Page 1 Owner’s Manual OW N E R’S M A N UA L 2023 CBR1000RR-R FIREBLADE...
Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
Page 3 Welcome Congratulations on your purchase of a new When service is required, remember that Honda vehicle. Your selection of a Honda your Honda dealer knows your vehicle best. makes you part of a worldwide family of If you have the required mechanical “know- satisfied customers who appreciate Honda's how”...
Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...
Page 5: Table Of Contents
Contents Vehicle Safety P. 2 Operation Guide P. 18 Maintenance P. 120 Troubleshooting P. 170 Information P. 187 Specifications P. 217...
Page 6: Vehicle Safety
Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Labels............P. 7 Safety Precautions..........P. 9 Riding Precautions ..........P. 11 Accessories & Modifications......P. 16 Loading ..............
Page 7: Safety Guidelines
Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused, and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
Page 8: Ride Defensively
Safety Guidelines We recommend that all riders take a certified Make Yourself Easy to See course approved by the Motorcycle Safety Make yourself more visible, especially at night, Foundation (MSF) or a state approved training by wearing bright reflective clothing, positioning course.
Page 9 Safety Guidelines the handlebars, control levers, brakes, and Keep Your Honda in Safe Condition wheels. Ride slowly and cautiously. It's important to keep your vehicle properly Your vehicle may have suffered damage that is maintained and in safe riding condition.
Page 10: Carbon Monoxide Hazard
Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colorless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.
Page 11: Safety Labels
Safety Labels Safety Labels If a label comes off or becomes hard to read, contact your dealer for a replacement. Safety and information labels on your vehicle provide important safety information and may warn you of potential hazards that could cause serious injury.
Page 12 Safety Labels...
Page 13: Safety Precautions
Safety Precautions Safety Precautions Helmet Should be safety-standard certified, high- Ride cautiously and keep your hands on the visibility, and the correct size for your head. ● handlebars and feet on the footpegs. Must fit comfortably but securely, with the ●...
Page 14 Safety Precautions Gloves Full-finger leather gloves with high abrasion resistance Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Jacket and Pants Protective, highly visible, long-sleeved jacket and durable long pants for riding (or a protective suit)
Page 15: Riding Precautions
Riding Precautions Riding Precautions Exercise caution on low traction surfaces. ● The tires slip more easily on such surfaces and braking distances are Break-in Period longer. During the first 300 miles (500 km) of running, Avoid continuous braking. ● follow these guidelines to ensure your vehicle's Repeated braking, such as when future reliability and performance.
Page 16 Riding Precautions Anti-lock Brake System (ABS) Engine Braking This model is equipped with an Anti-lock Brake Engine braking helps slow your vehicle down System (ABS) designed to help prevent the when you release the throttle. For further brakes from locking up during hard braking. slowing action, downshift to a lower gear.
Page 17 P. 96 and other high-temperature parts until they Then, leave your vehicle while taking the cool down. Honda SMART Key with you. Deactivate the To reduce the likelihood of theft, always lock ● Honda SMART Key system if necessary. the handlebars ( P.
Page 18 Riding Precautions Refueling and Fuel Guidelines Follow these guidelines to protect the engine, fuel system and catalytic converter: Use only unleaded gasoline. ● Use the recommended octane number. ● Using lower octane gasoline will result in decreased engine performance. Do not use fuels containing a high ●...
Page 19 Torque Control may not compensate for rough Honda Selectable Torque Control road conditions or rapid throttle operation. When the Honda Selectable Torque Control Always consider road and weather conditions, detects rear wheel spin during acceleration, the as well as your skills and condition, when system will limit the amount of torque applied applying throttle.
Page 20: Accessories & Modifications
We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed or approved for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.
Page 21: Loading
Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
Page 22: Parts Location
Parts Location Tool kit/Owner's manual (P.119) Fuse box (P.186) Battery (P.142) Front brake fluid reservoir (P.150) Front brake lever (P.159) Throttle grip (P.158) Engine oil fill cap (P.145) Engine oil dipstick (P.145) Rear brake pedal Rear brake fluid reservoir (P.150)
Page 23 Clutch lever (P.155) Front suspension spring preload adjuster (P.161) Fuel fill cap (P.117) Front seat (P.143) Rear seat (P.144) Drive chain (P.154) Rear suspension spring preload adjuster (P.163) Shift lever (P.112) Side stand (P.153) Coolant reserve tank (P.147)
Page 24 Instruments The display type consists of the following 5 patterns. • ANALOG (P.21) • DIGITAL (P.22) • BAR (P.23) • NO REV (P.24) • PRACTICE (P.25) To change the display type: (P.58) (P.70) Each display type has the SPORT mode. (P.26) The operation of the instrument is mainly explained in the ANALOG display type.
Page 25 (P.50) To set the clock: Tachometer (P.58) (P.79) NOTICE Do not operate the engine in the tachometer red zone. HESD (Honda Excessive engine speed can adversely affect engine life. Electronic Steering Tachometer red zone Damper) indicator (excessive engine rpm range) (P.50)
Page 26: Coolant Temperature Gauge
NOTICE Do not operate the engine in the tachometer red zone. Pop-up information (P.47) Excessive engine speed can adversely affect engine life. ABS mode indicator HESD (Honda Electronic Steering (P.50) Damper) indicator (P.50) Low oil pressure indicator High beam indicator (P.50)
Page 27 Display type: BAR Low oil pressure High coolant temperature indicator (P.50) indicator (P.50) Tachometer HESD (Honda Electronic NOTICE Steering Damper) Do not operate the engine in the tachometer red zone. indicator (P.50) Excessive engine speed can adversely affect engine life.
Page 28 Instruments (Continued) Display type: NO REV HESD (Honda Electronic Steering Damper) indicator (P.50) Clock Low oil pressure indicator (P.50) To set the clock: High coolant temperature indicator (P.50) (P.58) (P.79) ABS mode indicator (P.50) Current riding mode Gear position indicator (P.50)
Page 29 Display type: PRACTICE High beam indicator Reserve fuel mode HESD (Honda Electronic Steering (P.43) Damper) indicator (P.50) Tachometer NOTICE Low oil pressure Do not operate the engine in the tachometer red zone. indicator (P.50) Excessive engine speed can adversely affect engine life.
Page 30 Instruments (Continued) SPORT mode display To change to the SPORT mode display: Set the “LAP” to “ON” in setting mode. (P.58) (P.70) To return to the STD mode display, set the “LAP” to “OFF” in setting mode. When switching to SPORT mode display, the following message appears on the screen for a few seconds then the lap timer is displayed.
Page 31 Basic Operations You can operate and set the various functions of the display using the switches on the left handlebar. PASSING/LAP switch Sel up switch switch MODE Sel left/right switch Sel down switch Continued...
Page 32 Instruments (Continued) When switching or setting the display, refer to the switch operation guide is displayed. Switch operation guide Type of the switch operation guide: : Press the sel up switch : Press the sel down switch : Push the of the sel left/right switch : Push the...
Page 33 INFO area To switch the INFO area To change the page of the INFO area, push the sel left/right switch. You can change the information items to be displayed on the pages 1-3 (INFO 1-3). You can also change the number of items to be displayed in the information area. To select the FAVORITE INFORMATION (P.58) (P.76) To change the number of information items are displayed...
