Summary of Contents for AME Intl. APB 79730
- Page 1 INSTRUCTION MANUAL #79730 AIR POWER BUDDY (APB) 1” DRIVE PREMIUM AIR IMPACT WRENCH...
-
Page 2: Additional Safety Instructions
79730 INSTRUCTION MANUAL WARNING! You need to read and understand this manual before using, installing, repairing, maintaining, changing accessories on, or work- ing near this tool. The information this manual contains relates to protecting your safety and preventing problems. Safety Instructions •... - Page 3 79730 INSTRUCTION MANUAL Hazards: Air Supply & Connections • Air under pressure is dangerous and can cause severe injury. • Never direct air under pressure at yourself or anyone else. • Before using the tool, always check for damaged or loose hoses and fittings. A whipping hose can cause serious injury.
- Page 4 79730 INSTRUCTION MANUAL Hazards: Projectiles Continued • Use only impact wrench sockets and accessories in good condition. Do not use standard sockets. Sockets in poor condition or hand sockets and accessories used with impact wrenches can shatter. Always ensure that the socket is correctly installed onto the tool anvil before starting the tool. •...
- Page 5 79730 INSTRUCTION MANUAL Hazards: Operating the Tool Continued • Always check you can handle the weight and power of the tool before use. If you cannot handle the tool comfortably do not use the tool. • Do not use the tool: - with reduced air pressure (the clutch may not operate, resulting in sudden rotation of the tool handle).
- Page 6 79730 INSTRUCTION MANUAL Hazards: Vibrations & Noise • Be familiar with the work area. • Keep the work area clean and well-lit. Cluttered or dark areas invite accidents. • Excess air hose left on the walking or work surface may cause tripping hazards. Keep the hose away from traffic areas.
- Page 7 79730 INSTRUCTION MANUAL Operating Instructions Cont. Step 3, Operating the Air Impact Wrench: • Direction Control: Most air impact wrenches have a direction control switch to toggle between forward (tightening) and reverse (loosening) modes. Make sure the switch is in the desired position before operation.
-
Page 8: Parts Breakdown
79730 INSTRUCTION MANUAL Parts Breakdown DRAWING NO. PRODUCT NO. DESCRIPTION QUANTITY 79730-001 Socket Retainer 79730-002 O-Ring 79730-003 6” Extended Anvil Assembly (includes 1 & 2) 79730-004 Oil Seal for 6” Extended Anvil Assembly 79730-005 Hammer Case Assembly (includes 4 & 6) 79730-006 Bushing 79730-007... - Page 9 79730 INSTRUCTION MANUAL Parts Breakdown DRAWING NO. PRODUCT NO. DESCRIPTION QUANTITY 79730-019 Rear End Plate Assembly 79730-020 Ball Bearing 79730-021 Spring Pin 79730-022 Gasket 79730-023 Back-head Assembly 79730-025 O-Ring 79730-026 Reverse Valve Assembly (includes 27) 79730-027 Spring Pin 79730-028 Spring 79730-029 Steel Ball 79730-030...
