- Page 1 AIR COMPRESSOR PREMIUM Original operating manual Vers.No. 161027...
-
Page 3: Table Of Contents
Contents Overview Utilisation Contents of box Utilisation Explanation of symbols Introduction Layout Scope of delivery Intended use Safety information Technical data Before starting up Attachment and operation Electrical connection Maintenance Storage Disposal and recycling Troubleshooting... -
Page 4: Overview
Overview... -
Page 5: Utilisation
Utilisation 23 24 25... -
Page 6: Contents Of Box
Contents of Box Contents of Box 1 x Air Compressor Premium 1 x Air filter (15) 2 x Supporting foot (9) 2 x Wheel (11) 1 x Allen key 4mm 1 x Oil sealing plug (16) 1 x Transport handle (1) 1 x Instruction manual 1 x Warranty certificate... -
Page 7: Utilisation
Utilisation... -
Page 8: Explanation Of Symbols
Explanation of symbols Explanation of symbols The use of symbols in this manual is intended to draw your attention to possible risks. The safety symbols and the explanations that accompany them must be understood before using the generator. The warnings in themselves do not remove the risks and cannot replace correct actions for preventing accidents. -
Page 9: Introduction
Introduction 1. Introduction Congratulations on choosing to buy a WORKZONE TITANIUM product. ® All products brought to you by WORKZONE TITANIUM are manufactured to the ® highest standards of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 5 Years Warranty. We hope you will enjoy using your purchase for many years to come. -
Page 10: Layout
Layout/Scope of delivery 2. Layout (Fig. 1-13) 1. Transport handle 2. Pressure switch 3. Quick-lock coupling (unregulated compressed air) 4. Pressure gauge (for reading the vessel pressure) 5. Pressure regulator 6. Pressure gauge (for reading the preset vessel pressure) 7. Quick-lock coupling (regulated compressed air) 8. -
Page 11: Intended Use
Scope of delivery/Intended use/Safety information m Attention! The compressor and packaging materials are not toys! Children must not be allowed to play with plastic bags, film and small parts! There is a risk of swallowing and suffocation! 4. Intended use The compressor is designed to generate compressed air for compressed-air driven tools which can be driven with an air volume of up to approx. -
Page 12: General Safety Information
Safety information m DANGER Failure to follow these instructions may cause serious danger to life or the risk of severe injuries. m WARNING Failure to follow these instructions may cause danger to life or danger of serious injuries. m CAUTION Failure to follow these instructions may cause light to medium risk of injury. - Page 13 Safety information – Do not use electric tools where there is a risk of fire or explosion. Protect yourself from electric shock – Avoid physical contact with earthed parts (e.g. pipes, radiators, electric ranges, cooling units). Keep children away – Do not allow other persons to touch the equipment or cable, keep them away from your work area.
- Page 14 Safety information 14 Check the electric tool for potential damage – Protective devices and other parts must be carefully inspected to ensure that they are fault-free and function as intended prior to continued use of the electric tool. – Check whether the moving parts function faultlessly and do not jam or whether parts are damaged.
- Page 15 Safety information ADDITIONAL SAFETY INSTRUCTIONS Safety instructions for working with compressed air and blasting guns • The compressor pump and lines can become very hot during operation. Touching these parts will burn you. • The air which is sucked in by the compressor must be kept free of impurities that could cause fires or explosions in the compressor pump.
-
Page 16: Technical Data
Safety information/Technical data Operating pressure vessels • You must keep your pressure vessel in good working order, operate the vessel correctly, monitor the vessel, carry out necessary maintenance and repair work immediately and meet the relevant safety precautions. • The supervisory authority may enforce essential control measures in individual cases. -
Page 17: Before Starting Up
Before starting up/Attachment and operation 7. Before starting up m Attention! Before you connect the equipment to the mains supply make sure that the data on the rating plate are identical to the mains data. • Check the equipment for damage which may have occurred in transit. Report any damage immediately to the transport company which was used to deliver the compressor. - Page 18 Attachment and operation 8.5 Changing the transportation cover (A) (Fig. 9/10) • Remove the transportation cover from the oil filter opening (21) and insert the supplied oil sealing plug (16) into the oil filler opening. 8.6 Mains connection • The compressor is equipped with a mains cable with shock-proof plug. This can be connected to any 230-240V ~ 50 Hz shock-proof socket.
-
Page 19: Electrical Connection
Attachment and operation/Electrical connection ON/ OFF switch (17) and wait until the compressor cools down. Then press the overload switch (20) and restart the compressor. 9. Electrical connection The electrical motor installed is connected and ready for operation. The connection complies with the applicable VDE and DIN provisions. The customer‘s mains connection as well as the extension cable used must also comply with these regulations. -
Page 20: Maintenance
Electrical connection/Maintenance Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables with the marking „H05VV-F“. The printing of the type designation on the connection cable is mandatory. AC motor • The mains voltage must be 230-240 V~ •... - Page 21 Maintenance 10.2 Maintenance work on the pressure vessel (Fig. 1) m Important! To ensure a long service life of the pressure vessel (8), drain off the condensed water by opening the drain valve (10) each time after using. Release the vessel pressure first (see 11.1).
-
Page 22: Storage
Maintenance/Storage To fill in the correct quantity of oil, make sure that the compressor stands on an even surface. Fill new oil through the oil filler opening (21) until it comes up to the maximum level. This is marked with a red dot on the oil level window (18) (Fig. 11). Do not exceed the maximum filling quantity. -
Page 23: Disposal And Recycling
Disposal and recycling/Troubleshooting 12. Disposal and recycling The packaging protects the generator against damage during transport. Packing materials are usually chosen depending on their environmental friendliness and disposal method and can therefore be recycled. Returning the package to material circulation saves raw materials and reduces waste disposal costs. Parts of packaging (e.g. -
Page 25: Warranty Details
Air Compressor Premium Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months (dependant on product) from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 26: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint. - Page 27 HC520 AFTER SALES SUPPORT support@scheppach.com.au 1300 855 831 MODEL: HC520 PRODUCT CODE: 55946 II/2017...
- Page 28 If you are not enti rely sati sfi ed with this product, please return it to the nearest ALDI store within 60 days from the date of purchase, for a full refund or replacement, or take advantage of our aft er sales support by calling the supplier’s Customer Service Hotline.