Page 34 Instruments (Continued) The following items are types of information that can be displayed on pages 1-3 (INFO 1-3). TOTAL CBR logo (P.31) (P.35) TRIP A SHIFT POINT (P.31) (P.36) TRIP A CONS. LAP CONS. (P.32) (P.36) TRIP B LAP AVG. CONS. (P.31) (P.37) INST.
Page 35 Odometer [TOTAL] Tripmeter A/B [TRIP A/B] Total distance ridden. Distance ridden since the tripmeter was reset. When “------” is displayed, go to your dealer When “----.-” is displayed, go to your dealer for service. for service. To reset the tripmeter: (P.41) Continued...
Page 36 Instruments (Continued) Tripmeter A fuel consumption [TRIP A Current fuel mileage [INST. CONS.] CONS.] Displays the current instant fuel mileage. Displays the tripmeter A fuel consumption Display range: 0.0 to 299.9 mpg (L/100km or since the tripmeter A was reset. km/L) Display range: 0.0 to 299.9 gal (gallon) or 0.0 When your speed is less than 5 mph (7...
Page 37 Average fuel mileage [AVG. CONS.] Average speed [AVG. SPD.] Displays the average fuel mileage since the Displays the average speed since the average average fuel mileage was reset. speed was reset. Display range: 0.0 to 299.9 mpg (L/100km or Display range: 0 to 218 mph (0 to 350 km/h) km/L) Initial display: “---”...
Page 38 Instruments (Continued) Elapsed time [ELAPSED] Numerical tachometer display [REV] Displays the engine operating time since the Displays the engine revolutions per minutes. elapsed time was reset. Display range: 0 to 16,500 r/min Display range: 00:00 to 99:59 (hours:minutes) Above 16,500 r/min (rpm): “16500” is Above 99:59: back to 00:00 displayed.
Page 39 Battery voltage [VOLTAGE] User letter Displays the current voltage. Displays the characters of user's choice. Date [DATE] To set the USER LETTER: (P.58) (P.77) Show the date of today. CBR logo Displays the CBR logo. Display range: Day of the week: MON to SUN DAY: 1 to 31 MONTH: JAN to DEC YEAR: 2019 to 2119...
Page 40 Instruments (Continued) Shift indicator set value [SHIFT POINT] Lap fuel consumption [LAP CONS.] Displays the shift indicator set value. Displays the fuel consumption of the latest Display range: 5,000 - 16,500 r/min lap. When the brightness setting of the REV Display range: 0.0 to 50.0 gal (gallon) or 0.0 ●...
Page 41 Lap average fuel mileage [LAP AVG. Lap average speed [LAP AVG. SPD.] CONS.] Displays the average speed of the latest lap. Displays the average fuel mileage of the Display range: 0 to 218 mph (0 to 350 km/h) latest lap. When there is no lap data: “---”...
Page 42 Instruments (Continued) Maximum acceleration in this time Maximum right lean angle in this time [MAX ACC.] [MAX LEAN ANGLE R] Displays the maximum acceleration since the Displays the maximum lean angle of right side electrical system was turned on. since the electrical system was turned on. Display range: 0 to 1.5 G Display range: 0 to 60 deg Until detects the acceleration: “-.-”...
Page 43 Fuel consumption in this time [FUEL Average fuel mileage in this time [AVG. CONS.] CONS. Displays the fuel consumption since the Displays the average fuel mileage since the electrical system was turned on. electrical system was turned on. Display range: 0.0 to 50.0 gal (gallon) or 0.0 Display range: 0.0 to 299.9 mpg (L/100km or to 50.0 L (litres).
Page 44 Instruments (Continued) Average speed in this time [AVG. SPD. Elapsed time in this time [ELAPSED Displays the engine operating time since the Displays the average speed since the electrical system was turned on. electrical system was turned on. Display range: 00:00 to 99:59 (hours:minutes) Display range: 0 to 218 mph (0 to 350 km/h).
Page 45 Blank display To Reset the Information Display the blank. Select the page (INFO1, 2, 3) of INFO area that contains the item you want to reset with sel left/right switch. Push and hold the of the sel left/ right switch until the RESET turns to red. If there are no items on the page that can be reset, there is no response to the operation.
Page 46 Instruments (Continued) EQUALIZER Displays the current lean angle of left/right side. Displays the current acceleration/ deceleration.
Page 47: Available Driving Distance
Reserve Fuel Mode Available driving When the low fuel indicator appears the distance available driving distance and amount of remaining fuel displayed. You should refill the tank as soon as possible. Remaining fuel amount turned to the reserve fuel mode: 0.9 US gal (0.7 Imp gal, 3.5 L) Low fuel indicator Remaining fuel...
Page 48 Instruments (Continued) Available driving distance (Only reserve When “--” is displayed except for the above- fuel mode) mentioned cases, go to your dealer for When the low fuel indicator lights, the service. estimated available driving distance is indicated. Display range: 99 to 3 mile (5 km) Above 99 mile (km): “99”...
Page 49 Amount of remaining fuel (Only reserve When “-.-” is displayed except for the above- fuel mode) mentioned cases, go to your dealer for When the low fuel indicator lights, the service. estimated amount of remaining fuel can be selected. Display range: 0.9 to 0.3 gal (gallon) or 3.5 to 1.0 L (litres) 0.7 to 0.2 gal (gallon) or 3.5 to 1.0 L...
Page 50 Instruments (Continued) Coolant temperature gauge ( Display range: 94°F (35°C) to 269°F (132°C) 93°F (34°C) or less: “---” is displayed. ● Between 251°F (122°C) and 268°F (131°C): ● High coolant temperature indicator lights. Coolant temperature digits flash. Above 269°F (132°C): ●...
Page 51: Pop-Up Information
Pop-up information When your vehicle has multiple pieces of In the following cases, pop-up information is information, the high-priority pop-up displayed. information display will appear. Maintenance information: If the priorities are the same, pop-up ● When the inspection time of your vehicle information display appears alternately.
Page 52 Instruments (Continued) Maintenance Information Indication Explanation Remedy When the periodic inspection Have your vehicle inspected by time of your vehicle is your dealer. approaching. When the oil change time of Change the engine oil. your vehicle is approaching. Helpful Information Indication Explanation Remedy...
Page 53 Start Mode Information Indication Explanation Remedy When the background color is: Orange: Start Mode is allowed. To use the Start Mode (P.58) Green: Limiting the engine (P.69) (P.114) revolution. Gray: Start Mode is not allowed. Failure Information Indication Explanation Remedy When your vehicle has a Reduce speed and have your problem with the ÖHLINS Smart...
Page 54 If it comes on while engine is running: (P.173) ABS mode indicator [ABS 1/2] Displays the current ABS mode. HESD (Honda Electronic Steering ABS 1 is suitable for track riding. Damper) indicator ABS 2 is suitable for street riding or winding If it comes on while engine is running: roads.
Page 55 Quick Shifter indicator Displays the current status of the Quick Shifter. This indicator is displayed when the INFO area is in page 4 (Riding mode). Quick Shifter system is disabled. Quick Shifter upshifting is enabled. Quick Shifter downshifting is enabled. Quick Shifter upshifting and downshifting are both enabled.
Page 56 Instruments (Continued) Lap Timer You can record lap time in the SPORT mode. (P.58) (P.70) Previous lap time Number of laps Stopwatch/difference with the best lap...
