AVR5 / AVR7 / AVR9 / M1X1 / M2X1
AVRT5 / AVRT7 / AVRT7-PZX9
AVR5/7
500(w) x 700(h)
x 500(d) / 700(d)
AVR5/7 with
M1XI -->
Screen Size: 33-110"
*Please check model specific details before installing*
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
AVRT5/7 with
M2XI -->
Guide Max. Weight: 150kg
WARNING
01865 767676
sales@unicol.com
www.unicol.com
AVRT5/7
1015(w) x 700(h)
x 500(d)/(700d)
AVRT7-PZX9
-->
Revised 22/05/25
Advertisement
Related Manuals for Unicol AVR5
Summary of Contents for Unicol AVR5
- Page 1 01865 767676 sales@unicol.com www.unicol.com AVR5 / AVR7 / AVR9 / M1X1 / M2X1 AVRT5 / AVRT7 / AVRT7-PZX9 AVRT5/7 1015(w) x 700(h) x 500(d)/(700d) AVR5/7 500(w) x 700(h) x 500(d) / 700(d) AVR5/7 with M1XI --> AVRT5/7 with M2XI -->...
-
Page 2: Tools Required
M5 Allen Key 17mm Spanner Pozidrive Screwdriver COMPONENTS DESCRIPTION AVR5 / AVR7 Single Cabinet Complete AVR9 Oval Single Cabinet Complete AVRT5 / AVRT7 Twin Cabinet Complete Top Surface Column Blanking Plate Twin Column Clamp Unit (AVRT5/ AVRT7) AVRT-PZX9 Twin Cabinet Complete... - Page 3 01865 767676 sales@unicol.com www.unicol.com AVR5 / AVR7 / AVR9 Rear Front STEP 1 STEP 2 Place on a stable flat floor and apply brakes by Working from the rear remove button head screws pressing down the levers on each castor.
- Page 4 01865 767676 sales@unicol.com www.unicol.com AVRT7-PZX9 Rear Front STEP 1 STEP 2 Place on a stable flat floor and apply brakes by Working from the rear remove button head screws pressing down the levers on each castor. This holding rear covers on. Lift covers upwards and pull cabinet is the same size as the standard AVRT, so it free out of slots.
- Page 5 01865 767676 sales@unicol.com www.unicol.com STEP 5 STEP 6 Place 2x screws in the bottom two rivnuts of the Locate the mounting holes on the back of your mount back plate and slot into chosen keyholes in screen. Line the two mounting arms up and using mast.
- Page 6 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 3/16 Allen Key M4 Allen Key M5 Allen Key 17mm Spanner Pozidrive Screwdriver COMPONENTS DESCRIPTION PZX Universal Mount Back Plate PZX Universal Screen Arms AV2 Mount Adapter 15cm Avecta Infill Panels (Front)
- Page 7 01865 767676 sales@unicol.com www.unicol.com M1X1 SCREEN MAST STEP 3 STEP 4 If you want to fit a screen above the cabinet there Place the 2 columns through the holes and locate is a kit of parts M1X1 that enable this. It consists of 2 into column holder in base.
- Page 8 01865 767676 sales@unicol.com www.unicol.com Griplocks Taglocks STEP 4 STEP 5 Fit screen mount back plate to the AV2 using 4 x Fit screen mount arms to screen utilising the grip M10 Hex screws provided. locks (top), tag locks (bottom) and fixing pack...
- Page 9 01865 767676 sales@unicol.com www.unicol.com M2X1 TWIN SCREEN MAST ASSEMBLY STEP 1 STEP 2 If not already fitted, identify column clamp unit Place columns over clamps so that column holes are (supplied with the AVRT5 or AVRT7) and fix to the at the bottom - revolve to align hole with grub screw top using 4 domed head screws provided.
- Page 10 01865 767676 sales@unicol.com www.unicol.com Griplocks Taglocks STEP 6 STEP 5 Using another team member, lift each screen up Fit screen mount arms to each screen utilising the in turn and gradually offer them up to each back grip locks (top), tag locks (bottom) and fixing pack plate.
- Page 11 01865 767676 sales@unicol.com www.unicol.com SOUND BAR MOUNTS DSBM SBM / DSBM GENERAL ASSEMBLY SBM9 / DSBM9 INSTRUCTIONS Each style can be mounted with the devices above Connect your device to mount plate . Each mount or below the screen. Hook the assembled bracket is dedicated to your device so may vary from the over the rail of the PZX screen mount back plate.
