Summary of Contents for GeneralAire HEALTHYAire DH95
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. GENERAL DH95 Owner's Manual Shop genuine replacement parts for GENERAL DH95 Find Your GENERAL Dehumidifier Parts - Select From 5 Models -------- Manual continues below --------...
- Page 2 Crawl Space, Attic or Basement Breathe Healthier Manufacturers of Whole House Residential Indoor Air Quality Products. Humidifi ers - Dehumidifi ers - Air Cleaners - UV Air Purifi ers - Heat/Energy Recovery Ventilators www.generalfi lters.com By GeneralAire By GeneralAire ® ®...
-
Page 3: Table Of Contents
Model DH95 Dehumidifier Installation Manual DH95 Table of Contents Subject Page # Specifications Unit Location Electrical Requirements Condensate Removal Ducting Wiring Unit Schematic Field Connections, Low Voltage Typical Equipment Layout Specification & Duct Connection Operation Typical System Operation Sequence Coil Freeze Protection (Auto Defrost) Compressor Protection (Delay Timer) Maintenance Trouble Shooting... -
Page 4: Specifications
Model DH95 Dehumidifi er Installation Manual Specifi cations • Capacity: 95 pints/day, (4.14 lbs./hr.) @ 80°F/60%RH • Electrical: 110-120 VAC, 9.6 FLA Amps, 60 Hz, grounded • Operating Return Air Temp. Range: 50°F min., 90°F max. • Air Flow: • 375 CFM without external ducting • 295 CFM @ .30 IWG external static • 234 CFM @ .50 IWG external static • Refrigerant Charge: 17.5 oz. -
Page 5: Electrical Requirements
Model DH95 Dehumidifier Installation Manual Electrical Requirements • WARNING: Disconnect power before installation and / or servicing, as electric shock may occur and cause serious injury or death. • WARNING: The DH95 is equipped with a power cord and may be plugged directly into a 120 volt, 15 amp household type convenience outlet. - Page 6 Model DH95 Dehumidifi er Installation Manual B. Ducting for Dehumidifi cation For the ideal installation, draw air from the central part of the home and return it to the isolated areas of the home like the bedrooms, den, utility room, or family room. The ductwork of the existing HVAC system can be used to supply air to the home.
-
Page 7: Wiring Unit Schematic
Model DH95 Dehumidifier Installation Manual F. Installation in Structure with No Existing Forced-Air HVAC System (WH) When installing the DH95 in a structure that does not have a forced-air HVAC system, a single return for the DH95 should be installed in central open area of the structure. DO NOT locate the return in a bathroom or a kitchen. The supply of the DH95 should be located in the remote areas of the structure (such as bedrooms, den, etc.). -
Page 8: Field Connections, Low Voltage
Model DH95 Dehumidifi er Installation Manual Field Connections, Low Voltage Optional Blower Interlock Connections (Low Voltage) Optional Humidistat Blower InterLock Connections (Low Voltage) Dehumidistat Field Supplied Control Wiring Close on RH Rise Fan Coil / Air Handler Control Thermostat (Typ) Gt Gf Rf Disconnect Existing Control Wiring From Fan (G) Control Terminal... -
Page 9: Typical System Operation Sequence
Model DH95 Dehumidifier Installation Manual Typical System Operation Sequence Upon the relative humidity exceeding the Dehumidistat set point, the Dehumidistat will energize the dehumidification and air circulation components of the DH95 (note 15 minute delay on some electronic Dehumidistats). If the DH95 system is connected and interlocked with an existing Heating/Air conditioning system, the system circulation fan will also be energized. -
Page 10: Trouble Shooting
Model DH95 Dehumidifi er Installation Manual Trouble Shooting 1. My dehumidifi er won’t run. Check for the following: • Verify there is power to the unit. • Check that any disconnect switch is in the ON position. • Check that the circuit breaker is not tripped (a separate 15 amp circuit breaker is recommended). •... -
Page 11: Faq's
Model DH95 Dehumidifier Installation Manual FAQ’s 1. Does the dehumidifier require any maintenance? Yes. It is recommended that the filter be inspected regularly for the first three to four months to determine the loading and correct replacement intervals. Your installation contractor should be contacted for assistance. Replace your filter a minimum of once per year, or as often as required to keep unit clean to maintain your warranty. -
Page 12: Warranty Registration - Keep A Copy For Your Records
Model DH95 Dehumidifi er Installation Manual Warranty Registration - Keep a Copy For Your Records Cut Out to Mail Register Online Warranty Registration www.GeneralAire.com / Support Center Product Information Or Mail Serial Number: __________________________________________________ Model:__________________________________________________________ Installation Date Month: ___________Day: _________Year: __________... -
Page 13: Form No. 200-8101_Rev_A Dh95
Model DH95 Dehumidifi er Installation Manual What is Not Covered, Cont. • Liability for special, incidental, direct, indirect, collateral and consequential damages is excluded. Some states do not allow limitation of incidental damages, so the limitations or exclusions may not apply to you. General Filters, Inc. will not pay electricity or fuel costs, or increases in electricity or fuel costs, for any reason whatsoever, including additional or unusual use of supplemental electric heat.