Page 57 You can check and clear the recorded lap data in the setting mode. (P.58) (P.78) Best icon Time stamp (Displayed when the fastest lap User letter time displayed.) Lap time Lap number Maximum deceleration Maximum vehicle speed Average speed Maximum right lean angle Fuel consumption Maximum acceleration Maximum left lean angle...
Page 58: Display Range
Instruments (Continued) The lap data include the following: Lap data Display range 0 to 99 Number of lap Exceeds 99, repeats the “99” Previous lap time 00'00"00 to 99'59"99 Stopwatch 00'00"00 to 99'59"99 Difference with the best lap -99'59"99 to 00'00"00 to +99'59"99 Maximum vehicle speed 0 to 218 mph (0 to 350 km/h) Average speed...
Page 59 To record lap time, press the PASSING/LAP To Measure the Lap Time switch at each lap. Set the “LAP” to “ON” in setting mode. The stopwatch changes to display of the (P.58) (P.70) difference with the best lap. To start measuring, press the PASSING/LAP After 10 seconds, the display will return switch.
Page 60 Instruments (Continued) To restart the measurement Previous lap time Press the PASSING/LAP switch again. The stopwatch restarts measurement. Measurement starts from the next lap. To Check or Clear the Lap Time Select the “LAP DATA” menu in the setting mode. (P.58) (P.78) Number of laps Difference with the best lap...
Page 61 Setting mode To shift to the setting mode Push and hold the of the sel left/right switch. To select the desired setting menu, operate the sel up switch, sel down switch, sel left/right switch on the left handle. When switching to setting mode, the clock, indicator and speed are displayed at the top of the screen.
Page 62: Setting Flow
Instruments (Continued) Setting flow Ordinary display MODE Setting mode RIDING MODE (P.62) SUSPENSION A MODE (P.63) SUSPENSION M MODE (P.64) QUICK SHIFTER (P.65) FUNCTION STEERING DAMPER (P.66) ABS MODE (P.67) REV INDICATOR (P.68) Push/Press START MODE REV (P.69) Push and hold/ DISPLAY Press and hold...
Page 63 FUNCTION DISPLAY CUSTOMIZE (P.70) MECHANIC (P.73) BRIGHTNESS (P.74) DISPLAY BACKGROUND (P.75) FAVORITE INFORMATION (P.76) USER LETTER (P.77) GENERAL Push/Press Push and hold/ Press and hold Continued...
Page 64 Instruments (Continued) DISPLAY LAP DATA (P.78) DATE & TIME (P.79) GENERAL UNIT (P.80) LANGUAGE (P.81) RESTORE DEFAULT (P.81) SERVICE Push/Press Push and hold/ Press and hold...
Page 65 GENERAL MAINTENANCE (P.83) EQUIPMENT (P.86) QS INITIALIZE (P.86) SERVICE (P.87) RACE KIT ECU (P.87) USE HISTORY Push/Press Push and hold/ Press and hold Continued...
Page 66 Instruments (Continued) To return to the initialize settings: RIDING MODE (P.104) Push and hold the of the sel left/ You can select the RIDING MODE. right switch. Select the “MODE 1”, “MODE 2” or “MODE Reset the setting according to the switch 3”...
Page 67 SUSPENSION A MODE (P.164) You can change the levels of OBTi support items. Adjusting the ÖHLINS Smart EC system (P.160) Select the “A 1”, “A 2”, or “A 3” using the sel up or sel down switch. Default setting mark Push the of the sel left/right...
Page 68 Instruments (Continued) To return to the initialize settings: SUSPENSION M MODE (P.167) Push and hold the of the sel left/ You can adjust the compression and right switch. rebound damping of the front and rear Reset the setting according to the switch suspension electronically.
Page 69 Select the “UP” or “DOWN” using the QUICK SHIFTER up or sel down switch. You can change the setting of the Quick Select to the desired setting according to Shifter. the switch operation guide. UP: Change the setting for upshifting. Return to the ordinary display or upper DOWN: Change the setting for downshifting.
Page 70 Instruments (Continued) STEERING DAMPER You can change the damping level of the steering damper. The steering damping level can be selected from “SOFT”, “MEDIUM”, or “HARD”. Each level's characteristics SOFT: More agile steering feel. (Default setting level) MEDIUM: Medium steering damping level between “SOFT”...
Page 71 ABS MODE You can change the ABS mode. The ABS mode can be selected from the “ABS1 (TRACK)” or “ABS2 (SPORT)”. Select the “ABS1 (TRACK)” or “ABS2 (SPORT)” using the sel up or down switch. Return to the ordinary display or upper hierarchy to complete the setting.
Page 72 Instruments (Continued) BRIGHTNESS REV INDICATOR You can adjust the shift indicator brightness. You can change the setting of the shift Available setting range: OFF or 1 - 8 indicators. When “OFF” is selected, the shift indicator is deactivated. INTERVAL Select the “INTERVAL”, “SHIFT POINT”, or You can adjust the interval of lighting the “BRIGHTNESS”...
Page 73 START MODE REV You can change the engine revolutions when using the Start Mode. To use the Start Mode: (P.114) Available setting range: OFF or 6,000 - 9,000 r/min (rpm) Select the engine revolutions using the sel up or sel down switch. Return to the ordinary display or upper hierarchy to complete the setting.
Page 74 Instruments (Continued) To use a registered display setting as DISPLAY CUSTOMIZE the ordinary display: You can register 3 patterns of display settings Select the desired screen setting from the and use them as ordinary displays. “01”, “02”, or “03” using the sel up or You can select and combine your favorite sel down switch.
Page 75 To edit and register the display: Select the “EDIT” according to the switch operation guide. Select the “DISPLAY TYPE”, “REV STYLE”, “LAP”, or “INFO” using the sel up or sel down switch. Select to the desired setting according to the switch operation guide. Thumbnail You can check the current display settings with thumbnail.
Page 76: Display Name
Instruments (Continued) To edit the display name: Display name You can edit the display name with up to 10 characters. Select the “EDIT” according to the switch operation guide. Push and hold the of the sel left/ right switch. Edit the display name. To select the character using the up switch, sel down switch, and...
Page 77 MECHANIC Displays the current information of the vehicle. Displays the following information: Tachometer ● Gear position ● Throttle grip position ● Coolant temperature ● Battery voltage ● Tachometer Gear Throttle grip position position Coolant temperature Battery voltage Continued...
Page 78: Automatic Brightness Control
Instruments (Continued) BRIGHTNESS You can adjust the backlight brightness to one of the eight levels or select the auto adjustment. Automatic brightness control: (P.194) The display can become dark when the display is very hot. If it does not restore the original brightness, contact your dealer.
Page 79 BACKGROUND You can change the setting of the background to one of the two categories or select the auto adjustment. Automatic Background Control: (P.194) Select the “AUTO”, “BLACK”, or “WHITE” using the sel up or sel down switch. Return to the ordinary display or upper hierarchy to complete the setting.
Page 80 Instruments (Continued) The number of items displayed on the INFO FAVORITE INFORMATION area changes according to the “DISPLAY You can change the types of information CUSTOMIZE” setting. displayed in “INFO1”, “INFO2”, and “INFO3” (P.58) (P.70) of the INFO area. If the number of items to be displayed on the INFO area is set to “NONE”, “FAVORITE INFORMATION”...
Page 81 USER LETTER You can edit the USER LETTER with up to 10 characters. Select the “USER LETTER.” Edit the USER LETTER. To select the character using the up switch, sel down switch, and sel left/right switch. To set the character using the mode switch.
