Windbit

M2 Gateway Series

Installation Manual

M2 Gateway Series

Table of Contents

Need help?

Do you have a question about the M2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Windbit M2 Series

Page 2 Manual Windbit Legal Notice Warranty This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
Page 3: Table Of Contents
Table of Contents Windbit Table of Contents Related Documents....... . . 1 Chapter 1 About this Guide .
Page 4 Table of Contents Windbit Chapter 4 Compliance ........16 Manufacturer information .
Page 5: I Related Documents
Related Documents Windbit I Related Documents Windbit Dm704-I Configuration and Monitoring Windbit Dm709-I LAN interfaces Windbit Dm748-I Software Updating Windbit Dm746-I G.703 Interface Windbit Dm770-I VoIP Interfaces Windbit Dm722-I Telephony over IP M2 Gateway Series...
Page 6: Chapter 1 About This Guide
1.7 Technical support Windbit offers technical support. Device software can be upgraded on a regular basis for maintenance purposes and in case new features are developed.
Page 7 1 About this Guide Windbit Email: support@windbit.com Tel.: +34 91 807 65 65 Fax: +34 91 807 65 66 M2 Gateway Series...
Page 8: Chapter 2 M2 Gateway
2 M2 Gateway Windbit Chapter 2 M2 Gateway 2.1 Characteristics 2.1.1 Power supply To learn more about the M2 Gateway power supply, please refer to Components and Power Supply on page 5, Power source on page 11. 2.1.2 Hardware monitoring The LEDs located on the front panel of the M2 Gateway are employed for hardware monitoring purposes.
Page 9: Chapter 3 Components And Power Supply
3 Components and Power Supply Windbit Chapter 3 Components and Power Supply The next section contains comprehensive information on the chassis of the M2 Gateway and its various compon- ents. It covers details about the: • Components. • Assembly instructions.
Page 10 3 Components and Power Supply Windbit Aux. Grants access to the M2 Gateway local console for configuration and monit- oring purposes. To learn more about the Aux connector, please consult: Connecting for configuration on page 14 Configuration connector on page 23...
Page 11: Rear Panel
3 Components and Power Supply Windbit Green -> E1/T1 connection established (Physical layer). 3.1.2 Rear panel The following elements are present on the rear panel: Rear panel Fig. 3: The following table contains information about each connector along with a corresponding description:...
Page 12: Mounting An Anti-Theft Security Cable
3 Components and Power Supply Windbit Underside panel Fig. 5: Please refer to the table below for information about the elements found on the underside panel: Underside panel elements table Item Description Rubber feet. Slots for wall mounting. For more details, please see Wall mounting on page 9.
Page 13: Wall Mounting
3 Components and Power Supply Windbit • Avoid placing the device in areas with high humidity or dust accumulation. • Direct exposure to sunlight and other heat sources should be avoided. Do not to place the device in close proximity to papers, magazines or objects that may impede natural air circulation.
Page 14: 19'' Rack Installation
3 Components and Power Supply Windbit To mount the device on a wall or any other surface, please follow these steps: Procedure Step 1. Install the two screws (3.5x30 mm) horizontally on the desired wall or vertical surface. Make sure they are in- stalled 116.5 mm (4.56 inches) apart.
Page 15: Power Source
3 Components and Power Supply Windbit Rack installation Fig. 10: Both strips can be secured to the device using 4 screws, as shown in the figure below: Rack anchor bolts Fig. 11: Note The device chassis of the M2 Gateway has been designed for brackets to be attached at the front or rear.
Page 16: Rst Button
3 Components and Power Supply Windbit Warning The equipment must be used with the power supply provided by the manufacturer. To power up the device, connect the power supply to both the mains supply and the DC connector. Fig. 12: DC Connector 3.5 RST button...
