unit is a safety device and it must be connected CAUTION! to its own separate, fused power point to assure its continued When drilling into any vehicle surface, make sure that the operation should any other electrical accessory fail. area is free from any electrical wires, fuel lines, vehicle upholstery, etc.
  • Page 3 Rear surface mount: Step 1. Run the cable of the light head through the center hole of the stud mounting bracket. The countersunk holes and studs should be facing away from the light head. Secure the stud mounting bracket to the light head using the two M2.5x10mm flathead screws (not shown).
  • Page 4: Wiring Instructions

    Wiring Instructions: WHITE - SEE TABLE BELOW WHITE - GROUP 2 (CD5031XXX ONLY) GREEN - MODE TO POSITIVE GREEN - SEE TABLE BELOW SELECT TO GROUND RED/WHITE - SEE TABLE BELOW RED/WHITE - GROUP 3 TO POSITIVE SWITCH SWITCH (USER SUPPLIED) YELLOW - YELLOW - SEE TABLE BELOW (USER SUPPLIED)
  • Page 5 CD5031 Dual Color Flash Pattern Chart LED Color 1 & Color 3 LED Color 1 & Color 3 LED Color 2 & Color 4 Pattern LED Color 2 & Color 4 PATTERNS SYNC. COMPLIES WITH Red line White line Red & White line SAE/T13 SAE/T13 Single 75FPM Ph1 Color 1 Synchronous Color 3 S1,C SAE/T13 SAE/T13 Single 75FPM Ph2 Color 1 Synchronous Color 3...
  • Page 6 CD5031 Tri Color Flash Pattern Chart Red Wire (Color 1 Default) White Wire (Color 2 Default) PATTERN Red + White Wire (Color 3 Default) FLASH PATTERN SYNC. COMPLIES WITH GROUP Mode4 Mode5 Mode6 Mode7 Mode1 Mode2 Mode3 Color Color Color Color Color1 Color2...
  • Page 7: Warranty

    10986 North Warson Road, St. Louis, MO 63114 USA Technical Service USA (314) 996-2800 c3_tech_support@code3esg.com CODE3ESG.com An ECCO SAFETY GROUP™ Brand ECCOSAFETYGROUP.com © 2024 Code 3, Inc. all rights reserved. 920-1109-00 Rev. A Page 7 of 7...
  • Page 8: Especificaciones

    Instrucciones de instalación y operación MONTAJE EN SUPERFICIE/EN PERNO DE LA SERIE CD5031, CON 12 LUCES LED DE COLOR DOBLE ¡IMPORTANTE! Lea todas las instrucciones antes de instalar y utilizar. Instalador: Este manual se debe entregar al usuario final. ¡ADVERTENCIA! Si no sigue las instrucciones del fabricante a la hora de instalar o usar el producto, pueden producirse daños materiales, y lesiones graves o incluso mortales a aquellos que pretende proteger! No instale ni opere este producto de seguridad, a menos que haya leído y comprendido la información de...
  • Page 9: Instalación Y Montaje

    Instalación y montaje: Nota: Se recomienda aislar los cables, despuntados o no, IMPORTANTE Esta unidad es un dispositivo de seguridad, y debe que se hayan cortado o no se utilicen. El cabezal de luz tiene conectarse a una toma independiente de alimentación con fusible un pequeño orificio redondo cubierto con una membrana de para garantizar su funcionamiento continuo si fallase cualquier ventilación que debe mirar hacia abajo al montar el cabezal de...
  • Page 10 Montaje de superficie posterior: Paso 1. Pase el cable del cabezal de luz a través del orificio central del soporte de montaje del perno. Los orificios avellanados y los pernos deben estar orientados en dirección opuesta al cabezal de luz. Fije el soporte de montaje del perno al cabezal de luz con los dos tornillos de cabeza plana M2,5 x 10 mm (no se muestran).
  • Page 11: Instrucciones De Cableado

    Instrucciones de cableado: BLANCO - MIRA EL CUADRO DE (CD5031XXX SOLAMENTE: WHITE - GROUP 2 GREEN - MODE ABAJO VERDE - MIRA EL CUADRO DE TO POSITIVE SELECT TO GROUND ABAJO ROJO/BLANCO - MIRA EL RED/WHITE - GROUP 3 CUADRO DE ABAJO TO POSITIVE INTERRUPTOR SWITCH...
  • Page 12 10986 North Warson Road, St. Louis, MO 63114 USA Sevicio Técnico USA (314) 996-2800 c3_tech_support@code3esg.com CODE3ESG.com An ECCO SAFETY GROUP™ Brand ECCOSAFETYGROUP.com © 2024, Code 3, Inc. Todos los derechos reservados. 920-1109-00 Rev. A Página 5 de 5...
  • Page 13: Instructions D'installation Et D'utilisation

    Instructions d’installation et d’utilisation MONTAGE EN SURFACE/MONTAGE À ERGOT CD5031, 12 LED, BICOLORE IMPORTANT! Lisez toutes les instructions avant d’installer et d’utiliser le produit. Installateur : ce manuel doit être remis à l’utilisateur final. AVERTISSEMENT! Le non-respect des recommandations du fabricant au cours de l’installation ou de l’utilisation de ce produit peut entraîner des dommages matériels et causer à...
  • Page 14: Installation Et Montage

    Installation et montage : Remarque : il est recommandé d'isoler les câbles/câbles ATTENTION ! Cette unité est un dispositif de sécurité et elle doit émoussés qui ont été coupés ou ne sont pas utilisés. La tête être connectée à son propre point d'alimentation indépendant protégé...
  • Page 15 Montage en surface à l’arrière : Étape 1 Faites passer le câble de la tête d’éclairage dans le trou central du support de fixation du montant. Les trous fraisés et montants doivent être orientés à l’écart de la tête d’éclairage. Fixez le support de fixation du montant à...
  • Page 16 Instructions de câblage : BLANC - VOIR TABLEAU CI- (CD5031XXX SEULEMENT) WHITE - GROUP 2 GREEN - MODE DESSOUS VERTE - VOIR TABLEAU CI- TO POSITIVE SELECT TO GROUND DESSOUS ROUGE/BLANC - VOIR TABLEAU RED/WHITE - GROUP 3 CI-DESSOUS TO POSITIVE COMMUTATEUR (FOURNI SWITCH PAR L’UTILISATEUR)
  • Page 17: Garantie

    à l’expéditeur après la prestation. 10986 North Warson Road, St. Louis, MO 63114 USA Service Technique USA (314) 996-2800 c3_tech_support@code3esg.com CODE3ESG.com An ECCO SAFETY GROUP™ Brand ECCOSAFETYGROUP.com © 2024 Code 3, Inc. Tous droits réservés. 920-1109-00 Rév. A Page 5 sur 5...