Page 82 Instruments (Continued) To clear the recorded lap data: LAP DATA Push and hold the of the sel left/ You can check and clear the recorded lap right switch. data. Reset the lap data according to the switch If there is no lap data, “LAP DATA” cannot be operation guide.
Page 83 DATE & TIME Select the “24h or 12h”, “YEAR”, “MONTH / DAY”, “HOUR / MINUTE”, or “am / pm” using the sel up or sel down switch. Select to the desired setting according to the switch operation guide. When “24 / 12” is set to 24-hour indication, “am / pm”...
Page 84 Instruments (Continued) If you want to select “mile/gal” for fuel UNIT consumption, “mph” must be selected in the You can change the speed and mileage, and “SPEED” menu in advance. fuel mileage meter units. When “km/h” for speed is selected, “L/100km” Select the “SPEED”, “TEMP”, or “FUEL or “km/L”...
Page 85: Operation Guide
LANGUAGE RESTORE DEFAULT Changes the system language. The set values can be returned to the default settings. Select the “English” or “Turkish” using the sel up or sel down switch. Return to the ordinary display or upper Reset the settings according to the switch hierarchy to complete the setting.
Page 86 Instruments (Continued) The following items are restored to their • LANGUAGE default values: • QUICK SHIFTER • SUSPENSION A/M MODE • LAP DATA • DISPLAY CUSTOMIZE • REV INDICATOR • BRIGHTNESS • BACKGROUND • USER LETTER • FAVORITE INFORMATION • DATE & TIME •...
Page 87 Display range: MAINTENANCE DISTANCE: You can check the next inspection time and Next periodic inspection: change the setting of next inspection. -----, 8,000 to -99,999 mile (12,875 to Next periodic inspection -99,999 km) Next engine oil change: -----, 8,000 to -99,999 mile (12,875 to -99,999 km) Pass 0 mile (km): “-”...
Page 88 Instruments (Continued) When reaching any of the following, the pop-up information is appears in the ordinary display. (P.47) “300 mile” or “500 km” from the next ● periodic inspection. “60 mile” or “100 km” from the next ● engine oil change. One month before the set month.
Page 89 Next inspection setting Select to the desired setting according to the switch operation guide. Select “ ” (periodic inspection ) or “ ” If you press and hold the sel up or (engine oil change) using the sel up or sel down switch while setting the sel down switch.
Page 90 Instruments (Continued) EQUIPMENT QS INITIALIZE “EQUIPMENT” is displayed but not selectable. “QS INITIALIZE” is displayed but not selectable.
Page 91 RACE KIT ECU USE HISTORY Displays a current problem with the vehicle. “RACE KIT ECU USE HISTORY” is displayed If your vehicle has problem, DTC index is but not usable. displayed. Reduce speed and have your vehicle inspected by your dealer as soon as possible. DTC indexes...
Page 92 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Shift indicators (P.91) Comes on briefly when the electrical system is turned on. Right Turn Signal Indicator Torque Control indicator Comes on when the electrical system is turned ●...
Page 93 PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the electrical system is turned on. If it comes on while engine is running: (P.173) ABS (Anti-lock Brake System) indicator Comes on when the electrical system is turned on. Goes off when your speed reaches approximately 6 mph (10 km/h).
Page 94 Comes on when the transmission is in Neutral. Honda SMART Key indicator Comes on briefly when the electrical system is turned When the Honda SMART Key Indicator Flashes: (P.176) Steering lock indicator Comes on briefly while the steering lock is activating.
Page 95 Shift Indicators The indicator colors are as follows. The shift indicators light or blink by the engine revolutions. The timing and brightness of the indicators light/blink depend on the “REV INDICATOR” White Blue setting. Setting of the Shift Indicators (P.58) (P.68) Definition: Engine revolutions A –...
Page 96: Horn Button
Switches Headlight dimmer switch/PASSING/LAP switch • : High beam • : Low beam • /LAP: Flashes the high beam headlight. Also use lap timer. (P.52) Horn button Hazard switch Switchable when the electrical system is on. Can be turned to off regardless of whether the electrical system is on or off.
Page 97: Ignition Switch
Ignition Switch (Lock) Locks steering. (P.96) Switches the electrical system on/off, locks the steering. Make sure that the Honda SMART Key is activated and enter the (P.99) Turns engine off. operating range. (P.100) Ignition switch knob OFF/ (Lock) Turns electrical system on for starting/riding.
Page 98 Switches (Continued) These switches are used for operating and setting the display. (P.27) Sel up switch Sel left/right switch Sel down switch switch MODE Engine stop switch/ Start button Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position to stop the engine.
Page 99 To retract the mechanical key Push the key into the key case while pressing the release button. ON/OFF button This button is used to activate or deactivate the Honda SMART Key system and also to confirm the activation status. (P.99) Mechanical key Continued...
Page 100 Switches (Continued) Steering Lock Locking Turn the ignition switch knob OFF/ (Lock) Lock the steering when parking to help counterclockwise to turn off the electrical prevent theft. system. A U-shaped wheel lock or similar device is Turn the handlebars all the way to the left. also recommended.
Page 101 Turn and hold the ignition switch knob OFF/ Unlocking (Lock) counterclockwise. Make sure that the Honda SMART Key is The steering lock indicator comes on activated and enter the operating (P.99) briefly and the steering is automatically range. (P.100) locked.
Page 102 The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical...
Page 103: On/Off Button
SMART Key LED changes color. To check the Honda SMART Key ON/OFF button system status Lightly press the ON/OFF button. The Honda SMART Key LED will show the status. When the Honda SMART Key LED is: Green: Honda SMART Key system...
Page 104 The Honda SMART Key system uses low- Placing the Honda SMART Key on the fuel intensity radio waves. Therefore, the tank may cause communication failure. operating range may be wider or narrower,...
Page 105 Anyone can operate the ignition switch and When the ignition switch is locked: start the engine if your Honda SMART Key is The system can be operated within the within operating range of your vehicle, even shaded area shown in the illustration.
Page 106 • Starting the engine • Unlocking the steering lock (P.96) You should always keep the Honda SMART Key on your person after you get on and off the vehicle or while riding. Do not place the Honda SMART Key under the rear seat.
Page 107 Turn the ignition switch knob OFF/ (Lock) To Activate the Electrical System counterclockwise. Make sure that the Honda SMART Key is Leave the operating range with the Honda activated and enter the operating range for SMART Key or switch the Honda (P.100)
Page 108: Riding Mode
Riding mode You can change the riding mode. Current riding mode The riding mode consists of the following parameters. T value P value: Engine output level P value T value: Torque control level W value: Wheelie control level W value EB value: Engine brake level S mode: Suspension mode S mode...
Page 109 Riding mode has three modes. Available riding mode: MODE 1, MODE 2, or MODE 3. Each value can be changed. Initial setting Riding modes P value T value W value EB value S mode MODE 1 A1 (TRACK) MODE 2 A2 (SPORT) MODE 3 A3 (RAIN)
Page 110 Riding mode (Continued) W value (Wheelie control level) P value (Engine output level) W value has four setting levels. P value has five setting levels. Available setting range: 1 to 3 Available setting range: 1 to 5 Level 1 is the minimum Wheelie Control Level 1 has the most power.