Page 17: Lan Ethernet Connections
3 Components and Power Supply Windbit 3.6.1 LAN Ethernet connections To connect to a local area network (LAN), the M2 Gateway features four 10/100/1000 Base-T ports with automatic MDI/MDIX. It is important to differentiate this switch from other port types, so please pay close attention to the labeling.
Page 18: Connecting For Configuration
3 Components and Power Supply Windbit From the device’s point of view, TX signals are considered outgoing and RX signals incoming. We recommend that you use a 26 AWG cable, at the very least. This may be supplied with the device itself or be de- scribed in the safety instructions.
Page 19 3 Components and Power Supply Windbit AUX Connector Fig. 17: M2 Gateway Series...
Page 20: Chapter 4 Compliance
4 Compliance Windbit Chapter 4 Compliance 4.1 Manufacturer information Brand Windbit Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton, 10 Parque Tecnológico de Madrid, 28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 4.2 Risk identification WARNING: Signal term used to indicate a potentially hazardous situation that could result in serious injuries or loss of life if not heeded.
Page 21 4 Compliance Windbit M2 Gateway Series...
Page 22: Weee Information
4 Compliance Windbit 4.4 WEEE information The crossed-out wheelie bin symbol signifies that the device should be disposed of separately from regular household waste at a suitable waste disposal facility once it has completed its useful service life. Das auf dem Gerät befindliche Symbol mit dem durchgekreuzten Müllcontainer bedeutet, dass das Gerät am Ende der Nutzungsdauer bei den hierfür vorgese-...
Page 23: Ec Declaration Of Conformity
4 Compliance Windbit Output power 36.0 W Average active efficiency 87.403 % Efficiency at low load (10%) 78.3 % No-load power consumption Lower than 0.1 W 4.8 EC declaration of conformity English (EN) Teldat S.A. hereby confirms that the M2 Gateway Series telecommunications...
Page 24: Intended Use Of The Equipment
4 Compliance Windbit 4.10 Intended use of the equipment The M2 Gateway is suitable for deployment as a Customer Premises Equipment (CPE) in enterprise branch offices or in environments managed by service providers. Please note that this product is intended for indoor use only.
Page 25: Appendix A Technical Information
“Windbit Dm748-I Software Updating ” manual. When it comes to updating a Windbit device, the required software is provided in a distribution format. This contains all the necessary files for updating your device, along with detailed information on their content.
Page 26: Connectors
To establish a connection with the configuration port, use the RJ45 connector cable, supplied with the device, and an RJ45 female-DB9 female adapter (also provided). Connecting for Configuration Fig. 19: For more detailed instructions, please refer to the “Windbit Dm704-I Configuration and Monitoring” manual. A.4 Connectors A.4.1 LAN connectors RJ45 LAN...
Page 27: E1/T1 Rj45 Connector
Technical Information Windbit A.4.2 E1/T1 RJ45 connector RJ45 RJ45 PIN Signal Note From the device’s point of view, TX signals are considered outgoing and RX signals incoming. A.4.3 Configuration connector RJ45 CONFIGURATION RJ45 PIN CONF A.4.4 Power supply connector 5.5/2.5mm jack Internal ->...
Page 28: Technical Specifications
Technical Information Windbit A.5 Technical specifications A.5.1 Hardware architecture PROCESSORS Freescale LayerScape. MEMORY 512 MByte (DDR4) STORAGE UNIT eMMC Memory (4 GBytes). A.5.2 LAN interface • 802.3i (10BASE-T) PROTOCOLS • 802.3u (100BASE-TX) • 802.3ab (1000BASE-T) • 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports PORTS 4 with MDI/MDX auto-detection.
Page 29: Power Supply
Technical Information Windbit A.5.5 Power supply INPUT VOLTAGE +12V DC. INPUT CURRENT 3.0 A. CONNECTOR 5.5/2.5 mm jack A.5.6 Dimensions and weight TYPE Desktop / chassis for a 1 U high Rack mount enclosure. DIMENSION 283mm x 144mm x 40mm WEIGHT 0.6 Kg...
