- Page 1 CHEST FREEZER USER MANUAL Models: BCF-155, BCF-205, BCF-350, BCF-450 BCF-550, BCF-650, BCF-700D, BCF-900D Please read this manual thoroughly prior to equipment setup, operation and maintenance.
-
Page 2: Table Of Contents
..Table of Contents BEFORE USING YOUR APPLIANCE..........2 Safety Instructions................2 Warnings....................2 Installation .................... 3 OPERATING YOUR APPLIANCE........... 4 Parts of the Appliance ................4 Installation of latch hook ..............Installation for handle ..............Temperature Adjustment/Operation............7 Food Storage in the Appliance ............. 7 DEFROSTING AND CLEANING ............. -
Page 3: Before Using Your Appliance
Before Using Your Appliance Safety Instructions • After installation make sure that the power cord is not trapped underneath appliance. Please read this manual thoroughly before installing and turning the appliance on. The manufacturer accepts no responsibility for incorrect installation and use. •... -
Page 4: Installation
Installation • Install and level the appliance on a solid floor able to support the weight and is in a place that is suitable for its size and use. • Insert the plug into a socket which is appropriate. This appliance has a plug already fitted – if the plug is not suitable for your socket we suggest that you call an authorized electrician for assistance. -
Page 5: Operating Your Appliance
Operating Your Appliance Parts of the A pp liance HANDLE 2. DOOR BASKET GRILL POWER CORD KNOB 7. COMPRESSOR OPERA TED LIGHT 8. POWER LIGHT 9. WHEEL TEMPERATURE DISPLAY The function of the panel: • Your freezer has one control for regulating the te mpe rature . The temperature control is located on the lower right hand corner. -
Page 6: Installation Of Latch Hook
Installation of latch hook 1.Take off the tape covering the holes. 2. Attach the latch hook by lining it up with the holes and attaching it with two screws. 3. Installation of latch hook is finished. -
Page 7: Installation For Handle
Installation for handle I � \ � �� Step 1: Attach the handle on the door with � four screws. � Step 2: Insert the one side of handle cover into the handle pedestal. Step 3: Insert the other side of handle cover into the handle pedestal. -
Page 8: Temperature Adjustment/Operation
Temperature Adjustment/Operation • The appliance temperature can be adjusted by turning the thermostat on the Control Panel. • The thermostat should be adjusted according to different environment temperature and the quantity of food being stored by adjusting the knob of the thermostat. The knob rotates clockwise from”1”... -
Page 9: Defrosting And Cleaning
Defrosting and Cleaning • Defrost twice a year or when a frost layer of around 7 mm (1/4") has formed. To start defrosting procedure switch off the freezer and pull out the plug. All food should be wrapped in several layers of newspaper and stored in a cool place. •... -
Page 10: Trouble Shooting Guide
Trouble Shooting Guide Trouble Possibilities Cheek up Solutions Remarks Compressor Power is off The fuse is broken Check the fuse Replace the fuse If it is necessary does not please contact The connection Check the socket Repair or replace work after-sales between plug and the socket... - Page 11 This warranty applies to the original owner only and is not assignable. If a Berg Chest Freezer is found to be defective during this period, Berg Chest Freezers will repair the defective unit, replace any defective parts, or replace the defective unit.
-
Page 12: Warranty
TO REPLACEMENT OF THE BERG CHEST FREEZER. In no event shall Berg Chest Freezers. be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of interruption or down time, cost of substitute equipment, facilities, or services, or any other special, incidental, or consequential damages.