Page 111: Mode Switch
Selecting the riding mode The riding mode changes each time the switch is pressed. MODE When the riding mode is changed the P value, T value, W value, EB value, and S mode appear briefly in the INFO area. switch MODE Current riding mode MODE 1...
Page 112 Riding mode (Continued) Setting the riding mode Select the riding mode you want to set. You can change the P value, T value, W (P.107) To change the type of parameter value, EB value, and S mode. displayed in FAVORITE Press and hold the sel up switch or You can change the riding mode setting...
Page 113 Sel up switch Sel down switch Press and hold the sel up switch Press and hold the sel down switch Press the sel up switch Press the sel down switch...
Page 114: Starting The Engine
10 seconds before trying to start the engine This vehicle is equipped with a Honda again to recover battery voltage. SMART Key system. Always keep Honda • Extended fast idling and revving the engine...
Page 115 Shift the transmission to Neutral ( If the engine does not start: indicator comes on). Alternatively, pull in the Open the throttle fully and press the start clutch lever to start your vehicle while the button for 5 seconds. transmission is in gear as long as the side Repeat the normal starting procedure.
Page 116: Shifting Gears
Shifting Gears Your vehicle transmission has 6 forward Recommended Shift Points gears in a one-down, five-up shift pattern. Shifting Up From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) From 4th to 5th 31 mph (50 km/h)
Page 117 Quick Shifter The Quick Shifter can be individually ● This system enables very quick up and down turned ON (active) and OFF (deactivate), shifting without clutch and throttle also the shift pedal load level for operations. activating the Quick Shifter can be This system does not function when adjusted during up and down shifting.
Page 118: Start Mode
Start Mode Your vehicle controls the engine torque to To set the Start Mode support optimal acceleration from standstill. Start the engine. (P.110) Stop the vehicle completely with the transmission in Neutral. WARNING Set to SPORT mode. (P.58) (P.70) Using the Start Mode on public roads Press and hold the sel up or can lead to a crash in which you,...
Page 119 If a “START MODE” pop-up with a gray Press and hold the sel up or down switch and PASSING/LAP switch until background appears in the display, Start the “START MODE” pop-up information with Mode cannot be engaged due to one of the orange background appears in the display.
Page 120 Start Mode (Continued) Fully open the throttle. After the vehicle starts moving, it will Engine RPMs will be limited by the set deactivate when any one of the following value of “START MODE REV” The “START conditions occurs: MODE” pop-up information background The transmission is shifted into 3rd gear.
Page 121 Refueling Opening the Fuel Fill Cap Fuel fill cap Lock cover Open the lock cover, insert the mechanical key, Level plate and turn it clockwise to open the fuel fill cap. Closing the Fuel Fill Cap After refueling, push the fuel fill cap closed until it locks.
Page 122: Storage Equipment
Storage Equipment Helmet Holder WARNING The helmet holders are located underside of Riding with a helmet attached to the the rear seat. holder can interfere with your ability to safely operate the vehicle and could Helmet holder lead to a crash in which you can be seriously hurt or killed.
Page 123 Tool kit/Owner's manual Removing the Rear Seat (P.144) The tool kit is located under the rear seat. The owner's manual is stored in the tool bag. Tool kit Owner's manual...
Page 124: Maintenance
Adjusting the ÖHLINS Smart EC System..P. 160 Components ........... P. 142 Other Replacement......... P. 168 Battery..............P. 142 Replacing the Honda SMART Key Battery .. P. 168 Front Seat............P. 143 Rear Seat ............. P. 144 Engine Oil ............P. 145 Coolant ..............
Page 125: Importance Of Maintenance
Importance of Maintenance For information about the exhaust emission and Importance of Maintenance noise emission requirements of the U.S. Keeping your vehicle well-maintained is Environmental Protection Agency (EPA), the absolutely essential to your safety and to California Air Resources Board (CARB), and the protect your investment, obtain maximum Environment and Climate Change Canada performance, avoid breakdowns, and reduce air...
Page 126: Maintenance Safety
Importance of Maintenance Maintenance Safety Always read the maintenance instructions before you begin each task and make sure that you have the tools, parts, and skills required. We cannot warn you of every conceivable hazard that can arise in performing maintenance.
Page 127: Maintenance Schedule
Maintenance work should be performed in owner. accordance with Honda's standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. All scheduled maintenance is considered a normal owner operating cost and will be charged to you by your dealer.
Page 128 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Replace mechanically skilled. Lubricate Procedures are provided in an official Honda Service Manual (2 P. 209). : Technical. In the interest of safety, have your vehicle serviced by your dealer.
Page 129 Maintenance Schedule Frequency Regular Refer to Items × 1,000 mi Replace page × 1,000 km 12.8 19.2 25.6 32.0 38.4 Drive Chain Every 600 mi (1,000 km): Brake Fluid 2 Years Brake Pads Wear Brake System Brake light Switch Headlight Aim –...
Page 130: Maintenance Record
Maintenance Record Distance Odometer Date Performed By: Notes 600 miles (1,000 km) 4,000 miles (6,400 km) 8,000 miles (12,800 km) 12,000 miles (19,200 km) 16,000 miles (25,600 km) 20,000 miles (32,000 km) 24,000 miles (38,400 km) 28,000 miles (44,800 km) 32,000 miles (51,200 km) 36,000 miles (57,600 km) 40,000 miles (64,000 km)
Page 131: Maintenance Fundamentals
Maintenance Fundamentals Check the following items if you are carrying a Pre-ride Inspection passenger or cargo: To ensure safety, it is your responsibility to Combined weight is within load limits ● perform a pre-ride inspection and make sure P. 217 that any problem you find is corrected.
Page 132 Maintenance Fundamentals Check the following items at regular intervals: Oil level is between the upper and lower ● level marks P. 145 Brake fluid level is ● Front: between the MAX and MIN level marks P. 150 Rear: between the UPPER and LOWER level marks P.
Page 133 Maintenance Fundamentals Also, check the odometer reading against the Periodic Checks Maintenance Schedule and perform all You should also perform other periodic maintenance that is due. P. 123 maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently.
Page 134 Maintenance Fundamentals Replacing Parts Color label Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering colored components, specify the model name, color, and code mentioned on the color label. The color label is attached on the under the rear seat.
Page 135 Maintenance Fundamentals WARNING Lithium-Ion (Li-Ion) Battery Your vehicle has a lithium-ion (li-ion) battery. The battery contains flammable organic Clean the battery terminals if they become dirty solvent as electrolyte. or corroded. NOTICE You can be burned or seriously injured An improperly disposed of battery can be if the battery is handled improperly.
Page 136 Maintenance Fundamentals After cleaning, reinstall the battery. Cleaning the Battery Terminals Remove the battery. P. 142 The battery has a limited life span. Consult your If the terminals are starting to corrode and dealer about when you should replace the are coated with a white substance, wash battery.
Page 137 Bump starting is not recommended. 30 days using a charger recommended by your lithium-ion (li-ion) battery manufacturer. NOTICE Installing non-Honda electrical accessories can Contact your dealer before charging the overload the electrical system, discharging the battery. battery and possibly damaging the system.
Page 138 Selecting the Engine Oil Blown fuse For recommended engine oil, see “Specifications.” P. 218 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: NOTICE JASO T 903 standard : MA ●...
Page 139 The API classification specifies the quality and performance rating of engine oils. Use SL or Recommended brake fluid: higher oils, excluding oils marked as “Energy Honda DOT 4 Brake Fluid or equivalent Conserving” or “Resource Conserving” on the circular API service symbol. WARNING Clean filler cap before removing.
Page 140 Recommended lubricant: Also inspect the drive sprocket and driven Pro Honda HP Chain Lube or equivalent sprocket. If either has worn or damaged teeth, have the sprocket replaced by your dealer. Worn Normal...
Page 141: Recommended Coolant
Do not use a steam cleaner, a high pressure Recommended Coolant cleaner, a wire brush, volatile solvent such as Pro Honda HP Coolant is a pre-mixed solution gasoline and benzene, abrasive cleaner, chain of antifreeze and distilled water. cleaner or lubricant NOT designed specifically...
Page 142 Maintenance Fundamentals Inspecting for Damage Tires (Inspecting/Replacing) Checking the Air Pressure Inspect the tires for Visually inspect your tires and use an air cuts, slits, or cracks that pressure gauge to measure the air pressure at expose fabric or cords, least once a month or any time you think the or nails or other tires look low.
Page 143 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tires that are excessively worn become visible, replace the tires immediately. or improperly inflated can cause a crash For safe riding, you should replace the tires in which you can be seriously hurt or when the minimum tread depth is reached.
Page 144 Always use the size and type of tires speed rating, and load range. recommended in this owner's manual. Have the wheel balanced with Honda ● Genuine balance weights or equivalent after the tire is installed.
Page 145: Tire Identification Number (Tin)
Maintenance Fundamentals Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group The service life of your tires is dependent on of numbers and letters located on the sidewall many factors, including, but not limited to, of the tire.
Page 146: Removing & Installing Body Components
Removing & Installing Body Components Battery Removal Make sure the electrical system is turned off. Remove the front seat. P. 143 Positive terminal Negative terminal Unhook the rubber strap. Disconnect the negative - terminal from the battery. Disconnect the positive + terminal from the battery.
Page 147: Front Seat
Removing & Installing Body Components Front Seat Front Seat Removal Remove the mounting bolts and washers, Washer and then pull the front seat back and up. Mounting bolts Installation Washer Install the front seat while inserting the tab into the recess. Install the washers and mounting bolts.
Page 148: Rear Seat
Removing & Installing Body Components Rear Seat Rear Seat Removal Insert the mechanical key into the seat Rear seat lock. Turn the mechanical key clockwise, then pull the rear seat forward and up. Installation Recess Insert the tab into the recess. Push down on the front of the rear seat.
Page 149: Checking The Engine Oil
Engine Oil Checking the Engine Oil Oil fill cap If the engine is cold, idle the engine for 3 to 5 minutes. Turn off the electrical system to stop the engine, and wait for 2 to 3 minutes. Upper level Place your vehicle in an upright position on a firm, level surface.
Page 150: Adding Engine Oil
Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.
Page 151: Checking The Coolant
Coolant Checking the Coolant Check the coolant level in the reserve tank while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between the UPPER level and LOWER level marks on the reserve tank.
Page 152: Adding Coolant
Coolant Adding Coolant Adding Coolant Stopper Inner Panel If the coolant level is below the LOWER level mark, add the recommended coolant P. 137) until the level reaches the UPPER level mark. Add fluid only from the reserve tank cap and Bolt do not remove the radiator cap.
Page 153 Coolant Adding Coolant WARNING Remove the reserve tank cap and add fluid while monitoring the coolant level. Removing the radiator cap while the Do not overfill above the UPPER level engine is hot can cause the coolant to mark. spray out, potentially scalding you. Make sure no foreign objects enter the reserve tank opening.
Page 154: Brakes
Brakes Checking Brake Fluid between the LOWER level and UPPER level marks. Place your vehicle in an upright position If the brake fluid level in either reservoir is on a firm, level surface. below the LOWER level mark or MIN mark or Front the brake lever and pedal freeplay becomes Check that the brake fluid reservoir is...
Page 155: Inspecting The Brake Pads
Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from in front Front of the brake caliper. Always inspect both left and right Check the condition of the brake pad wear brake calipers. indicators. Inspect the brake pads from the Rear The pads need to be replaced if a brake pad underside of the rear of the vehicle.
Page 156: Adjusting The Brake Light Switch
Brakes Adjusting the Brake Light Switch Adjusting the Brake Light Switch Check the operation of the brake light switch. Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.
Page 157: Checking The Side Stand
Side Stand Checking the Side Stand Start the engine, pull the clutch lever in, and shift the transmission into gear. Lower the side stand all the way. The engine should stop as you lower the side stand. If the engine doesn't stop, have your vehicle inspected by your dealer.
Page 158: Drive Chain
Drive Chain Inspecting the Drive Chain Slack Drive Chain Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your dealer. Shift the transmission to Neutral.
Page 159: Checking The Clutch
Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary, have it replaced by your Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
Page 160 Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper clutch cable adjuster Freeplay Upper Adjustment Attempt adjustment with the upper clutch – cable adjuster first. Turn the clutch cable adjuster until the freeplay is 0.4 - 0.8 in (10 - 20 mm).
Page 161 Clutch Adjusting the Clutch Lever Freeplay Lower Adjustment Lower lock nut Adjusting nut If the upper clutch cable adjuster is threaded out near its limit, or the correct freeplay cannot be obtained, attempt adjustment with the lower clutch cable adjusting nut. Turn the upper clutch cable adjuster all the way in to provide maximum freeplay.
Page 162: Throttle
Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open. If the throttle does not move smoothly or close automatically, have the vehicle inspected by your dealer. Throttle...
Page 163: Other Adjustments
Other Adjustments Adjusting the Brake Lever Adjuster You can adjust the distance between the tip of the brake lever and handle grip. Forward Adjustment method Turn the adjuster clockwise while pushing the Brake lever lever forward to widen the distance. Turn the Handle grip adjuster counterclockwise while pushing the lever forward to narrow the distance.
Page 164: Adjusting The Öhlins Smart Ec System
Other Adjustments Adjusting the ÖHLINS Smart EC System Adjusting the ÖHLINS Smart EC SCU constantly determines riding conditions from vehicle information. As a result, this System system provides the optimum rebound and compression damping characteristics. This model is equipped with the ÖHLINS Smart EC system.
Page 165 Other Adjustments Adjusting the ÖHLINS Smart EC System Front Spring Preload Make sure the electrical system is turned off. You can adjust the spring preload by the Slide the connector cover, and then adjuster to suit the load or the road surface. disconnect the front suspension connector from the coupler clip.
Page 166 Other Adjustments Adjusting the ÖHLINS Smart EC System Turn clockwise to increase spring preload Connect the front suspension connector (hard), or turn counterclockwise to to the coupler clip and then install the decrease spring preload (soft). connector cover. The standard position is the 2 turns from the full soft position.
Page 167: Rear Spring Preload
Other Adjustments Adjusting the ÖHLINS Smart EC System Rear Spring Preload You can adjust the spring preload by the Adjuster adjuster knob to suit the load or the road surface. Turn clockwise to increase spring preload (hard), or turn counterclockwise to decrease spring preload (soft).
Page 168: Damping Adjustment
Other Adjustments Adjusting the ÖHLINS Smart EC System Damping Adjustment Defaults of A-mode can be adjusted using the ÖHLINS Objective Based Tuning interface You can select A-mode which automatically (OBTi). adjusts damping according to the riding “OBTi” provides the interface where the rider situation and MANUAL mode which allows can adjust the settings in order to enhance damping to be set at a fixed level.
Page 169 Other Adjustments Adjusting the ÖHLINS Smart EC System FRONT/REAR: BRAKE: By adjusting the front and rear firmness By adjusting the brake support objective it is objective, it is possible to increase(+) or possible to increase (+) or decrease (-) the decrease(-) the front and rear suspension pitching resistance during initial braking.
Page 170 Other Adjustments Adjusting the ÖHLINS Smart EC System ACC (TRACK only): CORNER (TRACK only): By adjusting the acceleration objective it is By adjusting the corner objective it is possible possible to increase (+) or decrease (-) the to increase (+) or decrease (-) the agile pitching resistance during accelerating.
Page 171 Other Adjustments Adjusting the ÖHLINS Smart EC System MANUAL mode In MANUAL mode, the following damping The suspension setting can be fixed at a levels can be adjusted as desired: certain value on compression and rebound FR COM: Compression damping for front damping of the front and rear suspensions.
Page 172: Other Replacement
Other Replacement Replacing the Honda SMART With the emblem upward, separate the Honda SMART Key by inserting a coin or Key Battery a flat head screwdriver covered with a protective cloth into the slit. If the Honda SMART Key indicator flashes 5...
Page 173 Other Replacement Replacing the Honda SMART Key Battery WARNING Replace the old battery with a new one with the positive + side facing up. Chemical Burn Hazard: do not Assemble the parts in the reverse order of swallow battery. disassembly.
Page 174: Troubleshooting
ABS (Anti-lock Brake System) Indicator ..P. 174 HESD (Honda Electronic Steering Damper) Indicator ............P. 174 Torque Control Indicator......... P. 175 Honda SMART Key Indicator......P. 176 When the Honda SMART Key System Does Not Operate Properly........... P. 177...
Page 175: Engine Will Not Start
Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 110 sequence.
Page 176: Overheating (High Coolant Temperature Indicator Is On)
Overheating (High coolant temperature indicator is on) The engine is overheating when the following Check that the radiator fan is operating, occurs: and then turn the electrical system off. High coolant temperature indicator If the fan is not operating: ● comes on.
Page 177: Warning Indicators On Or Flashing
Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your vehicle may have a leak or another serious problem. Have your vehicle inspected by If the low oil pressure indicator comes on, your dealer.
Page 178: Abs (Anti-Lock Brake System) Indicator
19 mph (30 km/h). Indicator comes on or starts flashing while ● riding. Indicator does not come on when the HESD (Honda Electronic ● electrical system is turned on. Steering Damper) Indicator Indicator does not go off at speeds above ●...
Page 179: Torque Control Indicator
Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.
Page 180: Honda Smart Key Indicator
Warning Indicators On or Flashing Honda SMART Key Indicator Honda SMART Key Indicator If you do not have the Honda SMART Key, the ignition switch can be unlocked in another way. P. 179 When the Honda SMART Key indicator flashes 5 times...
Page 181: When The Honda Smart Key System Does Not Operate Properly
When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system. Check that the Honda SMART Key system The Honda SMART Key system uses low- ●...
Page 182 When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the battery condition and battery ● ● Key is used. lead in your vehicle. Use a registered Honda SMART Key. Check the battery and battery terminals. If The Honda SMART Key system cannot be the battery is weak, contact your dealer.
Page 183: Activating The Electrical System In An Emergency
Check the ID number on the ID tag. to activate the electrical system when the electric system cannot be turned on because the Honda SMART Key battery becomes weak or dead. Set up to ID number input mode Remove the front seat using a 5 mm Hex wrench provided in the tool kit.
Page 184 Activating the Electrical System in an Emergency ID number input While inputting the ID number, if the button is not pressed for about 60 seconds, the You can input your ID number by pushing inputted ID number is cancelled and the the ignition ON switch and Turn the ignition system returns to the state before removing switch knob OFF/...
Page 185 Activating the Electrical System in an Emergency Example: To input “0”, turn the ignition switch knob To input “1”, push the ignition ON switch ● ● OFF/ (Lock) counterclockwise without once, and then turn the ignition switch pushing the ignition ON switch, and then knob OFF/ (Lock) counterclockwise to input next digit.
Page 186 Activating the Electrical System in an Emergency You can turn off the engine and electrical ID number input success After the last digit of the ID number is system and also lock the steering using the inputted, ID number is authenticated, the ignition switch.
Page 187 Activating the Electrical System in an Emergency ID number input failure ID number input cancel If the ID number is not authenticated after If you input the wrong number, you can inputting, the steering lock indicator goes off. cancel ID number input by not operating the The steering cannot be unlocked and the switch for about 60 seconds (the steering electrical system will not activate.
Page 188: Tire Puncture
Tire Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tire repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.
Page 189: Electrical Trouble
Electrical Trouble Battery Goes Dead If the battery does not recover after recharging, contact your dealer. Battery charging is needed. NOTICE A battery charger recommended by your Do not jump-start, as this can damage your lithium-ion (li-ion) battery manufacturer is vehicle's electrical system and battery.
Page 190: Blown Fuse
Electrical Trouble Blown Fuse Blown Fuse Fuse puller Before handling fuses, see “Inspecting and Replacing Fuses.” P. 134 Spare fuses Fuse Box Fuses Fuse box cover Remove the front seat. P. 143 Remove the fuse box cover. Pull the main fuse and other fuses out one by one with the fuse puller furnished in reverse side of the fuse box cover and check for a blown fuse.
Page 191: Information
You & the Environment ......... P. 200 Vehicle Identification Number..... P. 202 Emission Control Systems ......P. 203 Catalytic Converter ......... P. 207 Oxygenated Fuels..........P. 208 Authorized Manuals ........P. 209 Warranty Coverage and Service ....P. 210 Honda Contacts ..........P. 213...
Page 192: Service Diagnostic Recorders
However this data may be accessed by Honda, its authorised dealers and authorised repairers, employees, representatives and contractors only for the purpose of the technical diagnosis,...
Page 193: Keys
Do not store near any magnetized products ● such as a magnetized key chain. The ID number of the Honda SMART Key is on Always keep the Honda SMART Key away ● the ID tag. You can also unlock the steering (if it...
Page 194 Keys If fuel, wax, or grease adhere to the Honda To get an additional Honda SMART Key, take ● SMART Key, wipe it off immediately to avoid the Honda SMART Key and the vehicle to your cracking or warping. dealer.
Page 195 Keys Canada Each radio frequency device installed in the This device complies with Industry Canada’s vehicle conforms to the requirements and licence-exempt RSSs. Operation is subject to the standards of the regulation listed below: following two conditions: (1) This device may not cause interference;...
Page 196: Instruments, Controls, & Other Features
Instruments, Controls, & Other Features Instruments, Controls, & Odometer Other Features The display remains at 999,999 when the odometer exceeds 999,999. Ignition Switch Leaving the electrical system on with the engine Tripmeter stopped will drain the battery. Each tripmeter resets to 0.0 when the trip mileage exceeds 9,999.9.
Page 197 HESD Throttle by Wire System The Honda Electronic Steering Damper (HESD) automatically controls the steering damper This model is equipped with a Throttle by Wire characteristics in accordance with vehicle speed System.
Page 198 Instruments, Controls, & Other Features Automatic Brightness Control The backlight brightness of the meter will be controlled automatically when “AUTO” is selected on the brightness setting. Ambient brightness is detected by the photosensor. Do not damage or cover the photosensor. Otherwise, the automatic brightness control may not work properly.
Page 199: Caring For Your Vehicle
Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
Page 200 Caring for Your Vehicle Washing Precautions Do not direct water at the air cleaner: ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
Page 201 Caring for Your Vehicle Aluminum Components Windscreen Aluminum will corrode from contact with dirt, Using plenty of water, clean the windscreen with mud, or road salt. Clean aluminum parts a soft cloth or sponge. (Avoid using detergents regularly and follow these guidelines to avoid or any kind of chemical cleaner on the scratches: windscreen.) Dry with a soft, clean cloth.
Page 202 Caring for Your Vehicle Exhaust Pipe and Muffler Coated area To remove mud or dust, use a wet sponge and The exhaust pipe and muffler are titanium and a mild detergent, then rinse well with clean stainless steel but may become stained by mud water.
Page 203: Storing Your Vehicle
For more information about storage, Canada After rain, remove the body cover and allow ● visit our website at www.honda.ca and look up the vehicle to dry. “Storage Tips” under the “Honda Warranty” in the Warranty tab for your Model.
Page 204: Transporting Your Vehicle
Transporting Your Vehicle Transporting Your Vehicle You & the Environment If your vehicle needs to be transported, it Owning and riding a vehicle can be enjoyable, should be carried on a motorcycle trailer or a but you must do your part to protect the flatbed truck or trailer that has a loading ramp environment.
Page 205 You & the Environment Recycle Wastes Put oil and other toxic wastes in approved containers and take them to a recycling center. Call your local or state office of public works or environmental services to find a recycling center in your area and to get instructions on how to dispose of non-recyclable wastes.
Page 206: Vehicle Identification Number
Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.
Page 207: Emission Control Systems
Your vehicle engine emits combustion Compliance with the terms of the byproducts, including carbon monoxide (CO), Distributor's Warranties for Honda Motorcycle oxides of nitrogen (NOx), and hydrocarbons Emission Control Systems is necessary in order (HC). Gasoline evaporation also emits to maintain a valid emissions system warranty.
Page 208 Emission Control Systems Ignition Timing Control System Noise Emission Requirements The ignition timing control system adjusts the The EPA requires that vehicles built after ignition timing to reduce the amount of HC, January 1, 1983 comply with applicable noise CO, and NOx produced. emission standards for one year or 3,730 miles (6,000 km) after the time of purchase when Secondary Air Injection System...
Page 209 Emission Control Systems Crankcase Emissions Control System Noise Emission Control System The engine is equipped with a closed crankcase TAMPERING WITH THE NOISE CONTROL system to prevent discharging crankcase SYSTEM IS PROHIBITED: emissions into the atmosphere. U. S. federal law prohibits, and Canadian Blow-by gas is returned to the combustion provincial laws may prohibit, the following acts chamber through the crankcase breather hose...
Page 210 Emission Control Systems AMONG THOSE ACTS PRESUMED TO Problems Affecting Vehicle Exhaust CONSTITUTE TAMPERING ARE THE Emissions FOLLOWING ACTS: Have your vehicle inspected and repaired by Removal of, or puncturing the muffler, ● your dealer if you experience any of the baffles, header pipes or any other following symptoms: component which conducts exhaust gases.
Page 211: Catalytic Converter
A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine's vehicle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.
Page 212: Oxygenated Fuels
Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.
Page 213: Authorized Manuals
Authorized Manuals Authorized Manuals can help you prepare your Honda motorcycle, scooter, ATV, and SxS for winter storage. The Service Manual used by your These Honda manuals are written for the authorized dealer is available from your Honda professional technician. However, if you possess dealer or Helm, Inc.
Page 214: Warranty Coverage And Service
Service workmanship of your Honda. Your warranty coverage does not apply to the normal wear Coverage and deterioration associated with use of the Your new Honda is covered by the following vehicle. warranties: Vehicle Limited Warranty ● Your warranty coverage is not voided if you Emission Control System Warranty ●...
Page 215 Warranty Coverage and Service authorized service provider caused damage to Statement on Warranty Coverage for another part of the vehicle otherwise covered Aftermarket and Recycled Parts under warranty before denying warranty The Magnuson-Moss Warranty Act, 15 U.S.C. s. coverage. Additionally, federal law allows a 2301 et seq., makes it illegal for motor vehicle manufacturer to void a motor vehicle warranty manufacturers to void a motor vehicle warranty...
Page 216 If you believe you have a problem with your dealership or their designated representative. vehicle, call the service department of your Honda dealer. Make an appointment for an inspection and diagnosis. You will be asked to authorize that inspection, and your dealer will return the results of the inspection.
Page 217: Honda Contacts
P.O. Box 2200, Torrance, CA 90509-2200 Product model, year, and VIN ● Mailstop: 100-4W-5F Date of purchase ● Dealer name and address ● Telephone: (866) 784-1870 We will likely ask your Honda dealer to respond, or possibly acknowledge your comments directly. Website: https://powersports.honda.com/ contact-us Continued...
Page 218 Honda Contacts Your Honda Dealer The service department of your Honda dealer offers trained personnel to perform regular maintenance and unexpected repairs. It has the latest available service information from Honda and also handles warranty inspections and repairs. The parts department offers Honda Genuine...
Page 219: Reporting Safety Defects
Reporting Safety Defects Reporting Safety Defects dealer, or American Honda Motor Co., Inc. If you believe that your vehicle has a To contact NHTSA, you may call the defect which could cause a crash or Vehicle Safety Hotline toll-free at:...
Page 220 (English Link:) www.tc.canada.ca/recalls remedy campaign. However, Transport (French Link:) www.tc.canada.ca/rappels Canada cannot become involved in individual problems between you, your For more information on reporting safety defects or about motor vehicle dealer, or Honda Canada Inc. safety, go to https://www.tc.gc.ca/roadsafety.
Page 221: Specifications
Specifications Main Components ■ 2.615 Overall length 82.7 in (2,100 mm) 2.058 Overall width 29.3 in (745 mm) 1.700 Gear ratio Overall height 44.9 in (1,140 mm) 1.478 Wheelbase 57.5 in (1,460 mm) 1.333 Minimum ground clearance 4.5 in (115 mm) 1.214 Caster angle 24°...
Page 222 Minimum tread Recommended depth Rear 0.08 in (2.0 mm) drive chain Pro Honda HP Chain Lube or equivalent Spark plug (standard) SILMAR10C9S (NGK) lubricant Spark plug gap 0.031 - 0.035 in (0.80 - 0.90 mm) Drive chain slack 1.0 - 1.4 in (25 - 35 mm)
Page 223 Specifications Bulbs Torque Specifications ■ ■ Headlight Middle cowl bolt 0.7 lbf·ft (1.0 N·m, 0.1 kgf·m) Brake light/Taillight Front turn signal / Position light Rear turn signal License plate light Fuses ■ Main fuse 30 A Other fuse 30 A, 15 A, 10 A, 7.5A...
Page 224 Information Record Engine No. Color Label & Code Owner's Name Address City/State Phone Dealer's Name Address City/State Phone Service Manager...
Page 225 California Proposition 65 Warning WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.

Honda FIREBLADE CBR1000RR-R 2023 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Honda FIREBLADE CBR1000RR-R 2023

Summary of Contents for Honda FIREBLADE CBR1000RR-R 2023

Table of Contents
